Esatto EWC34B User manual

User Mnul
Exctly wht
you need
Model Code/s:
EWC34B
Online:
esatto.house
Product:
34 Bottle Wine Cbinet
Version:
V1.0 0721

User Manual
2
Applinces
Exctly wht
you need

esatto.house
3
Page 4
Welcome
Page 5
General Safety
Instructions
Page 9
Product Overview
Page 10
Getting Started
Page 11
Installation
Instructions
Page 12
Operation
Instructions
Page 13
Bottle Arrangement
Page 14
Tips for Wine
Storage
Page 15
Maintenance and
Cleaning
Page 16
FAQs and
Troubleshooting
Page 17
Specication
Page 17
Purchase Details
Page 18
Warranty
Contents

User Manual
4
Welcome
Congratulations on purchasing your washing machine. The Esatto brand is proudly
distributed within Australia by Residentia Group Pty Ltd.
Please refer to the warranty card at the rear of this manual for information regarding
your product’s parts and labour warranty, or visit us online at: www.residentia.group
At Residentia Group, we are customer obsessed and our Support Team are there to ensure
you get the most out of your appliance. Should you want to learn more about
your washing machine such as the various washing modes or importantly taking care
of the appliance, our Support Team are here to help.
You can use our online Support Centre at anytime by visiting:
http://support.residentiagroup.com.au
Or you can contact us via phone by dialing: 1300 11 HELP (4357).
It is important that you read through the following use and care manual thoroughly to
familiarise yourself with the installation and operation requirements of your appliance
to ensure optimum performance.
Again, thank you for choosing an Esatto appliance and we look forward to being of service
to you.
Kind Regards,
The Residentia Team
Residentia Group
—
Head Office
165 Barkly Avenue
Burnley, Victoria
Australia 3121
—
ACN
600 546 656
—
Online
residentia.group
www.esatto.house
@esatto.house
—
Postage
PO Box 5177
Burnley, Victoria
Australia 3121
—
Telephone
1300 11 4357

esatto.house
5
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read this manual thoroughly before rst use, even if you are familiar with this type of product. The safety
precautions enclosed herein reduce the risk of re, electric shock and injury when correctly adhered to.
Make sure you understand all instructions and warnings.
Keep the manual in a safe place for future reference, along with the completed warranty card and purchase
receipt. If you sell or transfer ownership of this product, pass on these instructions to the new owner.
Always follow basic safety precautions and accident prevention measures when using an electrical
appliance, including the following:
IMPORTANT: Pay particular attention to messages that contain the words DANGER, WARNING or
CAUTION. These words are used to alert you to a potential hazard that can seriously injure you and others.
The instructions will tell you how to reduce the chance of injury and let you know what can happen if the
instructions are not followed.
CAUTION
RISK OF FIRE
This symbol alerts you to take care as this appliance contains a ammable
refrigerant (isobutane) and insulation blowing gas (cyclopentane).
Do not expose it to high heat, sparks and open ames.
The refrigerant isobutane (R600) is contained within the refrigerant circuit of
the appliance, a gas with a high level of environmental compatibility, which is
nevertheless ammable. During transportation and installation of the appliance,
ensure that none of the components of the refrigerant circuit become damaged.
WARNING: Do not damage the refrigerant circuit! Never use an appliance with a damaged refrigerant
circuit! If the refrigerant circuit becomes damaged, avoid proximity to open res and all types of heat and
ignition sources. Thoroughly ventilate the room in which the appliance is located.
DANGER: It is hazardous for anyone other than an authorised service person to service this appliance.
In Queensland, the authorised service person MUST hold a Gas Work Authorisation for hydrocarbon
refrigerants to carry out servicing or repairs which involve the removal of covers.
The room for installing the appliance must be at least 1m³ per 8g of refrigerant. The amount and type of
refrigerant in the appliance can be found in the Technical Specications section of this user manual and on
the rating plate, found on the appliance.
USAGE CONDITIONS AND RESTRICTIONS
• Domestic use only: This appliance is intended for indoor household use only. It is not intended for
commercial, industrial or outdoor use. It is not intended for use in a recreational vehicle.
• Purpose: Do not use this appliance for anything other than its intended purpose. Other uses are not
recommended and may cause re, electric shock or personal injury.
• Attachments: The use of attachments is not recommended by the appliance manufacturer and distributor
as they may be hazardous.
• Improper use: Damage due to improper use, or repairs made by unqualied personnel will void
your warranty. We assume no liability for any eventual damages caused by misuse of the product or
noncompliance with these instructions.
Generl Sfety Instructions

User Manual
6
• WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other
than those recommended by the manufacturer.
• Usage restriction: This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instructions concerning use of the appliance by a person responsible for their safety.
• Children: Supervise young children to ensure they do not play with the appliance. Never allow children to
operate, play with or crawl inside the appliance.
• WARNING: Do not use electrical appliances inside the appliance, unless they are of the type
recommended by the manufacturer.
• Explosive or ammable substances: Do not store explosive substances such as aerosol cans with a
ammable propellant in this appliance. Do not store or use petrol or any other ammable vapours and
liquids in the vicinity of this or any other appliance. Do not use such substances for cleaning the appliance.
The fumes can create a re hazard or an explosion.
• Damage: Do not use the appliance if the power cord, plug or the appliance itself is damaged. If the cord is
damaged, contact the after sales support line and have the cord replaced by qualied personnel in order
to avoid a hazard.
• WARNING: Do not damage the refrigerant circuit.
• Do not modify: Do not attempt to alter or modify this appliance in any way.
• Repair: Do not attempt to repair or replace any part of this appliance unless it is specically
recommended in this manual. All other servicing should be referred to a qualied technician. Contact the
after sales support line for advice.
• WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of
the appliance.
• Usage: The gaps between cooler door and cooler body are small, because not to jam your ngers in these
areas. Please be gentle when close or open the cooler door to avoid falling objects.
• Care: Do not use cooler body, cooler door, etc. as pedal or support
ELECTRICAL SAFETY
• Voltage: Before connecting and turning on the appliance, ensure the electrical voltage and circuit
frequency correspond to that indicated on the appliance rating label.
• Earthing: This appliance should be properly earthed for your safety. The power cord of this appliance is
equipped with a three-prong plug for use in standard wall outlets to minimise the possibility of electrical
shock. Do not modify the cord and/or plug provided with the appliance. Improper use of the earthed plug
can result in the risk of electric shock.
• Connection: This appliance requires a standard 220-240 V AC 50Hz electrical outlet. Do not overload the
electrical circuit.
• Power cord: Do not kink or damage the power cord; do not leave it exposed or dangling. Secure it at the
back of the appliance so no one steps on or places anything on the cord or against it. Keep the cord out of
reach of children. When moving the appliance, make sure not to damage the power cord. When removing
the power cord, rmly grasp the plug and pull out it from the socket directly.
• Auxiliary Items: Do not use an inverter, adaptor or extension cord with this appliance. If the cord is too
short, have a qualied electrician install an outlet near the appliance. Use of an extension cord and an
inverter can negatively aect the performance of the unit.
• Protect from moisture: To protect against the risk of electric shock, do not immerse the unit, cord or plug
in water or spray it with any other liquid. Do not connect or disconnect the electric plug when your hands
are wet. Turn the power switch o before removing the plug from the socket.
• WARNING: Disconnect! To reduce the risk of re, electric shock or personal injury, always unplug the
appliance from the socket when not in use, when moving and before cleaning or servicing. Never unplug
the unit by pulling the power cord. Always grip the plug rmly and pull straight out from the power point.
• Electrical work: Any electrical work required for the installation of this appliance should be carried out by
a qualied electrician.
Generl Sfety Instructions (Continued)

esatto.house
7
Never use this appliance with a damaged refrigerant circuit! If the coolant circuit becomes damaged, avoid
proximity to open res and all types of heat sources. The room in which the appliance is located should be
ventilated for a few minutes.
WARNING: Leaking Gas: In the case of leaking gas, turn o the valve of the leaking gas, open the doors and
windows in case of leakage of gas and other ammable gases. Do not unplug the cooler and other electrical
appliances considering that spark may cause a re.
INSTALLATION
Heavy: This appliance is heavy, take care when moving it. To avoid back or other injury, consider a two
person lift or mechanical aid when installing it. Failure to do so can result in back or other injury.
Damage: When unpacking, check the appliance carefully for damage. If it is damaged, do not install the
appliance. Contact our after sales support centre on 1300 11 43 57 for advice on examination or return of the
damaged appliance.
Protect from moisture: Install the appliance in an indoor area protected from wind, rain, water spray or drips.
Protect from heat: Do not install the appliance next to an oven, grill or other source of high heat, or where it
will be exposed to direct sunlight for prolonged periods of time.
WARNING: Ventilation: To ensure proper ventilation, keep any ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstructions. Ensure adequate air circulation around the
appliance to prevent overheating.
Level: Install the appliance level in order to ensure proper operation.
Location: To ensure safety, it is not recommended to place socket, regulators, rice cookers, microwave
ovens and other appliances at the top of the wine cooler, those recommended by the manufacturer are not
included. Do not use electrical appliances in the food pantry.
Children: Do not give package and other components to children to play. The bending board and plastic lm
may lead to suocation! Do not allow children to enter or climb the cooler to prevent that children are sealed
in the cooler or children are injured by the falling cooler.
CLEANING AND MAINTENANCE
Disconnect: Unplug the appliance before cleaning or servicing. Failure to do so can result in electric shock,
injury or death. Do not connect or disconnect the plug when your hands are wet.
Flames: Do not let open ames or ignition sources enter the appliance.
Flammable/explosive substances: Never clean this appliance with ammable uids. Do not store or use
volatile, ammable or explosive propellants or liquids in or close to this or any other appliance. The fumes
can create a re hazard or explosion.
Washing: Do not spray or wash the cooler; do not put the cooler in moist places easy to be splashed with
water so as not to aect the electrical insulation properties of the cooler.
Solvents: Do not use solvent based cleaning agents or abrasives on the interior as these may damage or
discolour the surfaces of the appliances.
WARNING! Do not use mechanical devices or other means to accelerate the defrosting process. Never use a
sharp or metal instrument to remove frost or clean the appliance. Use a plastic scraper, if necessary.
Service: Do not attempt to repair, modify or replace any part of the appliance unless specically
recommended in this manual. Refer all other servicing to a qualied technician, or contact the after sales
support line for advice on examination or repair of the appliance.

User Manual
8
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such
waste separately for special treatment is necessary.
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return and collection systems
or contact the retailer where the product was purchased. They can take this product for
environmental
safe recycling.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local city oce, your household waste disposal service or the shop where you
purchased the product.
WARNINGS RELATED TO PLACING ITEMS
• Objects: Do not place heavy objects on the top of the cooler considering that objects may fall when open
or close the door, and accidental injuries might be caused.
• Items in the cooler: Do not put ammable, explosive, volatile and highly corrosive items in the cooler to
prevent damages to the product or re accidents.
• Flammable items: Do not place ammable items near the cooler to avoid res.
• Usage: This product is household cooler and this equipment can only be used for the storage of wine.
According to the standard requirements, household cooler shall not be used for other purposes, such as
storage of blood, drugs or biological products.
ENERGY WARNINGS
• Wine cooler might not operate consistently when siled for an extended period of time below the cold end
of the range of temperatures for which the cooler appliance is designed.
• The need to not exceed the storage time(s) recommended by the wine manufacturers for any kind
of wine.
• The precautions necessary to prevent an undue rise in the temperature of the wine while defrosting the
wine cooler.
• The fact that a rise in temperature of the wine during manual defrosting, maintenance or cleaning could
shorten the storage life.
• The necessity that, for doors or lids tted with locks and keys, the keys be kept out of the reach of
children and not in the vicinity of the cooler appliance, in order to prevent children from being
locking inside.
RESPONSIBLE DISPOSAL
Note: At the end of its working life, do not throw this appliance out with your household rubbish. Electrical
and electronic products contain substances that can have a detrimental eect on the environment and
human health if disposed of inappropriately. Observe any local regulations regarding the disposal of
electrical consumer goods and dispose of it appropriately for recycling and recovery of the refrigerant and
blowing agent. Contact your municipal authorities for advice on recycling facilities in your area. When the
wine cooler is scrapped, disassemble the doors, and remove gasket of door and shelves; put the doors and
shelves in a proper place, so as to prevent entrapment of any children.
WARNING! This refrigeration appliance contains ammable refrigerants and insulation blowing gases,
which must be removed before disposal. Contact your municipal authorities for any codes or regulations
concerning the disposal of such materials.
Generl Sfety Instructions (Continued)

esatto.house
9
4
5
6
7
1. Cabinet exterior
2. Door hinge cover
3. Temperature control panel
4. Wooden shelves (6)
5. Water tray
6. Chrome storage basket (1)
7. Adjustable feet
8. Double glazed tinted glass door
9. Light switch
10. Child lock
Not shown but also included:
°1 × Instruction manual
°1 × Quick start guide
Key:
8
3
2
1
Note: The images in this user manual are for reference only. Your appliance may appear dierently.
WINE CABINET LAYOUT
9
10
Product Overview

User Manual
10
UNPACKING
• Packaging materials: This appliance has been packaged to protect it against transportation damage.
Remove all packaging materials from around and inside the appliance including the bottom cushions,
foam pads, tapes inside the cooler, tear o the protective lm on the door and the cooler body. Keep the
original packaging carton and materials in a safe place. It will help prevent any damage if the product
needs to be transported in the future, and you can use it to store the appliance when it is not in use. In the
event the carton is to be disposed of, please recycle all packaging materials where possible.
• Check: to see if all items are present.
• Inspect: the equipment and accessories for transport damage. In case of complaints, the supplier is to be
informed immediately.
• Suocation: Plastic wrapping can be a suocation hazard for babies and young children, so ensure all
packaging materials are out of their reach and disposed of safely.
• Power cord: Unwind the power cord to its full length and inspect it for damage. Do not use the appliance
if it or its cord have been damaged or are not working properly. In case of damage, contact our after sales
support line for advice on examination, repair or return of the damaged product.
• Read the manual: Read this manual to familiarise yourself with the appliance. Pay particular attention to
the safety instructions on the previous pages.
• Clean: To remove any dust from transit and storage, clean the interior and exterior surfaces of the
appliance with lukewarm water and a soft cloth. Dry thoroughly. Important: do not use harsh or abrasive
detergents or powders as these will damage the nish.
FIRST USE
Before turning on your wine cooler for the rst time:
• The cooler must be rested for at least half an hour before connecting power.
• Clean up the inner chamber .
• Do not connect cooler to electronic energy saving plug and converter that can convert DC into AC
(E.g.: solar energy system. ship grid).
• Water drop or frost will be generated on back side of wine cooler when compressor is running.
This is a normal function of cooler, wiping out frost or water drop is not required as they will evaporate
automatically. The defrosted water will be collected into drain tank and then inow into water disposal
pan above the compressor and vaporized.
Getting Strted
