ETAS GETK-P4.0A User manual

ETAS GETK-P4.0A
Measurement Interface for Micro-
processors and Microcontroller
using PCI Express
User Guide

Copyright
The data in this document may not be altered or amended without special
notification from ETAS GmbH. ETAS GmbH undertakes no further obligation
in relation to this document. The software described in it can only be used if
the customer is in possession of a general license agreement or single
license. Using and copying is only allowed in concurrence with the specifica-
tions stipulated in the contract.
Under no circumstances may any part of this document be copied, repro-
duced, transmitted, stored in a retrieval system or translated into another
language without the express written permission of ETAS GmbH.
© Copyright 2023 ETAS GmbH, Stuttgart
The names and designations used in this document are trademarks or
brands belonging to the respective owners.
GETK-P4.0A | User Guide R03 EN -07/2023

3 | Contents
Contents
ETAS GETK-P4.0A | User Guide
1 Basic Safety Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.1 Classification of Safety Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2 Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.3 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3.1 Application areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3.2 Technical Condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4 Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4.1 Installation Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4.2 Securing the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4.3 Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.5 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.6 Electrical Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.6.1 Electrical Safety and Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.6.2 Connection to the power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.6.3 De-energizing the product. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.7 Cables and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.7.1 Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.7.2 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.7.3 Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.7.4 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.7.5 Cleaningl . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.7.6 Repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.7.7 Shipment and Packaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.8 Identifications on the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.9 Fulfilled Standards and Norms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.10 Taking the Product Back and Recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.11 Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.11.1 CE Declaration of Conformity (European Union) . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.11.2 UKCA Declaration of Conformity (Great Britain). . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.12 RoHS Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.12.1 European Union. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.12.2 China . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.13 Declarable Substances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.14 Use of Open Source Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.1 System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.1.1 Data Acquisition for Autonomous Driving ECUs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.1.2 System Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.1.3 Data Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.1.4 Setup Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.1.5 Cascading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2 Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3 Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.1 Architecture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.2 Interfaces Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4 | Contents
ETAS GETK-P4.0A | User Guide
3.2.1 40/100GE Ethernet Interface to Recorder PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.2.2 PCIe1-4 Interface to ECU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.2.3 CAS-IN Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.2.4 CAS-OUT Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.3 LED Display of the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.4 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.4.1 Voltage Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.4.2 Reverse Polarity Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.5 Temperature Control and Restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.6 Operation States . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.6.1 Standby State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.6.2 Operation State. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.7 Control Signals Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.7.1 Wakeup (GPIO_WAKE). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.7.2 /Present.P (/GPIO_ECU_PRST_P) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.7.3 Ready (GPIO_CASC_RDY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.8 Precision Time Protocol (PTP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.8.1 Precision Time Protocol IEEE 802.1AS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.8.2 PCIe Clock and ECU Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.9 Use Case Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.9.1 Measurement Technology Network (MT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.9.2 Measurement Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.10 Application Hints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.11 Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.1 Ventilation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.2 Inserting the Interface Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5 Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.1 IP Address Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.1.1 Fixed IP Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.1.2 Configuring Customized IP Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.1.3 IP Adresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.1.4 Configuring network adapter of Host-PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.1.5 TCP/IP6 configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.2 Firmware Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.2.1 Requirements for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.2.2 Verify the Python Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.2.3 Extract both packages into the same directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5.2.4 Start the processmanager in parallel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5.2.5 Start getkupdate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5.2.6 getkupdate command options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5.2.7 Check communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.2.8 Download the firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.3 Set the alias-name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.4 Web Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.4.1 Web Subpages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

5 | Contents
ETAS GETK-P4.0A | User Guide
6 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
6.1 System Requirements for the ECU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
6.2 Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.3 Mechanical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.4 Power Supply PWR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.4.1 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.4.2 Power Supply PWR Interface Pinning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.5 PCIe 1-5 Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.5.1 Interface Characteristics PCIe 1-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.5.2 Mini-SAS HD PCIe Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
6.6 CAS-IN Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6.6.1 CAS-IN Interface Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6.6.2 CAS-IN Interface Pinning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6.7 CAS-OUT Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6.7.1 CAS-OUT Interface Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6.7.2 CAS-OUT Interface Pinning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6.8 10GE Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.9 40/100GE Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.10 1GE Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.11 USB Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
7 Cables and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.1 Requirements for failsafe Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.2 Power Supply Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.3 Power Supply Cable Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.4 PCIe Gen4 Mini-SAS HD Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.5 Ethernet Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.5.1 1GE: Standard Ethernet Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.5.2 10GE: SFP+ Direct Attached Copper Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.5.3 40/100GE: QSFP28 Direct Attached Copper Cables . . . . . . . . . . . . . . . . . . . . . . . . 44
7.6 CBAV423.1 Chain Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
8 Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.1 GETK-P4.0A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.2 Cable and Adapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.2.1 Power Supply Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.2.2 CBAV423.1 Chain Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
9 Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

6 | Basic Safety Notices
ETAS GETK-P4.0A | User Guide
1 Basic Safety Notices
This chapter contains information about the following topics:
• Classification of Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
• Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
• Intended Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
• Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
• Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
• Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
• Cables and Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
• Identifications on the Product. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
• Fulfilled Standards and Norms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
• Taking the Product Back and Recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
• Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
• RoHS Conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
• Declarable Substances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
• Use of Open Source Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.1 Classification of Safety Messages
The safety messages used here warn of dangers that can lead to personal injury or
damage to property:
1.2 Safety Information
Refer to the following safety instructions and the technical documentation avail-
able to download from the ETAS website www.etas.com. Keep the information pro-
vided in a safe place.
DANGER
indicates a hazardous situation with a high risk of death or serious injury if not
avoided.
WARNING
indicates a hazardous situation of medium risk, which could result in death or
serious injury if not avoided.
CAUTION
indicates a hazardous situation of low risk, which may result in minor or moderate
injury if not avoided.
NOTICE
indicates a situation, which may result in damage to property if not avoided.

7 | Basic Safety Notices
ETAS GETK-P4.0A | User Guide
Failure to comply with the safety instructions may lead to the risk of damage to life
and limb or property. The ETAS Group and its representatives shall not be liable for
any damage or injury caused by improper operation or use of the product.
Only use the product if you have read and understood the information concerning
safe operation and have the required qualifications and training for this product. If
you have questions about safe operation, contact ETAS:
- Technical Support: www.etas.com/hotlines
- ETAS contact partners by region: www.etas.com/contact
The product is only approved for the applications described in the technical docu-
mentation. When using and operating this product, all applicable regulations and
laws must be observed.
ETAS products made available as beta versions or prototypes of firmware, hard-
ware and/or software are to be used exclusively for testing and evaluation pur-
poses. These products may not have sufficient technical documentation and not
fulfill all requirements regarding quality and accuracy for market-released series
products. The product performance may therefore differ from the product
description. Only use the product under controlled testing and evaluation condi-
tions. Do not use data and results from beta versions without prior and separate
verification and validation and do not share them with third parties.
Before starting up the product, check whether there is a Known Issue Report (KIR)
for that product version: www.etas.com/kir (password: KETASIR). Note the infor-
mation given in the report.
Program codes or program control sequences that are created or changed via
ETAS products, as well as all types of data obtained through the use of ETAS prod-
ucts, must be checked for their reliability and suitability prior to use or distribution.
Only use these codes or sequences in public areas (e.g., in road traffic) if you have
ensured that the application and product settings are safe through testing in self-
contained and designated testing environments and circuits.
This ETAS product allows you to influence safety-relevant systems or data (e.g. in
motor vehicles, vehicle components and test benches). In the event of a malfunc-
tion or a hazardous situation, it must be possible to put the system into a safe
state (e.g., emergency stop or emergency operation).
1.3 Intended Use
The product was developed and approved for applications in the automotive sec-
tor. Only operate the product as per its specifications. If the product is used in any
other way, product safety is no longer ensured.
The Gigabit Emulator Probe (GETK-P4.0A) is a measurement technology adapter
for access to vehicle control units. The GETK-P4.0A is designed for recording and
transfer internal data.
1.3.1 Application areas
- The product is approved for use in the following areas:

8 | Basic Safety Notices
ETAS GETK-P4.0A | User Guide
• Interior
• Passenger cell
• Trunk
• Laboratory
• Test bench
- Do not operate the product in a wet or damp environment.
- Do not operate the product in potentially explosive atmospheres.
1.3.2 Technical Condition
The product is designed in accordance with state-of-the-art technology. Only
operate the product and its accessories if they are in perfect working order. Shut
down a damaged product immediately. Do not open or alter the product. Only ETAS
may make changes to the product.
1.4 Assembly
Only install, connect, disconnect, and cable ETAS products and components when
they are de-energized.
1.4.1 Installation Location
Install the product into a rack or on a smooth, level and firm surface.
1.4.2 Securing the Product
The housing must not be damaged while securing the product.
Only secure the product to fastening elements intended for this.
1.4.3 Ventilation
- Protect the product against direct solar radiation and other sources of heat.
- Ensure that there is sufficient air circulation for efficient heat exchange.
• Keep a distance of at least 4 cm to the rear and at least 4 cm to the front.
• Do not cover the ventilation slots.
NOTICE
Damage to the electronics due to potential equalization
The cables' shield may be connected to the housing, the ground or the ground
for the product's power supply. If there are different ground potentials in the test
setup, equalizing currents can flow between the products via the cables' shield.
Take account of different electric potentials in your test setup and take appro-
priate measures to prevent equalizing currents.
WARNING
Risk of injury due to inadequate fastening
- Secure the product so that it does not move uncontrollably.
- Only use carrier systems and fastening materials that can accommodate the
static and dynamic forces of the product and are suitable for the ambient
conditions.

9 | Basic Safety Notices
ETAS GETK-P4.0A | User Guide
• Do not operate the product in enclosed areas.
1.5 Operation
Only operate the product with the latest firmware. You can find information about
updating the firmware in the user manual.
If the firmware update is not completed successfully, try it again. If a new firmware
update is not possible and the product is not functional, send the product to ETAS.
1.6 Electrical Connection
1.6.1 Electrical Safety and Power Supply
- Only connect the product to electric circuits with safety extra-low voltage in
accordance with IEC 61140 (devices of class III) within the voltage limits for
accessible parts as per IEC 61010-1.
- Comply with the connection and setting values (see chapter Technical
Data).
- The power supply for the product must be safely disconnected from the
mains power.
- Only use lab power supplies with dual protection for the supply network
(with double/reinforced insulation (DI/RI)).
- The power supply must be suitable for use according to the ambient condi-
tions for the product.
- It is possible to discharge the vehicle battery in regular operation and long
standby operation.
- Central load-dump protection is required for operation.
WARNING
Undefined vehicle behavior due to critical system error in the ECU
software
Disconnections or faulty communication via the PCIe interface can lead to a crit-
ical system error in the ECU software.
Only use the product with ECU hardware and ECU software that are not prone to
disconnections or faulty communication with the PCIe interface.

10 | Basic Safety Notices
ETAS GETK-P4.0A | User Guide
1.6.2 Connection to the power supply
- Only connect the product to the power supply via a suitable fuse protection.
- Ensure that the connections of the power supply are easily accessible.
1.6.3 De-energizing the product
1. Disconnect the product from the power supply in one of the following ways:
- Switch off the laboratory power supply for the test setup.
- Disconnect the test setup's connection to the vehicle battery.
- Remove the power cord.
2. Remove all cables from the product.
1.7 Cables and Accessories
1.7.1 Cables
- Only use ETAS cables, cables recommended by ETAS or other cables certi-
fied for the application.
- Route the cables such that they are protected against abrasion, dam-age,
deformation and kinking.
- Do not place any objects on the cables.
- Do not use any damaged cables.
- The connector and connection must not be dirty.
- The connector and connection must be compatible.
- Correctly align the connector with the connection.
- Do not connect the connector and connection by force.
1.7.2 Accessories
Use ETAS accessories, accessories recommended by ETAS or other accessories
certified for the application. For detailed information about accessories, see the
product's user manual.
1.7.3 Transport
- Only transport the product individually.
- Remove all connected cables before transportation.
- Do not transport the product by the connected cables.
WARNING
Risk to life from electric shock
If an unsuitable power supply is used, this may generate a hazardous electrical
voltage.
- Use a power supply that is permitted for the product.
- Do not connect the product to power outlets.
- To prevent inadvertent connection to power outlets, use power cords with
safety banana plugs in areas with power outlets.

11 | Basic Safety Notices
ETAS GETK-P4.0A | User Guide
1.7.4 Maintenance
The product is maintenance-free.
1.7.5 Cleaningl
- Only clean the product when it is de-energized.
- Do not use compressed air to clean the fans.
- Do not use cleaning agents that could harm the product.
- Do not apply cleaning agents directly onto the product
- Use a dry or slightly dampened, soft, lint-free cloth.
- Make sure that no moisture enters the product.
1.7.6 Repairs
If repairs are required, send the product to ETAS.
1.7.7 Shipment and Packaging
You will find the hardware return form and the procedure at the ETAS-Website:
www.etas.com/en/support/hw_return_form.php.
1.8 Identifications on the Product
The following symbols are used for identification of the product:
Symbol Description
The User Guide must be read prior to the startup of the prod-
uct!
WEEE symbol, see chapter 1.10 on page 12
CE conformity symbol, see chapter 1.11.1 on page 12
UKCA conformity symbol (Great Britain), see chapter 1.11.2
on page 13)
China RoHS symbol, see chapter 1.12.2 on page 13
Symbol for electrostatic sensitive components
GETK-P4.0A Product designation
F 00K XXX YYY Order number of the product
SN: yyxxxxx Serial number (7-digit)
XXXX/YY Product version
ZZZZ Year of manufacture
ETAS GmbH... Manufacturer's address

12 | Basic Safety Notices
ETAS GETK-P4.0A | User Guide
1.9 Fulfilled Standards and Norms
The module adheres to the following standards and norms:
When using the module outside of industrial environments avoid possible radio
disturbances by additional shielding measures!
1.10 Taking the Product Back and Recycling
The European Union has passed a directive called Waste Electrical and Electronic
Equipment, or WEEE for short, to ensure that systems are setup throughout the
EU for the collection, treating and recycling of electronic waste.
This ensures that the devices are recycled in a resource-saving way representing
no danger to health or the environment.
Fig. 1-1WEEE-Symbol
The WEEE symbol (see Fig. 1-1 on page 12) on the product or its packaging shows
that the product must not be disposed of as residual garbage.
The user is obliged to collect the old devices separately and return them to the
WEEE take-back system for recycling. The WEEE directive concerns all ETAS
devices but not external cables or batteries.
For more information on the ETAS GmbH Recycling software, contact the ETAS
sales and service locations.
1.11 Declaration of Conformity
1.11.1 CE Declaration of Conformity (European Union)
With the CE mark attached to the product or its packaging, ETAS confirms that the
product corresponds to the applicable product-specific European Directives. The
CE Declaration of Conformity for the product is available upon request.
NOTE
For symbols and product information one or several adhesive labels can be used.
Norm Test
EN 61326-11) Electrical equipment for measurement,
control and laboratory use - EMC require-
ments
EN 61000-6-2 Immunity (industrial environments)
EN 61000-6-4 Emission standard (industrial environ-
ments)
IEC 61010-1 Safety requirements for electrical equip-
ment for measurement, control and labo-
ratory use
1)the product is not suitable to be used in DC supply networks.

13 | Basic Safety Notices
ETAS GETK-P4.0A | User Guide
1.11.2 UKCA Declaration of Conformity (Great Britain)
With the UKCA mark attached to the product or its packaging, ETAS confirms that
the product corresponds to the product-specific, applicable standards and direc-
tives of Great Britain. The UKCA declaration of conformity for the product is avail-
able on request.
1.12 RoHS Conformity
1.12.1 European Union
The EU Directive 2011/65/EU limits the use of certain dangerous materials for elec-
trical and electronic devices (RoHS conformity).
This product does not contain any of the restricted substances specified in the EU
Directive 2011/65/EU or exceeds the maximum concentrations stipulated therein.
For individual electronic components used in our products, there are currently no
equivalent alternative substances, which is why we make use of the exception 6a,
7a, 7C-I in Annex III of this Directive.
ETAS confirms that the product corresponds to this directive which is applicable in
the European Union.
1.12.2 China
ETAS confirms that the product meets the product-specific applicable guidelines
of the China RoHS (Management Methods for Controlling Pollution Caused by
Electronic Information Products Regulation) applicable in China with the China
RoHS marking affixed to the product or its packaging.
1.13 Declarable Substances
European Union
Some products from ETAS GmbH (e.g., modules, boards, cables) use components
with substances that are subject to declaration in accordance with the REACH
regulation (EU) no.1907/2006.
Detailed information is located in the ETAS download center in the customer infor-
mation "REACH Declaration" (www.etas.com/Reach). This information is continu-
ously being updated.
1.14 Use of Open Source Software
The product uses Open Source Software (OSS). This software is installed in the
product at the time of delivery and does not have to be installed or updated by the
user. Reference shall be made to the use of the software in order to fulfill OSS
licensing terms. Additional information is available in the document "OSS Attribu-
tions List" at the ETAS website www.etas.com.

14 | Introduction
ETAS GETK-P4.0A | User Guide
2 Introduction
This chapter contains information about following topics:
• System Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
• Product Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.1 System Overview
2.1.1 Data Acquisition for Autonomous Driving ECUs
The GETK-P4.0A (Gigabit Emulator Test Probe PCIe) is a Measurement Interface
for Microprocessors and Microcontroller using PCI Express to access Electronic
Control Units (ECUs). Its key functionality is the fast data acquisition from ADAS-
ECUs and to storing the data on a High-Performance PC.
2.1.2 System Interfaces
To process the ECU data, the GETK-P4.0A connects the ECU microprocessors via
PCIe interface. A GETK-P4.0A ECU Driver must be installed on the ECU as part of
the middleware.
2.1.3 Data Transfer
The measurement data from the ECU will be transferred via Ethernet to one or
more Recorder PCs and/or to one or more Visualization PCs. Often the GETK-P4.0A
is connected to an Ethernet switch. At this switch, several other network devices
can be connected.
2.1.4 Setup Overview
The ETAS software RALO is used to control the setup.
Fig. 2-1GETK-P4.0A RALO overview
Beside the GETK-P4.0A and the ECU, one or more PCs installed in the Measure-
ment (Ethernet) network of the vehicle are necessary for the recording, visualiza-
tion and control, configuration or monitor functionalities.

15 | Introduction
ETAS GETK-P4.0A | User Guide
• Configuration functionality
Allows the user to configure and control one or more measurement ses-
sions and to monitor them and all the ETAS measurement devices
installed in the vehicle.
• Recorder functionality
Used to transfer the data with high-speed from the ECU to the Recorder
PC.
• Visualization functionality
Used to analyze and visualize the data. This can be done online during a
running measurement, or offline after the measurement.
The above functionality can be split onto different PCs.
2.1.5 Cascading
Multiple GETK-P4.0A devices or MDH devices can be added to the measurement
setup as well as connected by the cascading interface.
MHD is a Measurement Interface for capturing Video raw signals.
The cascading interfaces delivers the ECU with basic status information general-
ized for the connected measurement devices.
General signals:
- Wakeup
- Present
- Ready
- Replay mode
When using several GETK-P4.0A devices in the same network, make sure they
have a unique IP -address. See as well “Configuring Customized IP Addresses” on
page 29.

16 | Introduction
ETAS GETK-P4.0A | User Guide
Compatible devices can be added as well and can be integrated into the control
line at CAS-OUT.
Fig. 2-2Cascading of GETK-P4.0A and compatible devices
2.2 Product Features
The GETK-P4.0A provides following features:
- 4 PCIe Gen4 Mini-SAS HD interfaces to the ECU
- Additional control signals for Wakeup and cascading
- 40/100GE high-speed Ethernet connection to the Recorder PC
- 10 GE Interface
- 1 GE Interface
For more technical data on the GETK-P4.0A refer to “Technical Data” on page 34.
Wakeup, Present,
Ready.. .
GETK-P4.0AECU
Dat a
Processing
Unit
40/100 GE
PCIe 4.0
Switch
Microprocessor
1-4
CAS_OUT
PCIe1-4
Ct rl
Ct rl CAS_I N
GETK-P4.0A
Dat a
Processing
Uni t
40/100 GE
PCIe 4.0
Switch
CAS_OUT
1Ct rl
CAS_IN
PCIe1-4
Other device
CAS_OUT Ct r l
CAS_IN
Microprocessor
1-4

17 | Hardware Description
ETAS GETK-P4.0A | User Guide
3 Hardware Description
This chapter contains information about following topics:
• Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
• Interfaces Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
• LED Display of the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
• Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
• Temperature Control and Restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
• Operation States. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
• Control Signals Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
• Precision Time Protocol (PTP). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
• Use Case Measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
• Application Hints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
• Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.1 Architecture
The key functionality of the GETK-P4.0A (Gigabit Emulator Test Probe PCIe) is the
fast acquisition of measurement data from an ECU via PCIe and writing it to a local
harddrive.
Fig. 3-1GETK-P4.0A Architecture
On the four GETK-P4.0A PCIe Mini-SAS HD interfaces, standard PCIe Gen4 Mini-
SAS HD cables are used for the data transfer between ECU and GETK-P4.0A.
The ETAS cable CBAV423 (Cascading) cable is used for control signals and the
connection to additional GETK-P4.0A.
Wakeup, Present,
Ready...
GETK-P4.0AECU
Data
Processing
Unit
40/100 GE
PCIe 4.0
Switch
Power
Power
Supply Ground
Power
Power
Supply
Ground
Microprocessor
PCIe(2)
PCIe(1)
CtrlCtrl Wakeup, Present, Ready... CAS_OUTCAS_IN
PCIe(3)
PCIe(4)
Microprocessor
Microprocessor
Microprocessor
+
‐

18 | Hardware Description
ETAS GETK-P4.0A | User Guide
The GETK-P4.0A is supplied by the ETAS Power cable CBP510 or the Powercable
CBP5105-2.
3.2 Interfaces Overview
The interfaces are listed below:
Fig. 3-2GETK-P4.0A Interfaces
Fig. 3-3GETK-P4.0A Interfaces
Label Interface
Connector type
Connection
USB USB 3.0 (Host) connec-
tion
Reserved for ETAS internal use.
PCIe5 PCIe Gen4 Mini-SAS HD Reserved for ETAS internal use.
10GE 10 Gigabit Ethernet SFP+ To laptop/PC e.g., for monitoring
40/100GE QSFP28 To measurement network(switch) /
Recorder PC

19 | Hardware Description
ETAS GETK-P4.0A | User Guide
3.2.1 40/100GE Ethernet Interface to Recorder PC
The GETK-P4.0A is equipped with a 40/100 Gigabit Ethernet connector for connec-
tion to the measurement network(switch) / Recorder PC
3.2.2 PCIe1-4 Interface to ECU
The four PCIe interfaces are connected to the ECU.
Mini-SAS HD cables for PCIe Gen4 can be used to connect the GETK-P4.0A with
the ECU. All necessary signals between GETK-P4.0A and ECU interfaces are
routed via the Mini-SAS HD adapter. The GETK-P4.0A connects the ECU via its
microprocessor interfaces.
3.2.3 CAS-IN Interface
The CAS-IN interface contains control signals like Wakeup, Present, and Ready
between the ECU and the GETK-P4.0A
1GE RJ45 To laptop/PC for service operations
e.g., FW Update..
PCIe1 PCIe Gen4 Mini-SAS HD To PCIe Interface of ECU
PCIe2 PCIe Gen4 Mini-SAS HD To PCIe Interface of ECU
PCIe3 PCIe Gen4 Mini-SAS HD To PCIe Interface of ECU
PCIe4 PCIe Gen4 Mini-SAS HD To PCIe Interface of ECU
CAS-IN Control signals
LEMO 0B 9pin (A-key)
First GETK-P4.0A to ECU
Cascaded GETK-P4.0A to the previ-
ous GETK-P4.0A
CAS-OUT Control signals
LEMO 0B 9pin (G-key)
To a cascaded GETK-P4.0A
PWR Neutrik 3pin To power supply
WARNING
Undefined vehicle behavior due to critical system faults in the ECU software
Disconnections or faulty communication via the PCIe interface can lead to a crit-
ical system error in the ECU software.
Only use the product with ECU hardware and ECU software that are not prone to
disconnections or faulty communication with the PCIe interface
NOTICE
Damage to the electronics due to potential equalization
The cables' shield may be connected to the housing, the ground or the ground
for the product's power supply. If there are different ground potentials in the test
setup, equalizing currents can flow between the products via the cables' shield.
Take account of different electric potentials in your test setup and take appro-
priate measures to prevent equalizing currents.
Label Interface
Connector type
Connection

20 | Hardware Description
ETAS GETK-P4.0A | User Guide
3.2.4 CAS-OUT Interface
The CAS-OUT interface connects control signals like Wakeup, Present, and Ready
to the next connected GETK-P4.0A.
3.3 LED Display of the System
Fig. 3-4 on page 20 shows the location of the LEDs on the front plate. .
Fig. 3-4GETK-P4.0A Status LEDs
Description of the LED-states
List of the Frontpanel LEDs
Refer to Fig. 3-4 on page 20. .
LED State Description
PWR Off No voltage supplied to the device
On Voltage supplied to the device
ERR Off No error of the device
On Error state of the device.
More information is available with the web
interface
LinkX at PCIE1-4 Off No link, no traffic
Steady on Link established, no traffic
Flashing Link established, data traffic
LED-No. Interface State Color
1.1 SystemError ERR Red
1.2 SystemPower PWR Green
1.3 PCIe5 Act1 Yellow
1.4 PCIe5 Link1 Green
2.1 PCIe5 Act2 Yellow
2.2 PCIe5 Link2 Green
2.3 10GE Link Green
