Erskine attachments Es2000 User manual

Read the Operation & Maintenance Manual entirely. When you see this

symbol, the subsequent instructions and warnings are serious –follow

without exception. Your life and the lives of others depend on it!

Models ES2000 / ES2400 / ES2400XL

Hydraulic

Snow Blowers

for

Skid Steer Loaders

Operator’s Manual

Set-Up Assembly and

Parts Information

D

Do

o

n

no

ot

t

u

us

se

e

o

or

r

o

op

pe

er

ra

at

te

e

t

th

hi

is

s

m

ma

ac

ch

hi

in

ne

e

u

un

nt

ti

il

l

t

th

hi

is

s

manual has been read and understood.

P/N 320106 Date Printed: 3/29/2019

Erskine Attachments, Inc

Erskine, MN 56535 Printed in U.S.A.

IMPORTANT

If this machine is used by an employee or is loaned or

rented to others, make certain that the operator(s) prior

to operating:

Is instructed in safe and proper use.

Reviews and understands the operation and

maintenance manual(s) pertaining to the machine.

Remember, the operator is responsible for the safe

operation and maintenance of the machine. Most

accidents can be prevented. Good safety practices not

only protect you, but also the people around you.

NOTE: Erskine Attachments, Inc. reserves the right to make

improvements in design or changes in specifications at any time

without notice and without incurring any obligations to install them on

units previously sold.

-2-

LIMITED WARRANTY

Erskine Attachments, Inc. warrants each new machine manufactured by us to be free from

defects in material and workmanship for a period of twelve (12) months from date of delivery to

the original purchaser.

Our obligation under this warranty is to replace free of charge, at our factory or authorized

dealership, any part proven defective within the stated warranty time limit.

All parts must be returned freight prepaid and adequately packaged to prevent damage in

transit.

This warranty does not cover:

1. New products which have been operated in excess of rated capacities or negligence

2. Misuse, abuse, accidents or damage due to improperly routed hoses

3. Machines which have been altered, modified or repaired in any manner not

authorized by our company

4. Previously owned equipment

5. Any ground engaging tools in which natural wear is involved, i.e. tooth tips, cutting

teeth, etc

6. Normal maintenance

7. Fork tines

8. Hydraulic motors that have been disassembled in any manor

In no event will the Sales Representative, Dealership, Erskine Attachments, Inc., or any other

company affiliated with it or them be liable for incidental or consequential damages or injuries,

including but not limited to the loss of profit, rental or substitute equipment or other commercial

loss. Purchaser’s sole and exclusive remedy being as provided here in above.

Erskine Attachments, Inc. must receive immediate notification of defect and no allowance will be

made for repairs without our consent or approval.

This warranty is in lieu of all other warranties, express or implied by law or otherwise, and there

is no warranty of merchantability or fitness purpose.

No agent, employee, or representative of Erskine Attachments, Inc. has any authority to bind

Erskine Attachments, Inc. to any warranty except as specifically set forth herein. Any of these

limitations excluded by local law shall be deemed deleted from this warranty; all other terms

apply.

This warranty may not be enlarged or modified in any manner except in writing signed by an

executive officer of Erskine Attachments, Inc. to improve its products whenever it is possible

and practical to do so. Erskine Attachments, Inc. reserves the right to make changes and or

add improvements at any time without incurring any obligation to make such changes or add

such improvements to products previously sold.

Erskine Attachments, Inc.

P.O. Box 1083 Alexandria, MN 56308

Phone (218) 687-4045 Fax (218) 687-5293

-3-

TABLE OF CONTENTS

REFERENCE INFORMATION

Write the correct information for YOUR Snow Blower in the spaces below. Always use

these numbers when referring to your Snow Blower.

Snow Blower Serial Number…………..

YOUR ERSKINE ATTACHMENTS DEALER

ADDRESS:

PHONE:

CONTACT:

FOREWORD

4

SAFETY

5

SERIAL NUMBER/DECAL LOCATION

6-7

USERS INSTRUCTIONS FOR MOUNTING THE SNOWBLOWER

8-9

OPERATING THE SNOWBLOWER

10-11

ROUTINE MAINTENANCE

12-16

PARTS INFORMATION

18-28

SET UP ASSEMBLY OF THE SNOWBLOWER

29-34

GENERAL SPECIFICATIONS

36-37

-38-

NOTES

____________________________________________________

-4-

FOREWORD

To The Owner/Operator:

DO NOT use or operate this machine until this manual has been read and

understood. If you require additional information, contact your Dealer or Erskine

Attachments, Inc.

Operation and Maintenance Manuals are written to

give the owner/operator instructions on the safe

operation and maintenance of the product. For your

safety and the safety of other persons, you must

not operate, service, inspect or otherwise handle

this equipment before you have reviewed and

understood the Operation and Maintenance

Manual(s) pertaining to the Erskine™ Snow Blower

and the “Skid Steer Loader”.

Throughout this manual reference may be made to

the left hand (LH) or right hand (RH) side. These

terms are used as viewed from the operator’s seat

facing front.

In order to get the optimum performance and

efficiency that has been designed into the

Erskine™ Snow Blower, read this manual

thoroughly before setting-up, operating, or

performing maintenance procedures on the

machine.

It is the responsibility of the user to read the

operator’s manual and comply with the safety

instructions, operating instructions and

maintenance guidelines set forth in this manual.

The user is responsible for inspecting the machine

daily, and for having parts repaired or replaced

when continued use of the machine would cause

damage, excessive wear to other parts or make the

machine unsafe for continued operation.

The signal words CAUTION, WARNING, or

DANGER are used to indicate degree of hazards

and to warn against unsafe practices that may

cause personal injury and are used with

appropriate safety instructions. These signal words

are not to be ignored; your safety is involved.

CAUTION: denotes a general

reminder of good safety practices or

directs attention to unsafe practices.



WARNING: denotes a hazard

intermediate between DANGER and

CAUTION.



DANGER: denotes the most serious

hazard.



The word NOTE is used to convey information that

is out of context with the manual text; special

information such as specifications, techniques,

reference information, and other information of a

supplementary nature.

The word IMPORTANT, is used in the text when

immediate damage will occur to the machine due to

improper technique or operation. IMPORTANT will

apply to the same information specified by NOTE,

only of an immediate and urgent nature.

Erskine Attachments, Inc. cannot anticipate every

possible circumstance that might involve potential

hazard. The safety messages found in this manual

and on the machine are therefore not all inclusive.

If an operating procedure, tool device, maintenance

or work method not specifically recommended is

used; you must satisfy yourself that it is safe for you

and others. You must also ensure that the machine

will not be damaged or made unsafe by the

procedures you choose.

Model ES2400

ES2400 x 73”

ES2400 x 85”

Working Width

73”

85”

Height

36”

Fan Diameter

24” 4-blade

Auger Diameter

18” open flighting

Auger Shear Protection

Hydraulic relief valve

Chute Rotation

Hydraulic 270°

Cutting Edge

replaceable 1/2” x 4”

Mounting Plate

universal

Casting Distance

up to 40’

Flow Required

24 - 42 GPM

Shipping Weight

Approx. 1160lbs

Approx. 1200lbs

All dimensions are in INCHES.

75

87

45

69

-37-

MODEL ES2400 SNOW BLOWER GENERAL SPECIFICATIONS

MODEL ES2000 SNOW BLOWER GENERAL SPECIFICATIONS

1

2

SAFETY

Whenever you see this symbol, it means Attention!

Become Alert! Your Safety is involved.

Failure to obey warnings or instructions can cause

personal injury or death.

Operating instructions must be given to everyone before operating this machine and at least once a year

thereafter in accordance with OSHA regulations.

The machine is designed for snow removal only.

NEVER use this machine for other materials.

Do not modify equipment or add attachments that

are not approved by Erskine Attachments, Inc.

Remember, YOU are responsible for the safe

operation and maintenance of the equipment.

Most accidents can be prevented. Good safety

practices not only protect you, but also the

people around you.

General Safety Instructions

Read the operator’s manual for the “Skid Steer

Loader” to become totally familiar with the

controls and instruments. Know how to stop all

equipment operation in case of emergency.

Avoid the possibility of personal injury and/or

machine damage. NEVER exceed the maximum

recommended input power or speed

specifications for the Erskine™ Snow Blower.

Check and be sure all operating controls are in

neutral before starting the engine.

Disengage hydraulic drive, lower the Erskine™

Snow Blower to rest flat on the skid shoes, stop

engine, set park brake, and wait for all motion to

stop before leaving the operators seat for any

reason.

WARNING: Before adjusting, or

servicing the unit, stop the engine

and relieve all hydraulic pressure by

opening the control valve.

Keep all shields, guards, and covers in place.

Stay clear of the Erskine™ Snow Blower when

unit is in operation.

NEVER make adjustments, lubricate, or perform

any service on the machine while it is in

operation.

Keep people at least 10 feet (3m) away from

machine when machine is in operation.

NEVER operate near embankments or terrain

that is so steep that rollover could occur.

NEVER allow children or untrained persons to

operate.

DO NOT permit riders on equipment.

Use adequate safety warning lights and devices

as required by local regulations.

Obey all local laws and regulations regarding

machine operation on public property.

Wear Protective Equipment

Protective clothing and equipment should be

worn.

Wear clothing and equipment appropriate for the

job. Avoid loose fitting clothing.

Prolonged exposure to loud noise can cause

hearing impairment or hearing loss. Wear

suitable hearing protection such as earmuffs or

earplugs.

Operating equipment safely requires the full

attention of the operator. Avoid wearing radio

headphones while operating equipment.

Avoid High Pressure Fluids Hazard

Escaping fluid under pressure can penetrate the

skin causing serious injury.

Avoid the hazard by relieving the pressure

before disconnecting hydraulic lines.

Use a piece of paper or cardboard, NOT BODY

PARTS, to check for suspected leaks. Wear

protective gloves and safety glasses or goggles

when working with hydraulic systems.

If an accident occurs, see a doctor immediately.

Any fluid injected into the skin must be

surgically removed within a few hours or

gangrene may result.

-5-

-36-

Model ES2000

ES2000 x 61”

ES2000 x 73”

ES2000 x 79”

ES2000 x 85”

Working Width

61”

73”

79”

85”

Height

29”

Fan Diameter

20” 4-blade

Auger Diameter

16” open flighting

Auger Shear Protection

Hydraulic relief valve

Chute Rotation

Hydraulic 270°

Cutting Edge

replaceable 1/2” x 4”

Mounting Plate

Universal

Casting Distance

up to 30’

Flow Required

11 - 25 GPM

Shipping Weight

Approx. 915lbs.

Approx. 965lbs.

Approx. 1000lbs.

Approx. 1100lbs.

All dimensions are in INCHES.

62

74

80

43

65

SERIAL NUMBER AND SAFETY DECAL LOCATIONS

Serial Number Location:

It is important to refer to the serial number of the Snow Blower when making repairs or ordering parts. Early or

later models (identification made by serial number) may use different parts, or it may be necessary to use

different procedures in doing a specific operation.

-6-

Serial Plate

E

D

A

C

B

-35-

NOTES

____________________________________________________

Location: Front of chute assembly, adjacent

to chute opening

Quantity: 1

Location: Sides of chute assembly

Quantity: 2

-7-

SERIAL NUMBER AND SAFETY DECAL LOCATIONS

Erskine™ Snow Blower Safety Decals Locations:

The locations of the safety decals are shown. If these

decals are missing, damaged, or painted over they

must be replaced. Call Erskine Attachments, Inc.

(218-687-4045) for replacement decals.

A

Location: On each side of blower assembly

Quantity: 2

C

B

Location: Back right side of blower

assembly

Quantity: 1

D

E

Location: Chute rotation chain cover.

Quantity: 1

Clinch Wire Hook

Retaining Loop

Hole in Mounting Plate Arm

-34-

SET UP ASSEMBLY OF THE SNOW BLOWER

HOSE ROUTING

Install the hydraulic couplers on the correct

hoses, being sure to match the correct coupler

(male/female) to the coupler on the Loader

pressure line (see Loader Operation Manual).

NOTE: The pressure line on the snow blower

is labeled “Pressure” on the hose sleeving, as

well as having a RED cable tie on the hose end.

Drive the loader to the rear of the snow blower

and attach the Loader mounting bracket to the

snow blower mounting bracket (see loader

Operation Manual).

To prevent the hoses and wire harness from

rubbing on the tires, route the hoses through

the retaining loop and couple the hoses and

wire harness to the loader.

Install the retaining strap to the hoses about 10”

above the retaining loop. Wrap the strap

around the hoses and secure in place by

clinching the wire hook shut with a pliers.

Connect the other end of the retaining strap to

the snow blower by putting the wire hook

through the hole on the mounting plate arm.

Run the snow blower and check all operational

functions. Set up assembly is now complete.

NOTE: Make sure the hoses are properly

routed to fit your specific loader. If the

hoses are not routed correctly, hoses may get

pinched or rub on tires. Be sure to check the

hose routing through the full range of intended

motion of the attachment before operating it.

More than one routing may be acceptable

depending on the loader. Pick the routing that

best suits your loader.

PROPER HOSE ROUTING IS THE

RESPONSIBILITY OF THE OWNER AND/OR

OPERATOR. PINCHED OR STRETCHED

HOSES ARE NOT COVERED UNDER

WARRANTY.

-33-

SET UP ASSEMBLY OF THE SNOW BLOWER

5. Open the rear door. Pull the excess wire

harness into the engine compartment.

6. Raise the operator cab. (See Loader

Operation and Maintenance Manual for the

correct procedure.)

7. Connect the red fused wire to the positive

battery terminal or to a suitable accessory

wire with a minimum rating of 5 amps.

Route the wiring along the Loader main

frame toward the front of the Loader.

Connect the black wire from the harness to

a frame ground.

8. Fasten the control handle wire harness

connector to the main wire harness

connector.

NOTE: Secure the wire harness in place with

plastic cable ties, making sure it is clear of extra

hot areas or any moving parts on the engine or

Loader.

9. Lower the cab. (See Loader Operation

and Maintenance Manual for the correct

procedure.)

NOTE: Be sure the control handle wire

harness is properly positioned as the cab is

lowered.

-8-

USERS INSTRUCTIONS FOR MOUNTING THE SNOW BLOWER

After the initial set-up assembly is completed use the following procedure to mount the Erskine™ Snow Blower

to the Loader for user operation.

1. Use the step, safety treads, and grab

handles to get on and off the Loader and

snow blower.

2. Sitting in the operator’s seat, lower seat bar

and fasten the seat belt.

3. Drive the Loader to the rear of the snow

blower. Put the Loader quick attach coupler

into the snow blower mounting bracket.

4. Tilt the Loader coupler backward a small

amount until it is fully engaged in the snow

blower mounting bracket.

5. Stop the engine and engage the parking

brake.

6. Secure the coupler locking mechanism that

attaches the snow blower to the Loader.

WARNING: Coupler wedges or

pins must extend through the

holes in attachment. Levers

must be fully down and locked.

Failure to secure wedges or

pins can allow attachment to

come off and cause injury or

death.

-9-

USERS INSTRUCTIONS FOR MOUNTING THE SNOW BLOWER

NOTE: Attachment is shipped with 12FJX (1-

1/16” Female JIC Swivel) fittings on the ends of

the lead hoses.

7. Connect the hydraulic quick couplers from

the snow blower to the Loader.

NOTE: Make sure the quick couplers are

fully engaged. If the quick couplers do not fully

engage, check to see that the couplers are the

same size and brand. Do not force the quick

couplers together.

If the quick couplers will not connect together

due to thermal expansion of the fluid in the

hoses, stop the engine and activate the

auxiliary hydraulic control to relieve the

pressure.

NOTE: See the Loader Operation and

Maintenance Manual.

8. Connect the snow blower wire harness to the

Loader wire harness receptacle.

9. Mounting is now complete and you are ready

to use the snow blower. Use reverse order

of above instructions to dismount the snow

blower from the Loader.

-32-

SET UP ASSEMBLY OF THE SNOW BLOWER

Adjusting the Skid Shoe Height (continued)

ES2400 & ES2400XL

Remove the two skid shoe retaining bolts and

adjust the shoes equally on both sides to obtain

the desired cutting depth. Reinstall and tighten

the retaining bolts.

Wire Harness Installation

A wire harness is needed to activate the

rotation and deflection. If the Loader is

equipped with an Attachment Control package,

the appropriate harness should be installed

from the factory.

If the snow blower was ordered with the Pistol

Grip Control Harness, follow these instructions:

1. Install the control handle on either steering

level, whichever you prefer, with (2) hose

clamps.

IMPORTANT: The control handle bracket

can be positioned several different ways.

We recommend it be positioned as shown.

2. Put a cable tie around the wiring harness

and the steering lever.

3. Install the wire harness receptacle bracket

on either the loader arm or near the

hydraulic quick couplers.

IMPORTANT: It may be necessary to make

an adapter bracket in order to attach the

wire harness to the Loader.

4. Route the wire harness back along the tube

lines on the Loader arms and fasten with

cable ties.

Cable Tie

Hose Clamp

-31-

SET UP ASSEMBLY OF THE SNOW BLOWER

Loosen the rotation mount bolts. Push the

rotation mount all the way towards the chute.

Install the No. 40 roller chain around the

sprocket.

Tighten the rotation mount by moving it

outward to remove all slack in the chain.

Tighten the rotation mount bolts and install

the chain shield.

CAUTION: Do not operate the

snow blower without the chain

shield in place.

Install the cylinder with the rod end to the

deflector ears. Fasten with two 1/2” bolts.

NOTE: Usually the hoses will remain

connected to the cylinder when the chute is

removed.

IMPORTANT: Be sure the hoses are

routed properly to allow the chute to

rotate freely in both directions.

Adjusting the Skid Shoe Height

Tilt the snow blower all the way back.

Put blocks under the snow blower to hold

the cutting edge off the ground.

Lower the lift arms until the snow blower

rests on the blocks.

Stop the engine and exit the Loader.

ES2000

Remove the lynch pin (1) on the skid shoes.

Install washers (2) for the desired skid shoe

height. Reinstall the lynch pin.

1

2

DISCHARGE CHUTE INSTALLATION (continued)

-10-

OPERATING THE SNOW BLOWER

WARNING: DO NOT operate from any position except seated in the operator’s seat with

the seat belt fastened. DO NOT permit riders.

1. With the operator in the seat of the Loader,

the seat belt fastened and the seat bar

lowered (if so equipped), start the engine.

CAUTION: Keep bystanders

away! Thrown objects and ice

can cause serious injury.

2. Rest the snow blower on the skid shoes

and/or cutting edge depending on the

application.

3. Adjust the skid shoes to the position that will

most benefit your application.

4. If desired, the Loader lift arms can be put in

the float position. (See Loader Operation and

Maintenance Manual.)

5. Activate the auxiliary hydraulic system to start

the snow blower turning. (See Loader

Operation and Maintenance Manual.)

CAUTION: Engine must be at

idle speed when engaging

auxiliary hydraulic system.

Hydraulic Chute Rotation and Deflection

All chute functions can be activated by the

steering lever switches on the Loader (if Loader

is equipped), or with the Pistol Grip Control

Harness.

NOTE: Your Loader must have the attachment

control kit installed to make use of the lever

switches.

The previously installed Pistol Grip allows the

operator to engage all chute functions. (see Set

Up Assembly)

FUNCTIONS ARE ACTIVATED AS FOLLOWS:

(A) Button 1 moves deflector UP.

(B) Button 2 moves deflector DOWN.

(C) Button 3 rotates chute LEFT.

(D) Button 4 rotates chute RIGHT.

NOTE: For steering lever functions, refer to your

Loader Operation and Maintenance Manual.

After you become familiar with the controls, direct

the chute towards an open space and away from

bystanders or obstructions. Operate the engine

at full throttle and start moving the Loader

forward into the snow.

NOTE: The Loader travel speed is determined

by the depth and density of the snow.

-11-

OPERATING THE SNOW BLOWER

-30-

SET UP ASSEMBLY OF THE SNOW BLOWER

Remove one of the roller guides from the

blower housing by removing the bolt securing

the roller guide.

After unpacking the chute, slip the chute into

the grooves on the two remaining roller guides.

Install the roller guide and bushings with bolt,

lock washer, and lock nut.

IMPORTANT: Tighten each lock nut to 75

ft./lbs.

Rotate the chute to the straight forward

position.

Remove the chain shield from the blower

housing.

DISCHARGE CHUTE INSTALLATION

Use No. 2 lithium base gun grease when

lubricating all Erskine™ Snow Blower grease

fittings.

Grease the bearing on the end of the auger

after every 30 hours of operation.

WARNING: These are

requirements. It is the

responsibility of the

owner/operator to make sure

the attachment is serviced on a

daily basis. Improper

maintenance can cause

extensive damage to the

attachment and/or your

equipment.

Use clean engine oil to lubricate the chute

rotation chain after every 24 hours of

operation.

30

24

-12-

ROUTINE SNOW BLOWER MAINTENANCE

It is the operator’s responsibility to make daily inspections of the loader and attachment for damage, loose bolts, fluid

leaks, or anything else that could cause a potential service or safety problem. Preventive maintenance is the easiest and

least expensive type of maintenance.

IMPORTANT: Bolts and set screws can loosen after initial usage. After the first hour of operation

check all bolts and set screws.

WARNING: Lower the Erskine™ Snow Blower to rest on the skid shoes, shut down the

engine, relieve the hydraulic pressure to the Erskine™ Snow Blower, wait for all motion to

stop, and set park brake before leaving the operator’s seat to perform service of any kind.

LUBRICATION

No. 2 Lithium

base gun grease

Clean engine oil

SET UP ASSEMBLY OF THE SNOW BLOWER

Remove screws to disassemble crate.

ES2400 & ES2400XL Only

Remove the two bolts securing the mounting

plate. Turn the mounting plate so that the

brackets of the blower are flat against the

mounting plate. Align the mounting plate holes

and reinstall the two bolts, lock washers, and

nuts that were previously removed. Install the six

additional bolts provided inside the box attached

to the auger. There should be four bolts on each

side arranged in a square pattern with the fifth

hole left open.

WARNING: Make sure to tighten

each of the bolts on the mounting

plate to 240 ft-lbs. Failure to do

this could result in serious injury

or damage to the machine.

The mounting plate can be installed in the “lower”

position for most skid steers with standard sized

tires, or in the “upper” position for skid steers with

taller or oversized tires.

CRATE REMOVAL AND ASSEMBLY

-29-

LUBRICATION (continued)

-13-

ROUTINE SNOW BLOWER MAINTENANCE

Grease the auger drive after every 4 hours of

operation.

NOTE: There are (2) grease fittings, one on

each side of the auger tube.

Grease the (3) chute roller guide bushings also

after every 4 hours of operation. (Not Pictured)

The fan is shear-protected by the Loader

hydraulic system pressure relief valve. No

adjustments are required.

The auger is shear-protected by pressure relief

valve ‘A’ located in the hydraulic control

manifold on the rear of the snow blower, directly

above the fan motor.

NOTE: The auger relief valve is set at the

factory to assure the best performance in

average conditions. If the auger should stall too

easily, the relief valve can be adjusted as

follows:

A. Loosen the lock nut on valve ‘A’.

B. Turn the set screw in one turn.

C. Tighten the lock nut.

D. If the auger still stalls, adjust the relief valve

again by repeating steps A through C.

NOTE: Do not adjust the relief valve more than

one turn at a time or a total of more than 4

turns. If the auger still stalls, look for other

problems.

A

HYDRAULIC RELIEF VALVE ADJUSTMENT

4

1

4

-28-

WIRE HARNESS PARTS INFORMATION

2

3

REF.

PART NO.

DESCRIPTION

QTY.

315128

COMPLETE HARNESS –generic (shown)……………………..

1

315110

PISTOL GRIP –handle assembly w/ harness...………………..

1

2

315126

LOADER HARNESS –assembly………………………………...

1

3

202489

RECEPTACLE BRACKET –loader harness……………………

1

4

315127

BLOWER HARNESS –assembly………………………………..

1

Optional Harnesses (not shown):

320256

14-PIN UNIVERSAL –

for Bobcat® Loaders

320233

14-PIN UNIVERSAL –

for Case® & New Holland® Loaders

320084

14-PIN UNIVERSAL –

for John Deere® Loaders

200008

8-PIN –for Caterpillar® A series Loaders

315153

8-PIN –for ASV® Loaders

315339

8-PIN –for Caterpillar® B series

-14-

ROUTINE SNOW BLOWER MAINTENANCE

1. Loosen the setscrew on the bearing

eccentric locking collar. Using a hammer

and punch, rotate the collar in the opposite

direction of auger travel.

NOTE: This frees up the bearing and allows it

to slide on the auger shaft.

2. Disconnect the tubelines from the auger

motor.

3. Remove the two bearing retaining bolts and

the four auger motor housing bolts.

NOTE: Pry the bearing flange approximately

1/4” to the inside to allow clearance for the

auger to be removed.

AUGER REMOVAL AND INSTALLATION

-27-

HYDRAULIC ASSEMBLY

REF.

PART NO.

DESCRIPTION

QTY.

1

315093

HOSE –1/4" x 53” 6MB-2MP upper deflector………………

1

2

103284

ADAPTER - elbow 2MP-2FPX90 …………………………..

1

3

103273

CYLINDER –2” x 4”…………………………………………...

1

4

103318

ADAPTER - elbow 2MP-2FPX ……………………………...

1

5

315094

HOSE –1/4” x 46” 6MB-2MP lower deflector………………

1

6

103330

ADAPTER - elbow 10MB-6MJ90 …………………………..

2

7

103329

MOTOR –chute rotator……………………………………….

1

8

100540

KEY –1/4” x 1” woodruff………………………………………

1

9

315092

HOSE –3/8” x 21” 6MB-6FJX chute rotator………………..

2

10

315136

HOSE –1/4" x 22” 6MB-4FJX case drain…………………..

1

11

315085

TUBELINE –right, motor to valve……………………………

1

315260

TUBELINE –right, motor to valve (2400XL only)..…………

1

12

103431

ADAPTER –12MB-12MJ …………………………………….

4

13

103521

MOTOR –fan 9.6 CID ………………………………………..

1

200104

MOTOR –fan 11.9 CID ………………………………………

1

200319

MOTOR –fan 11.9 CID (ES2400XL) ……………………….

1

320085

MOTOR –fan 14.9 CID ………………………………………

1

200168

MOTOR –fan 15.0 CID (ES2400XL) ……………………….

1

14

103497

ADAPTER –elbow 4MB-4MJ90 …………………………….

1

203212

ADAPTER –straight 4MB-4MJ (2400XL only) ………….

1

15

315084

TUBELINE –left, valve to motor……………………………..

1

315259

TUBELINE –left, valve to motor (ES2400XL only)..………

1

16

315091

HOSE –3/4" x 72” 12FJX-12MB lead, pressure…………...

1

17

315143

HOSE –3/4" x 72” 12FJX-12MB case drain …………........

1

18

315425

TUBELINE –return……………………………………………

1

19

315424

TUBELINE –pressure…………………………………………

1

20

202113

ADAPTER –straight 10MB-12MJ …………….....................

2

21

103396

MOTOR –auger 24 CID (ES2400, ES2400XL) ……………

1

320077

MOTOR –auger 30 CID (ES2400, ES2400XL) ……………

1

22

315451

HOSE –3/4" x 24.5” 12MB-12MJ auger 60” ……………….

2

315452

HOSE –3/4" x 30.5” 12MB-12MJ auger 72” ……………….

2

315454

HOSE –3/4" x 36.5” 12MB-12MJ auger 84” ……………….

2

315328

HOSE –3/4" x 42.5” 12MB-12MJ auger 96” ……………….

2

23

315068

MANIFOLD –hydraulic control……………………………….

1

A

320107

BLOCK………………………………………………………..

1

B

200046

PRESSURE RELIEF VALVE –auger……………………..

1

C

200045

FLOW CONTROL VALVE………………………………….

1

D

320096

COIL –assembly…………………………………………….

4

E

200042

DIRECTIONAL VALVE……………………………………...

2

F

200041

WASHER……………………………………………………..

2

G

200039

NUT……………………………………………………………

2

24

201527

ADAPTER - straight 16MB-12MJ (2400XL only) ..………

2

PARTS INFORMATION

-15-

ROUTINE SNOW BLOWER MAINTENANCE

4. Slide the auger straight forward and out of

the blower body.

5. The hydraulic motor and housing can now be

removed from the auger.

6. To install, use reverse procedure.

7. When everything is assembled and

tightened, with the exception of the bearing

locking collar, the auger should have from

1/4” to 1/2” endplay travel. Slide the auger

toward the auger motor until it bottoms out.

Then, tap it back in the opposite direction

approximately 1/16”.

8. Tighten the eccentric locking collar by using

a hammer and punch to rotate the collar in

the direction of the auger travel. Tighten the

setscrew.

NOTE: Grease the auger drive when

installing (see page 13).

AUGER REMOVAL AND INSTALLATION (continued)

-26-

A

B

D

G

F

E

C

24

ROUTINE SNOW BLOWER MAINTENANCE

The auger must be removed first. (see Auger

Removal page 15)

Remove the five lug nuts.

NOTE: A block of wood placed through the

discharge chute and into the fan area will keep the

fan from rotating when loosening or tightening the

lug nuts on the fan.

Remove the fan from the blower.

To install, use the reverse procedure.

NOTE: If the fan hub requires removing, loosen

the retaining castle nut before removing the fan.

FAN HUB REMOVAL

Remove the cotter key and castle nut.

NOTE: The castle nut should be loosened and

tightened with the fan assembled to prevent the

hub from rotating.

Remove the hub from the tapered motor shaft with

a pulley puller.

To install, use reverse procedure.

CAUTION: The castle nut must be

torqued to a minimum of 200-ft. lbs.

FAN REMOVAL AND INSTALLATION

-16-

Block

-25-

ES2400/ES2400XL DRIVE ASSEMBLY

REF.

PART NO.

DESCRIPTION

QTY.

1

315342

AUGER - 18” diameter x 60” …………………………………

1

315202

AUGER - 18” diameter x 72” …………………………………

1

315203

AUGER - 18” diameter x 84” …………………………………

1

315297

AUGER - 18” diameter x 96” …………………………………

1

2

100832

BEARING ASSEMBLY - 1-1/4” 2-bolt flange……………….

1

3

- -

WASHER - flat 7/16……………………………………………

6

4

- -

BOLT - 1/2 x 1-3/4 NC gr5…………………………………..

2

5

- -

NUT - lock 1/2 NC……………………………………………..

6

103925

NUT - lug 1/2 NF……………………………………………….

5

200310

NUT - lug 9/16 NF (ES2400XL)..…………………………….

5

7

315229

FAN - 24” diameter…………………………………………….

1

315254

FAN - 24” diameter (ES2400XL only)……………………….

1

8

202499

HUB - fan motor (w/o bolts)…………………………………..

1

202671

HUB –fan motor (w/o bolts) (ES2400XL only) …………….

1

9

103970

BOLT - lug 1/2 NF……………………………………………..

5

200309

BOLT - lug 9/16 NF (ES2400XL only)..……………………..

5

10

- -

PIN - cotter 1/8 x 2…………………………………………….

1

11

103981

KEY - 5/16 x 1-3/8 round end………………………………...

1

12

- -

MOTOR - fan…………………………………………………...

1

13

103947

NUT - 1” NF castle…………………………………………….

1

14

- -

BOLT - 3/8 x 1-1/2 NC gr5……………………………………

1

15

- -

WASHER - lock 3/8……………………………………………

1

16

103891

DRIVE COUPLER - auger…………………………………….

1

17

310037

HOUSING - auger motor……………………………………...

1

18

103914

KEY - 5/16 x 1-1/2……………………………………………..

1

19

- -

MOTOR - auger………………………………………………..

1

20

- -

BOLT - 1/2 x 1-1/4 NC gr5……………………………………

4

-17-

NOTES

____________________________________________________

-24-

PARTS INFORMATION ES2400/ES2400XL

-23-

ES2000 DRIVE ASSEMBLY

-18-

PARTS INFORMATION ES2000

REF.

PART NO.

DESCRIPTION

QTY.

1

315404

AUGER - 16” diameter x 61” …………………………………

1

315405

AUGER - 16” diameter x 73” …………………………………

1

315406

AUGER - 16” diameter x 79” …………………………………

1

315447

AUGER - 16” diameter x 85” …………………………………

1

2

100832

BEARING ASSEMBLY - 1-1/4” 2-bolt flange……………….

1

3

- -

WASHER - flat 7/16……………………………………………

6

4

- -

BOLT - 1/2 x 1-1/2 NC gr5……………………………………

2

5

- -

NUT - lock 1/2 NC……………………………………………..

6

103925

NUT - lug 1/2 NF……………………………………………….

5

7

315065

FAN - 20” diameter…………………………………………….

1

8

202499

HUB - fan motor (w/o bolts)…………………………………..

1

9

103970

BOLT - lug 1/2 NF……………………………………………..

5

10

- -

PIN - cotter 1/8 x 2…………………………………………….

1

11

103981

KEY - 5/16 x 1-3/8 round end………………………………...

1

12

- -

MOTOR - fan…………………………………………………...

1

13

103947

NUT - 1” NF castle…………………………………………….

1

14

- -

BOLT - 3/8 x 1-1/2 NC gr5……………………………………

1

15

- -

WASHER - lock 3/8……………………………………………

1

16

103891

DRIVE COUPLER - auger…………………………………….

1

17

310037

HOUSING - auger motor……………………………………...

1

18

103914

KEY - 5/16 x 1-1/2……………………………………………..

1

19

- -

MOTOR - auger………………………………………………..

1

20

- -

BOLT - 1/2 x 1-1/4 NC gr5……………………………………

4

REF.

PART NO.

DESCRIPTION

QTY.

1

315124

HINGE PIN - deflector..........................................…........

1

2

- -

PIN - cotter…………………………………………………..

1

3

- -

BOLT - 1/2 x 2-1/2 NC gr5………………………………....

9

4

315067

DEFLECTOR - chute ………………………………………

1

6

- -

NUT –lock 1/2" NC …………………………………………

20

7

315443

CHUTE.....................................................................….....

1

315410

CHUTE - without decals ………… ………………………..

1

8

- -

BOLT –flanged 3/8 x 3/4 NC gr8…………………………

4

9

315049

SHIELD - chain ……………………………………………..

1

10

100539

SPROCKET - 40B12 ………………………………………

1

11

- -

NUT –lock 3/8” NC…………………………………………

4

12

- -

BOLT –carriage 3/8” x 3/4” NC gr5 - OBSOLETE

1

13

- -

WASHER –flat 3/8” - OBSOLETE

2

14

315456

SHIELD –fan cover - OBSOLETE

1

15

- -

BOLT 3/8” x 1” NC gr5………………………………………

3

16

- -

BOLT –threadrolling 3/8” x 3/4” NC gr5 - OBSOLETE

1

17

- -

WASHER –7/16 flat………………………………………..

1

18

315046

BRACKET - rotator motor …………………………………

1

19

315043

BRACKET - tightener ………………………………………

1

20

315400

BODY - blower 60” …………………………………………

1

315401

BODY - blower 72” …………………………………………

1

315402

BODY - blower 78” ………………………………………….

1

315446

BODY - blower 84” …………………………………………

1

21

200012

BOLT - carriage 1/2 x 1-1/2 NC gr5 ……………….…….

(10)60” (12)72” (13)78” (14)84”

22

201507

CUTTING EDGE –1/2 x 4 x 59” bolt-on …………………

1

100450

CUTTING EDGE –1/2 x 4 x 71” bolt-on …………………

1

200132

CUTTING EDGE –1/2 x 4 x 77” bolt-on …………………

1

104038

CUTTING EDGE –1/2 x 4 x 83” bolt –on ……………….

1

23

100301

SKID SHOE ES2000 - assembly (includes lynch pin)…..

2

24

- -

BOLT - 5/8 x 1-1/2 NF gr8…………………………………

8

25

33897

WASHER –lock 5/8 high alloy.…………………………….

8

26

- -

NUT - 5/8 NF gr8..…………………………………………..

8

27

315051

MOUNTING PLATE ……………………..…………………

1

28

33006

WASHER- flat 5/16 …………………………………………

2

29

315444

SHIELD - auger hose ………………………………………

1

30

201992

RETAINING STRAP - 21” ………………………………….

1

31

315020

ROLLER GUIDE…………………………………………….

3

32

315155

BUSHING –grease able……………………………………

3

33

33860

WASHER –flat 7/16 hardened…………………………….

3

35

- -

BOLT - 1/2 x 1-3/4 NC gr5…...…………………………….

1

36

315089

ROLLER CHAIN - no. 40 ………………………………….

1

37

103622

CONN LINK - no. 40………………………………………..

2

38

- -

BOLT - 1/2 x 2-1/2 NC gr5…...…………………………….

(13)60” (15)72” (16)78” (17)84”

39

- -

WASHER –flat 1/2" ………………………………………..

(10)60” (12)72” (13)78” (14)84”

40

315463

BACKING PLATE –for opt. urethane 60” cutting edge

1

315464

BACKING PLATE –for opt. urethane 72” cutting edge

1

315465

BACKING PLATE –for opt. urethane 78” cutting edge

1

315466

BACKING PLATE –for opt. urethane 84” cutting edge

1

41

315459

CUTTING EDGE –urethane optional 60” ……………....

1

315460

CUTTING EDGE –urethane optional 72” ………………

1

315461

CUTTING EDGE –urethane optional 78” ………………

1

315462

CUTTING EDGE –urethane optional 84” ………………

1

42

315467

SKID SHOE –optional urethane ………………………..

2

43

3000086

SKID SHOE –optional hardened ……………………….

2

-19-

ES2000 BODY ASSEMBLY

-22-

PARTS INFORMATION ES2000

-21-

ES2400/ES2400XL BODY ASSEMBLY

-20-

PARTS INFORMATION ES2400/ES2400XL

REF.

PART NO.

DESCRIPTION

QTY.

1

315124

HINGE PIN - deflector..........................................…........…

1

2

- -

PIN - cotter……………………………………………………..

1

3

- -

BOLT - 1/2 x 1-1/2 NC gr5……………………………………

2

4

- -

NUT - lock 1/2 NC……………………………………………..

(20)60” (22)72” (24)84”

5

315067

DEFLECTOR - chute …………………………………………

1

7

315443

CHUTE.....................................................................…......

1

315410

CHUTE - without decals ………….…………………………..

1

8

- -

BOLT –flanged 3/8 x 3/4 NC gr8…………………………...

4

9

315049

SHIELD - chain ………………………………………………..

1

10

- -

BOLT - 1/2 x 1-3/4 NC gr5……………………………………

1

11

- -

NUT –lock 3/8” NC……………………………………………

4

12

- -

BOLT –carriage 3/8” x 3/4” NC gr5 - OBSOLETE

1

13

- -

WASHER –flat 3/8” - OBSOLETE

2

14

- -

BOLT 3/8” x 1” NC gr5………………………………………...

3

15

- -

BOLT –threadrolling 3/8” x 3/4” NC gr5 - OBSOLETE

1

16

315293

SHIELD –fan cover - OBSOLETE

1

17

315341

BODY - blower (ES2400 x 60”) ……………………………...

1

315200

BODY - blower (ES2400 x 72”) ……………………………...

1

315201

BODY - blower (ES2400 x 84”) ……………………………...

1

315296

BODY - blower (ES2400 x 96”) ……………………………...

1

315252

BODY - blower (ES2400XL x 72”) …………………………..

1

315253

BODY - blower (ES2400XL x 84”) …………………………..

1

18

- -

WASHER –7/16 flat………………………………………….

1

19

100539

SPROCKET - 40B12 …………………………………………

1

20

315046

BRACKET - rotator motor ……………………………………

1

21

315043

BRACKET - tightener …………………………………………

1

22

200012

BOLT - carriage 1/2 x 1-1/2 NC gr5………………………….

(10)60” (12)72” (14)84”

23

201507

CUTTING EDGE - 1/2 x 4 x 59” bolt-on …………………….

1

100450

CUTTING EDGE - 1/2 x 4 x 71” bolt-on …………………….

1

104038

CUTTING EDGE - 1/2 x 4 x 83” bolt-on …………………….

1

200158

CUTTING EDGE - 1/2 x 4 x 95” bolt-on …………………….

1

24

- -

BOLT - 3/4 x 2-1/2 NC gr5…………….……………………...

2

25

201316

SKID SHOE ES2400 - hardened…………………………….

2

26

- -

NUT - lock 3/4 NC……………………………………………..

2

27

200010

LEG - skid shoe………………………………………………..

2

28

- -

BOLT - 5/8 x 1-1/2 NF gr8……………………………………

8

29

33897

WASHER –lock 5/8 high alloy.……………………………...

8

30

- -

NUT - 5/8 NF gr8..……………………………………………..

8

31

315051

MOUNTING PLATE ……………………..……………………

1

32

315444

SHIELD - auger hose …………………………………………

1

33

- -

WASHER –flat 5/16…………………………………………...

2

34

201992

RETAINING STRAP - 21” ……………………………………

1

35

315020

ROLLER GUIDE……………………………………………….

3

36

315155

BUSHING –grease able………………………………………

3

37

33860

WASHER –flat 7/16 hardened……………………………….

3

38

- -

BOLT - 1/2 x 2-1/2 NC gr5…...……………………………….

(13)60” (15)72” (17)84”

39

315089

ROLLER CHAIN - no. 40 …………………………………….

1

40

103622

CONN LINK - no. 40…………………………………………..

2

41

- -

BOLT –9/16 x 2-1/2 NF gr5 (2400XL only)…………………

4

42

315459

CUTTING EDGE –urethane optional 60” …………….......

1

315460

CUTTING EDGE –urethane optional 72” …………………

1

315462

CUTTING EDGE –urethane optional 84” …………………

1

43

315463

BACKING PLATE –for opt. urethane 60” cutting edge

1

315464

BACKING PLATE –for opt. urethane 72” cutting edge

1

315466

BACKING PLATE –for opt. urethane 84” cutting edge

1

44

- -

WASHER –flat 1/2" …………………………………………...

(10)60” (12)72” (14)84”

Erskine Attachments ES2000 User manual

Popular Snow Blower manuals by other brands
