Ethnicraft OAK DOUBLE EXTENDABLE DINING TABLE User manual

IN YOUR PACKAGE :
ASSEMBLY INSTRUCTION
HARDWARE ( AS LISTED ABOVE)
HARDWARE
SYMBOLS
DIRECTION NUMBER OF
PERSONS NEEDED
OAK DOUBLE EXTENDABLE DINING TABLE
ASSEMBLY INSTRUCTION FOR DINING TABLE INSTALLATION
USE L KEY
USE HAND
PARTS TO BE INSTALLED
1. TOP PANEL 1pc
2. CONNECTING BAR 1pc
3. LEGS 2pcs
LOCK THE TABLE TOP
1
UNLOCK THE TABLE TOP
(4X)
JCBC SCREW
Ø 6 x 6cm
2 3
1 2
NOTICE
X3
SMB NA SEL
YINSTRUCTIO
WHEN LIFTING THE TABLE :
- LIFT ONLY ON THE APRON
- MAKE SURE TABLE IS IN UNEXTENDED POSITION
WHEN LIFTING THE TABLE :
- LIFT ONLY ON THE APRON
- MAKE SURE TABLE IS IN UNEXTENDED POSITION
X
3
USE SCREWDRIVER
1/5
(4X)
JCBC SCREW
Ø 6 x 3cm
TOOLS
L KEY
(Included in package)
SCREWDRIVER
(Not Included in package)
3
2
1
3
(4X)
WASHER
Ø 6
RECOMMENDATION :
In order to avoid colour differences between
the fixed table top and the extensions due to
UV light, we suggest to put your dining table in
extended version during the first month.

ASSEMBLY INSTRUCTION FOR DINING TABLE INSTALLATION
B.
REMOVING THE WOODEN LOCKER
A.
REMOVING THE WOODEN LOCKER
2/5
OAK DOUBLE EXTENDABLE DINING TABLE
Position of
wooden locks
1
2
1
2

ASSEMBLY INSTRUCTION FOR DINING TABLE INSTALLATION
D.
INSTALLING THE TABLE TOP TO THE CONNECTING BAR
MAKE SURE TABLE TOP IS LOCKED POSITION
C.
INSTALLING THE CONNECTING BAR
USE JCBC SCREWS Ø 6 x 6cm
3/5
OAK DOUBLE EXTENDABLE DINING TABLE
2
3
3
21
3
1

ASSEMBLY INSTRUCTION FOR DINING TABLE INSTALLATION
E.
FIXING THE TABLE TOP TO THE CONNECTING BAR
View Without Top Panel
2
Metal
Support
Leg
1
3
4/5
1 2
F.
FIXING THE TABLE TOP TO THE CONNECTING BAR
3
4
- MAKE SURE TABLE TOP IS IN UN-LOCKED POSITION
- USE JCBC SCREWS Ø 6 x 3cm
USE JCBC SCREWS Ø 6 x 3cm
OAK DOUBLE EXTENDABLE DINING TABLE

ASSEMBLY INSTRUCTION FOR DINING TABLE INSTALLATION
1 2
3
H.
DISMANTLING
- UNLOCK BEFORE EXTENDING
- SHOULD BE FULLY EXTENDED
- LOCK AFTER EXTENDING
4
3
4
- UNLOCK BEFORE DISMANTLING
- LOCK AFTER DISMANTLING
G.
EXTENDING
5
5
- BE CAREFUL WITH YOUR HANDS
21
5/5
OAK DOUBLE EXTENDABLE DINING TABLE
