Esprit 728 Ultra & 738 Ultra - 1 - Programming Guide
System Programming Guide
Software Versions 4.4 (728ULT) and 4.1 (738ULT)
Installer Code (Default - 728 Ultra: 282828; 738 Ultra: 383838)
Full access to programming, except user access codes (PINs). No access to arming/disarming. Use only numeric keys from [0] to [9].
Zone Recognition
Streamlined Section Programming
This is an alternate method to Hex Programming (see page 2). Addresses 000 to 043 and 300 to 527 are grouped into 68 sections where
each section contains four addresses (i.e. section 00 = addresses 000 to 003). Using this method allows you to program 8 digits
(4 addresses) without having to exit and re-enter addresses.
The keypad will not display the current data in the Streamlined Section Programming method.
Table 1: Zone Recognition
Device connected to which input? 728 Ultra
No ATZ 728 Ultra With ATZ 738 Ultra No ATZ 738 Ultra With ATZ
Control Panel
Input 1 = Zone 1 Zones 1 & 2 Zone 1 Zones 1 & 9
Input 2 = Zone 2 Zones 3 & 4 Zone 2 Zones 2 & 10
Input 3 = Zone 3 Zones 5 & 6 Zone 3 Zones 3 & 11
Input 4 = Zone 4 Zones 7 & 8 Zone 4 Zones 4 & 12
Input 5 = N/A N/A Zone 5 Zones 5 & 13
Input 6 = N/A N/A Zone 6 Zones 6 & 14
Input 7 = N/A N/A Zone 7 Zones 7 & 15
Input 8 = N/A N/A Zone 8 Zones 8 & 16
Keypad
Zone 1 = Zone 5 Zone 9 Zone 9 Zone 17
Zone 2 = Zone 6 Zone 10 Zone 10 Zone 18
Table 2: Streamlined Section Programming Method
1. Press [ENTER]+ [INSTALLER CODE](Default - 728 Ultra: 282828; 738 Ultra: 383838) + [7].
2. The [ENTER]and [2ND]keys will flash to indicate you are in programming mode (LED keypad only).
3. Enter 2-digit [SECTION](00 to 67).
4. The [ENTER]key will remain on while the [2ND]key will be off (LED keypad only).
5. Enter 8-digit [DATA]to program the section.
6. The keypad will beep to indicate that the section has been programmed, data is saved and the
software has advanced to the next section.
7. Return to step 4 or press [CLEAR]to exit programming mode.
&

Esprit 728 Ultra & 738 Ultra - 2 - Programming Guide
Keypad Trouble Display
Press the [TBL]/[TRBL]key to view the trouble. Any illuminated keys represent a specific trouble as indicated in Table 3 below. Press the
[CLEAR]button to exit the trouble display.
Hex Programming
This is an alternate method to the Streamlined Section Programming (see page 1). Addresses 000 to 043 and 300 to 527 can be
programmed using the Hex Programming method. In this mode, you can enter any hexadecimal digit from 0 to F where keys [1] to [9]
represent digits 1 to 9 respectively; the other keys represent hexadecimal digits A to F as shown in Figure 1 below.
Figure 1: Hex Digit Data Entry and Data Display for LED Keypads
Table 3: Trouble Display
[1] - No Battery or Low Voltage [7] - Communicator Report Failure
[2] - Power Failure [8] - Timer Loss* (to clear, see [MEM]key in
Table 11 on page 11)
[4] - Bell Output Disconnected [9] - Tamper or Zone Wiring Failure
[5] - Exceeded Maximum Bell Current [10] - Telephone Line Monitoring Failure
[6] - Exceeded Maximum Auxiliary Current [11] - Fire Loop Trouble
Table 4: Hex Programming Method
1. Press [ENTER]+ [INSTALLER CODE](Default - 728 Ultra: 282828; 738 Ultra: 383838).
2. The [ENTER]key will flash indicating you are in programming mode (LED keypad only).
3. Enter the desired 3-digit [ADDRESS].
4. The keypad will display the 2-digit data currently saved at this address as described in Figure 1 below.
5. Enter 2-digit [DATA]and do not press [ENTER], the software automatically saves the data.
6. Return to step 2 or press [CLEAR]to exit programming mode.
Therefore 2-digit data = 7A
= First digit = 4 + 2 + 1 = 7
= Second digit = 8 + 2 = 10
Note: Values 10 to 15 represent hex digits A to F respectively. See keypad to the left.
Each key in the first 2 rows of the keypad represents a specific value when the key is lit, as
shown above. If the key isn’t lit, the key represents 0. The sum of the values of the lit keys in
the first row correspond to the second hex digit. The sum of the values of the lit keys in the
second row correspond to the first hex digit as shown in the example below.
Sum of the second row = first hex digit
Sum of the first row = second hex digit
If the key is not lit, value = 0
Note: LCD keypads will display current data on the screen.

Esprit 728 Ultra & 738 Ultra - 3 - Programming Guide
INSTALLER / Panel Answer Options
Telephone and Account Numbers
If only one monitoring station phone number is used, program the same number for telephone numbers 1 and 2. If only one account
number is required, the same number must be entered for both accounts "A" and "B".
[0] to [9] = numeric value [BYP]= switch from pulse to tone while dialing
[STAY]= * [MEM]= pause 4 seconds
[AWAY]/[FORCE]= # [TBL]/[TRBL]= end of number
Streamline Section Data
Description Address Answering Machine Override
___ / ___ Installer code (1st, 2nd digit) 000 [2ND]or [1] = disabled [5] = 40 seconds
___ / ___ Installer code (3rd, 4th digit) 001 [2] = 16 seconds [6] = 48 seconds
___ / ___ Installer code (5th, 6th digit) 002 [3] = 24 seconds [7] = 56 seconds
___ / ___ Panel answer options 003 [4] = 32 seconds [8] to [F] = 60 seconds
Number of rings (Max. 15)
Streamline Section Data Description Address
___ / ___ Panel Identifier (1st, 2nd digit) 004
___ / ___ Panel Identifier (3rd, 4th digit) 005
___ / ___ PC Password (1st, 2nd digit) 006
___ / ___ PC Password (3rd, 4th digit) 007
Computer Telephone Number (View at addresses 008 to 015 )
Streamline Section Streamline Section Press the [TBL]/[TRBL]
key to end phone
number if less than 16
digits are programmed.
02 __/__/__/__/__/__/__/__ 03 __/__/__/__/__/__/__/__
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Monitoring Station Telephone Number 1 (View at addresses 016 to 023 )
Streamline Section Streamline Section Press the [TBL]/[TRBL]
key to end phone
number if less than 16
digits are programmed.
04 __/__/__/__/__/__/__/__ 05 __/__/__/__/__/__/__/__
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Monitoring Station Telephone Number 2 (View at addresses 024 to 031 )
Streamline Section Streamline Section Press the [TBL]/[TRBL]
key to end phone
number if less than 16
digits are programmed.
06 __/__/__/__/__/__/__/__ 07 __/__/__/__/__/__/__/__
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Accounts “A” and “B” (View at addresses 032 to 035)
Streamline Section For 3-digit account
numbers, enter “skip”
([2ND]) as first digit.
The Standard Pulse
report format can
support 3- or 4-digit
account numbers.
The Ademco Express,
Ademco Contact ID
and the Pager report
formats only support 4-
digit account numbers.
08 __/__/__/__ __/__/__/__
1234 5678
AB
00
01 {Identifies the control panel to the PC.
{Identifies the PC to the control panel.
First digit disables “Answering Machine Override”
(key [2ND]or key [1]), or determines period of time
between first and second call. Second digit
determines number of rings required before panel
will answer. If [2ND][2ND]is entered, panel will not
answer (Default value is [2ND] [8]).

Esprit 728 Ultra & 738 Ultra - 4 - Programming Guide
Streamline Section Data Description Address
[2ND] / [2ND]Future Use 036
___ / ___ 1st digit: Pager Delay (see table at right)
2nd digit: Timecorrection (see table at right) 037
___ / ___ 1st digit: Communicator Format 1
2nd digit: Communicator Format 2 038
___ / ___ 1st digit: PGM1 type
2nd digit: PGM2 type (738 Ultra only) 039
Streamline Section Data
Description Address
___ / ___ PGM1 040
___ / ___ PGM2 (738 Ultra only) 041
___ / ___ PGM Mask 1 042
___ / ___ PGM Mask 2 (738 Ultra only) 043
Communicator Formats (* = supports 4-digit account codes only)
Key Key
[2ND]= ADEMCO slow (1400Hz, 1900Hz, 10bps) [6] = RADIONICS with PARITY (1400Hz, 40bps)
[1] = (1400Hz, 1800Hz, 10bps) [7] = RADIONICS with PARITY (2300Hz, 40bps)
[2] = SILENT KNIGHT fast (1400Hz, 1900Hz, 20bps) [8] = * ADEMCO express
[3] = SESCOA (2300Hz, 1800Hz, 20bps) [9] = * ADEMCO contact ID (programmable codes)
[4] = RADIONICS (40bps with 1400Hz handshake) [0] = * ADEMCO contact ID (all codes)
[5] = RADIONICS (40bps with 2300Hz handshake) [TBL] / [TRBL]= * PAGER FORMAT (personal dialing)
Programmable Contact ID Event Codes
All addresses from 300 to 527 (sections 11 to 67) programmed with values other than [2ND][2ND]will report the contact ID codes corresponding to the
values programmed. Values to be programmed should be selected from this table.
CID Reporting Code Prog. Value CID Reporting Code Prog. Value
100: AUXILIARY ALARM [2ND] / [1] 300: SYSTEM TROUBLE [2] / [2]
110: FIRE ALARM [2ND] / [2] 301: AC LOSS [2] / [3]
111: FIRE SMOKE [2ND] / [3] 302: LOW SYSTEM BATTERY [2] / [4]
112: COMBUSTION [2ND] / [4] 305: SYSTEM RESET [2] / [5]
113: WATER FLOW [2ND] / [5] 306: PROGRAM CHANGED [2] / [6]
114: HEAT [2ND] / [6] 309: BATTERY TEST FAIL [2] / [7]
115: PULLSTATION [2ND] / [7] 320: SOUNDER/RELAY TROUBLE [2] / [8]
116: DUCT [2ND] / [8] 321: BELL 1 TROUBLE [2] / [9]
117: FLAME [2ND] / [9] 323: ALARM RELAY TROUBLE [2] / [0]
118: NEAR ALARM [2ND] / [0] 350: COMMUNICATION TROUBLE [2] / [STAY]
120: PANIC ALARM [2ND] / [STAY]351: TELCO 1 FAULT [2ND] / [AWAY] OR [FORCE]
121: DURESS [2ND] / [AWAY] OR [FORCE]354: FAIL TO COMMUNICATE [2] / [BYP]
122: SILENT PANIC [2ND] / [BYP]370: PROTECTION LOOP TROUBLE [2] / [MEM]
123: AUDIBLE PANIC [2ND] / [MEM]371:
P ROTECTION L OOP O PEN [2] / [TRBL]
130: BURGLARY [2ND] / [TRBL]372: PROTECTION LOOP SHORT [3] / [2ND]
131: PERIMETER BURGLARY [1] / [2ND]373: FIRE LOOP TROUBLE [3] / [1]
132: INTERIOR BURGLARY [1] / [1] 382: SENSOR TROUBLE [3] / [2]
133: 24HRBURGLARY [1] / [2] 383: SENSOR TAMPER [3] / [3]
136: BURGLARY OUTDOOR [1] / [3] 400: OPEN / CLOSE [3] / [4]
137: BURGLARY TAMPER [1] / [4] 401: OPEN / CLOSE BY USER # [3] / [5]
138: BURGLARY NEAR ALARM [1] / [5] 402: GROUP OPEN / CLOSE [3] / [6]
140: GENERAL ALARM [1] / [6] 403: AUTOMATIC OPENING / CLOSING [3] / [7]
150: 24 HOUR AUXILIARY [1] / [7] 404: LATE TO OPEN / CLOSE [3] / [8]
151: GAS DETECTED [1] / [8] 407: REMOTE ARM DOWNLOAD [3] / [9]
152: REFRIGERATION [1] / [9] 410: REMOTE ACCESS [3] / [0]
153: LOSS OF HEAT [1] / [0] 441: OPEN / CLOSE - STAY MODE [3] / [STAY]
154: WATER LEAKAGE [1] / [STAY]570: BYPASS [3] / [AWAY] OR [FORCE]
155: FOIL BREAK ALARM [1] / [AWAY] OR [FORCE]572: 24 HOUR ZONE BYPASS [3] / [BYP]
156: DAY TROUBLE ALARM [1] / [BYP]573: BURGLARY BYPASS # [3] / [MEM]
157: LOW GAS LEVEL [1] / [MEM]574: GROUP BYPASS [3] / [TRBL]
158: HIGH TEMPERATURE [1] / [TRBL]601: MANUAL TEST [4] / [2ND]
159: LOW TEMPERATURE [2] / [2ND]602: PERIODIC TEST [4] / [1]
161: LOSS AIR FLOW [2] / [1] 625: TIME / DATE RESET [4] / [2]
654: SYSTEM INACTIVITY [4] / [3]
09
10
[2ND]or [1] = 8s
[2] = 16s
[3] = 24s
[4] = 32s
[5] = 40s
[6] = 48s
[7] = 56s
[8] = 64s
[2ND]= No adjustment
[1] = Plus 4s
[2] = Plus 8s
[3] = Plus 12s
[4] = Plus 16s
[5] = Plus 20s
[6] = Plus 24s
[7] = Plus 28s
[8] = Minus 4s
[9] = Minus 8s
[0] = Minus 12s
[STAY]= Minus 16s
[FORCE]= Minus 20s
[ BYP ] = Minus 24s
[ MEM ] = Minus 28s
[ TRBL ] = Minus 32s
Time Correction Table (2nd digit)
Pager Delay Table (1st digit)
[9] = 72s
[0] = 80s
[STAY]= 88s
[FORCE]/[AWAY]= 96s
[BYP]= 104s
[MEM]= 112 s
[TBL]/[TRBL]= 120s

Esprit 728 Ultra & 738 Ultra - 5 - Programming Guide
Reporting Codes
All digits from [1] to [F] are valid. [2ND]= digit will not be reported except for Contact ID programmable codes. For single digit reporting,
enter “skip” ([2ND]) as the first digit (Default = [2ND]/ [2ND]).
Enter FF to program the default Ademco Contact ID report code when using the Ademco Contact ID (programmable
codes) or Pager report formats.
If the Contact ID Format (all codes) is selected, addresses 300 to 527 (sections 11 to 67) do not have to be programmed.
To select Contact ID (all codes) you must set key [0] at section 09/address 038 for both monitoring station numbers (see
page 4).
Arming (Closing) Report Codes:
Streamline
Section Data Description Address Streamline
Section Data Description Address
___ / ___ Auto / Espload 300 ___ / ___ User Code 23 324
___ / ___ Master 301 ___ / ___ User Code 24 325
___ / ___ User Code 1 302 ___ / ___ User Code 25 326
___ / ___ User Code 2 303 ___ / ___ User Code 26 327
___ / ___ User Code 3 304 ___ / ___ User Code 27 328
___ / ___ User Code 4 305 ___ / ___ User Code 28 329
___ / ___ User Code 5 306 ___ / ___ User Code 29 330
___ / ___ User Code 6 307 ___ / ___ User Code 30 331
___ / ___ User Code 7 308 ___ / ___ User Code 31 332
___ / ___ User Code 8 309 ___ / ___ User Code 32 333
___ / ___ User Code 9 310 ___ / ___ User Code 33 334
___ / ___ User Code 10 311 ___ / ___ User Code 34 335
___ / ___ User Code 11 312 ___ / ___ User Code 35 336
___ / ___ User Code 12 313 ___ / ___ User Code 36 337
___ / ___ User Code 13 314 ___ / ___ User Code 37 338
___ / ___ User Code 14 315 ___ / ___ User Code 38 339
___ / ___ User Code 15 316 ___ / ___ User Code 39 340
___ / ___ User Code 16 317 ___ / ___ User Code 40 341
___ / ___ User Code 17 318 ___ / ___ User Code 41 342
___ / ___ User Code 18 319 ___ / ___ User Code 42 343
___ / ___ User Code 19 320 ___ / ___ User Code 43 344
___ / ___ User Code 20 321 ___ / ___ User Code 44 345
___ / ___ User Code 21 322 ___ / ___ User Code 45 346
___ / ___ User Code 22 323 ___ / ___ User Code 46 347
___ / ___ User Code 47 348
___ / ___ User Code 48 / 349
(Duress)
Continues in next section.
Disarming (Opening) Report Codes (reset code “empty”):
Streamline
Section Data Description Address Streamline
Section Data Description Address
See previous section ___ / ___ User Code 5 356
___ / ___ Auto / Espload 350 ___ / ___ User Code 6 357
___ / ___ Master 351 ___ / ___ User Code 7 358
___ / ___ User Code 8 359
___ / ___ User Code 1 352 ___ / ___ User Code 9 360
___ / ___ User Code 2 353 ___ / ___ User Code 10 361
___ / ___ User Code 3 354 ___ / ___ User Code 11 362
___ / ___ User Code 4 355 ___ / ___ User Code 12 363
11 17
12 18
13 19
14 20
15 21
16 22
23
23 25
24 26

Esprit 728 Ultra & 738 Ultra - 6 - Programming Guide
* = Fire zone for 4-wire smoke detectors or 2-wire smoke detectors (with no ATZ enabled—728 Ultra only).
** = Fire zone for 2-wire smoke detectors (address 086, key [BYP]) only when ATZ is enabled (address 090, key [8]). Applies only to 728 Ultra.
† = Zones 1 to 10 for the 728 Ultra and Zones 1 to 18 for the 738 Ultra
Disarming (Opening) Report Codes (reset code “empty”):(continued)
Streamline
Section Data Description Address Streamline
Section Data Description Address
___ / ___ User Code 13 364 ___ / ___ User Code 29 380
___ / ___ User Code 14 365 ___ / ___ User Code 30 381
___ / ___ User Code 15 366 ___ / ___ User Code 31 382
___ / ___ User Code 16 367 ___ / ___ User Code 32 383
___ / ___ User Code 17 368 ___ / ___ User Code 33 384
___ / ___ User Code 18 369 ___ / ___ User Code 34 385
___ / ___ User Code 19 370 ___ / ___ User Code 35 386
___ / ___ User Code 20 371 ___ / ___ User Code 36 387
___ / ___ User Code 21 372 ___ / ___ User Code 37 388
___ / ___ User Code 22 373 ___ / ___ User Code 38 389
___ / ___ User Code 23 374 ___ / ___ User Code 39 390
___ / ___ User Code 24 375 ___ / ___ User Code 40 391
___ / ___ User Code 25 376 ___ / ___ User Code 41 392
___ / ___ User Code 26 377 ___ / ___ User Code 42 393
___ / ___ User Code 27 378 ___ / ___ User Code 43 394
___ / ___ User Code 28 379 ___ / ___ User Code 44 395
___ / ___ User Code 45 396
___ / ___ User Code 46 397
___ / ___ User Code 47 398
___ / ___ User Code 48 /
(Duress) 399
Alarm Report Codes For Zones 1 to 10 (18) †: Alarm Restore Report Codes For Zones 1 to 10 (18) †:
Streamline
Section Data Description Address Streamline Section Data Description Address
___ / ___ Zone 1 400 ___ / ___ Zone 1 424
___ / ___ Zone 2 401 ___ / ___ Zone 2 425
___ / ___ Zone 3/Fire zone*
(fire address 100) 402 ___ / ___ Zone 3/Fire zone* (fire address 100) 426
___ / ___ Zone 4 403 ___ / ___ Zone 4 427
___ / ___ Zone 5/Fire zone** 404 ___ / ___ Zone 5/Fire zone** 428
___ / ___ Zone 6 405 ___ / ___ Zone 6 429
___ / ___ Zone 7 406 ___ / ___ Zone 7 430
___ / ___ Zone 8 407 ___ / ___ Zone 8 431
___ / ___ Zone 9 408 ___ / ___ Zone 9 432
___ / ___ Zone 10 409 ___ / ___ Zone 10 433
___ / ___ Zone 11 (738 Ultra only) 410 ___ / ___ Zone 11 (738 Ultra only) 434
___ / ___ Zone 12 (738 Ultra only) 411 ___ / ___ Zone 12 (738 Ultra only) 435
___ / ___ Zone 13 412 ___ / ___ Zone 13 436
___ / ___ Zone 14 413 ___ / ___ Zone 14 437
___ / ___ Zone 15 414 ___ / ___ Zone 15 438
___ / ___ Zone 16 415 ___ / ___ Zone 16 439
___ / ___ Zone 17 416 ___ / ___ Zone 17 440
___ / ___ Zone 18 417 ___ / ___ Zone 18 441
41 Future Use 418 - 423 47 Future Use 442 - 447
27 31
28 32
29 33
30 34
35
36 42
37 43
38 44
39
738 Ultra
only
45
738 Ultra
only
40
738 Ultra only 46
738 Ultra only

Esprit 728 Ultra & 738 Ultra - 7 - Programming Guide
Zones 1 to 10 (18)† Shutdown Report Codes: Tampers 1 to 4, 5 and 7 (8)‡ Report Codes:
Streamline
Section Data Description Address Streamline
Section Data Description Address
___ / ___ Zone 1 448 ___ / ___ Tamper 1 472
___ / ___ Zone 2 449 ___ / ___ Tamper 2 473
___ / ___ Zone 3 450 ___ / ___ Tamper 3 474
___ / ___ Zone 4 451 ___ / ___ Tamper 4 475
___ / ___ Zone 5 452 ___ / ___ Tamper 5 476
___ / ___ Zone 6 453 ___ / ___ Tamper 6 (738 Ultra only) 477
___ / ___ Zone 7 454 ___ / ___ Tamper 7 478
___ / ___ Zone 8 455 ___ / ___ Tamper 8 (738 Ultra only) 479
___ / ___ Zone 9 456 56 to 59 Future Use 480 - 495
___ / ___ Zone 10 457
___ / ___ Zone 11 (738 Ultra only) 458
___ / ___ Zone 12 (738 Ultra only) 459
___ / ___ Zone13 460 † = Zones 1 to 10 for the 728 Ultra and
Zones 1 to 18 for the 738 Ultra
___ / ___ Zone 14 461
___ / ___ Zone 15 462 ‡= Zones 1 to 4, 5 and 7 for 728 Ultra and
Zones 1 to 8 for 738 Ultra
___ / ___ Zone 16 463
___ / ___ Zone17 464
___ / ___ Zone 18 465
53 Future Use 466 - 471
Trouble Report Codes:
Streamline
Section Data Description Address Streamline Section Data Description Address
___ / ___ Max. aux. current 496 ___ / ___ Fire loop trouble 500
___ / ___ Bell disconnect /
max. bell current 497 ___ / ___ Timer loss 501
___ / ___ Battery disconnect /
low voltage 498 [2ND]/[2ND]Future Use 502
___ / ___ Power failure 499 [2ND]/[2ND]Future Use 503
Trouble Restore Report Codes:
Streamline
Section Data Description Address Streamline Section Data Description Address
___ / ___ Max. aux. current 504 ___ / ___ Fire loop trouble 508
___ / ___ Bell disconnect /
max. bell current 505 ___ / ___ Timer programmed 509
___ / ___ Battery disconnect /
low voltage 506 ___ / ___ Tamper / wiring fault 510
___ / ___ Power failure 507 ___ / ___ TLM restore 511
Special Report Codes:
Streamline
Section Data Description Address Streamline Section Data Description Address
___ / ___ Test report 512 ___ / ___ Duress 520
___ / ___ Panic 1 513 ___ / ___
Closing Delinquency 521
___ / ___ Panic 2 514 [2ND]/[2ND]Future Use 522
___ / ___ Panic 3 515 [2ND]/[2ND]Future Use 523
___ / ___ Late to close 516 ___ / ___ Login (Espload) 524
___ / ___ No movement 517 ___ / ___ Program Change 525
___ / ___ Partial Arming 518 [2ND]/[2ND]Future Use 526
___ / ___ Recent Close 519 [2ND]/[2ND]Future Use 527
48 54
49 55
50
51
738 Ultra
only
52
738 Ultra only
60 61
62 63
64 66
65 67

Esprit 728 Ultra & 738 Ultra - 8 - Programming Guide
Decimal Programming
The decimal programming method is used to program all of the system’s timers. This method uses a 3-digit address from 044 to 061 and
each address is programmed with a value from 000 to 255.
Figure 2: Decimal Display For LED Keypads
Table 5: Decimal Programming Method
1. Press [ENTER]+ [INSTALLER CODE](Default - 728 Ultra: 282828; 738 Ultra: 383838)
2. The [ENTER]key will flash to indicate that you are in programming mode (LED keypad only).
3. Enter 3-digit [ADDRESS](044 to 061).
4. The keypad displays the current 3-digit data saved at this address as described in Figure 2 below.
5. Enter 3-digit [DATA](000 to 255) and do not press [ENTER]. The software will automatically save the data.
6. Return to step 2 or press [CLEAR]to exit programming mode.
Address Data
Description Default
044 ___ / ___ / ___ (hours) Auto arm time (between "000" and "023") 000
045 ___ / ___ / ___ (minutes) Auto arm time (between "000" and "059") 000
046 ___ / ___ / ___ (days or hours) Auto test report every ? (between "001" and "254") (000 = disabled)
If address 090 key [3] OFF = address 046 in days (see page 10)
If address 090 key [3] ON = address 046 in hours (see page 10)
738 Ultra only: Enter “255” to enable a Timed Test Transmission when the system is armed or
disarmed (see the 728 Ultra/738 Ultra Reference & Installation Manual for more information)
000
047 ___ / ___ / ___ (hours) Auto test report (between "000" and "023")
738 Ultra only: (minutes) If address 046 = 255 and the system is armed, Armed Test Report
(between “001” and “255”) 000
048 ___ / ___ / ___ (minutes) Auto test report (between "000" and "059")
738 Ultra only: (minutes) If address 046 = 255 and the system is disarmed, Disarmed Test
Report (between “001” and “255”) 000
049 ___ / ___ / ___ (seconds) Exit delay 60 seconds
050 ___ / ___ / ___ (seconds) Entry delay 1 45 seconds
051 ___ / ___ / ___ (seconds) Entry delay 2 45 seconds
052 ___ / ___ / ___ (minutes) Bell cut-off time 5 minutes
053 ___ / ___ / ___ (x 15 ms) Zone speed 600 ms
054 ___ / ___ / ___ (minutes) Power failure report delay (000 = disabled) 30 minutes
055 ___ / ___ / ___ (x 15 minutes) No movement Auto-Arm time (000 = disabled) Disabled
056 ___ / ___ / ___ PGM timer setting (001 to 127 for seconds and 129 to 255 for minutes)
Add 128 to desired value in minutes (i.e. for 5 minutes: enter 5 + 128 = 133) 5 seconds
057 ___ / ___ / ___ Intellizone delay (in seconds, minimum = 10 seconds) 48 seconds
058 ___ / ___ / ___ Installer code lock (147 = locked, 000 = unlocked). When Installer Lock is enabled on a control
panel: For 4 seconds during power up, the STATUS LED flashes while the dialer relay opens
and closes making a clicking noise.
Unlocked
059 ___ / ___ / ___ (seconds) Programmable delay before alarm transmission (005 to 063 seconds)
(000 = disabled) Disabled
060 ___ / ___ / ___ (seconds) Recent closing delay (000 = disabled) Disabled
061 ___ / ___ / ___ (days or hours) Closing delinquency timer (System A)
If address 090 key [3] OFF = address 061 in days (see page 10)
If address 090 key [3] ON = address 061 in hours (see page 10)
Disabled
Each key in the first 2 rows of the keypad represents a specific value when the key is lit, as shown below left. When the key isn’t lit, the
key represents 0. Add the values of the lit keys to obtain the entered data value as shown in the example below right.
Note: LCD keypads will display current data on the screen.
Example:
Therefore
8 + 1 + 32 + 16 = 057

Esprit 728 Ultra & 738 Ultra - 9 - Programming Guide
Feature Select Programming
Addresses 062 to 126 are programmed using the Feature Select Programming method. In this method, every key on the keypad in each
address represents an option or feature. Pressing a key will display it on the keypad and pressing it again will extinguish the key. The ON
or OFF status of each key determines the selected feature. Addresses 080 to 085 are reserved for future use. To program using the
Feature Select Programming method:
Table 7: Code Priority For System “A” / STAY
Table 8: Code Priority For System “B” / AWAY / FORCE
Table 9: Code Priority for Codes with Bypass Access
Table 6: Feature Select Programming Method
1. Press [ENTER]+ [INSTALLER CODE](Default - 728 Ultra: 282828; 738 Ultra: 383838)
2. The [ENTER]key will flash to indicate you are in programming mode (LED keypad only).
3. Enter 3-digit [ADDRESS](062 to 126).
4. After entering the address, the keypad will display the feature selection status. Turn the keys ON or
OFF by pressing the appropriate key until the desired options are set. Press the [ENTER]key to accept,
there will be a confirmation beep indicating the options have been accepted. The [ENTER]key will flash
to indicate that the software is awaiting the next address entry.
5. Return to step 3 to continue programming or press [CLEAR]to exit programming mode.
KEY SELECT:
[1][2][3][4][5][6][7][8][9][0][STAY][AWAY]/
[FORCE][BYP][MEM]
[ TRBL ] [2ND]
User #: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
062
NNNNNNNNNN N N N N N N
User #: 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
064
NNNNNNNNNN N N N N N N
User #: 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
066:
NNNNNNNNNN N N N N N N
KEY SELECT:
[1][2][3][4][5][6][7][8][9][0][STAY][AWAY]/
[FORCE][BYP][MEM]
[ TRBL ] [2ND]
User #: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
068:
NNNNNNNNNN N N N N N N
User #: 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
070:
NNNNNNNNNN N N N N N N
User #: 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
072:
NNNNNNNNNN N N N N N N
KEY SELECT:
[1][2][3][4][5][6][7][8][9][0][STAY][AWAY]/
[FORCE][BYP][MEM]
[ TRBL ] [2ND]
User #: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
074:
NNNNNNNNNN N N N N N N
User #: 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
076:
NNNNNNNNNN N N N N N N
User #: 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
078:
NNNNNNNNNN N N N N N N

Esprit 728 Ultra & 738 Ultra - 10 - Programming Guide
U= default KEY
086: OFF / ON
See “TLM” table at right U[2ND]N
U[1] N
Keyswitch = Regular arm U[2] NStay arm / System A
Keyswitch arming U[3] NEnabled
Call back U[4] NEnabled
Auto arm on time U[5] NEnabled
Auto arm on no movement U[6] NEnabled
Pulse dialing U[7] NTone dialing (DTMF)
Partitioning U[8] NEnabled
Silent zone/panic generates a silent alarm U[9] NGenerates only a report
(1:2) Pulse Europe U[0] N(1:1.5) Pulse USA
See “Reporting Options” table at right
U[STAY]N
U[AWAY]/
[FORCE]N
2-wire smoke detector (input 3) U[BYP]NEnabled
Bell squawk on arm/disarm U[MEM]NEnabled
Auto zone shutdown U[TRBL]NEnabled
088: OFF / ON
Automatic event buffer transmission U[2ND]NEnabled
Panic 1 (keys [1] and [3])U[1] NEnabled
Panic 2 (keys [4] and [6])U[2] NEnabled
Panic 3 (keys [7] and [9])U[3] NEnabled
Panic 1 silent U[4] NAudible
Panic 2 silent U[5] NAudible
Panic 3 silent U[6] NFire
Key [0]/[ARM]- Regular arming U[7] NEnabled
Key [STAY]- Stay or system A arm U[8] NEnabled
6-digit access codes U[9] N4-digit access codes
Tamper Recognition U[0] N
U[STAY]N
Beep on exit delay U[AWAY]/
[FORCE]NEnabled
Report zone restore on bell cut-off U[BYP]NOn zone closure
Zones with EOL (1k9)N[MEM]UNo EOL
Always report disarm U[TRBL]NOnly after alarm
090: OFF / ON
Exclude power failure from trouble display U[2ND]NEnabled
Zone 4 (728 Ultra)/Zone 11 (738 Ultra)* enabled U[1] NDisabled** NOTE 1: When ATZ is enabled (address 090 key [8] ON)
and zone 3 is defined as a 4-wire fire zone, if you are not
using zone 4 (728 Ultra) or 11 (738 Ultra), it must be
disabled.
Auto arm = Regular arm U[2] NStay / System A
Auto test report / Closing delinquency timer in
days U[3] NIn hours
Restrict arming on battery failure U[4] NEnabled
Restrict arming on tamper trouble** U[5] NEnabled**
No tamper bypass U[6] NTamper follows zone bypass definition
Zone doubling (ATZ) wiring in series U[7] NParallel
Zone doubling (ATZ) U[8] NEnabled ** NOTE 2: Only the installer can clear a tamper trouble
Audible trouble warning U[9] NEnabled
Duress U[0] NEnabled
Keypad zone 1 supervision U[STAY]NEnabled
Keypad zone 2 supervision U[AWAY]/
[FORCE]NEnabled
Master code lock U[BYP]NEnabled
Pager format (wait delay) U[MEM]NPersonal dialing (during delay)
Pager report alarms only U[TRBL]NAll events
Telephone Line Monitoring (TLM)
(address 086, key [9] has to be OFF)
KEY
[2ND][1]
OFF OFF - TLM disabled
OFF ON - TLM generates trouble only
ON OFF - generates an alarm if armed
ON ON - silent alarm becomes audible
R
eport
i
ng
O
pt
i
ons
* On alarm, all reports are made to Tel. #1 until system is
disarmed. Once disarmed, system reports are made to Tel. #2.
KEY
[STAY][AWAY]/[FORCE]
OFF OFF - Reporting disabled
OFF ON - Regular reporting
ON OFF - Split*reporting (Alarms & System)
ON ON - Double reporting
Report Dialing Sequence (tel. no.)
Regular: 1,2,1,2,1,2,1,2, fail to comm.
Split*: Alarms - 1,1,1,1,1,1,1,1, fail to comm
System - 2,2,2,2,2,2,2,2, fail to comm
Double: 1,1,1,1,1,1,1,1, fail to comm
2,2,2,2,2,2,2,2, fail to comm
Tamper / Wire Fault Definitions
KEY
System Armed [0] [STAY]System Disarmed*
Alarm as per
individual zone
definitions
OFF OFF - Tamper supervision
disabled
Alwaysgenerate
trouble and
alarm,audibleor
silent as per
individual zone
definitions
OFF ON - No alarm. Trouble
code reported
ON OFF - Silent alarm.
Trouble & alarm
codes reported
ON ON - Audible alarm.
Trouble & alarm
codes reported**
* Exception: for 24 hour zones, the tamper definition
will follow the audible/silent alarm definition of the 24
hour zone.
** Silent zones will generate a silent alarm.

Esprit 728 Ultra & 738 Ultra - 11 - Programming Guide
Table 10: Zone Definition
Do not use the Intellizone feature and an entry delay for the same zone, otherwise an alarm may occur as a user tries to
disarm the system. Zones that are not selected at addresses 100 to 112 (728 Ultra) or 114 (738 Ultra) become “Delay 1” zones.
Key Access Programming
Programs features quickly, without entering addresses or sections numbers. To activate Key Access Programming, press [ENTER]
followed by the Installer code, Master code or User code 1 (code required depends on the desired feature; see below). Press the key
corresponding to the desired feature. Press [ENTER]or [CLEAR]to exit. When communicating with Espload, it is impossible to enter
programming mode.
Address
KEY SELECT: [1] [2] [3] [4] [5] [6] [7] [8] [9] [0] [STAY][FORCE]
/[AWAY][1] [2] [3] [4] [5] [6]
Zone: 1234567891011 12 13 14 15 161718
092:
Intellizone = ON 092: NNNNNNNNNN N N 094: NN NNNN
Zone: 1234567891011 12 13 14 15 161718
096:
Silent = ON 096: NNNNNNNNNN N N 098: NN NNNN
Zone: 1 2 3*4567891011 12 13 14 15 161718
100:
24Hr./Fire = ON 100: NNNNNNNNNN N N 102: NN NNNN
Keypad zones
cannot be set as
24Hr zones.
* When zone 3 is defined as “24Hr”,it becomes a 4-wire smoke detector fire zone (2-wire smoke detector support must be
disabled, address 086 key [BYP]= OFF).
If using 2-wire smoke detectors and ATZ is enabled, zone 3 can be defined as “24Hr” (728 Ultra only).
Zone: 1234567891011 12 13 14 15 161718
104:
Instant = ON 104: NNNNNNNNNN N N 106: NN NNNN
Zone: 1234567891011 12 13 14 15 161718
108:
Follow = ON 108: NNNNNNNNNN N N 110: NN NNNN
Zone: 1234567891011 12 13 14 15 161718
112:
Delay 2 = ON 112: NNNNNNNNNN N N 114: NN NNNN
SYSTEM A / STAY (if ON, zone is armed on Stay or “System A” arming)
Zone: 1234567891011 12 13 14 15 161718
116:
116: NNNNNNNNNN N N 118: NN NNNN
SYSTEM B (if ON, zone is armed in “System B” arming)
Zone: 1234567891011 12 13 14 15 161718
120:
120: NNNNNNNNNN N N 122: NN NNNN
Zone: 1234567891011 12 13 14 15 161718
124:
Bypass = ON 124: NNNNNNNNNN N N 126: NN NNNN
Fire zones cannot be bypassed.
Table 11: Key Access Programming
Key Feature Codes that can access feature
[8]
Installer Test Mode Installer Code Only
In Installer Test mode, a confirmation beep (intermittent) indicates that the test
mode is enabled. A rejection beep indicates that the test mode is disabled. The
bell will squawk during walk testing to indicate opened, functional zones.
[9] “Auto Arming” Time Program Installer Code, Master Code or User Code 1
Key [9] flashes. Enter 2-digit hour (00 to 23) and 2-digit minutes (00 to 59).
[MEM] Panel Time Programming Installer Code, Master Code or User Code 1
[MEM]key flashes. Enter 2-digit hour (00 to 23) and 2-digit minutes (00 to 59).
[BYP] Test Report Installer Code, Master Code or User Code 1
Reporting is enabled at address 086, keys [STAY]and [AWAY]/[FORCE](see
page 10). A value must be entered at address 512 (page 7) and both telephone
and account numbers must be programmed.
[TRBL] Call Espload Via Telephone Installer Code, Master Code or User Code 1
Panel identifier and PC password (addresses 004 to 007 on page 3) and
computer telephone number (addresses 008 to 015 on page 3) must be
programmed.
[AWAY] Answer Espload Installer Code, Master Code or User Code 1
This feature is available when using the ADP-1 adapter. In Espload, “blind dial” must
be activated in the “modem setup” section and panel phone number programmed.
[STAY] Cancel Communication Attempts
Until next reportable event. Master Code/User Code 1 only cancel calls to Espload
The Installer Code can cancel all communications

Esprit 728 Ultra & 738 Ultra - 12 - Programming Guide
Connection Diagrams
The system hardware will recognize the following zone conditions:
Single Zone Connections
Figure 3: N.C. Contacts, without EOL Resistor Figure 4: N.C. Contacts, with EOL Resistor (UL/cUL)
Figure 5: N.O. Contacts, with EOL Resistor (UL/cUL) Figure 6: N.C. Contacts, without EOL Resistor, with Tamper
Recognition
Figure 7: N.C. Contacts, with EOL resistor, with Tamper and Wire
Fault Recognition (UL/cUL)
Address 088,[MEM]= “ON” (EOL resistor disabled)
[0] = “OFF”
[STAY]= “OFF”
Address 090,[8] = “OFF” (ATZ disabled)
Tamper/Wire Fault disabled. Address 088,[MEM]= “OFF” (EOL resistor enabled)
[0] = “OFF”
[STAY]= “OFF”
Address 090,[8] = “OFF” (ATZ disabled)
Tamper/Wire Fault disabled.
Address 088,[MEM]= “OFF” (EOL resistor enabled)
[0] = “OFF”
[STAY]= “OFF”
Address 090,[8] = “OFF” (ATZ disabled)
Tamper/Wire Fault disabled.
Address 088,[MEM]= “ON” (EOL resistor disabled)
[0] = (See Tamper/Wire Fault definitions on
[STAY]= page 10.)
Address 090,[8] = “OFF” (ATZ disabled)
Address 088,[MEM]= “OFF” (EOL resistor enabled)
[0] = (See Tamper/Wire Fault definitions on
[STAY]= page 10.)
Address 090,[8] = “OFF” (ATZ disabled)

Esprit 728 Ultra & 738 Ultra - 13 - Programming Guide
Advanced Technology Zone (ATZ) Connections
Other Connection Diagrams
Figure 8: N.C. Contacts, without EOL Resistor Figure 9: N.C. Contacts, without EOL Resistor, with Tamper
Recognition
Figure 10: N.C. Contacts, with EOL Resistor, with Tamper and Wire
Fault Recognition (UL/cUL) Figure 11: Parallel Wiring
Figure 12: Connecting Keypad Zone(s)
Address 088,[MEM]= “ON” (EOL resistor disabled)
[0] = “OFF”
[STAY]= “OFF”
Address 090,[8] = “ON” (ATZ enabled)
[7] = “OFF” (ATZ wiring in serial)
Tamper/Wire Fault disabled.
Address 088,[MEM]= “ON” (EOL resistor disabled)
[0] = (See Tamper/Wire Fault definitions on
[STAY]= page 10.)
Address 090,[8] = “ON” (ATZ enabled)
[7] = “OFF” (ATZ wiring in serial)
Address 088,[MEM]= “OFF” (EOL resistor enabled)
[0] = (See Tamper/Wire Fault definitions on
[STAY]= page 10.)
Address 090,[8] = “ON” (ATZ enabled)
[7] = “OFF” (ATZ wiring in serial)
Address 088,[MEM]= “OFF” (EOL resistor enabled)
[0] = “OFF”
[STAY]= “OFF”
Address 090,[8] = “ON” (ATZ enabled)
[7] = “ON” (ATZ wiring in parallel)
Tamper/Wire Fault disabled.

Esprit 728 Ultra & 738 Ultra - 14 - Programming Guide
It is recommended that the smoke detectors be connected using a daisy chain configuration.
Figure 13: LED Keypad Anti-Tamper Switch Connection Figure 14: PGM Output Relay Figure 15: Ground Start Circuit
Figure 16: 4-Wire Smoke Detector Connections (Fire Zone) Figure 17: 4-Wire Smoke Detector Fire Reset
Figure 18: 2-Wire Smoke Detector Connections (Fire Zone)
Address 086; key [BYP] ON (728 Ultra)
Connect the two-wire smoke detector to input 3. Without
ATZ, zone 3 is used by the two-wire smoke detector. With
ATZ enabled, zone 5 is used by the 2-wire smoke detector
and zone 6 will be disabled automatically.
2-Wire Smoke Detector Fire Reset:
Simultaneously press and hold for 3 seconds the [ENTER]and
[CLEAR]keys on any keypad to conduct a 30 second reset.
Address 086; key [BYP] ON (738 Ultra)
Connect the two-wire smoke detector to input 3. Zone 3 is
used by the two-wire smoke detector. With ATZ enabled,
zone 11 will be disabled automatically.
UL Warnings. For UL/cUL installations:
- The operating voltage of the fire circuit must be between 11 to 12Vdc.
- Use only the Hochicki model SLR 835BH-2 2-wire smoke detector.
- 2-wire smoke detectors of different models other than the Hochicki model are not to be used.
- Both the 728 Ultra and the 738 Ultra control panels support a maximum of five 2-wire smoke
detectors per control panel.

Esprit 728 Ultra & 738 Ultra - 15 - Programming Guide
728 Ultra Wiring Diagram
Keypads
- LED Keypads 636 and 646
- LCD Keypad 642
The maximum number of keypads per installation is
dependent on the auxiliary output, which is not to exceed
450mA. Refer to the 728 Ultra & 738 Ultra Reference &
Installation Manual for the current consumption table. Refer
to Figure 12 on page 13 for information on keypad zone
connections.
Please refer to Inset 1 for the
input terminals. For the hardwired
connections, refer toSingle Zone
Connections on page 12 and
Advanced Technology Zone
(ATZ) Connections on page 13.
Note: To use you must disable the PGM. To do so,
program [2ND][2ND]in sections 039, 040 and 042.
For use with the 708, Esprint and SRI-18 PGM expander
Disconnect the
battery before
replacing the fuse
Rechargeable Acid/
Lead or Gel Cell
Backup Battery
Improper connection may result
in damage to the system.
AUX POWER:
450mA maximum. UL/cUL: 250mA maximum for 24Hr
Stand-by. To connect additional wiring to the auxiliary
power, use the red (+) and the black (-) keypad connectors.
AUX power will shutdown if current exceeds 650mA.
For UL and cUL warnings, refer to the Warnings section in the Esprit 728
Ultra & 738 Ultra Reference and Installation Manual.
Bell/Siren
TheBELL output
will shutdown if
the current
exceeds 3A.
To provide maximum lightning
protection we strongly recommend
having separate earth connections
for the dialer and zone ground
terminals.
To metallic
enclosure
Cold water
pipe or
grounding rod
Ground
clamp
Disconnect the
telephone line
before servicing.
AWG# 14 single conductor
solid copper wire
STATUS LED:
Flash once every second = normal
Toggle ON 1s / OFF 1s = trouble
Always ON = panel is using phone line
Fast flash 4s after power up = installer lock enabled
Note: For UL installations, the metallic
enclosure must be grounded to the cold
water pipe or to the grounding rod.
**
** UL Note:
Do not connect this ground with
UL installations.

Esprit 728 Ultra & 738 Ultra - 16 - Programming Guide
738 Ultra Wiring Diagram
Keypads
- LED Keypads 636 and 646
- LCD Keypad 642
The maximum number of keypads per installation is
dependent on the auxiliary output, which is not to exceed
500mA. Refer to the 728 Ultra & 738 Ultra Reference &
Installation Manual for the current consumption table. Refer
to Figure 12 on page 13 for information on keypad zone
connections.
Please refer to Inset 1 for the input terminals.
For the hardwired connections, refer to Single
Zone Connections on page 12 and Advanced
Technology Zone (ATZ) Connections on
Note: To use you must disable the PGM. To do
so, program [2ND][2ND]in sections 040 and 042.
For use with the 708, Esprint and SRI-18 PGM expander
Caution:
Disconnect the
battery before
replacing the
fuse
Rechargeable
Acid/Lead or
Gel Cell
Backup
Battery
Improper connectionmay result
in damage to the system.
AUX POWER:
500mA maximum. 250mA maximum for 24Hr Stand-by.
To connect additional wiring to the auxiliary power, use
the red (+) and the black (-) keypad connectors. AUX
power will shutdown if current exceeds 700mA.
For UL and cUL
warnings, refer to
the Warnings
section in the
Esprit728 Ultra &
738 Ultra
Reference and
Installation
Manual.
Bell/Siren
TheBELL output
will shutdown if
the current
exceeds 3A.
To provide maximum lightning
protection we strongly recommend
having separate earth connections
for the dialer and zone ground
terminals.
To metallic
enclosure
Cold water
pipe or
grounding rod
Ground
clamp
WARNING:
Disconnect
the
telephone
line before
servicing.
AWG# 14 single conductor
solid copper wire
STATUS LED:
Flash once every second = normal
Toggle ON 1s / OFF 1s = trouble
Always ON = panel is using phone line
Fast flash 4s after power up = installer lock enabled
ULapproval
pending

Esprit 728 Ultra & 738 Ultra - 17 - Programming Guide
Power Down Reset
Performing a power down reset will set the Installer and Master codes to factory default. Values entered at addresses 008 to 043, 062 to
124,300 to 527 and all user codes will be set to factory defaults. Programmed values at addresses 003 to 007 do not change. To perform
a reset, the installer lock must be disabled. To perform a power down reset perform the following:
1. Verify installer lock is disabled.
2. Remove the battery and AC power from the control panel.
3. Remove all connected wires and devices from the PGM (PGM1 for 738 Ultra) and zone 1 terminals.
4. Short the PGM (PGM1 for 738 Ultra) and zone 1 terminals with a wire.
5. Reconnect the AC and battery power to the control panel.
6. Wait for 10 seconds and remove the wire.
Figure 19: Power Down Reset for 728 Ultra or 738 Ultra
Warranty
Paradox Security Systems Ltd. (“Seller”) warrants its products to be free from defects in materials and workmanship under normal use for a period of one year. Except as
specifically stated herein,all express or implied warranties whatsoever, statutory or otherwise, including without limitation,any implied warranty of merchantability and fitness for
a particular purpose, are expressly excluded. Because Seller does not install or connect the products and because the products may be used in conjunction with products not
manufactured by Seller, Seller cannot guarantee the performance of the security system and shall not be responsible for circumstances resulting from the product’s inability to
operate. Seller obligation and liability under this warranty is expressly limited to repairing or replacing, at Seller's option, any product not meeting the specifications. Returns
must include proof of purchase and be within the warranty period. In no event shall the Seller be liable to the buyer or any other person for any loss or damages whether direct
or indirect or consequential or incidental, including without limitation, any damages for lost profits stolen goods, or claims by any other party, caused by defective goods or
otherwise arising from the improper, incorrect or otherwise faulty installation or use of the merchandise sold.
Notwithstanding the preceding paragraph, the Seller’s maximum liability will be strictly limited to the purchase price of the defective product. Your use of this product signifies
your acceptance of this warranty.
BEWARE: Dealers, installers and/or others selling the product are not authorized to modify this warranty or make additional warranties that are binding on the Seller.
© 2003-2005 Paradox Security Systems Ltd. All rights reserved. Specifications may change without prior notice. One or more of the following US patents may apply: 6215399,
6111256, 5751803, 5721542, 5287111, 5119069, 5077549, 5920259 and 5886632. Canadian and international patents may also apply. Esprit is a trademark or registered
trademark of Paradox Security Systems Ltd. or its affiliates in Canada, the United States and/or other countries.
1. Remove power.
2. Remove all connected wires and devices from the
PGM (PGM1 for 738 Ultra) and zone 1 terminals.
3. Short the PGM (PGM1 for 738 Ultra) and zone 1
terminals.
4. Reconnect power.
5. Wait 10 seconds and remove wire.

Notes

780 Industriel Blvd., Saint-Eustache (Quebec) J7R 5V3 CANADA
Tel.: [phone] Fax: [phone]
www.paradox.ca
PRINTED IN CANADA - 03/2005 7X8ULT-EP01
