Etymotic BlastPLG EB1 User manual

ETYMOTIC RESEARCH INC.
61 Martin Lane • Elk Grove Village, IL 60007
www.etymotic.com 1-888-389-6684 847-228-0006
©2010.BlastPLG a d Musicia s Earplugs are trademarks of Etymotic Research,I c.
ER098518
Etymotic will repair or replace the defective product at its optio if
retur ed withi o e year of purchase to our desig ated service
facility. This warra ty is i lieu of all other warra ties,expressed or
implied,i cludi g,but ot limited to,a y implied warra ty of
mercha tability or fit ess for a particular purpose.
Warran y

User Manual

2
In roduc ion
he High-Fidelity Electronic BlastPLG™ Earplug was
developed by Etymotic Research to mitigate hearing
damage and tinnitus sustained by an alarmingly high
percentage of deployed soldiers. Despite risks to
hearing from loud machinery and blasts, most
warriors decline to wear hearing protection because
they find it interferes with situational awareness.
he there are two versions of BlastPLG Earplug, the
EB1 and the EB15. Both versions are designed to
restore sound that is blocked when the ear canal is
sealed. Both allow you to hear naturally, as though
there were nothing in the ear, and both prevent ear
damage from loud impulse noise.
EB1 is a good choice for hunters who want to hear
naturally and be protected from sudden firearm
blasts when there isn’t time to insert hearing
protection. Increased loudness can be selected which
boosts the faint sounds of speech and improves
hearing at a distance. Additional clarity is built in for
high-pitched sounds which are most difficult to hear.

3
EB15 is for persons who operate some or most of
the time around continuous loud noise such as
machinery, trucks, or construction equipment and
want both blast protection and natural hearing when
no background noise is present.
Both versions use a new adaptation of the original
high-fidelity K-AMP®integrated circuit. he EB1
permits natural hearing until a blast occurs. EB1 has
a switch to boost faint sounds if desired. EB15
circuitry is configured to protect the user in loud
continuous noise from machinery and vehicles and
from unexpected impulse noise such as gunfire and
explosions. When no loud noise is present, the EB15
returns to natural hearing, as if nothing is in the ear
to block sound. he EB15 also has a switch to boost
faint sounds.
With practice, most users should experience normal
situational awareness: Normal detection and normal
ability to determine where a sound is located.

4
E ymo ic Research Inc.
For over 25 years, Etymotic Research has designed
innovative products to measure, enhance and protect
hearing. Etymotic has contributed many of the major
breakthroughs in hearing devices and consumer
products available today, including advanced hearing
aid circuitry, directional microphones and Musicians
Earplugs™. Etymotic is the original inventor of
noise-isolating in-ear earphones.

5
• he EB1 is made from materials and components
that are standard in hearing aids and hearing
protection devices.
• Allergic reactions are uncommon. If redness,
soreness or other adverse reactions occur,
discontinue use and contact a medical practitioner.
• Do not shower or swim while wearing the device.
• Do not put batteries in your mouth.
• Batteries may be harmful if swallowed.
• Keep batteries out of the reach of children.
Precau ions

6
Iden ifica ion
Pouch
Cleaning
ool
Filter tool and extra
filters
312 Batteries
Headband
Eartip
Battery Door
2-position
Switch
Remova Cord

7
Ba ery Inser ion
Low Battery Warning
he EB1 has an audible low battery warning that
alerts you when the battery is about to die. he
signal starts as a slow ticking sound that becomes
louder, faster and higher in pitch as the battery nears
its end of life. EB1 performance is not altered when
the warning is heard.
1. Remove the tab on the battery before inserting
it in the EB1.
2. he battery door will not close if the battery is
not inserted correctly.

8
Ear ips
Se ecting an eartip:
he eartip that is most comfortable is the likely
choice but it MUS SEAL well. If you can easily
hear others with the device turned off (battery door
open) you don’t have a good seal. wist it in deeper,
or choose another eartip.
When changing eartips make sure the eartip fits
secure y on the stem of the EB1.
correct incorrect
Lg. 3-flange Sm. 3-flange Foam Glider Sm. Foam
Eartips

9
Inser ion & Removal
Inserting the EB1
• Pull the ear up and out while
inserting.
•
wist and push gently
until the eartip seals in
the ear canal.
• When first using one of the
3-flange eartips, moistening
slightly may ease insertion.
Removing the EB1
• Remove the device with a slow twisting motion.
Wind Noise
he EB1 includes a headband to wear over the
earplugs if wind noise interferes with performance.

10
Opera ion
ON/OFF
he EB1 turns on and off by opening and closing
the battery door. Note: It is not necessary to
remove the battery as long as the door is open
wide enough to disable the circuit.
Switch
LO position: Automatic 2-stage action
• Natural hearing for faint and loud sounds
• Maximum protection from blasts
HI position: Automatic 3-stage action
• Boost for faint and conversational sounds
• Natural hearing for loud sounds
• Maximum protection from blasts
2-position Switch
oward battery door = LO position
Away from battery door = HI position
Battery Door
Open = OFF
Closed = ON

11
Changing Fil ers
he BlastPLG Earplug has a special filter that
enhances sound quality and prevents earwax from
entering the device. A filter should be changed if the
volume decreases or the sound quality declines.
Filter Removal Note: Use the tool to remove the filter.
Filter Replacement Note: Do not use the tool to replace the filter.
1.Remove Eartip. 2.Insert tool into
the filter.
3.Remove filter.
1. Insert a new filter and press
gentl against a hard surface
to secure it in place.
2.Re-attach eartip.

12
Trouble Shoo ing
Prob em: No sound
What to do:
• Check to see if the battery door is closed
(EB1 turned on).
• Check battery; replace if dead.
• Clean the eartip and the end of the EB1.
• Check the filter
- remove the filter
- listen for sound to return before replacing
the filter
• If sound returns replace the filter.

13
Simple cleaning with the tool provided will keep
the eartip clean and the EB1 working properly.
• Use the cleaning tool to pick out or brush off debris.
• he 3-flange eartip can be removed and cleaned
in mild detergent. Dry the eartip thoroughly
before reattaching it.
• Foam and glider eartips should be replaced as
needed. hey are not reusable.
• Do not use alcohol to clean the device.
• Remove the device before using hair products.
• Do not expose to extreme heat or moisture.
• Avoid dropping or hitting the device on a hard
surface.
Cleaning ool
Care

14
Specifica ions
Switch: LO

15
Specifica ions
Switch: HI
