The CUBEecho™ IP65 HEX is a DMX intelligent LED par light rated for outdoor use.
Unpacking: Thank you for purchasing the CUBEecho™ IP65 HEX light fixture. Every CUBEecho™ IP65
HEX been thoroughly tested and has been shipped in perfect operating condition. Carefully check the
shipping carton for damage that may have occurred during shipping. If the carton appears to be damaged,
carefully inspect your fixture for any damage and be sure all accessories necessary to operate the unit has
arrived intact. In the case damage has been found or parts are missing, please contact the manufacturer
or your dealer for further instructions. Do not return this unit to your dealer without first contacting
them.
Contents in each package: (1) CUBEecho™ IP65 HEX, (1) power cord, (1) Bracket Set, (2) knobs, (6)
washers.
How to put on the bracket: Use 2 washers for each side of the bracket. Save the other 2 washers for
replacements/spares. Put 1 washer on each knob, put knob through the bracket hole(s) and put the
other 1 washer on the other side. Twist knob(s) to the fixture to tighten.
CHARGE YOUR FIXTURE(S) FOR 6-8 HOURS BEFORE EACH USE.Carefully twist off the
cap for the power input. Securely, plug the power cord in the Power Input on the bottom of the light
fixture, and then plug into the charging road case (keeping the lid open while charging) or plug into a
powerstrip connected to a wall outlet that supports 100-220V/50-60Hz. On the top of the fixture, the
Battery Charge Indicator will illuminate Red while charging or illuminate Green when fully charged. If
the fixture turns on when plugged in to charge, turn off the fixture. To do this, press the Menu button
once to activate the display, then press and hold the Up and Enter button at the same time for 10 seconds.
When you release buttons the CUBEecho™ IP65 HEX will now be off. Please visually verify the light is off.
NOTE: The CUBEecho™ IP65 HEX battery will fully discharge after each use. For example a fully charged
light will discharge in the off setting as described above after 5 days, gradually about 20% per day. This is
an important design feature to lengthen the life of the battery. Remember to charge the fixtures before
each use to ensure the fixture is fully charged before event use.
Caution: Never leave lighting fixtures charging unattended.
Caution: There are no user serviceable parts inside this unit. Do not attempt any repairs yourself; doing
so will void your manufactures warranty. In the unlikely event your unit may require service please
contact the manufacturer or your dealer.
How Long Does the Battery Last?
The CUBEecho™ IP65 HEX will last up to 17 hours on a single full charge. It will depend on which LED
colors and how many LED colors are being used and will depend on the intensity level (0-255) scale. The
(0-255) scale you see on the push button display is directly related to the 0-255 scale you are using with a
DMX controller or DMX software.
Example:
Full Red (255) will go about 17 hours
Full Green (255) will go about 14 hours
Full Blue (255) will go about 13 hours
Full White (255) will go about 14 hours

3
CUBEecho™ IP65 HEX Eternal Lighting November 2015
Full Amber (255) will go about 17 hours
Full UV (255) will go about 13 hours
With that being said once you color mix and you use the before stated run times of each color and average
the estimated run time you will be able to calculate about how long a battery with a full charge should
last.
For Example:
2 Colors at Full - Red (255) + Green (255) will go about 7 hours.
3 Colors at Full –Red (255) + Green (255) + Amber (255) will go about 5 hours.
Note: With Color mixing 6in1 RGBWA+UV High Powered 18Watt LEDs. You will find that you typically
only need to mix only 2 or 3 main colors to achieve the desired color.
Keep in mind that a single color at FULL (255) is bright enough so when color mixing…to achieve longer
battery run times, try the following: instead of making the color “Purple” by way of Red (255) + Blue 255)
which will give you about 7.5 hours. Try making “Purple” by way of Red (127) + Blue (128) which will
equal “Purple” (127+128 = 255) which will give you about 14 hours. This will be half as bright as before
at full intensity. However, you will get almost double the battery run time.
Operation Guide: Turn on the fixture by battery or by plugging the power cord into the power input. To
turn on by battery or by power cord, press and hold the Menu and the Down button at the same time for
10 seconds. To turn off the fixture, press the Menu button once to activate the display. Press and hold
the Up and Enter button at the same time for 10 seconds.
Addr
Address: 001-512
chnd
Channel: 3/4/5/6/8/8A/11/13
nanu
Custom Color - R, G, B, W, A, UV (0-255)
Shnd
Color, Auto, Fade
SLnd
Master/Slave Mode
UE 1.0
Run Time Hours and Total Life Hours
btcc
Battery Percentage Indicator
Ir
IR Sensor (On/Off)
UIrE
Wireless Receiver (On/Off)

4
CUBEecho™ IP65 HEX Eternal Lighting November 2015
Id
Wireless ID Code Selector (1-7)
node
6in1 (R,G,B,W,A,UV) or 5in1 (R,G,B,W,A) Mode
Menu:
Addr: DMX Address –Press Enter, then press Up or Down to choose from DMX Address 001-512.
Press Enter to save the command.
Chnd: Channel Mode –Press Enter, then press Up or Down to choose from channel
3/4/5/6/8/8A/11/13. Press Enter to save the command.
nanu: Press Enter, Red will be on the display, press Enter again to adjust 0-255 brightness by
pressing Up or Down. Press Enter to save and press Up to go to Green, Blue, White, Amber, UV.
Adjust from 0-255 to make a custom color. Your custom color will be saved here in nanu.
Shnd: Color, Auto, Fade - Press Enter, then press Up or Down to choose Color, Auto, or Fade.
Press Enter to select choice.
oColor - press Up or Down to choose pre-set color 1-50.
oAuto - press Up or Down to choose the speed of the Auto change of colors. Slow (1) to Fast (8).
oFade –press Up or Down to choose Fade 1 through 10. Fast (1) to slow (10).
SLnd: Master/Slave –Press Enter, then press Up or Down to change the command of Master
(nast) or Slave (SLAu). Enter to save the command. (NOTE: In order to use the IR Remote, put the
CUBEecho™ IP65 HEX in Master Mode. The CUBEecho™ IP65 HEX will not respond to the IR
Remote if it is in Slave Mode.)
UE 1.0: Press Enter to see how long the fixture has been on since turning it on. Press Enter again
to see the total lifetime run hours.
btcc: Battery Percentage Indicator –Press Enter to see the battery percentage indicator. This is
an indicator of the percentage left on the battery on the fixture. Note: the fixture will turn off
anywhere from 10-35% on the btcc.
Ir: IR Remote –Press Enter, then press Up or Down to turn On or Off the IR sensor.
UIrE: Wireless Receiver –Press Enter, then press Up or Down to turn on (U-On) or turn off (U-
OF) the wireless receiver.
Id: Wireless ID Code Selector –Press Enter, then press Up or Down to choose the ID Code. Red
(1), Green (2), Yellow (3), Blue (4), Purple (5), Cyan (6), White (7).
node: Mode (6in1) or (5in1) –Press Enter, then press Up or Down to choose 6in1 (RGBWA+UV)
or 5in1 (RGBWA) mode.
Master/Slave- Have one fixture in Master Mode and the rest of the fixtures in Slave Mode. Turn on the
Wireless Receiver and put all fixtures on same Wireless ID Code Color. You now control the Master
fixture and all the Slave fixtures will do what the Master is doing. On the Master fixture, the display will
have one solid red dot and one blinking red dot.
How to use the XT-Mitter PRO 3.0 with your lights: To operate the XT-Mitter PRO 3.0, you must
connect the XT-Mitter Pro 3.0 with a DMX cable to a DMX Controller.

5
CUBEecho™ IP65 HEX Eternal Lighting November 2015
To sync the CUBEecho™ IP65 HEX to your XT-Mitter PRO 3.0 transmitter, select the same Wireless ID
Code color on all the CUBEecho™ IP65 HEX(s) and select the ID on the XT-Mitter PRO 3.0 to correspond to
the color. Reference the chart below. Note: Transmitter ID 8, 9, A, B, C, D, E & F is inactive. Only Select 1-
7 to coordinate with the Receiver Color on your fixture.
Transmitter
ID
1
2
3
4
5
6
7
Receiver
LED Color
RED
GREEN
YELLOW
BLUE
PURPLE
CYAN
WHITE
Transmission Power Level on XT-Mitter PRO 3.0: Displays current transmission power (1) 2dBm
(Lowest), (2) 8dBm, (3) 14dBm, or (4) 20dBm (Highest). To change the transmission power level, use
the “PA” button located on the front panel. Recommended is P4.
The XT-Mitter PRO will start blinking RED (meaning transmitting signal) and all the Slave fixture(s) will
start blinking GREEN (meaning receiving signal). You will have up to 300 feet, line of sight of
communication with your XT-Mitter PRO and the CUBEecho™ IP65 HEX IP65. Please reference the DMX
chart below for information on the Channel Mode programs.
Infrared remote control: SKU IR Remote Plus (Sold Separately)
To use the IR Remote Plus control on the CUBEecho™ IP65 HEX, first ENABLE the IR located in the MENU
selection. Also, turn the fixture into a MASTER. To control the fixture you must aim the remote at the
infrared sensor located on the top of the fixture by the LEDs.

6
CUBEecho™ IP65 HEX Eternal Lighting November 2015
DMX Values and Functions:
3CH Mode
4CH Mode
5CH Mode
Value
RGBWA+UV 18 Watt x 6in1
CH1
0-255
RED dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH2
0-255
GREEN dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH3
0-255
BLUE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
Value
RGBWA+UV 18 Watt x 6in1
CH1
0-255
RED dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH2
0-255
GREEN dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH3
0-255
BLUE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH4
0-255
WHITE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
Value
RGBWA+UV 18 Watt x 6in1
CH1
0-255
RED dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH2
0-255
GREEN dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH3
0-255
BLUE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH4
0-255
WHITE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH5
0-255
AMBER dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)

7
CUBEecho™ IP65 HEX Eternal Lighting November 2015
6CH Mode
8CH Mode
Value
RGBWA+UV 18 Watt x 6in1
CH1
0-255
RED dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH2
0-255
GREEN dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH3
0-255
BLUE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH4
0-255
WHITE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH5
0-255
AMBER dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH6
0-255
Ultra Violet dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
Value
RGBWA+UV 18 Watt x 6in1
CH1
0-255
RED dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH2
0-255
GREEN dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH3
0-255
BLUE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH4
0-255
WHITE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH5
0-255
Auto (0-10 Off, 11-255 Auto Change Color Snap through the preset colors)
CH6
0-255
Auto Slow to Fast (0-255)
CH7
0-255
R, G, B,W STROBE from slow to fast (0-15 Off, 16-255 Strobe Slow to Fast)
CH8
0
Not Used

8
CUBEecho™ IP65 HEX Eternal Lighting November 2015
8ACH Mode
11CH Mode
Value
RGBWA+UV 18 Watt x 6in1
CH1
0-255
RED (0-255)
CH2
0-255
GREEN (0-255)
CH3
0-255
BLUE (0-255)
CH4
0-255
WHITE (0-255)
CH5
0-255
Amber (0-255)
CH6
0-255
UV (0-255)
CH7
0-255
R, G, B, W, A, UV Master dimmer (0-255)
CH8
0
Strobe (0-255) Slow to Fast
Value
RGBWA+UV 18 Watt x 6in1
CH1
0-255
RED dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH2
0-255
GREEN dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH3
0-255
BLUE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH4
0-255
WHITE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH5
0-255
AMBER dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH6
0-255
R, G, B, W Master Dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH7
0-255
Amber Dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH8
0-255
Auto Program Built in Macro (0-10 Off, 11-31 RED, 32- 53 Green, 54-75
Blue, 76-96 Color Snap White to Amber, 97-119 UV, 120-141 Color
Snap Red to Green to Blue to White, 142-185 Color Snap UV to Yellow,
186-207 Orange as RED/Amber mixed, 208-255 Color Snap Red to
Green to Blue to White to Amber)
CH9
0-255
Auto Speed Slow to Fast (0-255)
CH10
0-255
R, G, B,W, A STROBE from slow to fast (0-255)
CH11
0
Not Used

9
CUBEecho™ IP65 HEX Eternal Lighting November 2015
13CH Mode
Value
RGBWA+UV 18 Watt x 6in1
CH1
0-255
RED dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH2
0-255
GREEN dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH3
0-255
BLUE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH4
0-255
WHITE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH5
0-255
AMBER dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH6
0-255
Ultra Violet dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright)
CH7
0-255
R, G, B, W Master Dimmer (0 Off, 1-255 Dim to Bright)
CH8
0-255
Amber Master Dimmer (0 Off, 1-255 Dim to Bright)
CH9
0-255
Ultra Violet Master Dimmer (0 Off, 1-255 Dim to Bright)
CH10
0-255
Auto Program Built in Macro (0-10 Off, 11-31 RED, 32- 53 Green, 54-75 Blue,
76-96 Color Snap White to Amber, 97-119 UV, 120-141 Color Snap Red to
Green to Blue to White, 142-185 Color Snap UV to Yellow, 186-207 Orange as
RED/Amber mixed, 208-250 Color Snap Red to Green to Blue to White to
Amber, 251-255 Fade Program)
CH11
0-255
Auto/Fade Speed Slow to Fast (0-255)
CH12
0-255
R, G, B,W, A STROBE from slow to fast (0-255)
CH13
0
Not Used
For more information, please contact Support by email at [email protected]
