Eureka MAGNUM EB Programming manual

MAGNUM EB
“BATTERY POWERED”
BASIC OPERATION, MAINTENANCE &
TROUBLESHOOTING MANUAL
__________________________________________________
EUREKA S.r.l.
Via dell’Industria 32, 35013 CITTADELLA (PD) ITALY
Tel. ++39 - 049 - 9481800 Fax. ++39 -049 –9481899
INTERNET: www.eurekasweepers.com E-MAIL: inf[email protected]

2
TABLE OF CONTENTS
TOPIC
1. INTRODUCTION
2. GENERAL NOTE
3. WARNINGS AND RECOMMENDATIONS
4. THE DASHBOARD
5. BASIC OPERATING CONTROLS
6. DANGER AND OBLIGATION SYMBOLS
7. USE AND MAINTENANCE OF THE SWEEPER
STARTING THE ENGINE
STARTING THE FUNCTIONS
TURNING OFF THE MACHINE
MOVING THE MACHINE
PARKING BRAKE
SERVICE BRAKE
EMERGENCY BRAKE
REPLACING THE FUSES
SIDE BRUSH CONTROL
ADJUSTING THE SIDE BRUSH
REMOVING THE SIDE BRUSH
RE-INSTALLING THE SIDE BRUSH
THE MAIN BRUSH
REPLACING THE MAIN BRUSH
REPLACING THE RUBBER FLAPS ( RIGHT AND REAR )
REPLACING THE RUBBER FLAPS ( LEFT SIDE )
REPLACING THE FILTERS
CHECKING THE HYDRAULIC OIL LEVEL
REPLACING THE HYDRAULIC OIL FILTER
CHARGING THE BATTERY
TOWING THE MACHINE
MOVING THE MACHINE WHEN ENGINE IS OFF
EMERGENCY CASES
WASTE MATERIAL
VIBRATIONS
NOISE LEVEL
8. PLANNED MAINTENANCE CHART
9. TROUBLE-SHOOTING AND ALARMS GUIDE
10. THE OPTIONAL POLYESTER BAG FILTER
11. PRODUCT WARRANTY
12. INSTALLATION FORM
PAGE
3
3
3
4
5
5
6
6
6
6
6
6
6
6
6
7
7
7
7
7
8
8
8
9
9
9
9
10
10
10
10
11
12-13
14
15
16
LAST UPDATE 16-07-08

3
INTRODUCTION
“EUREKA S.r.l.” , leader manufacturer of sweeping machines, is pleased to welcome you as an owner of the “ MAGNUM EB”
sweeper. We are sure that its use will give you great satisfaction and that while working with the MAGNUM EB you will have the
opportunity to appreciate its quality, robustness, and versatility. The MAGNUM EB” is suitable for the cleaning of medium to large
areas, for private, industrial and public use. In this handbook are described and shown various operations of installation, control and
maintenance, necessary to keep your MAGNUM EB in perfect working condition. These are normal maintenance operations, which
any operator can carry out with tools normally available. For additional maintenance operations you should contact your nearest
EUREKA service point.
BEFORE USING THE MACHINE, CAREFULLY READ THIS MANUAL AND KEEP IT WITHIN EASY REACH FOR
FURTHER CONSULTATION.
The observance of the instructions given in this manual, and a careful operator, are the best guarantee against accidents which may
occur while working with the machine. The sweeping machines produced by EUREKA are designed according to the latest safety
requirements, but they must be used following these instructions.
GENERAL NOTE
All information contained in this manual is current at the time of printing. However, due to constant updates and improvements, we
reserve the right to make changes at any time without notice
WARNING AND RECOMMENDATIONS
IMPORTANT POINTS FOR THE SAFETY OF ALL THE PEOPLE INTERESTED IN THE USE OF THIS SWEEPER
“MAGNUM EB”.
THE SWEEPER HAS BEEN DESIGNED FOR THE CLEANING OF DRY FLOORS.
DO NOT WORK IN THE PRESENCE OF TOXIC POWDERS.
DO NOT WORK IN ENVIRONMENTS WHICH MAY BE UNDER RISK OF EXPLOSION.
DO NOT COLLECT MATERIAL AND ALL THAT MAY LEAD TO FIRE (FOR EXAMPLE LIGHTED CIGARETTES)
NEVER ALLOW ANYONE TO ENTER THE SWEEPER’S OPERATING AREA.
NEVER LEAVE THE SWEEPER WITH THE ENGINE RUNNING ; TURN THE ENGINE OFF AND TAKE THE KEY AWAY.
NEVER OPEN THE PROTECTIVE COVERS WHEN THE SWEEPER IS RUNNING.
MAINTENANCE OPERATIONS SHOULD ONLY BE CARRIED OUT WITH THE ENGINE TURNED OFF.
ONLY OPERATE THE SWEEPER FROM THE DRIVING SEAT.
DO NOT ATTEMPT TO WORK ON SLOPES WHOSE GRADIENTS EXCEED THE VALUE SHOWN ON THE TABLE.
DO NOT USE THE MACHINE FOR THE CLEANING OF OBJECTS.
THE MAIN BRUSH MUST NOT SWEEP UP WIRES, ROPES, OR ANY OTHER LONG MATERIAL THAT MAY GET
TANGLED WITH IT.
DO NOT CARRY OUT ANY MODIFICATION TO THE MACHINE WITHOUT OUR PREVIOUS AUTHORISATION.
THE SWEEPER IS NOT OMOLOGATED FOR USE ON PUBLIC STREETS.
DUMPING OPERATIONS MUST BE MADE ONLY AND SOLELY WHEN THE SWEEPERS IS IN HORIZONTAL
POSITION, MAKING SURE THAT THE FLOOR IS NOT DISJOINTED.
N.B. EUREKA S.R:L. DECLINES ALL RESPONSIBILITIES FOR ANY DAMAGE TO PERSONS AND/OR PROPERTIES CAUSED
BY FAILING TO OBSERVE THE ABOVE WARNINGS OR AS A CONSEQUENCE TO THE INAPPROPRIATE OR INCORRECT
USE OF THE SWEEPER.
The sweeping machines manufactured by EUREKA follow the CE directory and show the label :

4

5
MAGNUM “EB” – MAJOR COMPONENTS
THE DASHBOARD
PIC. A
1. KEY SWITCH
2. PRIMARY MOTOR SWITCH
3. SECONDARY MOTOR SWITCH
4. HOUR METER
5. HYDRAULIC OIL TEMPERATURE WARNING LIGHT
6. BATTERY CHARGE INDICATOR
7. HEADLIGHTS & HORN SWITCH
8. FILTER-SHAKER BUTTON
9. MAIN BRUSH WARNING LIGHT
10. SIDE BRUSH MOTOR FUSE
11. SIDE BRUSH WARNING LIGHT
12. HOPPER FIRE DETECTOR WARNING LIGHT (OPTIONAL)
13. SIDE BRUSH LEVER
14. MAIN BRUSH LEVER
15. HOPPER DOOR CLOSE-OPEN LEVER
16. HOPPER UP-DOWN LEVER
17. CLOSED HOPPER DOOR WARNING LIGHT
18. MAIN BRUSH ADJUSTING KNOB
19. VACUUM CUT-OFF LEVER

6
BASIC OPERATING CONTROLS
HOUR METER: Indicates the total running hours of the machine (n° 4 pic. A).
HYDRAULIC OIL TEMPERATURE WARNING LIGHT: If the temperature of the hydraulic oil in the tank exceeds
83° - 88°C the warning light will show. (n° 5 pic. A). IMPORTANT! You must stop the machine.
BATTERY CHARGE INDICATOR: It indicates the remaining level of charge of the battery ( n°6 - pic.A ). You may work
while the green light is on. The yellow light indicates that you should re-charge the battery. When the red light shows, stop the
machine immediately or the battery could get damaged irreversibly.
Besides the sweepers includes as standars an acoustic alarm (signal for low charge of battery). (See alarms - page 13)
HEADLIGHTS & HORN SWITCH
By turning the knob (n° 7 pic. A) clockwise, the headlights will switch-on.
To use the horn, press down the knob.
FILTER-SHAKER FUNCTION: The working efficiency of the Magnum is greatly influenced by the state of cleanliness
of the filters; we therefore recommend to shake them frequently, especially if the area to be cleaned is particularly dusty.
TO SHAKE FILTERS:
Turn the key (n° 1 fig. A) to position 1.
Press the filter-shaker button (n° 8 fig. A) for 5 10 seconds.
Repeat this operation a few times.
NOTE: Before shaking the filters, you must turn the secondary motor ( n°3 pic.A ) off.
SAFETY FUSE FOR SIDE BRUSH MOTOR: It stops the side brush to prevent damages to the motor.
RE-SET OPERATIONS:
After the brush stops, wait a few minutes, then:
Press the fuse rubber cap n° 10 fig. A.
The side brush should rotate.
NOTE! If the side brush stops again, please check if there is anything tangled in it. Then, clean it and repeat above operations.
FIRE DETECTOR WARNING LIGHT (optional) : It flashes (n° 12 fig. A) and activates an acoustic signal when temperature
in the hopper exceeds 60°C.
NOTE! When this situation occurs, close immediately the vacuum (n° 19 Fig. A) and the rubbish box (n° 15 Fig. A). Then move
the sweeper away from dangerous areas. Open the inspection door of the hopper and in case of fire extinguish it by mean of a
DRY FIRE EXTINGUISHER
DUMP DOOR WARNING LIGHT: Warning light will show when the dump door is closed.(n°17 fig. A).
MAIN BRUSH PRESSURE ADJUSTMENT KNOB:
TO INCREASE PRESSURE: turn the knob (n° 18 pic. A) counter-clockwise.
TO DECREASE PRESSURE: turn the knob (n° 218 pic. A) clockwise.
VACUUM CUT-OFF: The vacuum-fan should be turned off (n°19 fig. A) when sweeping on wet areas, in order to protect
the filters. It should be also turned off when shaking the filters.
DANGER AND OBLIGATION SYMBOLS
DANGER SYMBOL.
WARNING: very hot surfaces
OBLIGATION SYMBOL.
WARNING: Use adequate acoustic protection.
In a number of working environments, sweepers might
generate an acoustic danger which can be eliminated with
adequate acoustic protection .

7
USE AND MAINTENANCE OF THE SWEEPER
Eureka sweepers should never be operated unless the operator is trained and authorised to operate the equipment and the sweepers are free of
malfunctions. Malfunctioning equipment should be removed from service.
STARTING THE MACHINE
Before starting the machine, make sure that main brush and side brushes are raised from
the ground.
The operator must sit down on the machine’s seat.
NOTE! The seat is equipped with a micro-switch which cuts off all functions if the
operator is not sat on it.
Turn the ignition key clockwise to position 1 ( n°1 –pic.A )
Switch on the primary motor switch ( n°2 –pic.A )
THE MACHINE IS READY TO MOVE
STARTING THE FUNCTIONS
The operator must sit down on the machine’s seat.
NOTE! The seat is equipped with a micro-switch which cuts off all functions if the
operator is not sat on it.
Turn the ignition key clockwise to position 1 ( n°1 –pic.A )
Switch on the secondary motor switch ( n°3 –pic.A )
THE MACHINE IS READY TO WORK
TURNING OFF THE MACHINE
Disengage the switches n° 2-3 pic.A
Turn the ignition key counter-clockwise ( n°1 –pic.A ) to position 0
PIC. B
1. FWD\REV SPEED LEVER
2. PARKING BRAKE
3. EMERGENCY BRAKE
4. ACCELERATOR PEDAL
5. FUSES
6. HYDRAULIC DAMPER
MOVING THE MACHINE
FORWARD: pull-up the lever n°1 then press the accelerator pedal n° 4
REVERSE: pull-down the lever n° 1 then press the accelerator pedal n° 4
NOTE! Stop the machine before changing speed direction.
PARKING BRAKE
To engage it, push down the button then pull-up the lever n° 2
SERVICE BRAKE
The service brake is engaged each time the accelerator pedal is released ( n° 4 )
EMERGENCY BRAKE
To stop the machine in case of emergency, press the pedal n°3
REPLACING THE FUSES
( N° 5 )
Remove the clamps from the battery ( n°4 –pic.H ).
Remove the metal protection.
Replace the fuse.
Re-assembly the unit.
NOTE! DON’T CHANGE THE AMPS. VALUE OF THE FUSE.

8
PIC. C
1. SIDE BRUSH DRIVE SHAFT
2. SIDE BRUSH
SIDE BRUSH CONTROL
The side brush can be raised or lowered by mean of the lever n°13 pic. A.
NOTE! The side brush will rotate when:
1. The hopper is down and the lip is open;
2. The main brush lever (n°14 pic. A) and side brush lever ( n°13 pic: A ), are
lowered.
ADJUSTING THE SIDE BRUSH
INCREASE PRESSURE: turn the handle of lever ( n°13 pic. A ) counter-clockwise.
DECREASE PRESSURE: turn the handle of lever (n°13 pic. A) clockwise.
REMOVING THE SIDE BRUSH
Raise the brush (lever n°13 pic. A)
Hold the brush with both hands and turn it counter-clockwise (pic. C.)
RE-INSTALLING THE SIDE BRUSH
Match the side brush hub in the drive shaft (n° 1 pic. C)
Push it up and turn it slowly clockwise to match the seats.
Now turn it until completely connected.
PIC. D
1. MULTI-PURPOSE KEY
2. METAL RING
3. MAIN BRUSH
4. SUPPORT (RIGHT)
MAIN BRUSH
The main brush can be raised or lowered by mean of lever n° 14 pic. A.
NOTE! The main brush will rotate only when:
1. The hopper is down and the lip is open;
2. The main brush lever (n° 14 pic. A) is lowered.
REPLACING THE MAIN BRUSH
The motors must be turned off.
The hopper must be lowered: lever n°16 pic. A.
Hopper lip must be open:lever n°15 pic. A.
Main brush lever n°14 pic. A. must be lowered
Turn the starting key to position 1 (n°1 pic. A.)
Turn the adjustment knob completely (n°18 pic.A) clockwise, then counter-clockwise
3 turns.
Open the rear panel (n° 7 pic. G) and take the multi-purpose key (n°1 pic. G.)
Open the bottom metal right panel.
Remove the metal ring n°2 pic. D.
Remove the support n°4 pic. D, and the brush n° 3 pic. D.
Replace the brush, then re-assembly the unit making sure to set the brush lever and the
starting key at their original position.
Adjust the clean path (max 50 –60 mm) of the brush by turning the knob ( n° 18 pic.A)

9
PIC. E
1. RIGHT SIDE RUBBER FLAP
2. REAR RUBBER FLAP
REPLACING THE RUBBER FLAPS
(RIGHT AND REAR)
Open the rear panel (n° 7 pic. G)
Take the multi-purpose key (n°1 pic. G.)
Open the bottom metal right panel
Hook the key to the flaps then pull as indicated in pic. E.
Replace the flaps.
Insert the new flaps in the correct brackets.
REPLACING THE RUBBER FLAPS
(LEFT SIDE)
Open the rear panel (n° 7 pic. G)
Take the multi-purpose key (n°1 pic. G.)
Open the bottom metal left panel
Remove the 2 metal locking rings.
Replace the flap, then re-assembly the unit.
PIC. F
1. PANEL FILTER
2. LOCK NUTS
3. SPRINGS
4. LOCK PLATE
5. LABEL
6. FILTER
7. FILTERS GASKET
REPLACING THE FILTERS
Shake the filters throughout
Open the front hood
Remove the lock nuts (n° 2 pic. F) and the springs (n°3 pic. F).
Remove the lock plate (n° 4 pic. F).
Replace the filters (n° 6 pic. F).
Make sure both filters and gaskets (n°7 pic.F) are fitted properly in their seats.
Re-assembly the unit by locking the nuts, then press the springs as indicated on label
(N° 5 PIC. F).

10
PIC. G
1. MULTI-PURPOSE KEY
2. AIR EXHAUST FILTER
3. PLUG - HYDRAULIC OIL TANK
4. HYDRAULIC OIL LEVEL GAUGE
5. HYDRAULIC OIL FILTER
6. RIGHT PANEL
CHECKING THE HYDRAULIC OIL
LEVEL
Check periodically (every 100 hours) the oil level (n°4 pic. G).
If level is low, add oil (plug n° 3 pic. G) up to the middle of indicator (n° 4 pic. G).
In case of leaks, consult a service centre.
REPLACING THE HYDRAULIC OIL
FILTER
Remove the right panel n°6 pic. G.
Replace the filter (n°5 pic. G).
PIC. H
1. FUSE 80 A
2. FUSE 100 A
3. LEFT SIDE PANEL
4. BATTERY CONNECTOR
5. BATTERY
6. ELECTRONIC CARD
CHARGING THE BATTERY
Turn off the sweeper
Open the rear hood ( n°7 –pic.G )
Disconnect the connector n°4 and connect the battery charger connector
Read the battery charger instruction manual for a correct use of the charger
The rate of charge should not exceed 1/20 of the battery capacity
After charging the battery, check the acid level and top up if necessary
Connect the mobile connector n°4 into the fixed connector
NOTE:
Batteries must be charged in ventilated places.
The gas generated during charging operations may produce explosions when in
presence
of flames or sparks.
The battery acid must not come in contact with eyes, skin, clothes, painted or zinc
coated
surfaces.
Should this happen, wash off the acid with water.
Do not lean metallic objects over the batteries.
Remove all caps from the various battery cells before charging the battery.
Do not top up with sulphuric acid.

11
PIC. I
TOWING THE MACHINE
Remove the foot panel n° 1.
Release the bolt n° 2.
Remove the chain joint n° 3.
Remove the chain n° 4 .
Re-assemble the foot panel n°1.
Tow the machine without exceeding speed of 3 –
4 Km/h.
MOVING THE MACHINE WHEN ENGINE
IS OFF
Push the sweeper only for a short distance (about 3 m), or until it stops. Wait 1 min then
repeat
EMERGENCY CASES
Strictly observe the following instructions :
In the event of fire, use only powder fire extinguishers.
In the event of unusual failures (engines or motor overheating, etc.) turn off immediately
the machine
WASTE MATERIAL.
For the dumping of waste material such as oil, plastic part, batteries, packing boxes, please
contact those facilities authorised for the dumping of special waste.
VIBRATIONS
The level of vibration to which the operator is subjected is below the maximum level
allowed by the CE DIRECTORY for industrial machinery ( CEE 89\392 ).
NOISE LEVEL
NOISE LEVEL IN OBSERVANCE OF ISO 3744:
Acoustic pressure medium level Lpm= 73 Db
Acoustic power level Lwa= 87 Db
Guaranteed acoustic power level Lwa,g = 90 Db
Acoustic pressure level (from operator’s ear ): 72 Db

12
PLANNED MAINTENANCE CHART
INTRODUCTION
Regular maintenance on your sweeper results in better cleaning, faster cleaning, and a prolonged service life for the equipment and
components. This section contains the following information to help you give your sweeper the maintenance attention it requires.
WARNING: never attempt to perform any service on the equipment or components until the machine is OFF, the parking brake is
LOCKED, the wheels are CHOCKED, the battery clamps are DISCONNECTED
WARNING: The safety parts and devices must not be tampered with. They can be removed only when executing maintenance
operations and by Authorised Service Centres ( ASC ).
FREQUENCY ( IN HOURS )
SERVICE
DAILY
50
100
200
300
500
1000
2000
X
X
X
ELECTRICAL SYSTEM
Check electrolyte level in starting battery and fill as needed
Check state of wear of electric motor carbon brushes
Clean air intakes of electric motors
X
HYDRAULIC SYSTEM
Check hydraulic fluid level and fill as needed
ACS
REPLACE hydraulic fluid
ACS
ACS
REPLACE filter ( 1st time )
REPLACE filter
X
SWEEPING COMPONENTS
Inspect main and side brooms for wear and remove strings\debris
from bristles and drive assembly
X
X
Perform main broom adjustment test and adjust as needed
Inspect main broom door seals\flaps for wear
REPLACE flaps as needed
ACS to REPLACE seals as needed
REPLACE main and side brooms as needed
X
FILTERS
Check and clean cartridge filers
REPLACE cartridge filters as needed
X
X
Check and clean main panel filter
Check and clean panel filter on air exhaust
REPLACE main panel filter as needed
REPLACE panel filter on air exhaust as needed
X
X
HOPPER
Check hopper flaps for wear or damage and replace as needed
Check hopper door rubber seals for wear or damage and replace as
needed
ACS
ACS
ACS
ACS
LUBRICATED COMPONENTS
Check and if needed lubricate steering shaft and links
Check and if needed lubricate gearbox unit
Check and if needed lubricate main brush floating shaft
Lubricate the transmission chain by the appropriate lubricating
X
X
ACS
ACS
MISCELLANEOUS
Check belts tension and adjust as needed
Check chains tension and adjust as needed
ACS
ACS
REPLACE belts
REPLACE chains
ACS
Check inlet\outlet vacuum hoses
ACS
ACS
REPLACE inlet\outlet vacuum hoses
Check all brakes for proper functioning and adjust as needed

13
TROUBLE-SHOOTING GUIDE
WARNING! Any other type of service operation or test, with the exception of those shown in the engine’s manual or the battery’s manual, must be
carried out by Authorised Service Centres only.
PROBLEM
CAUSE
SOLUTION
The machine will not start
1. Flat or worn out battery
2. Fuse is blown
1. Re-charge or replace the battery
2. Replace it
The battery does not maintain the charge
3. Motors are over loaded
4. The density of the electrolyte solution is
low
3. Remove any object that could cause friction
4. Check the battery
The primary motor is on, but the sweeper does
not move.
5. Chain is broken
6. Belts are broken
7. Hydrostatic drive is broken
5. Replace it
6. Replace belts
7. Replace it
The motor switch is on but the motor will not
start
8. Fuse is blown
9. Solenoid is broken
10. Electronic card is faulty
11. Micro-switch is faulty
12. Motor is faulty
8. Replace it
9. Replace it
10. Check it\replace it
11. Repair\replace it
12. Repair\replace it
The secondary motor will not start
13. Fuse is blown
14. Solenoid is broken
15. Micro-switch is faulty
16. Motor is faulty
13. Replace it
14. Replace it
15. Repair\replace it
16. Repair\replace it
Dust in the bonnet
17. Broken or old filters.
18. Filter gaskets have not been mounted
17. Replace the filters
18. Mount the gaskets
Uneven sweeping action by main brush
19. Worn main brush
20. Brush is raised from floor
21. Some material may be tangled with brush
22. Low brush pressure to floor
19. Replace the brush .
20. Lower it
21. Clean main brush
22. Increase pressure
Dust and debris leak out from container
23. Rubber flaps are worn or broken
23. Replace them
No vacuum power
24. Vacuum fan is off
25. Filters are clogged
26. Fan belt is broken
27. Side panels in main brush compartment
are open
24. Turn it on
25. Clean or replace filters
26. Replace belt
27. Close them
Filter shaker does not work
28. Blown fuse
29. Faulty filtershaker
30. Faulty filter-shaker button
28. Replace it
29. Check and repair\replace it
30. Check and repair\replace it
Main brush does not work
31. Belt is broken
32. Belt is loose
33. Electro-magnetic clutch is off
34. Electro-magnetic clutch is broken
35. Microswitches: Main brush m.s.;
Hopper door m.s.; Hopper lift m.s.: any
of above features are off or broken
31. Replace it
32. Check belt tensioner or replace it
33. Turn it on
34. Replace it
35. Turn it on or replace it
Side brush does not work
36. Belt is broken
37. Reduction motor is burnt or faulty
38. Safety fuse is still engaged
39. Main brush is off
40. Microswitch is faulty
36. Replace it
37. Check and repair\replace it
38. Disengage it
39. Turn it on
40. Check and repair\replace it

14
PROBLEM
CAUSE
SOLUTION
Hopper will not raise
41. Hopper load is too heavy
42. Pump is faulty
43. Hydraulic distributor is faulty
44. Lift cylinder is faulty
45. Hydraulic flow limit valve is faulty
41. Dump more frequently
42. Check and repair\replace pump
43. Check and repair\replace it
44. Replace the seals
45. Check and repair\replace it
Hopper can not be lowered
46. Safety bar is installed on lift cylinder
47. Hydraulic distributor is faulty
48. Hydraulic flow limit valve is faulty
49. Lift cylinder is blocked
46. Remove it
47. Check and repair\replace it
48. Check and repair\replace it
49. Check and repair\replace it
Hopper door will not close
50. Hopper is over-filled
51. Piston is blocked
52. Hydraulic distributor is faulty
53. Check and repair\replace it
50. Dump more frequently
51. Check and repair\replace it
52. Replace it
53. Check and repair\replace it
Hopper door will not open
54. Debris may obstacle the door
55. Piston is blocked
56. Hydraulic distributor is faulty
57. Check and repair\replace it
54. Remove all debris
55. Check and repair\replace it
56. Check and repair\replace it
57. Check and repair\replace it
ALARMS
The sweeper includes nr. 2 acoustic alarms as standard accessories:
1) Acoustic intermittance alarm indicating low charge of battery
It starts when the charge level of battery is inferior to the one stated. You have to stop and charge the battery in order
to avoid irreversible damage to it.
2) Continuous acoustic alarm indicating high temperature or short circuit
It is mounted in the starting chopper (electric card) of the main engine.
It starts, on stopping the engine, when the temperature of the chopper goes over 90 °, or when there is a short circuit.
Pay attention that the above mentioned alarms starts for about 3-4 seconds when you insert the key on the dashboard
(page 4 –pos. 1).
In this way the correct function of the alarm cards are tested.

15
THE OPTIONAL POLYESTER BAG FILTER
The optional polyester bag filter is particularly recommended in presence of very fine dust and applications such as
cement plants, chalk plants, talcum powder plants and other similar products.
To achieve best performances, shake the filter often ( every 15 –20 minutes ) or at least prior to dump the dirt.
NOTE: the dirt container must be lowered to the floor when shaking the filter.
Every 100 hours, shake the filter throughout and clean it with compressed air without removing it from its support.
TECHNICAL SPECIFICATIONS
COMPOSITION
POLYESTER FIBRE
WEIGHT ( g/m² )
450
THICKNESS
mm 1,35
DENSITY ( g/cm² )
0,33
AIR PERMEABILITY
DIN 53887 lt/dm² x min. 150
FILTERING AREA ( m² )
6
FILTERING CLASS
L - USG
Max penetration value = 1%
Dusts with values of max. occupational exposure > 0,1 mg/m²
EXPLODED VIEW
1. FILTER COMPARTMENT HOOD
2. LOCKING BOLTS
3. POLYESTER FILTER
4. CONNECTOR
5. 12V FILTER-SHAKER ( 36V ON “EB” VERSION )
6. FRONT ABS PANEL
7. 40 Amps. FUSE ( 30 A. ON “EB” VERSION )
REMOVING THE FILTER:
A. REMOVE THE HOOD n° 1
B. REMOVE THE BOLTS n° 2
C. REMOVE THE POLYESTER FILTER n° 3
D. DISCONNECT THE CONNECTOR n° 4
REPLACING THE FUSE
E. OPEN THE FILTER COVER n°1
F. REMOVE THE FRONT ABS PANEL n° 6
G. REPLACE THE FUSE n° 7
NOTE: DO NOT CHANGE THE Amps. VALUE OF THE FUSE

16
1°
CONTROL AND MAINTENANCE SERVICE
SWEEPER MODEL MAGNUM EB
AT 50 HOURS
DATE
DAY
MONTH
YEAR
WORKING HOURS
Before starting the service operation look at the machine and check carefully if there are
leaks of oil or battery liquid.
Then lift the hood and check the same inside the machine.
PLEASE PAY ATTENTION THAT ALL MEASUREMENTS MUST BE EFFECTED :
•with the standard main brush (part nr. 520035);
•on a flat cement floor;
•with a full charge battery , i.e. 36/37 volt.
MAIN MOTOR (Traction –Part Nr 610024):
Check the absorption:
with machine still from 38 to 48 Ah
with machine at maximum speed from 75 to 85 Ah
SECONDARY MOTOR (For main brush and vacuum fan –Part Nr
610025):
Check the absorption:
with raised brush from 27 to 35 Ah
with working brush (trace from 50 to 60 MM) from 38 to 48 Ah
MACHINE:
Control the water level in the battery
Control the wear state and the trace of brushes
Control the rubber flaps
Control the hopper gaskets
Control the dust filter efficiency
Control the tension of all belts
Control the tension of all chains
Control the functioning of all devices and control levers
Control the correct functioning of braking system
Control the hydraulic oil level
Test the machine
THE SERVICE HAS BEEN EFFECTED BY:
NAME: _____________________________
SURNAME: _____________________________
SIGNATURE:_____________________________
DISTRIBUTOR’S STAMP
NOTES:

17
2°
CONTROL AND MAINTENANCE SERVICE
SWEEPER MODEL MAGNUM EB
AT 100 HOURS
DATE
DAY
MONTH
YEAR
WORKING HOURS
Before starting the service operation look at the machine and check carefully if there are
leaks of oil or battery liquid.
Then lift the hood and check the same inside the machine.
PLEASE PAY ATTENTION THAT ALL MEASUREMENTS MUST BE EFFECTED :
•with the standard main brush (part nr. 520035);
•on a flat cement floor;
•with a full charge battery , i.e. 36/37 volt.
MAIN MOTOR (Traction –Part Nr 610024):
Check the absorption:
with machine still from 38 to 48 Ah
with machine at maximum speed from 75 to 85 Ah
SECONDARY MOTOR (For main brush and vacuum fan –Part Nr
610025):
Check the absorption:
with raised brush from 27 to 35 Ah
with working brush (trace from 50 to 60 MM) from 38 to 48 Ah
MACHINE:
Control the water level in the battery
Control the wear state and the trace of brushes
Control the rubber flaps
Control the hopper gaskets
Control the dust filter efficiency
Control the tension of all belts
Control the tension of all chains
Control the functioning of all devices and control levers
Control the correct functioning of braking system
Change of hydraulic oil filter part nr. 520047
Control the hydraulic oil level
Test the machine
THE SERVICE HAS BEEN EFFECTED BY:
NAME: _____________________________
SURNAME: _____________________________
SIGNATURE:_____________________________
DISTRIBUTOR’S STAMP
NOTES:

18
3°
CONTROL AND MAINTENANCE SERVICE
SWEEPER MODEL MAGNUM EB
AT 200 HOURS
DATE
DAY
MONTH
YEAR
WORKING HOURS
Before starting the service operation look at the machine and check carefully if there are
leaks of oil or battery liquid.
Then lift the hood and check the same inside the machine.
PLEASE PAY ATTENTION THAT ALL MEASUREMENTS MUST BE EFFECTED :
•with the standard main brush (part nr. 520035);
•on a flat cement floor;
•with a full charge battery , i.e. 36/37 volt.
MAIN MOTOR (Traction –Part Nr 610024):
Check the absorption:
with machine still from 38 to 48 Ah
with machine at maximum speed from 75 to 85 Ah
SECONDARY MOTOR (For main brush and vacuum fan –Part Nr
610025):
Check the absorption:
with raised brush from 27 to 35 Ah
with working brush (trace from 50 to 60 MM) from 38 to 48 Ah
MACHINE:
Control the water level in the battery
Control the wear state and the trace of brushes
Control the rubber flaps
Control the hopper gaskets
Control the dust filter efficiency
Control the tension of all belts
Control the tension of all chains
Control the functioning of all devices and control levers
Control the correct functioning of braking system
Oil the steering wheel, the forward/reverse speed group and the main brush shaft
Lubricate the chains with the proper solution
Check the system of pipes
Test the machine
THE SERVICE HAS BEEN EFFECTED BY:
NAME: _____________________________
SURNAME: _____________________________
SIGNATURE:_____________________________
DISTRIBUTOR’S STAMP
NOTES:

19
4°
CONTROL AND MAINTENANCE SERVICE
SWEEPER MODEL MAGNUM EB
AT 300 HOURS
DATE
DAY
MONTH
YEAR
WORKING HOURS
Before starting the service operation look at the machine and check carefully if there are
leaks of oil or battery liquid.
Then lift the hood and check the same inside the machine.
PLEASE PAY ATTENTION THAT ALL MEASUREMENTS MUST BE EFFECTED :
•with the standard main brush (part nr. 520035);
•on a flat cement floor;
•with a full charge battery , i.e. 36/37 volt.
MAIN MOTOR (Traction –Part Nr 610024):
Check the absorption:
with machine still from 38 to 48 Ah
with machine at maximum speed from 75 to 85 Ah
SECONDARY MOTOR (For main brush and vacuum fan –Part Nr
610025):
Check the absorption:
with raised brush from 27 to 35 Ah
with working brush (trace from 50 to 60 MM) from 38 to 48 Ah
MACHINE:
Control the water level in the battery
Control the wear state and the trace of brushes
Control the rubber flaps
Control the hopper gaskets
Control the dust filter efficiency
Control the tension of all belts
Control the tension of all chains
Control the functioning of all devices and control levers
Control the correct functioning of braking system
Check the hydraulic oil level
Test the machine
THE SERVICE HAS BEEN EFFECTED BY:
NAME: _____________________________
SURNAME: _____________________________
SIGNATURE:_____________________________
DISTRIBUTOR’S STAMP
NOTES:

20
5°
CONTROL AND MAINTENANCE SERVICE
SWEEPER MODEL MAGNUM EB
AT 400 HOURS
DATE
DAY
MONTH
YEAR
WORKING HOURS
Before starting the service operation look at the machine and check carefully if there are
leaks of oil or battery liquid.
Then lift the hood and check the same inside the machine.
PLEASE PAY ATTENTION THAT ALL MEASUREMENTS MUST BE EFFECTED :
•with the standard main brush (part nr. 520035);
•on a flat cement floor;
•with a full charge battery , i.e. 36/37 volt.
MAIN MOTOR (Traction –Part Nr 610024):
Check the absorption:
with machine still from 38 to 48 Ah
with machine at maximum speed from 75 to 85 Ah
SECONDARY MOTOR (For main brush and vacuum fan –Part Nr
610025):
Check the absorption:
with raised brush from 27 to 35 Ah
with working brush (trace from 50 to 60 MM) from 38 to 48 Ah
MACHINE:
Control the water level in the battery
Control the wear state and the trace of brushes
Control the rubber flaps
Control the hopper gaskets
Control the dust filter efficiency
Control the tension of all belts
Control the tension of all chains
Control the functioning of all devices and control levers
Control the correct functioning of braking system
Oil the steering wheel, the forward/reverse speed group and the main brush shaft
Lubricate the chains with the proper solution
Check the system of pipes
Test the machine
THE SERVICE HAS BEEN EFFECTED BY:
NAME: _____________________________
SURNAME: _____________________________
SIGNATURE:_____________________________
DISTRIBUTOR’S STAMP
NOTES:
