Origo™
Mig C280 PRO
Mig C340 PRO
Instruction manual

- 2 -

- 3 -
TOCe
Rights reserved to alter specifications without notice.
1 SAFETY 4...........................................................
2 INTRODUCTION 6...................................................
2.1 Equipment 6................................................................
3 TECHNICAL DATA 7.................................................
4 INSTALLATION 8....................................................
4.1 Location 8..................................................................
4.2 Assembly of components 9...................................................
WARNING 9.....................................................................
4.3 Electrical installation 10.......................................................
4.4 Mains power supply 10........................................................
5 OPERATION 11.......................................................
5.1 Connection and control devices 12.............................................
5.2 Overheating protection 12.....................................................
5.3 Inductance connection 12.....................................................
5.4 Polarity change 13...........................................................
5.5 Wire feed pressure 13........................................................
5.6 Replacing and inserting wire 14................................................
6 MAINTENANCE 14....................................................
6.1 Inspection and cleaning 14....................................................
7 FAULT TRACING 15..................................................
8 ORDERING OF SPARE PARTS 15......................................
DIAGRAM 16............................................................
CONNECTION INSTRUCTION 24..........................................
ORDER NUMBER 25.....................................................
WEAR PARTS 26........................................................
ACCESSORIES 29.......................................................

© ESAB AB 2011
- 4 -
bc23de
1 SAFETY
Users of ESAB equipment have the ultimate responsibility for ensuring that anyone who works on or
near the equipment observes all the relevant safety precautions. Safety precautions must meet the
requirements that apply to this type of equipment. The following recommendations should be ob
served in addition to the standard regulations that apply to the workplace.
All work must be carried out by trained personnel well-acquainted with the operation of the equip
ment. Incorrect operation of the equipment may lead to hazardous situations which can result in in
jury to the operator and damage to the equipment.
1. Anyone who uses the equipment must be familiar with:
Sits operation
Slocation of emergency stops
Sits function
Srelevant safety precautions
Swelding and cutting
2. The operator must ensure that:
Sno unauthorised person is stationed within the working area of the equipment when it is
started up.
Sno-one is unprotected when the arc is struck
3. The workplace must:
Sbe suitable for the purpose
Sbe free from drafts
4. Personal safety equipment
SAlways wear recommended personal safety equipment, such as safety glasses, flame-proof
clothing, safety gloves.
SDo not wear loose-fitting items, such as scarves, bracelets, rings, etc., which could become
trapped or cause burns.
5. General precautions
SMake sure the return cable is connected securely.
SWork on high voltage equipment may only be carried out by a qualified electrician.
SAppropriate fire extinquishing equipment must be clearly marked and close at hand.
SLubrication and maintenance must not be carried out on the equipment during operation.
WARNING
Do not use the power source for thawing frozen pipes.
GB

© ESAB AB 2011
- 5 -
bc23de
WARNING
Read and understand the instruction manual before installing or operating.
Arc welding and cutting can be injurious to yourself and others. Take precautions when welding and
cutting. Ask for your employer's safety practices which should be based on manufacturers' hazard
data.
ELECTRIC SHOCK - Can kill
SInstall and earth the unit in accordance with applicable standards.
SDo not touch live electrical parts or electrodes with bare skin, wet gloves or wet clothing.
SInsulate yourself from earth and the workpiece.
SEnsure your working stance is safe.
FUMES AND GASES - Can be dangerous to health
SKeep your head out of the fumes.
SUse ventilation, extraction at the arc, or both, to take fumes and gases away from your breathing zone
and the general area.
ARC RAYS - Can injure eyes and burn skin.
SProtect your eyes and body. Use the correct welding screen and filter lens and wear protective
clothing.
SProtect bystanders with suitable screens or curtains.
FIRE HAZARD
SSparks (spatter) can cause fire. Make sure therefore that there are no inflammable materials nearby.
NOISE - Excessive noise can damage hearing
SProtect your ears. Use earmuffs or other hearing protection.
SWarn bystanders of the risk.
MALFUNCTION - Call for expert assistance in the event of malfunction.
PROTECT YOURSELF AND OTHERS!
CAUTION
Class A equipment is not intended for use in residential locations where
the electrical power is provided by the public low-voltage supply system.
There may be potential difficulties in ensuring electromagnetic
compatibility of class A equipment in those locations, due to conducted
as well as radiated disturbances.
CAUTION
Read and understand the instruction manual before
installing or operating.
CAUTION
This product is solely intended for arc welding.
GB

© ESAB AB 2011
- 6 -
bc23de
Dispose of electronic equipment at the recycling facility!
In observance of European Directive 2002/96/EC on Waste Electrical and Electronic
Equipment and its implementation in accordance with national law, electrical and/or
electronic equipment that has reached the end of its life must be disposed of at a
recycling facility.
As the person responsible for the equipment, it is your responsibility to obtain
information on approved collection stations.
For further information contact the nearest ESAB dealer.
ESAB can provide you with all necessary welding protection and accessories.
2 INTRODUCTION
The Mig C280 PRO and Mig C340 PRO are step controlled power sources in a
compact design, intended for welding with solid steel, stainless steel or aluminium
wire as well as cored wire with or without shielding gas.
The possibility of welding with homogeneous wire/shielding gas and welding with
gasless cored wire is obtained by switching the + and - connections on the switching
terminal above the wire feed unit.
The power sources comes in different variants, see page 25
ESAB's accessories for the product can be found on page 29.
2.1 Equipment
The power source Mig C280 PRO is supplied with:
SWelding gun PSF 250 - 3m ( Mig C280 PRO 4WD - 4,5m)
SReturn cable 3.5m with return clamp (Mig C280 PRO 4WD - 5m)
SShelf for gas cylinder
SInstruction manual
The power source Mig C340 PRO is supplied with:
SWelding gun PSF 305 - 3m (Mig C340 PRO 4WD - 4,5m)
SReturn cable 3.5m with return clamp (Mig C340 PRO 4WD - 5m)
SShelf for gas cylinder
SInstruction manual
GB

© ESAB AB 2011
- 7 -
bc23de
3 TECHNICAL DATA
Mig C280 PRO
Voltage 400-415 V, 3∼50/60 Hz
380V, 3∼50/60 Hz
230/400-415/500V, 3∼50Hz
230/440-460V, 3∼60Hz
Permissible load at
100% duty cycle 150 A/22 V 150 A/22 V
60 % duty cycle 190 A/24 V 190 A/24 V
30 % duty cycle 280 A/28 V 280 A/28 V
Setting range (DC) 30A/15V-280A/28V 30A/15V-280A/28V
Open circuit voltage 15-38 V 15-38 V
Open circuit power 190 W 190 W
Efficiency 69% 69%
Power factor 0.97 0.97
Control voltage 42 V, 50/60 Hz 42 V, 50/60 Hz
Wire feed speed 1,9 - 19m/min 1,9 - 19m/min
Burnback time 0 - 0,25s 0 - 0,25s
Spot welding 0,2 - 2,5s 0,2 - 2,5s
Welding gun connection EURO EURO
Dimensions LxWxH 840x425x830 840x425x830
Weight 91 kg 91 kg
Operating temperature -10 to +40°C -10 to +40°C
Transportation temperature -20 to +55°C -20 to +55°C
Enclosure class IP 23 IP 23
Application classification
Mig C340 PRO
Voltage 400-415 V, 3∼50/60 Hz
380V, 3∼50/60 Hz
230/400-415/500V, 3∼50Hz
230/440-460V, 3∼60Hz
Permissible load at
100% duty cycle 195 A/24 V 195 A/24 V
60 % duty cycle 250 A/27 V 250 A/27 V
30 % duty cycle 340 A/31 V 340 A/31 V
Setting range (DC) 40A/16V-340A/31V 40A/16V-340A/31V
Open circuit voltage 16-40 V 16-40 V
Open circuit power 240 W 240 W
Efficiency 77% 77%
Power factor 0.95 0.95
Control voltage 42 V, 50/60 Hz 42 V, 50/60 Hz
Wire feed speed 1,9 - 20m/min 1,9 - 20m/min
Burnback time 0 - 0,5s 0 - 0,5s
Creep start OFF / ON OFF / ON
GB

© ESAB AB 2011
- 8 -
bc23de
Mig C340 PRO
2/4 stroke 2 / 4 2 / 4
Welding gun connection EURO EURO
Dimensions LxWxH 840x425x830 840x425x830
Weight 114 kg 114 kg
Operating temperature -10 to +40°C -10 to +40°C
Transportation temperature -20 to +55°C -20 to +55°C
Enclosure class IP 23 IP 23
Application classification
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Equipment marked IP23 is designed for indoor and outdoor use.
Duty cycle
The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or cut at
a certain load without overloading. The duty cycle is valid for 40°C.
Application class
The symbol indicates that the power source is designed for use in areas with increased
electrical hazard.
4 INSTALLATION
The installation must be carried out by a professional.
CAUTION
This product is intended for industrial use. In a domestic environment this product may
cause radio interference. It is the user's responsibility to take adequate precautions.
4.1 Location
Position the welding power source in such a way that its cooling air inlets and outlets
are not obstructed.
GB

© ESAB AB 2011
- 9 -
bc23de
4.2 Assembly of components
WARNING
During transport, the rear wheels of the power source are in their forward position. Before
use, place the wheels in their rear position.
GB

© ESAB AB 2011
- 10 -
bc23de
4.3 Electrical installation
4.4 Mains power supply
Check that the unit is connected to the correct mains power supply voltage, and that
it is protected by the correct fuse size. A protective earth connection must be made,
in accordance with regulations.
Rating plate with supply connection data
GB

© ESAB AB 2011
- 11 -
bc23de
Recommended fuse sizes and minimum cable areas
Mig C280 PRO 3∼50 Hz 3∼50 Hz 3∼50/60 Hz 3∼50 Hz 3∼60 Hz 3∼60 Hz
Voltage V 230 380 400-415 500 230 440-460
Current A
at 100% duty cycle 13 87 5 11 7
at 60% duty cycle 18 11 10 8 18 10
at 30% duty cycle 32 19 18 15 32 17
at 30% duty cycle 4 x 2.5 4 x 1.5 4 x 1.5 4 x 1.5 4 x 2.5 4 x 1.5
Fuse slow A 20 16 16 16 20 16
Mig C340 PRO 3~50 Hz 3∼50 Hz 3~50/60 Hz 3~50 Hz 3~60 Hz 3~60 Hz
Voltage V 230 380 400-415 500 230 440-460
Current A
at 100% duty cycle 16 10 9 7 16 8
at 60% duty cycle 24 15 14 11 23 12
at 30% duty cycle 37 20 21 17 36 19
at 30% duty cycle 4 x 4 4 x 2.5 4 x 2.5 4 x 2.5 4 x 4 4 x 2.5
Fuse slow A 20 16 16 16 20 16
NOTE: The mains cable areas and fuse sizes as shown above are in accordance with Swedish
regulations. They may not be applicable in other countries: make sure that the cable area and fuse
sizes comply with the relevant national regulations.
5 OPERATION
General safety regulations for handling the equipment can be found on
page 4. Read through before you start using the equipment!
WARNING
Rotating parts can cause injury, take great care.
WARNING
To prevent the reel from sliding off the hub: Lock the
reel in place by turning the red knob as shown on the
warning label attached next to the hub.
WARNING
Secure the equipment - particularly if the
ground is uneven or sloping.
GB

© ESAB AB 2011
- 12 -
bc23de
5.1 Connection and control devices
1Mains supply switch 8Connection for return cable (-), low
inductance
2Switch, coarse control 9Knob for selecting - creep start - ON/OFF
3Switch, precise control 10 Knob for wire speed setting
4Indicating lamp, power supply ON 11 Knob for selecting 2/4-stroke control mode
5Orange indicator lamp, overheating 12 Knob for burn-back time setting
6EURO - connector (for welding gun) 13 Digital instrument - V / A
7Connection for return cable (-), high
inductance
14 Knob for spot welding - ON/OFF and time
setting
5.2 Overheating protection
A thermal overload cutout protects against overheating. The cutout resets automatically
when the unit has cooled.
5.3 Inductance connection
Higher inductance produces a more flowing weld and fewer spatters. Lower inductance
produces a harsher sound and a stable, concentrated arc.
GB

© ESAB AB 2011
- 13 -
bc23de
5.4 Polarity change
The power source is delivered with the welding wire connected to the plus pole.
Some wires, e.g self shielded cored wires, are recommended for welding with
negative polarity. Negative polarity means that the wire is connected to the minus
pole and the return cable to the plus pole.
Check the recommended polarity for the welding wire you want to use.
5.5 Wire feed pressure
Start by making sure that the wire moves smoothly through the wire guide. Then
set the pressure of the wire feeder's pressure rollers. It is important that the
pressure is not too great.
Fig 1 Fig 2
To check that the feed pressure is set correctly, you can feed out the wire against
an insulated object, e.g. a piece of wood.
When you hold the gun approx. 5 mm from the piece of wood (fig. 1) the feed
rollers should slip.
If you hold the gun approx. 50 mm from the piece of wood, the wire should be
fed out and bend (fig. 2).
ÏÏ
ÏÏ
ÏÏ
ÏÏ
ÏÏ
ÏÏ
ÏÏ
ÏÏ
ÏÏ
ÏÏ
ÏÏ
ÏÏ
GB

© ESAB AB 2011
- 14 -
bc23de
5.6 Replacing and inserting wire
SOpen the side panel.
SDisconnect the pressure sensor by folding it backwards, the pressure rollers
slide up.
SStraighten out 10-20 cm of new wire. File off any burrs and sharp edges from the
end of the wire before inserting it into the wire feed unit.
SMake sure that the wire goes properly into the feed roller track and into the outlet
nozzle and the wire guide.
SSecure the pressure sensor.
SClose the side panel.
6 MAINTENANCE
Regular maintenance is important for safe, reliable operation.
CAUTION
All guarantee undertakings from the supplier cease to apply if the customer attempts any
work to rectify any faults in the product during the guarantee period.
6.1 Inspection and cleaning
Power source
Check regularly that the power source is free from dirt.
The power source should be regularly blown clean using dry compressed air at reduced
pressure. This should be done more frequently in dirty environments.
Otherwise the air inlet/outlet may become blocked and cause overheating. To avoid
this you can use an airfilter.
The airfilter is an accessory. Order number can be found on page 29.
Welding gun
SThe welding gun's wear parts should be cleaned and replaced at regular
intervals in order to achieve trouble-free wire feed. Blow the wire guide clean
regularly and clean the contact tip.
The brake hub
The hub is adjusted when delivered, if
readjustment is required, follow the instructions
below. Adjust the brake hub so that wire is slightly
slack when wire feed stops.
SAdjusting the braking torque:
STurn the red handle to the locked position.
SInsert a screwdriver into the springs in the hub.
Turn the springs clockwise to reduce the braking torque
Turn the springs counter-clockwise to increase the braking torque. NB: Turn
both springs the same amount.
GB

© ESAB AB 2011
- 15 -
bc23de
7 FAULT TRACING
Try these recommended checks and inspections before sending for an authorised
service technican.
Type of fault Actions
No arc SCheck that the mains power supply switch is turned on.
SCheck that the welding current supply and return cables are
correctly connected.
SCheck that correct current value is set.
Welding current is interrupted
during welding
SCheck whether the thermal overload trip has operated
(indicated by the orange lamp on the front).
SCheck the main power supply fuses.
Thermal overload trips
operate frequently
SCheck to see whether the air filters are clogged.
SMake sure that you are not exceeding the rated data for the
power source (i.e. that the unit is not being overloaded).
Poor welding performance SCheck that the welding current supply and return cables are
correctly connected.
SCheck that the correct current value is set.
SCheck that the correct welding wires are being used.
SCheck the main power supply fuses.
SCheck the wire feed unit - if proper rolls are applied and
properly set the pressure of the wire feeder's pressure rollers
8 ORDERING OF SPARE PARTS
Repair and electrical work should be performed by an authorised ESAB service
technician. Use only ESAB original spare and wear parts.
Mig C280 PRO, Mig C340 PRO is designed and tested in accordance with the interna
tional and European standards 60974-1, 60974-5 and 60974-10 . It is the obligation of
the service unit which has carried out the service or repair work to make sure that the
product still conforms to the said standard.
Spare parts may be ordered through your nearest ESAB dealer, see the last page of
this publication.
GB

© ESAB AB 2011
Diagram
- 16 -
bc23e
Mig C280, 380-415V

© ESAB AB 2011
- 17 -
bc23e
Mig C280, 380-415V

© ESAB AB 2011
- 18 -
bc23e
Mig C280, 230-500V

© ESAB AB 2011
- 19 -
bc23e
Mig C280, 230-500V

© ESAB AB 2011
- 20 -
bc23e
Mig C340, 380-415V
