EPV Efinity Edge Free Series User manual

1
030714-JA www.elitescreens.com
Efinity Series
Edge Free™Fixed Frame Projection Screen
User’s Guide
Applies to all available screen materials:
CineGrey 5D Edge Free™, CineWhite Edge Free™, PowerGain 3D Edge Free™
Hardware and Parts List
Please make sure all parts listed below are included before installation.
A. Elbow joint x 4 pcs
B. Top/Bottom horizontal fame x 4 pcs
C. Left/Right vertical frame x 2 pcs
D. Center joints x 2 pcs
E. Center support bar x 1-2 pc
F. Wall brackets x2-3 pcs
G. M6 screw x 2-4 pcs
H. M5x15 screw x 24 pcs
I. M6x12 screw x 2-4pcs
J. M5x50 screws and anchor x 6 pcs
K. Rubber mallet x 1 pc
L. Screwdriver x 1 pc
M. Black Tape x1pc
N. Edge trim x6pc

2
030714-JA www.elitescreens.com
Frame Assembly
Note: Refer to the section “ Splicer Installation” if joining two or more frames.
1. Insert the center joint into one of the ½ horizontal frames and fasten it with the two M5x15 screws (H).
2. Insert the other ½ horizontal frame piece to the center joint and fasten also using two M5x15 screws.
3. Repeat steps 1 and 2 for assembling the second horizontal frame.
Push Push
4. Insert and slide in one M6 screws (G)through the channel located on the back each horizontal frame.
5. Insert the elbow joint (A) into each end of the horizontal frames (B)as shown below.
Horizontal long frame (B)
Elbow Joint (A)
Push
Elbow Joint (A)
Place one M6 hex screw (G) in the center for attaching the center support bar (E)
Horizontal long frame
Face up
M6 hex screws (G)
Horizontal frame
Center Joints
Top right Frame
Top left Frame

3
030714-JA www.elitescreens.com
6. Insert the two vertical short frames (C) into the elbow joint (A).
7. Join the remaining horizontal long frame (B) with the frame built in the previous steps as shown below.
Horizontal long frame (B)
Vertical short frame (C)
Horizontal Long frame (B)
push
push
push
push
Vertical short frame (C)

4
030714-JA www.elitescreens.com
8. Make sure all four corners are properly in place to form a perfect rectangle. Then fasten the four angles with
the M5x15 Screws (H).
Screen Material Installation
1. Lay the screen material completely flat with the front facing down on a clean surface in a horizontal position. The
back side of the screen material should be placed upwards.
Note: The back side of the material has the velcro borders all around the edges.
2. Carefully and gently place the assembled frame on top the screen material as shown below. Make sure to not
allow the angle edge of the frame to come in direct contact with the screen material to avoid puncturing it.
3. After all of the corners of the frame have been properly aligned, snap the material on the frame in the following
order A→B→C→D (see instructions below for details).
Four corners join correctly to form a perfect
rectangle. Use the included screwdriver (L)
to fasten the Mx15 screws (H) into each
corner by aligning the frame screw holes to
the holes in the elbow joint (A).
Screen material back facing up
Velcro

5
030714-JA www.elitescreens.com
Attach the screen material to the corners as shown below.
4．After all four corners have been attached, please check whether the frame corners are wrapped by the screen
material. If not, please loosen the buttons and repeat the above steps so the frame is not exposed.
Note: The black shaded part represents the velcro on the frame. That Velcro
end will ultimately attach with the other velcro end on the screen material.
Note:
Represents
the screen
material
2) Fold over and
snap onto frame
3) Fold over second side
and snap onto frame
4) Repeat until all four
sides are done in the
order A, B, C, D
1) Stretch the screen
material in the direction
of the arrowhead.
A
B
C
D

6
030714-JA www.elitescreens.com
5. Proceed to attach the rest of the material to the frame as described in the illustrations below.
Lay the Velcro end on the screen
material over the Velcro end of the
frame and keep it within the edge.
Proceed in the following sequence
below ①②
The key is to attach within the
middle sections of 1 and 2. Then
continue attaching the remaining
unattached areas.
Repeat the same steps on
remaining three sides in the
sequence A, B, C, D as show
below.
Grasp the middle of the screen
material and attach it to the velcro
strip on the frame
Attach in the following sequence: a-b-c-d
A
B
C
D

7
030714-JA www.elitescreens.com
Screen Material Removal
Follow the steps to properly remove the screen material from the frame. This procedure will ensure prolonging the
life of the screen material.
1. Detach the velcro from the frame.
2. Gently pull back the material to unsnap the material from the buttons on the corners
Support bar installation:
1. Position the center support bar (E) in the middle of the frame and align the hole on each end of the support bar
with the M6 hex screws (G)on the top and bottom frames. Then fasten with the M6x12 screws (I).
Move the M6 hex screw (G) to the middle area of the frames.
Align the M6 screws
with the two holes.
Pull back the screen material from
the buttons to detach from the frame.
Support bar

8
030714-JA www.elitescreens.com
Notice to Installer:
These instructions only apply if you have the CineGrey 5D or PowerGain 3DALR material.
Please use the following installation instructions to obtain superior optical performance from the Angular
Reflective ALR (Ambient Light Rejecting) Screen.
Projector Ceiling Installation: Make sure the
projector (light in) is angled (ϴ1) to reflect (ϴ2) at
the mirror-opposite angle (light out) to align with
the viewer’s eye level.
Projector Table Top: Make sure the projector
(light in) is angled (ϴ1) to reflect (ϴ2) at the
mirror-opposite angle (light out) to align with the
viewer’s eye level.
Images are not up to scale and are for illustrations purposes only.
Note: Improper installation will result in light loss and produce a dark image. This is due to the projector’s light
reflecting in the wrong direction.
Installation
Locate your desired installation location with a stud finder (recommended) and mark the drill-hole area of where the
screen is to be installed.
1. Drill a hole with the proper bit size according to the wood screws included.
2. Line up the wall brackets with the drilled holes on the installation location and screw them in using a
Phillips screwdriver.
3. Position the frame screen onto the wall brackets (F) as shown in below.
4. The design of the wall brackets allows the frame to slide over them through its sides. This is an important
feature of the installation design as it allows your screen to be properly centered.

9
030714-JA www.elitescreens.com
Edge trim Installation
The Aeon fixed screen is edge free, but you may install the trim strip to provide it with an elegant pencil thin bezel
finish.
1. Put the assembled frame on the flat and clean surface (Please face up), and then stick the black tape on the center
of the top and bottom of the screen, please align the tape with the edge of the screen, as shown in the fig.
2．Then align and adjust the edge trim with the screen edge to make the four corners into a better joint. (Note: please
don’t remove the tape on the trim, and put the trim with Elite logo on the bottom right). As shown in the
following figs.
3. After alignment, please take down the trim A, remove the inside tape and stick on the original place.
And accordingly stick B-C-D-E-F trims. As shown in the following fig.
The front side of the frame with trim The back side of the frame with the trim installed
Edge trim x 6 PCS
Black tape x1pcs
trim
strip
The curtain
The black tape
The black tape
A B
F C
E D

10
030714-JA www.elitescreens.com
Attention: the comparison of view size between the before and after installing the trim strip, take 100H&120H as
examples as the following shown.
100H comparison:
120H comparison
Splicer Installation (sold separately)
If you want to joint two frameworks, please insert twelve M6 screws into each vertical short frame each before
completely assembling the frame. See figure below for example.
1. Layout the frame:
The two frameworks should be parallel and aligned as shown below.
push
M6 screws x 24pcs
X24PCS
Splicer x 3 PCS
M6X12 screws x 24 PCS
Parts list for
splice option:
Vertical (short) frame
Before installing the trim strip
After installing the trim strip
After installing the trim strip
Before installing the trim strip

11
030714-JA www.elitescreens.com
2. Align the position of the M6 screws with the splicer.
3. Join the frames together with the splicer, and tighten the frame and splicer with M6X12 screws as shown in the
figure below:
For a local Elite Screens contact or Technical Support, please visit
www.elitescreens.com
splicer
M6 Screws
