Esonic BR-25 User manual
User Manual
MODEL No. : BR-25
1. Charging before use
Please charge by using USB or DC adaptor(optional).
Charging : The motion LED alternates between a green light and a red light.
Charging complete : Motion LED turns off.
Check ! The remaining battery can be checked by pressing and holding the VOL+,- key while waiting for
playback or recording..
Battery remains
Operation
Enough : 70 ~ 100%
Green LED is turned on for 5 seconds
Usual : 30 ~ 70 %
Green LED blinks for 5 seconds
Short : less than 30%
No indication
2. Turning on power
1) Connecting to bluetooth device(pairing)
A. For pairing, mobile device starts Bluetooth search.
B. Move the mode switch to Bluetooth.
C. Press the Talk/Power button until the blue LED flashes rapidly. (5 seconds)
D. Select BR-25 which mobile device has searched.
Function
Operation
Power On/Off
Until blue LED is turned on/of, press the button of talk/power for 1
second.
Answering/ending call
Press the button of talk/power.
Rejecting talk
Press the button of talk/power two times rapidly.
Adjusting volume
Press the button of volume + or -on the side during call or playback.
2) Recording call
A. Pair with mobile device by pressing the button of talk/power. (refer to “Connecting to bluetooth
device”)
B. Move the mode switch to Bluetooth.
C. When you receive a call or make a call, recording starts automatically and recording ends when call is
finished.
D. Motion LED is turned on in red during recording.
Caution ! In case talking time is less than 10 seconds, recording might not start.
3) General recording
A. Move mode switch to recording.
B. To turn on the power, press and hold the Talk/Power button until it vibrates.
C. After showing current battery remains, the Motion LED lights up red and recording starts.
D. Press and hold the Talk/Power button to end recording and turn off power.
4) Playing back
A. Move mode switch to VOICE playback (⊙)
B. To turn on the power, press and hold the Talk/Power button until it vibrates.
C. Press the PLAY/STOP(▶/■) button.
D. Play the recorded file if it exists..
E. During playback, it is possible to move files by pressing the button of previous file(◁◁) or next
file(▷▷).
F. Press the PLAY/STOP(▶/■) button again to stop.
5) Connecting to a PC
A. Remove the product's L-channel (left) earphone and connect the USB cable to the terminal..
B. Connect the opposite cable to your PC.
C. Connect to your PC as a removable disk.
D. Removable disk ->VOICE folder contains recorded files and can be played and deleted.
Caution ! Deleted files can not be recovered. Delete the files after checking them carefully.
3. Name of each part
Motion LED
Talk/Power
Mike
Mode Switch
↑Bluetooth
⊙VOICE playback
↓Recording
Right Earphone
Left Earphone
, USB Terminal
+Next File, Volume+
▷Play
-Previous File,
Volume -
4. Specification
Model No.
BR-25
Bluetooth version
V 4.0
Supported profiles
HFP, HSP, A2DP
Usage Distance
Max. 10m
Range of frequency
2402-2480 MHz
Recording a call/Standby time
about 10 hours / about 25 days
General recording time
XHQ about 25 hours / HQ about 30 hours
Charging time
about 2.5 hours
Rechargeable Battery
230mAh Lithium Polymer
5. Cautions
1) In case there are no battery remains, recording is not possible. Please use it after charging all the time.
2) If you remove it from PC in using, contents could be lost and please be sure to use the USB safety
removal.
3) Please undergo a backup for the files saved in internal memory all the time.
FCC notice to users and product statements
European CE notice to users and product statements
A/S TEL : 070-4015-7114~6
Address : 2fl., 10-19, 166 beongil, LS-ro, Gunpo-si, Gyeonggi-do, Korea 15807
Homepage : http://www.esonic.co.kr
Caution : Any changes or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user's authority
to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must
accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, any cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Caution
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
