eSSL SDO-PK23 User manual

Swing Door Motor
www.esslsecurity.com
User Manual
SDO-PK23

1
1) CAUTION! For personal safety it is important to follow all the instructions
carefully. Incorrect installation or misuse of the product may cause serious
injury to people .
2) This product must be installed, debugged and maintained by professional
and qualied personnel.
3) The power supply voltage must match the design requirements of this
product and comply with electrical safety regulations.
4) This product was designed and manufactured strictly for the use indicated
in this document. Any other usage not expressly indicated in this
Document, may damage the product and/or be a source of danger.
5) The company is not responsible for losses caused by improper use .
6) Before carrying out any work on the product, turn off the Power supply.
7) This product must be equipped with an independent 6 A circuit breaker.
8) Do not make any alterations to the components of the automatic mach- ine
( Opener and Accessory).
9) Keep the instructions in a safe place for future reference.
WARNING TO THE INSTALLER GENERAL
SAFETY OBLIGATIONS

2
1. Main Parts
2.Dimensions
Long&Short Pin one each
PK23,swing door opener Power supply 1pcs Support 1pcs Adaptor arm 1pcs
Straight arm 1pcs Bent arm 1pcs Circlip 12pcs
Anti-water joint 1pcs Flat key 1pcs
M8x20 6pcs
M8x20 6pcs
Spring washer 6pcs
φ12
φ8
Flat washer φ8 8pcs
Flat washer φ12 6pcs
Hexagon socket head cap screws
Hexagon socket button head screws
118
90
PK23,swing door opener Arms

5
0
100V~240V AC
3
3.Technical Data
Power supply
Power of motor 24VDC/40W
Rpm of motor
Open/close time 3-10S(adjustable)
Maximum door width 1 00mm
Maximum door weight 15 Kg
Working temperature -20℃～50℃
4.Features
* Pull or push to activate the door opener operation.
* Automatic learning open-limits and close-limits when power on.
* Soft stop before open and close limits.
* Automatically Return when encountering resistance.
* Protection and access control equipment can be connected, such as radar,
infrared sensor, card reader, electromagnetic lock, electric bolt lock, etc.
* With Fire alarm linkage interface.
5.Installation
3000rpm±10%
2.8A±10%
20°~90° adjustable
Current of motor
Maximum opening angle

4
5.1 Installation diagram
5.2 Installation steps of PULLING OPENER
5.2.1 Installation location and measurement
Connect output power 24V
by 2-core wire 1.5mm²
Connect output power 24V
by 2-core wire 1.5mm²
Connect input power 100-240V
by 3-core wire 1.5mm²
Drill M8 hole 6pcs at depth at min 25mm.
Door width ＜1m ≥1m
L 500±20（mm）450±20（mm）
and the door are rm and reliable, and will not loosen during operation!
Very Important Notice!
Both the door frame and the door must be rm and strong.
Ensure the xed points that the door opener installed on the door frame

5
5.2.2 Installation of OPENER
5.2.3 Installation of adaptor arm
Top cover
Led cover
Fix braket by M8x20mm screws
+sping washer
+at washer
6×20mm Flat pin 2pcs
Adaptor arm
Fix at pin,then install adaptor arm as arrow direction.

6
5.2.4 Installation of top cover
5.2.5 Connet arms group
5.2.6 Installation of arms group
Top cover
(+Spring washer)
Install top cover as arrow direction
2-M5×25mm(Hexagon socket head cap screws)
Bent arm
Straight arm
Long pin
Circlip
Flash washer
connect straight arm and bent arm as picture
Arms
Braket Short pin
Circlip
Flash washer
Install arms as picture

7
5.2.7 Installation of arms group to adaptor arm
There are 3 installation holes, fix 2 holes by 2pcs M8X20mm scews and flat washer
as arrow position to connect arms group and adaptor arm.
5.2.8 Open the cover
Press one side of the cover to geit it out of the slot,
Remove motor cover
turn it over and take it out
Front install Rear install
L500±20(mm)
Installation Front install Rear install
450±20(mm)

8
5.2.9 Install the LED cover and connect wires.
5.2.10 Assemble the cover.
Led cable
24V power cable
2-M5×10mm
(Screws and spring washers)
Connect power cable and led cable to
PCB board, please refer to page
Fix led cover by 2pcs M5X10mm screws.

9
6.CONTROL BOARDS
6.1 Sketch map
1
2
34
5
6
7
8910 11
1.Learn button
2.Motor connector
3.Button cell
4.Dip switch
5.Buzzer
6.Digital display
7.24V input power connector
8.Electromagnetic lock connector
9.Led connector
10. External input signal connector
11. Rs485 connector

10
6.2 Wiring diagram
Notice:
Dene the door that opens ahead but and closes behind as the MASTER
DOOR.
Dene the door that opens behind but closes ahead as the SLAVE DOOR.
All signals are accessed by the MASTER and send out instructions.（Refer
to 6.1 DIP switch settings for dual-door mode.)
The SLAVE needn’t learn Transmitter. It acts following the MASTER.
Board
Motor
220V
~
transformer
E-lock
Led
Radar
Red
Black
Black
Red
Green
Identication device
Fire alarm Infrared
Slave Opener A
Slave Opener B
24V

11
OPEN
STOP
CLOSE
SET
7. Dip switch, learning code and mode setting
7.1 Definition of Dipswitches and Transmitter
(close clockwise)
(close
counterclockwise)
(MASTER) (SLAVE)
(single door) (dual door)
33
3
33
3
Important:There is only a "learn" button on the door opener control
board.Before setting on the Transmitter, it must be coded.
For a dual-door,only the MASTER OPENER code Transmitter. All
parameters be set on the Master.

12
7.2 Limits self-learning
* Functions of Buttons
OPEN: ①Open the door. ②To be set to normally open mode after being
pressed and hold for 3 seconds . ③Increase parameter value during
setting.
CLOSE: ①Close the door. ②Restore automatic close function after being
pressed in normally open mode. ③ Decrease parameter value during
setting.
STOP: ①Stop the running door. ②Exit from setting.
SET: ①Enter SETTING after being pressed and hold for 3 seconds.
②Switch menu when entering setting.
③Exit the setting by keep pressing.
The Opener can be used only after the Limits Self-learning (setting) is nished.
Close the doors completely before power on.When the display value of the
digital tube changes from 40 to 10, it means that the limits setting is completed.
If the door open after power-on,dial the dip-switch 3 to the opposite , then
power off and power on again.
7.3 Transmitter's coding and Erasing
7.3.1 Transmitter's code setting
Press "LEARN”button on the Control Board to the LED light on, then press the
button which you choose on the transmitter till the LED ashes and goes out.
Now, the transmitter is coded. Other transmitters can be coded as this way.
7.3.2 Erasing the transmitter's code
Press" LEARN”button on the Control Board and hold on to make the "LEARN
LED" light on up to go out. Now, all transmitters which had been coded are
cleared.

13
7.4 Parameters setting
7.4.1 Denitions
The larger the value,
the faster the speed
P1 50
15-70
Open speed
P2 40
15-70
Close speed
P3
2510-50
Open slow speed
P4 2010-50
Close slow speed
P5 25
15-99
Open deceleration range
15-99
P6 25
Close deceleration range
P7
05
5-99
Automatic closing time
P8 40
20-90
Maximum open angle
P9 01
00-01
Mode of opening
H0 01
00-99
Start interval
H1 40
10-99
Resistance sensitivity
H2 00
00-01
Vigorously close door mode
H3 01 1-10
Duration of vigorously closing
H4 05
0-25
strength
H5
01
00-01
Remote control mode
H6 0000-01
Infrared protector mode
E1
00
00-01
Hall sensor failure
E2 00
00-01
Run timeout failure
E3 00 00-01
Door opening is blocked
E4 00
00-01
Door closing is blocked
E5 00
00-01
Abnormal voltage
Menu code range Factory
settngis functions description
The larger the value,
the larger the slow-moving range.
The larger the value,
the longer the door stays open.
The larger the value,
the larger the open angle.
00 push to open
01 with E-LOCK
Master opener and
Slave Opener start interval
The smaller the value,
the higher the sensitivity.
00 not enabled.01 enabled. This
function is activated when there
is a brush edge between two doors
Unit:second
The larger the value,
the greater the force.
00 Three buttons respectively
control open,stop and close
01 one button control open,
stop and close
00 normal open
01 normal close
Error code
* P9=00,PUSH TO OPEN. When the door be pushed at the angle ＞5°, it will
open automatic.
* H2=00,the door will stop when it touches the door frame slightly. H2=01,
when the door is close to the door frame the closing force is stronger.
* H5=01,only one button works step by step,open-stop-close-stop-open...

14
7.4.2 Setting
Press the SET button on the Transmitter and hold till displaying P1 to enter
Setting process.Refer to the following steps and the 6.3.1 Denitionstable for
parameter setting.
After setting the parameters, keep pressing the SET or STOP to save and exit.
CLOSE
CLOSE
P1
SET
SET
SET
SET
SET
P2
P6
P5
P4
P3
CLOSE
CLOSE SPEED
STOP
OPEN
OPEN
STOP
CLOSE
STOP
OPEN
CLOSE
OPEN
CLOSE
STOP
STOP
OPEN
EXIT
OPEN
OPEN SPEED
default
Press and hold SET for 3 seconds
CLOSE
CLOSE
OPEN
SET
SET
P8
P7
OPEN
STOP
STOP
Open slow speed
Close slow speed
Open deceleration range
Close deceleration range
Automatic closing time
Maximum open angle

15
Infrared protector mode
Remote control mode
strength
Duration of vigorously closing
Vigorously close door mode
Resistance sensitivity
Start interval
Mode of opening
P9
H0
H1
H2
H3
H4
H5
H6
SET
SET
SET
SET
SET
SET
SET
SET
CLOSE
CLOSE
CLOSE
CLOSE
CLOSE
OPEN
OPEN
OPEN
OPEN
SET
OPEN
STOP
STOP
STOP
STOP
STOP
CLOSE
CLOSE
OPEN SET
OPEN
STOP
STOP
EXIT
CLOSE
OPEN
STOP

16
8.Trouble shooting
·Check the communication wiring.
·Check the dip-switch 1 and 2 setting correct.
·Change control boards.
·Check if the transmitter is coded.
·Check if the coded transmitter works normally.
·Check the dip-switch2.
·Check the communication wiring.
·Check whether the Master and the Slave openers set
normally.
·Change control boards.
·Check the terminal wiring.
·Check the power-on switch.
·Check the fuse.
·Measure the transformer’s input and output.
·Check the power chip on the control board.
Door opening and closing are
inconsistent with control mode.
The Master and the Slave
openers can not communicate
Unable to set Limits by
self-learning
·Check the dip-switch 3.
·Change the battery.
·Re-code.
·Code another new transmitter.
·After conrming the transmitter is normal,check
whether the receiver on the control board works
well.If not,change a new receiver.
·Check and rewire the terminals.
·Change a new motor and test whether the control
board works well.
·Change a new control board and test whether the
motor works well.
trouble Trouble shooting
Transmitter doesn’t work.
Motor doesn’t work
Unable to set parameters
All LED indicators are
off after power on.

#24, Shambavi Building, 23rd Main, Marenahalli, JP Nagar 2nd Phase, Bengaluru - 560078
Phone : [phone] | Email : [e-mail]
www.esslsecurity.com
