ETT McShine FL-1815 User manual
EN
Made by ETT Distribution GmbH, Schmalbachstraße 16, 38112 Braunschweig
Reprinting or reproduction only with express permission.
Item number: 1452931
Instruction manual
Status: 08/2023
TECHNICAL DATA
Operating voltage: 220 – 240 V
Light color: neutralwhite
Color temperature: 4000 K
Absorbed power: 40,30 W
Lifetime: 30000 h
Illumination technology: LED
Length: 1480 mm
Width: 72 mm
Height: 61 mm
Energy efciency class: This product contains a
light source of
Energy effciency class C
Dimmable: no
Protection class: IP65
LED Damp Proof Light
McShine „FL-1815“
IP65, 7.200lm, 4000K, 40W, 180lm/W
EN
Item number: 1452931
Status: 08/2023
DISPOSAL INSTRUCTIONS
By separating materials, recycling and disposing of old equip-
ment in this way, you are making an important contribution
to protecting our environment.
Packaging can be disposed of free of charge at the appro-
priate collection points:
• Paper in the paper bin
• Plastics in the yellow bag
• Glass in the used glass container
WEEE DISPOSAL NOTE
According to the European WEEE Directive, electrical and
electronic WEEE Directive, electrical and electronic equip-
ment must not be disposed of with household waste.
Their components must be recycled or disposed of separa-
tely, because toxic and hazardous components can cause
lasting damage to health and the environment if disposed of
improperly.
As a consumer, you are obliged under the Electrical and
Electronic Equipment Act (ElektroG) to return electrical and
electronic equipment free of charge at the end of its service
life to the manufacturer, the point of sale or to public collec-
tion points set up for this purpose.
Details are regulated by the respective state law.
The symbol of the wheeled garbage can on the product, the
operating instructions and/or the packaging refers to these
regulations. regulations.
INSTALLATION
• Turn off the circuit‘s fuse! Verify the absence of voltage
using an appropriate measuring device.
• Mark the mounting holes for the two mounting brackets.
• Drill the holes while adhering to the safety instructions.
• The mounting brackets can now be installed on the
ceiling/wall using anchors and appropriate screws.
• Open the cable gland and the plastic lamp cover by
releasing the lamp clips. The connecting cable must be
threaded through the designated hole into the interior of
the luminaire.
• For connecting the power cable, use the terminal block
inside the device.
• Please connect the product‘s power cable to the mains
cable following this rule:
L to L, N to N, green-yellow to green-yellow.
• Tighten the cable gland securely.
• Reattach and secure the lamp cover onto the housing
using the lamp clips.
• Press the lamp into the mounting brackets on the ceiling.
• Turn the circuit‘s fuse back on and test the
lamp‘s functionality.
• Up to 11 luminaires can be connected in parallel.
SAFETY INSTRUCTIONS
• Please inspect the device for any damage before operation.
If this is the case, please do not put the device into
operation.
• Please note that any technical modications to the device
immediately void the device‘s approval!
• Keep the user manual of the device.
• When drilling, protect your eyes with safety goggles!
• Wearing gloves is prohibited during drilling operations!
• The glove could get caught in the rotating drill.
• When working with 230 V, please strictly adhere to the
accident prevention regulations.
• Do not short-circuit the connections and circuits.
• The installation must only be carried out by qualied
personnel.
• Do not drop the device. It could be damaged upon impact
with a hard surface.
• Avoid installation in places with signicant temperature
differences or high humidity.
• Do not leave the packaging materials lying around
carelessly; plastic foils/bags, Styrofoam parts, etc., could
become hazardous toys for children.
• The device is not meant for children, it is not a toy!
INTENDED USE
• The product is dustproof, IP65 rated, and suitable for use in
damp environments.
• The product may only be used for its intended purpose, as
outlined in this user manual!
GENERAL INSTRUCTIONS
• Only use supplied original parts.
• The product has no replaceable parts.
• Do not attempt to open or repair the product.
Made by ETT Distribution GmbH, Schmalbachstraße 16, 38112 Braunschweig
Reprinting or reproduction only with express permission.
1 2
3 4
65
Made by ETT Distribution GmbH, Schmalbachstraße 16, 38112 Braunschweig
Reprinting or reproduction only with express permission.
Item number: 1452931
Status: 08/2023
7 up to 11 luminaires in parallel
EN
