Erskine Attachments 200001 User manual

Salt, Sand, and Fertilizer
Spreader
for
Skid Steer Loaders
Operator’s Manual
Maintenance
Parts Information
Read this Manual Before Use

2
NOTE: Erskine Attachments LLC reserves the right to make
improvements in design or changes in specifications at any time
without notice and without incurring any obligations to install them on
units previously sold.
TABLE OF CONTENTS
SAFETY
3-4
SERIAL NUMBER/DECAL LOCATION
5-6
USERS MOUNTING INSTRUCTIONS
7-8
OPERATING INSTRUCTIONS
9-11
ROUTINE MAINTENANCE
12
NOTES
13
PARTS INFORMATION
14-16
GENERAL SPECIFICATIONS
17
BOLT TORQUE INFORMATION
18
WARRANTY
19
REFERENCE INFORMATION
Write the serial number for your attachment in the spaces below. Always refer to this serial
number when calling for service or parts.
Serial Number………….._____________
YOUR ATTACHMENTS DEALER
ADDRESS:
PHONE:
CONTACT:

3
The signal words CAUTION, WARNING, or
DANGER are used to indicate hazards.
Indicates a potentially
hazardous situation which, if not avoided,
may result in minor or moderate injury.
Indicates a potentially
hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a potentially
hazardous situation which, if not avoided,
will result in death or serious injury.

The word IMPORTANT is used in the text when
immediate damage will occur due to improper
technique or operation.

The word NOTE is used to convey information that
is out of context with the manual text; special
information such as specifications, techniques,
reference information, and other information of a
supplementary nature.
The user is responsible for inspecting the machine
daily, and for having parts repaired or replaced
when continued use of the machine would cause
damage, excessive wear to other parts or make the
machine unsafe for continued operation.
If an operating procedure, tool device, maintenance
or work method not specifically recommended is
used, you must satisfy yourself that it is safe for you
and others. You must also ensure that the
attachment will not be damaged or made unsafe by
the procedures you choose.
Erskine Attachments LLC cannot anticipate every
possible circumstance that might involve potential
hazard. The safety messages found in this manual
and on the machine are therefore not all inclusive.
SAFETY
DO NOT use or perform maintenance on this machine until this manual has
been read and understood. In addition, read the Operation and Maintenance
Manual(s) pertaining to the attachment and the attachment carrier (“Loader”).

4
SAFETY
Improper operation can cause serious
injury or death.
Pre-operation
•This machine is designed for spreading dry free
flowing material only. NEVER use this machine
for any other purpose.
•Read the operator’s manual for the “Skid Steer
Loader.” NEVER allow untrained people to
operate.
•Operating instructions must be given to everyone
before operating this attachment and at least
once a year thereafter in accordance with OSHA
regulations.
•NEVER exceed the maximum recommended
input power or speed specifications for the
attachment. Over-powering or over-speeding the
attachment may cause personal injury and/or
machine damage.
•Keep all shields, guards, and covers in place.
•Do not modify equipment or add attachments that
are not approved by Erskine Attachments LLC.
•Use adequate safety warning lights and devices
as required by local regulations. Obey all local
laws and regulations regarding machine
operation on public property.
Operation
•Always wear eye protection that meets z87.1 or
use with a loader enclosure that provides similar
protection.
•Hydraulic connections may be hot after use. Use
gloves if connecting or disconnecting after use.
•Check and be sure all operating controls are in
neutral before starting the engine.
•Keep people away from loader, attachment and
discharge when in use. This attachment has
rotating parts. NEVER direct discharge toward
people.
•NEVER operate near embankments or terrain
that is so steep that rollover could occur.
Operation (continued)
•Always stay in the operator position when using
the attachment.
•Before leaving the operators position,
disengage hydraulic drive, lower the attachment
to rest flat on the ground, stop engine, set park
brake, and wait for all motion to stop.
•NEVER place hands in the discharge area or
clear debris while the engine is running.
Avoid High Pressure Fluids Hazard
•Escaping fluid under pressure can
penetrate the skin causing serious
injury.
•Avoid the hazard by relieving the
pressure before disconnecting
hydraulic lines.
•Use a piece of paper or cardboard, NOT BODY
PARTS, to check for suspected leaks. Wear
protective gloves and safety glasses or goggles
when servicing or performing maintenance on
hydraulic systems.
•If an accident occurs, see a doctor immediately.
Any fluid injected into the skin must be
surgically removed within a few hours or
gangrene may result.
Maintenance
•NEVER make adjustments, lubricate, clean, or
perform any service on the machine while it is in
operation.
•Make sure the attachment is serviced on a daily
basis. Improper maintenance can cause
serious injury or death in addition to damage to
the attachment and/or your equipment.

5
SERIAL NUMBER AND SAFETY DECAL LOCATIONS
Serial Number Location:
It is important to refer to the serial number of the attachment when making repairs or ordering parts. Early or
later models (identification made by serial number) may use different parts, or it may be necessary to use
different procedures in doing a specific operation.

6
Safety Decals Locations:
The locations of the safety decals are shown. If these
decals are missing, damaged, or painted over they must be
replaced. Call Erskine Attachments LLC (218-435-4045)
for replacement decals.
A
B
Part number: 200001
Location: On left mount plate
Quantity: 1
Part number: 318161
Location: On left rear panel of hopper
Quantity: 1
SERIAL NUMBER AND SAFETY DECAL LOCATIONS________
Large Brand Decal
Location: Front of hopper, centered
Quantity: 1

7
1. The flow control must be mounted as shown
with the nuts and bolts provided.
2. Use the step, safety treads, and grab handles
to get on and off the loader and attachment.
3. Sitting in the operator’s seat, lower the seat bar
and fasten the seat belt.
4. Drive the loader to the rear of the attachment.
5. Put the loader quick attach coupler into the
attachment mounting bracket.
6. Tilt the loader coupler backward a small amount
until it is fully engaged in the attachment
mounting bracket.
7. Stop the engine and engage the park brake.
8. Secure the coupler locking mechanism that
attaches the attachment to the loader.
USER’S MOUNTING INSTRUCTIONS
After initial set-up assembly is complete, use the following procedure to mount the attachment to the
loader for user operation.
Coupler wedges or pins must extend through the holes in attachment. Levers
must be fully down and locked. Failure to secure wedges or pins can allow attachment to
come off and cause injury or death.

8
9. Connect the hydraulic quick couplers from the
attachment to the loader.
IMPORTANT: Make sure the quick couplers
are fully engaged. If the quick couplers do not
fully engage, check to see that the couplers
are the same size and brand. Do not force
the quick couplers together.
IMPORTANT: Wipe the ends of the hydraulic
quick couplers (both lead and loader) with a
rag to remove any possible contamination.
Contamination can cause hydraulic
components to fail and is not covered under
warranty.
NOTE: See the loader’s operator’s manual.
NOTE: Attachment is shipped with 12FJX (1-
1/16” Female JIC Swivel) fittings on the ends of
the lead hoses.
10. Make sure the hoses are properly routed to fit
your specific loader. If the hoses are not
routed correctly, hoses may get pinched or
rub on tires. Be sure to check the hose
routing through the full range of intended
motion of the attachment before operating it.
More than one routing may be acceptable
depending on the loader. Pick the routing that
best suits your loader.
IMPORTANT: Proper hose routing is the
responsibility of the owner and/or operator.
Pinched or stretched hoses are not covered
under warranty.
Mounting is now complete and you are ready to use
the attachment. Use reverse order of above
instructions to dismount the attachment from the
loader.
USER’S MOUNTING INSTRUCTIONS

9
OPERATING INSTRUCTIONS
.
Filling the Hopper
The hopper can be filled by manually pouring
material from bags. If the loose material is kept in a
pile, the loader can be used to scoop material into
the hopper using the following steps:
1. If the spreader is equipped with a sidewalk kit,
remove it before attempting to load the hopper.
The hopper can be loaded manually with a
sidewalk kit equipped.
2. With the operator in the loader seat, seat belt
fastened, and seat bar lowered (if so equipped),
start the engine.
3. Lift the boom and roll out the attachment
coupler until the cutting edge of the hopper is
engaged with the ground.
4. Drive the hopper into the material pile while
rolling the attachment coupler back to fill the
hopper.
To avoid injury or death due
to tipping, carry loaded hopper as low as
possible while moving to spreading
location.

10
OPERATING INSTRUCTIONS
Spreading Material
This attachment can throw
loose material up to 40 feet. Keep people far
enough away to avoid being struck.
IMPORTANT: Spreading material that contains
rocks larger than 3/8” diameter may result in
damage to the attachment.
1. With the operator in the loader seat, seat belt
fastened, and seat bar lowered (if so
equipped), start the engine.
To avoid injury or death
due to tipping, carry loaded hopper as low
as possible while moving to spreading
location.
2. Raise the loader arms so the spreading disc
is 18-24 inches off of the ground. Use the tilt
cylinders on the loader to keep the spreading
disc level for optimum performance.
3. Activate the hydraulics on the loader to
spread material. The spreader disc should
rotate clockwise when viewed from above.
4. Depending on the material being spread, it
may be necessary to experiment with the
gate settings until a suitable spread pattern is
found.
Adjusting Spreader Flow Control
The flow control unit on the side of the spreader
can be used to adjust the spreading width. The
control range is marked from 1 to 10, with 10
being full flow.
Depending on the material and material
conditions, the flow control can be used to
accurately meter spread as narrow as 4 feet.
The three gates on the hopper can be adjusted
by loosening the locking screw, sliding the gate
to the desired position, and retightening the
locking screw.
NOTE: If the material being spread is not dry and
free flowing, it may be necessary to adjust/close
the gate on the front of the hopper due to material
from the other two gates sticking to the spreader
disc.
NOTE: The agitator/spinner may not function
properly if the flow control is turned down too far for
the material or material conditions. To avoid
stalling the spreader motor, adjust the flow control
for higher flow.
