Erbauer EPS800 User manual

Original Instructions - MNL_EPS800_GB_V1_201020
EAN: 5059340043357
EPS800
ORIGINAL INSTRUCTIONS
V11020 BX220IM
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 1 10/20/20 5:03 PM

Safety instructions 3
Product description 14
Assembly 23
Use 26
Care & maintenance 30
Guarantee 37
Declaration of conformity 38
2
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 2 10/20/20 5:03 PM

3
Safety instructions
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings,
instructions, illustrations and specications
provided with this power tool. Failure to follow all
instructions listed below may result in electric shock,
re and/or serious injury.
Save all warnings and instructions for future
reference. The term “power tool” in the warnings
refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive atmospheres,
such as in the presence of ammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodied plugs
and matching outlets will reduce risk of electric shock.
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 3 10/20/20 5:03 PM

4
b) Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is
earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric
shock.
d) Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
PERSONAL SAFETY
a) Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a
power tool while you are tired or under the inuence
of drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious personal
injury.
b) Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or
energising power tools that have the switch on invites
accidents.
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 4 10/20/20 5:03 PM

5
d) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
e) Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool
safety principles. A careless action can cause severe
injury within a fraction of a second.
POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from the
power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool
accidentally.
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 5 10/20/20 5:03 PM

6
d) Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpected situations.
SERVICE
a) Have your power tools serviced by a qualied repair
person using only identical replacement parts. This
will ensure that safety of the power tool is maintained.
SPRAY GUN SAFETY WARNINGS
a) Do not use the product for spraying ammable
materials.
b) Be aware of any hazards presented by the material
being sprayed. Consult the markings on the container
or the information supplied by the manufacturer of the
material to be sprayed, including the request to wear
personal protective equipment.
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 6 10/20/20 5:03 PM

7
c) Do not spray any material where the hazard is not
known. Unknown materials can create hazardous
conditions.
d) Use appropriate personal protective equipment,
such as dust masks or respirators, safety goggles,
protective gloves and ear protection when spraying
or handling chemicals. Wearing protective equipment
for the appropriate conditions reduces the exposure to
hazardous substances.
e) Do not clean the product with ammable solvents.
f) Keep area clean, well lit and free of paint or solvent
containers, rags, and other ammable materials.
Spontaneous combustion may occur. Fire extinguisher
equipment shall be present and working at all times.
g) Provide good ventilation in the spraying area and for
sufcient fresh air in the complete room. Evaporating
inammable solvents create an explosive environment.
h) Do not spray and clean with materials that have a ash
point of less than 55 °C. Use materials based on water,
non-volatile hydrocarbons or similar materials. Volatile
evaporating solvents create an explosive environment.
i) Do not spray in the vicinity of ignition sources, such
as static electricity sparks, open ames, pilot lights,
hot objects, engines/motors, cigarettes and sparks
from plugging in or unplugging power cords or
operating switches. Such spark sources can ignite the
spraying vicinity/ environment.
j) Do not spray wallpaper stripper or boiling water. Spray
only warm water (max. 55 °C) without chemical additives.
k) Keep the plug of the mains cord and the trigger switch
of the spray gun clear of paint and other uids. Never
hold the cord by its connectors to support it. Failure to
follow the instruction can lead to electric shock.
l) Do not allow children to play with the product. Never
work near children or animals.
m) Never point the product toward open ames!
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 7 10/20/20 5:03 PM

8
n) Never manipulate the product and always use the safety
and/or protective guards on the product to avoid risks.
o) Risk of injury: Do not direct the product towards people or
animals.
p) Never smoke during the paint process.
q) Always ensure sufcient circulation of fresh air.
r) Never use paint containing lead.
s) Before any work (such as transport, construction,
conversion, cleaning or maintenance) and when the
product is not being used, disconnect it from the power
supply and empty the paint container!
The following information applies to professional users
only but is good practice for all users:
VIBRATION
The European Physical Agents (Vibration) Directive has
been brought in to help reduce hand arm vibration syndrome
injuries to power tool users. The directive requires power tool
manufacturers and suppliers to provide indicative vibration
test results to enable users to make informed decisions as to
the period of time a power tool can be used safely on a daily
basis and the choice of tool.
SEE TECHNICAL SPECIFICATIONS IN THE INSTRUCTION
MANUAL FOR THE VIBRATION LEVELS OF YOUR TOOL.
The declared vibration emission value should be used as a
minimum level and should be used with the current guidance
on vibration.
Calculating the actual period of use can be difcult and the
HSE website has further information.
The declared vibration total value has been measured in
accordance with EN 60745-1 and EN 50580 and may be used
for compare one tool with another.
The declared vibration total value may also be used in a
preliminary assessment of exposure.
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 8 10/20/20 5:03 PM

9
WARNING! The vibration emission during actual
use of the power tool can differ from the declared
total value depending on the ways in which the
tool is used:
• How the materials are grinded, cut or drilled.
• If the tool is in good condition and well maintained.
• Use correct accessory for the tool and ensure it is
sharp and in good condition.
• The tightness of the gripping handles.
While working with this power tool, hand/arm
vibrations occur. Adopt the correct working
practices in order to reduce the exposure
to vibration. This tool may cause hand-arm
vibration syndrome if its use is not adequately
managed.
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 9 10/20/20 5:03 PM

10
WARNING! Identify safety measures to protect the
operator that are based on an estimation of exposure
in the actual conditions of use (taking account of all
parts of the operating cycle such as the times when
the tool is switched off and when it is running idle in
addition to the trigger time).
Note:
• The use of other tools will reduce the users’ total
working period on this tool.
• Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades.
• Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
• Avoid using tools in temperatures of 10ºC or
less. Plan your work schedule to spread any high
vibration tool use across a number of days.
HEALTH SURVEILLANCE
All employees should be part of an employer’s health
surveillance scheme to help identity any vibration related
diseases at an early stage, prevent disease progression and
help employees stay in work.
VIBRATION AND NOISE REDUCTION
To reduce the impact of noise and vibration emission, limit
the time of operation, use low-vibration and low-noise
operating modes as well as wear personal protective
equipment.
Take the following points into account to minimise the vibration
and noise exposure risks:
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 10 10/20/20 5:03 PM

11
a) Only use the product as intended by its design and these
instructions.
b) Ensure that the product is in good condition and well
maintained.
c) Use correct attachments for the product and ensure they
are in good condition.
d) Keep tight grip on the handles/grip surface.
e) Maintain this product in accordance with these instructions
and keep it well lubricated (where appropriate).
f) Plan your work schedule to spread any high vibration tool
use across a longer period of time.
g) Prolonged use of the product exposes the user to
vibrations that can cause a range of conditions collectively
known as hand-arm vibration syndrome (HAVS) e.g.
ngers going white; as well as specic diseases such as
carpal tunnel syndrome. To reduce this risk when using
the product, always wear protective gloves and keep your
hands warm.
EMERGENCY
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the safety
directions and follow them to the letter. This will help to
prevent risks and hazards.
a) Always be alert when using this product, so that you
can recognise and handle risks early. Fast intervention
can prevent serious injury and damage to property.
b) Switch off and disconnect from the power supply if
there are malfunctions. Have the product checked by a
qualied professional and repaired, if necessary, before
you operate it again.
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 11 10/20/20 5:03 PM

12
Measures to take in the event of contact with chemicals
Skin
contact:
clean with plenty of water and soap, consult a
doctor if necessary
Eye contact: rinse with plenty of water, consult a doctor
Swallowing: do not vomit, consult a doctor
Inhalation: fresh air, consult a doctor if necessary
RESIDUAL RISKS
Even if you are operating this product in accordance
with all the safety requirements, potential risks of injury
and damage remain. The following dangers can arise in
connection with the structure and design of this product:
a) Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
b) Injuries and damage to property due to broken attachments
or the sudden impact of hidden objects during use.
c) Danger of injury and property damage caused by ying
objects.
d) Risk of bursting.
WARNING! This product produces an
electromagnetic eld during operation! This eld
may under some circumstances interfere with active
or passive medical implants! To reduce the risk of
serious or fatal injury, we recommend persons with
medical implants to consult their doctor and the
medical implant manufacturer before operating this
product!
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 12 10/20/20 5:03 PM

13
x1
1
WARNING! Please read all safety warnings carefully and be
sure that they are fully understood before handling the tool.
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 13 10/20/20 5:03 PM

14
Product description
1
1 2 3
3a
3b
4a
4b
8
9
11
12 13
14
15a
15
16
17a
17
18
19 12
20
22
23
25
26
8a
27
27b
27f
27e
27d
27a
27c
24
21a 21
10
4c
4d
4 5 6 7
6a
28
29 30
31
32
28a
28b
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 14 10/20/20 5:03 PM

15
A22a 22a
20a
22
B
24b
24
20a
22a 22a
24b
C D
27
28a
28a
28b
28
4. 1.
2.
3.
29
E F
14 5 6
23
1.
2.3.
4.
1a
12
3a
3
3b
4b
4a
4c 44d 5 6
6a
30
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 15 10/20/20 5:03 PM

16
G25
2.
10
9a
25
10
910a
9b
9a
1.
3.
27c
26
H
12
19b
19a
12a
1.
2.
I J
11a
11
12 12a
11b
1. 2.
18
K L
18 18a
+-
7
8
8a
+
+
1.
2.
-
-
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 16 10/20/20 5:03 PM

17
M
3
1
2
1.
3
2
2. 3.
1
N
O P
Q R
1.
2.
27
6
8
27b
27f
27e
27d
27a
27
27d-i
27d-ii
27d-iii
27d-iV
27d-V
1.
2.
3.
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 17 10/20/20 5:03 PM

18
S
31
31
4a
5
T23b
23a
23b
23c 2.
1.
U V
24
13
14
24b
24b
21a
25 27
20
21
20b 1.
2.
3.
17a
17
16
15
15a
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 18 10/20/20 5:03 PM

19
Part index
The index below refers to Fig. 1 on page 4.
1. Air cap adjusting cover
a) Slot* (x2)
2. Union nut
3. Air cap
a) Anchor (x2)
b) Spigot (x2)
4. Spray nozzle (Ø 2.5mm)
a) Nozzle hole
b) Notch
c) Lower step
d) Higher step
5. Nozzle needle
6. Spray head
a) Spigot
7. Air ow adjustment lever
8. Switch Trigger
a) Fluid adjusting knob
9. Container holder attachment point
a) Indication mark*
b) Slot* (x2)
10. Handle front attachment point
a) Pin* (x2)
11. Air inlet attachment point
a) Slot* (x2)
b) Indication arrow*
12. Hose connector (x2)
a) Pin* (x2)
13. Air hose
14. Compartment for spray gun
15. Lower extension
a) Locking pin
16. Upper extension
17. Transport handle
a) Lock button
18. Rotatable On/Off switch
a) Indication line*
19. Air outlet attachment point
a) Slot* (x2)
b) Indication arrow*
20. Air hose bracket (x2)
a) Wheel compartment* (x4)
b) Cord holder* (x2)
21. Power cord with plug
a) Cord clip
22. Front wheel (x2)
a) Latch* (x2)
23. Air vents
a) Air lter*
b) Air lter cover*
c) Latch* (x3)
24. Rear wheel (x2)
a) Latch* (x2)
b) brake*
25. Handle
26. Lock catch
27. Paint container
a) Suction tube
b) Quick ll cap
c) Holder hook
d) Check valve
i) Top sleeve
ii) Rubber seal
iii) Spring
iv) Middle Sleeve
v) Valve extension
e) Seal ring
f) Seal pad
28. Paint dipstick
a) Hook
b) Paint level marking
29. Viscosity measuring cup
30. Spray nozzle (Ø 1.8 mm)
31. Cleaning needle (with protector)
32. Cleaning brush
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 19 10/20/20 5:03 PM

20
NOTE: Parts marked with * are not shown in this overview. Please refer
to the respective section in the instruction manual.
Symbols
the following symbols and abbreviations. Familiarise yourself with them to reduce
hazards like personal injuries and damage to property.
V ~ Volt, (alternating voltage) mm Millimetre
Hz Hertz kg Kilogram
A Ampere ml Millilitre
°C Degree Celsius ml/min Millilitre per minute
W Watt dB(A) Decibel (A-rated)
/min or
min-1
Per minute m/s² Metres per seconds squared
Lock / to tighten or secure. Unlock / to loosen.
Read the instruction manual. Always wear eye protection.
Always wear ear protection. Wear respiratory protection.
Wear protective gloves. Wear protective, slip-resistant
footwear.
Note / Remark. Caution / Warning.
xxWyy Manufacturing date code; year of manufacturing (20xx) and week of
manufacturing (Wyy)
DIN-sec The time (seconds) taken for the paint to run out of one full viscosity
measuring cup
Switch the product off and disconnect it from the power supply before
assembly, cleaning, adjustments, maintenance, storage and transportation.
MNL_Erbauer_GB_EPS800_800W paint sprayer_V1_201020.indd 20 10/20/20 5:03 PM
