Etnyre Black-Topper Instruction Manual

Supplement to:
Etnyre Black-Topper® Operation, Main-
tenance & Safety Manuals, and
Etnyre Black-Topper® Parts Manuals
Black-Topper®
Enviro-Flush
E. D. ETNYRE & CO. 1333 S. Daysville Road, Oregon, Illinois 61061
Recirculating Flushing System
Parts and Operation
Flow Diagram......................2
Enviro-Flush Instructions.....3
Part No. & Description.........4
Updated April 22, 2014
M-102-25-12R

2
open
1
Flush Tank
Enviro-Flush Valve,
Tank
Enviro-Flush Valve,
Return Line
4-way valve
Transfer Line
Fill Line
Return Valve
Must Be Closed
If Return Valve is open
flushing solvent will be
emptied into asphalt tank
3
2
Enviro-Flush
Recirculating Flushing System Operation
Enviro-Flush
Flow Diagram
Enviro-Flush System
The Enviro-Flush system is a closed system which pulls ushing solvent from the Flush Tank, pumps it through the
circulating system and spray bar and returns the solvent to the Flush Tank.
Complete the appropriate suck back procedure(s) found in your Black-Topper® operation manual.
Flushing Solvent must be in the Enviro-Flush tank for this procedure.
On the cab control panel, turn on the POWER switch and complete the instructions beginning on the next page.
Normally the suckback procedure will remove sufcient material from the circulating system to negate the need for
performing the Enviro-Flush procedure.

3
At the rear control panel:
1. Turn the FUNCTION knob to AUX.
2. Turn the EMERGENCY STOP switch ON.
3. Put the PUMP CONTROL to AUTO.
4. Press START. The pump will start turning at the desired circulation rate (50 GPM).
5. Open all three Enviro-Flush valves in order: The Enviro-Flush Return Valve , then the Strainer Box Valve and
nally the Enviro-Flush Tank Valve .
6. After 1-2 minutes close the Enviro-Flush Tank Valve and then the Strainer Box Valve .
7. Put the PUMP CONTROL to MANUAL to stop the pump.
8. Turn the FUNCTION knob to SUCK BACK.
9. Press START. Turn the PUMP SPEED knob to obtain 50 GPM (conrm rate on display).
10. Press START. The pump will start turning at the desired circulation rate (50 GPM).
11. Open the bleeder valve on the left wing for 1 minute and then close the valve.
12. Open the bleeder valve on the right wing for 1 minute and then close the valve.
13. Turn the FUNCTION knob to HOME to stop the pump.
14. Close the Enviro-Flush Return Valve .
Complete the appropriate suckback procedure(s) found in your Black-Topper® operation manual.
To prevent possible burns from foaming or violent eruption:
Do not transfer the contents of the Enviro-Flush Tank if the material temperature in the Asphalt Tank is over 200ºF or if water
and/or condensation is present in the Enviro-Flush Tank or if emulsion was previously ushed with the Enviro-Flush system.
1
2
3
3
2
1
Recycle Enviro-Flush
NOTE: To stop the pump in MANUAL control select AUTO control. To stop the pump in AUTO control with the PUMP
SPEED knob fully counter clockwise select MANUAL control. The pump can be stopped and the automatic tank valve can
be closed immediately at any time during any operation by turning the EMERGENCY STOP switch OFF. Before turning the
EMERGENCY STOP switch back ON, turn the PUMP SPEED to zero to prevent the pump from turning.
WARNING
Normally the suckback procedure will remove sufcient material from the circulating system to negate the need
for performing the Enviro-Flush procedure. The frequency of recycling the Enviro-Flush spent solvent is then
dependant upon the operator’s use of the suck back feature and the type of material being ushed.
At the rear control panel:
1. Turn the FUNCTION knob to LOAD.
2. Turn the EMERGENCY STOP switch ON.
3. Put the PUMP CONTROL to MANUAL.
4. Press START. Turn the PUMP SPEED knob to obtain 50 GPM (conrm rate on display).
5. Open the Strainer Box Valve and then the Enviro-Flush Tank Valve .
6. When the desired amount of material is removed from the Enviro-Flush Tank close the Enviro-Flush Tank Valve and then
the Strainer Box Valve .
7. Turn the FUNCTION knob to HOME to stop the pump.
8. Rell Enviro-Flush Tank with new solvent.
Complete the appropriate suckback procedure(s) found in your Black-Topper® operation manual.
NOTE: To stop the pump in MANUAL control select AUTO control. To stop the pump in AUTO control with the PUMP
SPEED knob fully counter clockwise select MANUAL control. The pump can be stopped and the automatic tank valve can
be closed immediately at any time during any operation by turning the EMERGENCY STOP switch OFF. Before turning the
EMERGENCY STOP switch back ON, turn the PUMP SPEED to zero to prevent the pump from turning.
NOTE: This procedure will transfer material from the Enviro-Flush Tank to the Asphalt Tank.
On the cab control panel, turn on the POWER switch and complete the following instructions.
2
3
3
2

4
CIRCULATION SYSTEM
Specify Unit Serial No., Part No., & Part Description
24
25
25
26
26
27
28
28
29
29
30
6
7
95
8
4
10
11
12
23
23
2
3
10 11 12
22
14
15
17
18
19
20
21
2
2
3
3
1
10
11
12
13
10
11
31
32
16
REF PART NO. QTY DESCRIPTION REF PART NO. QTY DESCRIPTION
Recirculating Flushing System
1 3342671 1 Return Line with Drain
2 0108687 3 Elbow-Pipe, 1", 90, Street
3 0127874 3 Nipple-Pipe, 1" X Close
4 6600726 1 Valve-Cock, Steam, 1.00"
5 0103389 1 Pin-Cotter, 1/8 X 2
6 S1391AC 1 Crosshaft-Drain Valve
7 C1257AH 1 Bracket-Mount, Lever
8 C1257AJ 1 Decal-Drain Valve
9 C1257AG 1 Lever-Drain Valve
10 6601565 4 Hose End-1.00"NPT
11 6000792 4 Hose Clamp, Screw Type, MS, 1.00
12 6601564 20' Hose-1.00", Suction
13 3342678 1 Suction Strainer Box, Recirc
14 6601307 1 Gauge-Liquid, 14" Tank
15 6100235 1 Filler Cap
16 0108686 1 Elbow-Pipe, 0.50" NPT, PN
17 S1495AD 1 Flushing Tank
18 0121900 16 Screw-Hex, 0.25 X 1.00, GR2, PD
19 0120386 32 Washer-Flat, 0.24
20 9413946 16 Nut-Hex, Lock, 0.25NC
21 C1257AC 2 Gasket-Flange
22 6600162 1 Drain Cock-0.25"
23 6601177 2 Valve-Buttery, 1.00" NPT
24 2610041 2 Bracket Asm-Mtg, Fuel Tank
25 0122459 4 Screw-Hex, 0.50NC x 2.00, GR2, PD
26 9411727 4 Nut-Hex, Lock, 0.50NC EA, PD
27 3311022 2 Band-Support, Fuel Tank
28 9413948 4 Nut-Hex, Lock, 0.62NC, EA, GRA, PD
29 9422850 4 Washer-Flat, 0.62A (0.65 x 1.31)HN
30 3360726 4 Bolt-Hook, Bit, Frame Truck
31 6600663 1 Hose End-08 x 08 ST, LPSP
32 6600662 2' Hose-0.50"
3360180 1 Plate-Fill with Diesel Fuel Only
(Not Shown)
AR = As Required
