Ericsson BML 161 54/1 User manual

Operator’s Manual
Monogram
Series
DUAL DESK CHARGER
BML 161 54/1,3 (120 VAC)
BML 161 54/2,4 (230 VAC)
E

Copyright © June 1995, Ericsson Inc.
TABLE OF CONTENTS
Page
IMPORTANT SAFETY INFORMATION . . . . . . . . . . 3
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . 7
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . 7
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . 8
INDICATORS . . . . . . . . . . . . . . . . . . . . . . . 9
CHARGER OPERATION . . . . . . . . . . . . . . . . . 10
NOTICE!
This manual covers Ericsson and General Electric products sold by Ericsson Inc.
NOTE
Repairs to this equipment should be made only by an authorized service technician or facility
designatedby the supplier. Any repairs, alterationsor substitution of recommended parts made
by the user to this equipment not approved by the manufacturer could void the user’s authority
to operate the equipment in addition to the manufacturer’s warranty.
This manual is published by Ericsson Inc., without any warranty. Improvements and changes
to this manual necessitated by typographical errors, inaccuracies of current information, or
improvements to programs and/or equipment, may be made by Ericsson Inc., at any time and
without notice. Such changes will be incorporated into new editions of this manual. No part of
this manual may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose, without the express written
permission of Ericsson Inc.
2

IMPORTANT SAFETY
INFORMATION
1. SAVE THIS MANUAL - It contains important safety and operating
instructions for MONOGRAM Series Dual Desk Charger.
2. Beforeusingthebatterycharger,readallinstructionsandcautionary
markings on (1) the battery charger, (2) the battery, and (3) the
product using the battery.
3. CAUTION-Toreducetheriskofinjury,chargeonlyEricsson battery
packs.Charging any other battery pack or batteries may cause the
battery to burst and cause personal injury or damage.
4. Do not expose charger to rain or snow.
5. Do not use auxiliary equipment not recommended or sold by the
manufacturer. To do so may result in a risk of fire, electric shock, or
injury to persons.
6 To reduce risk of damage to electric plug and cord, pull by the plug
rather than the cord when disconnecting the charger.
7. Makesurethecordislocatedsothatitwillnotbesteppedon,tripped
over, or otherwise subjected to damage or stress.
8. An extension cord should not be used unless absolutely necessary.
Use of an improper extension cord could result in a risk of fire and
electric shock. If an extension cord must be used, make sure:
a. Thatpinsontheplugoftheextensioncordarethesamenumber,
size, and shape as those on the charger’s plug;
3

IMPORTANT SAFETY INFORMATION
b. That the extension cord is properly wired and in good condition;
and
c. That the wire size is large enough for the AC ampere rating of
the charger as specified in Table 1.
Table 1
Recommended Minimum Size For
Extension Cords
LENGTH OF EXTENSION CORD (ft.) 25 50 100 150
AWG SIZE OF EXTENSION CORD 18 18 18 16
9. Do not operate charger with damaged cord or plug - replace them
immediately.
10. Donotoperatechargerifithasreceivedasharpblow,beendropped,
or otherwise damaged in any way; return it to a qualified service
shop.
11. Do not disassemble the charger;return it to a qualified service shop
whcn service or repair is required.Incorrect reassembly may result
in a risk of electrical shock or fire.
12. To reduce risk of electric shock, unplug the charger from the outlet
before attempting any maintenance or cleaning.
4

IMPORTANT SAFETY INFORMATION
13. GROUNDING AND AC POWER CORD CONNECTION -To reduce
the risk of electrical shock use only a properly grounded outlet.The
charger is equipped with an electric cord having an equipment-
grounding conductor and a grounding plug. Be sure that the outlet
is properly installed and grounded in accordance with all local codes
and ordinances.
14. DANGER -NeveraltertheACcordorplug.Ifitwillnotfitintheoutlet,
have a proper outlet installed by a qualified electrician. Improper
connection can result in risk of an electric shock.
15. TheBML16154/1,3charger120Vaclinecordhasagroundingplug
that looks like the plug illustrated in Figure l. A temporary adapter,
which looks like the adapter illustrated in sketches B and C, may be
usedtoconnectthisplugtoatwo-polereceptacleasshowninsketch
B if a properly grounded outlet is not available. The temporary
adapter should be usedonly until a properly grounded outlet canbe
installed by a qualified electrician.
16. DANGER - Before using an adapter as illustrated, be certain the
center screw of the outlet plate is grounded. The green-color rigid
ear or lug extending from the adapter must be connected to a
properly grounded outlet--make certain it is grounded.If necessary,
replace the outlet cover plate screw with a longer screw that will
secureadapterearorlugtooutletplateandmakegroundconnection
to grounded outlet.
17. Care should be taken when placing the charger in service to insure
proper top and bottom ventilation. A minimum of 1/4" is required
between the bottom of the charger and the surface on which it sits.
5

IMPORTANT SAFETY INFORMATION
Figure 1 - Grounding Methods
Due to the temperature characteristics of nickel-cadmium batteries,
thebatterieswillnotacceptafullchargeattemperatureextremes.For
maximum capacity, recharge the battery pack at a room temperature
of 65° to 85° Fahrenheit, whenever possible.
NOTE
6

SPECIFICATIONS
VOLTAGE SOURCE 120 VAC ±10%, 50/60 Hz
230 VAC ±10%, 50/60 Hz
POWER CONSUMPTION 27 watts
FUSE RATING 500mA 125V fast blow
OPERATING
TEMPERATURE RANGE +5° to +45°C (+41° to +113°F)
DIMENSIONS (H x W x D)
Height
Width
Depth
81 mm
143.5 mm
131 mm
WEIGHT 2.1 lb.
APPROVALS UL / CSA (BML 151 54/1,3 only)
DESCRIPTION
The Dual Desk Charger is designed to charge Ericsson Monogram Series
LTR ®and EDACS Portable radio battery packs.
The rear slot is used for fast charging of a portable radio with battery or
independent charging of a battery. This slot charges the battery in 1 to 2
hours.
LTR is a tradename of E.F. Johnson
7

The front slot is used for slow charging of a portable radio with battery or
independent charging of a battery. This slot charges the battery in 14 to 20
hours.
INSTALLATION
LocatetheDualDeskChargeronadeskorother flatsurface neara120/230
VAC 50/60 Hz source. Connect the power cable to a convenient 120/230
VAC outlet.
Recharging any battery pack or batteries other than the ones your
equipment was designed to charge may result in damage to
equipment, leakage, or explosion.
CAUTION
Refer to Dual Desk Charger Maintenance Manual if it is necessary
to replace printed wiring boards, components, or assemblies.
Only an authorized or certified electronic technician should attempt
to disassemble or service the charger.
NOTES
8

INDICATORS
1. Rear Charge Slot: For fast charging of a Monogram Series radio with
battery or independent charging of batteries. Polarity of battery in
charger must be correct, or no charging will occur.
2. Front Charge Slot: For slow charging of Monogram Series radio with
battery or independent charging of batteries. Polarity of battery in
charger must be correct, or no charging will occur.
3. FAST LED:Flashes when radio or battery is inserted into Rear Charge
Slot.
4. SLOW LED:(in Front Charge Slot) illuminates when radio or battery is
inserted. SLOW LED: (in Rear Charge Slot) will illuminate when fast
charge is complete, or fully charged battery is inserted.
5. Power LED: Indicates AC power is supplied to charger.
NEVER INSERT A RADIO INTO THE CHARGER WITHOUT A BATTERY
INSTALLED
9

CHARGER OPERATION
Rear Charge Slot: Insert battery or radio with battery into the Rear Charge
Slot, observing correct polarity. The FAST LED will begin to flash and fast
charge begins according to the amount of charge in the battery.(ln the case
of a fully discharged battery, the initial charge is executed during the first
minute. The FAST and SLOW LED’s will not be illuminated. After the initial
charge, the battery mode will change to fast charge.)
ln the fast charge mode, the BKB 191 204/1 or BKB 191 204/2 battery will
take approximately 1 hour to fully charge.
If the initial charge on the battery is over 95%, then the fast charge mode will
turn to a "trickle-charge" mode. ln the "trickle-charge" mode, the battery will
bemaintainedatfullcharge,providedtheradiois turnedoff.TheSLOWLED
is turned on continuously, and may turn off momentarily every 34 seconds
by the "trickle-charging" current. If the battery is charged to 100% of its
capacity, the FAST LED will turn off and the SLOW LED wiIl turn on.
Front Charge Slot:Insert battery or radio with battery into Front Charge Slot,
observingcorrectpolarity.TheSLOWLEDwillbeilluminated,andacharging
current of approximately 50mA is provided to the battery.In the slow charge
mode, the BKB 191 204/1 or BKB 191 204/2 battery will take approximately
14 hours to fully charge.
On occasion when charging a new battery or a battery which has
been out of use for a few months, the charger will prematurely switch
to the trickle charge before the battery has been fully charged.If this
happens, allow the battery to continue trickle-charging overnight.
Then remove and reinsert the battery and observe that the battery
goes through a normal rapid charge before putting it into service.
NOTE
10

MONOGRAM SERIES WARRANTY
A. Ericsson Inc. (hereinafter "Seller") warrants to the original purchaser for use (hereinafter "Buyer") that
Equipment manufactured by Seller shall be free from defects in material, workmanship and title, and shall
conform to its published specifications.Withrespect toanyEquipmentnotmanufactured by Seller (except
for integral parts of Seller’s Equipment to which the warranties set forth above shall apply). Seller gives
no warranty, and only the warranty, if any, given by the manufacturer shall apply.Batteries are excluded
from this warranty but are warranted under a separate Nickel-Cadmium Battery Warranty.
B. Seller’s obligations set forth inParagraph C below shall apply only tofailurestomeet the above warranties
(except as to title) occurring within the following periods of time from date of sale to the Buyer and are
conditioned on Buyer’s giving written notice to Seller within thirty (30) days of such occurrence:
1. for fuses, incandescent lamps, vacuum tubes and non-rechargeable batteries, operable on arrival
only.
2. for parts and accessories (except as noted in B.1) sold by Seller’s Service Parts Operation, ninety
(90) days.
3. for all other Equipment of Seller’s manufacture, one (1) year.
C. If any Equipment fails to meet the foregoing warranties, Seller shall correct the failure at its option (i) by
repairing any defective or damaged part or parts thereof, or (ii) by making available at Seller’s factory any
necessary repaired or replacement parts.Any repaired or replacement part furnished thereunder shall be
warranted for the remainder of the warranty period of the Equipment in which it is installed. Where such
failurecannotbecorrectedbySeller’sreasonableefforts,thepartieswillnegotiateanequitableadjustment
in price.Labor to perform warranty service will be provided at no change only for the Equipment covered
under Paragraph B.3, and only during the first three (3) months following the date of sale to the Buyer.
Thereafter, labor will be charged at prevailing rates. To be eligible for no-charge labor, service must be
performed by an Authorized Service Center or other Services approved for these purposes either at its
place of business during normal business hours, for mobile or personal equipment, or at the Buyer’s
location,forfixedlocationequipment.Serviceonfixedlocationequipment morethanthirty(30) milesfrom
the Service Center or other approved Service’s place of business will include a charge for transportation.
Equipment located off-shore is not eligible for no-charge labor.
D. Seller’s obligations under Paragraph C shall not apply to any Equipment, or part thereof, which (i) has
been modified or otherwise altered other than pursuant to Seller’s written instructions or written approval
or, (ii) is normally consumed in operation or, (iii) has a normal life inherently shorter than the warranty
periods specified in Paragraph B, or (iv) is not properly stored, installed, used, maintained or repaired, or,
(v) has been subjected to any other kind of misuse or detrimental exposure, or has been involved in an
accident.
E. The preceding paragraphs set forth the exclusive remedies for claims (except as to title) based upon
defects in or nonconformity of the Equipment, whether the claim is in contract, warranty, tort (including
negligence), strict liability or otherwise,and however instituted.Upon the expiration of the warranty period,
all such liability shall terminate.The foregoing warranties are exclusive and in lieu of all other warranties,
whether oral, written, expressed, implied or statutory.NO IMPLIED OR STATUTORY WARRANTIES OF
MERCHANTABILITYORFITNESSFORPARTICULARPURPOSESHALLAPPLY.INNOEVENTSHALL
THE SELLER BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, INDIRECT OR
EXEMPLARY DAMAGES.This warranty applies only within the United States.
This warranty applies only within the United States.
ECX-362S
11

Ericsson Inc.
Private Radio Systems 937-263
Mountain View Road 680-090-0098
Lynchburg, Virginia 24502 AE/LZT 123 1878 R2A
1-800-592-7711 (Outside USA, 804-592-7711) Printed in U.S.A.
