ESCO Technologies ETS-Lindgren 3165-01 User manual

Models 3165-01, 3165-02, 3165-04
Dual-Polarized Dual-Vivaldi
Array Antenna
User Manual
Model 3165-01-SQ
Model 3165-02-MG
Model 3165-04

ii www.ets-lindgren.com
ETS-Lindgren Inc. reserves the right to make changes to any product described
herein in order to improve function, design, or for any other reason. Nothing
contained herein shall constitute ETS-Lindgren Inc. assuming any liability
whatsoever arising out of the application or use of any product or circuit
described herein. ETS-Lindgren Inc. does not convey any license under its
patent rights or the rights of others.
© Copyright 2011–2020 by ETS-Lindgren Inc. All Rights Reserved. No part
of this document may be copied by any means without written permission
from ETS-Lindgren Inc.
Trademarks used in this document: The ETS-Lindgren logo is a trademark of
ETS-Lindgren Inc.; WiMAX is a trademark of the WiMAX Forum.
Revision Record | MANUAL,3165-01/3165-02 | Part # 399322, Rev. C
Revision Description Date
A Initial Release January, 2011
B Added Model 3165-02 content October, 2013
C Added Model 3165-04 content November, 2020

www.ets-lindgren.com iii
Table of Contents
Notes, Cautions, and Warnings................................................ v
1.0 Introduction .......................................................................... 7
Model 3165-01...............................................................................................8
Model 3165-02...............................................................................................8
Model 3165-04...............................................................................................8
Mounting Options...........................................................................................9
3165-01-MG / 3165-02-MG ...................................................................9
3165-01-SQ / 3165-02-SQ...................................................................10
3165-01-RD / 3165-02-RD...................................................................10
ETS-Lindgren Product Information Bulletin .................................................11
2.0 Maintenance ....................................................................... 13
Annual Calibration .......................................................................................13
Replacement and Optional Parts.................................................................14
Service Procedures .....................................................................................14
3.0 Specifications..................................................................... 15
Electrical Specifications ...............................................................................15
Physical Specifications ................................................................................15
3165-01 Series ....................................................................................15
3165-02 Series ....................................................................................16
3165-04 Series ....................................................................................17
4.0 3165-01 Typical Data.......................................................... 18
3165-01 Typical Gain...................................................................................18
3165-01 Typical VSWR ...............................................................................19
3165-01 Typical Cross-Port Isolation...........................................................20
3165-01 Typical Reflectivity.........................................................................21
3165-01 Typical E-Plane .............................................................................22
3165-01 Typical H-Plane .............................................................................23
5.0 3165-02 Typical Data.......................................................... 24
3165-02 Typical Gain...................................................................................24
3165-02 Typical VSWR ...............................................................................25
3165-02 Typical Cross-Port Isolation...........................................................26

iv www.ets-lindgren.com
3165-02 Typical Radiation Patterns.............................................................27
3165-02 at 400 MHz and 500MHz.......................................................27
3165-02 at 600 MHz and 700 MHz......................................................28
3165-02 at 800 MHz and 900 MHz......................................................29
3165-02 at 1000 MHz and 1250 MHz..................................................30
3165-02 at 1500 MHz and 1750 MHz..................................................31
3165-02 at 2000 MHz and 2500 MHz..................................................32
3165-02 at 3000 MHz and 3500 MHz..................................................33
3165-02 at 4000 MHz and 4500 MHz..................................................34
3165-02 at 5000 MHz and 6000 MHz..................................................35
6.0 3165-04 Typical Data.......................................................... 36
3165-04 Typical Gain...................................................................................36
3165-04 Typical VSWR ...............................................................................37
3165-04 Cross Pol .......................................................................................38
3165-04 Typical Radiation Patterns.............................................................39
3165-04 at 600 MHz and 1000MHz.....................................................39
3165-04 at 1500 MHz and 2000MHz...................................................40
3165-04 at 2500 MHz and 3000MHz...................................................41
3165-04 at 3500 MHz and 4000MHz...................................................42
3165-04 at 4500 MHz and 5000MHz...................................................43
3165-04 at 5500 MHz and 6000MHz...................................................44
3165-04 at 6500 MHz and 7000MHz...................................................45
3165-04 at 7500 MHz and 8000MHz...................................................46
3165-04 at 8500 MHz and 9000MHz...................................................47
3165-04 at 9500 MHz and 10000MHz.................................................48

www.ets-lindgren.com v
Notes, Cautions, and Warnings
Note: Denotes helpful information intended to
provide tips for better use of the product.
Caution: Denotes a hazard. Failure to follow
instructions could result in minor personal injury
and/or property damage. Included text gives proper
procedures.
Warning: Denotes a hazard. Failure to follow
instructions could result in SEVERE personal injury
and/or property damage. Included text gives proper
procedures.
See the ETS-Lindgren Product Information Bulletin for safety,
regulatory, and other product marking information.

vi www.ets-lindgren.com
This page intentionally left blank.

www.ets-lindgren.com Introduction 7
1.0 Introduction
The ETS-Lindgren 3165 Series
Absorber Nested Dual-Polarized
Dual-Vivaldi Array Antenna is
designed for applications that require
minimum effect from the source
antenna, such as in chambers where
the Equipment Under Test (EUT) is
illuminated from different directions.
Model 3165-01-SQ
Each antenna in the 3165 Series is dual-linearly polarized and capable of
simultaneously measuring two orthogonal components in the field.
The 3165 Series possesses low VSWR
while maintaining high directivity. This
allows use in the illumination of the EUT
without affecting adjacent antennas in a
multi-antenna installation.
Model 3165-02-MG

8Introduction www.ets-lindgren.com
Model 3165-01
The Model 3165-01 has a frequency range of 700 MHz to 6 GHz, which covers
most cell phone, Wi-Fi, WiMAX™, and GPS bands. It is designed to be nested in
the anechoic absorber lining of a chamber, and when installed in this
configuration, will exhibit very low reflectivity, even when the input ports are
mismatched. The normal incidence reflectivity is approximately -40 dB for a
majority of the frequency range.
Model 3165-02
The Model 3165-02 has a frequency range of 400 MHz to 6 GHz, although it is
usable to 7 GHz. The VSWR is less than 3:1 for more than 90% of the range.
The 3165-02 exhibits positive gain from around 500 MHz and above, reaching
gain levels of over 8 dBi above 2 GHz; the difference in gain between the two
ports is extremely small (less than 0.25 dB for over 90% of the range).
Model 3165-04
The Model 3165-04 has a frequency range of 600 MHz to 10 GHz, which covers
most cell phone, Wi-Fi, WiMAX™, and GPS bands.

www.ets-lindgren.com Introduction 9
Mounting Options
Following are the mounting options available for the 3165-01/3165-02/3165-04;
for more information on mounting, contact ETS-Lindgren Sales.
3165-01-MG / 3165-02-MG/3165-04
The MG Series allows you to
magnetically attach the antenna to a
positioning system, existing bracket, or
shielding.
3165-01-MG
3165-02-MG
3165-04

10 Introduction www.ets-lindgren.com
3165-01-SQ / 3165-02-SQ
The SQ Series includes brackets that allow you to manually adjust the pan and
tilt of the antenna. These brackets mount to a 50-mm square tube.
3165-01-SQ
3165-02-SQ
3165-01-RD / 3165-02-RD
The RD Series includes a fixture
that allows you to manually adjust
the pan and tilt of the antenna.
The fixture is designed to be
attached to a 50-mm (diameter)
round tube.
3165-02-RD

www.ets-lindgren.com Introduction 11
ETS-Lindgren Product Information Bulletin
See the ETS-Lindgren Product Information Bulletin included with your shipment
for the following:
Safety, regulatory, and other product marking information
Steps to receive your shipment
Steps to return a component for service
ETS-Lindgren calibration service
ETS-Lindgren contact information

12 Introduction www.ets-lindgren.com
This page intentionally left blank.

www.ets-lindgren.com Maintenance 13
2.0 Maintenance
Before performing any maintenance,
follow the safety information in the
ETS-Lindgren Product Information
Bulletin included with your shipment.
Maintenance of the 3165-01/3165-02 is
limited to external components such as
cables or connectors.
If you have any questions concerning
maintenance, contact ETS-Lindgren
Customer Service.
Annual Calibration
See the Product Information Bulletin included with your shipment for information
on ETS-Lindgren calibration services.
WARRANTY

14 Maintenance www.ets-lindgren.com
Replacement and Optional Parts
ETS-Lindgren may substitute a similar part or new part number with
the same functionality for another part/part number. Contact
ETS-Lindgren for questions about part numbers and ordering parts.
Following are the part numbers for ordering replacement or optional parts for the
3165 Series Absorber Nested Dual-Polarized Dual-Vivaldi Array Antenna.
Part Number
Part Description 3165-01 3165-02 3165-04
Magnetic Attachment
Mounting Option
3165-01-MG 3165-02-MG 3165-02-MG
Pan and Tilt Manual
Adjustment Brackets
(50-mm Square Tube
Mounting Option)
3165-01-SQ 3165-02-SQ 3165-02-SQ
Pan and Tilt Manual
Adjustment Fixture
(50-mm Round Tube
Mounting Option)
3165-01-RD 3165-01-RD 3165-01-RD
Service Procedures
For the steps to return a system or system component to ETS-Lindgren for
service, see the Product Information Bulletin included with your shipment.

www.ets-lindgren.com Specifications 15
3.0 Specifications
Electrical Specifications
Model 3165-01 Model 3165-02 Model 3165-04
Frequency
Range:
700 MHz–6 GHz 400 MHz–7 GHz 700 MHz-10 GHz
Cross
Polarization
Isolation:
>25 dB
Maximum
Continuous
Power:
5 Watts
Impedance
(Nominal): 50 Ω
Connectors: SMA female (2)
Physical Specifications
3165-01 SERIES
3165-01-MG 3165-01-SQ 3165-01-RD
Length: 19.0 cm
7.5 in
36.3 cm
14.3 in
36.3 cm
14.3 in
Aperture
Height:
17.8 cm
7.0 in
35.5 cm
14.0 in
35.5 cm
14.0 in
Aperture
Width:
17.8 cm
7.0 in
35.5 cm
14.0 in
35.5 cm
14.0 in
Weight: 1.3 kg
2.9 lb
2.6 kg
5.8 lb
2.6 kg
5.8 lb

16 Specifications www.ets-lindgren.com
3165-02 SERIES
3165-02-MG
3165-02-SQ
(with absorber
and mounting
bracket)
3165-02-RD
(with absorber
and mounting
bracket)
LENGTH No Absorber:
25 cm (9.8 in)
With Absorber:
42 cm (18.5 in)
58 cm (22.8 in) 66 cm (26 in)
HEIGHT No Absorber:
24 cm (9.4 in)
With Absorber:
27 cm (10.6 in)
27 cm (10.6 in) 27 cm (10.6 in)
WIDTH: No Absorber:
24 cm (9.4 in)
With Absorber:
27 cm (10.6 in)
27 cm (10.6 in) 27 cm (10.6 in)
WEIGHT 1.3 kg (2.9 lb) 2.6 kg (5.8 lb) 2.6 kg (5.8 lb)

www.ets-lindgren.com Specifications 17
3165-04 SERIES
3165-04
3165-04
(with absorber
and mounting
bracket)
LENGTH No Absorber:
17.1 cm (6.75 in)
With Absorber:
27.2 cm (10.72 in)
21.3 cm (8.4 in)
HEIGHT No Absorber:
26.5 cm (10.45 in)
With Absorber:
40.6 cm (16.0 in)
31.2 cm (12.25 in)
WIDTH: No Absorber:
17.1 cm (6.75 in)
With Absorber:
27.9 cm (11.0 in)
22.1 cm(8.7 in)
WEIGHT 0.86 kg (1.9 lb) 1.4 kg (3.0 lb)

18 3165-01 Typical Data www.ets-lindgren.com
4.0 3165-01 Typical Data
3165-01 Typical Gain

www.ets-lindgren.com 3165-01 Typical Data 19
3165-01 Typical VSWR

20 3165-01 Typical Data www.ets-lindgren.com
3165-01 Typical Cross-Port Isolation
