Eureka Combat User manual

PARTS LIST:
Qty. Description of Item National Stock Number
or Product Code
1 combat tent, complete with contents: 8340-01-452-591
1 tent body 8340-01-464-0809
1 rain y (reversible) 8340-01-464-0773
3 tent poles 8340-01-462-6873
1 combat tent transport bag 8340-01-464- 0405
1 tent pole bag 8340-01-464-0395
1 rain y bag 8340-01-464- 0370
1 combat tent manual 5690460
1 repair kit /stake bag, w/contents: 8340-01-462- 6490
8 stakes 8340-01-462-6547
6 10' pull out cords 8340-01-464-0829
2 5' pull out cords 8340-01-462-6881
2 side rain y pitching webs 8340-01-464-0822
1 middle rain y pitching web 8340-01-462-6866
1 pole repair sleeve 8340-01-462-6818
3 shok locks 8340-01-462-6861
1 16' length of shock cord 5651805
1 12" x 12" piece oor fabric 8340-01-462-6877
1 12" x 12" piece rain y fabric 8340-01-464-0270
1 12" x 12" piece roof cloth fabric 8340-01-464-0186
1 12" x 12" piece net 8340-01-462-6569
1 sewing needle 5285020
1 thimble 5285025
1 spool of thread (100 yards) 5285030
1 1 oz. bottle Seam Grip™ 8340-01-458-2768
1 12" of 3/4" black, heavy duty web 8340-01-464-0099
1 12" of 1" black, light weight web 8340-01-464-0092
2 side squeeze buckles 5678210 / 5678215
2 toggles 8340-01-464-0836
Replacement part:
1 combat leg section 2628946
For information, parts, or repairs, contact the Eureka! Customer
Satisfaction Department at our address in the Limited Warranty.
www.eurekamilitarytents.com or
E-mail militar[email protected]
Combat Tent Manual
REV. C 6/08

E
D
A
C
B
F
Pole sleeve
Follow seams
where poles
cross
A
E
C
B
D
F
1. Lay the tent body out on the ground. Assemble the poles. Make
sure each rod is fully inserted into the next rod. Do not let the rods
snap together.
2. Open the doors of the tent. Do not stake the tent down yet. In
windy conditions, stake down the corner that faces into the wind.
3. Start at a corner and slide a pole through a sleeve. Follow the
seam to the next sleeve and slide the pole through. Continue until
you reach the other side of the tent. Be careful wherever seams
cross.
4. Repeat with second and third poles. One pole should run from A
to B, a second from Cto Dand the third from Eto F.
5. Place the pole posts into the grommets at the corners of the tent
in the following order: A to B, Cto D and E to F.
Pitching Instructions:

10' pull out cord
ties to rain y
here
10' pull out cords
tie to rain y here
Stake vestibule here
Tie 5' pull out cord
to rain y here
6. Move the tent into position and stake down the tent body at the
corners and at the side stake loops E and F.
7. Choose the color and drape the reversible rain y over the tent.
Arrange the y so that the
arc of the door aligns with
the arc of the third pole.
NOTE: Always stake your tent down - placing objects inside the tent is not
adequate. Use the 10' pull out cords for added stability in high winds. Tie
the cords to the loops on the rain y and stake them down 3-4 feet from the
tent. The cords should be taut, but they should not warp the poles or distort
the shape of the tent.
8. There are seven Velcro® wraps on the underside of the rain y.
Wrap these around the tent poles to secure the y.
9. Fasten the buckles at the corners of the y to their mates at the
corners of the tent.
10. Stake down the vestibules. Attach the 5' pull out cords to the
loops at the sides of the y and stake them down.
11. Adjust the tension on the rain y at the corner buckles until the
y is taut and secure. Adjust 5' pull out cord if needed.

F
D
A
E
C
B
Post in grommet
Velcro
Ring
Snap RPW
Buckle RPW
Buckle RPW
Striking Instructions
Pull up all stakes. Release four buckles on rain y. Unfasten Velcro® on rain y
from tent poles. Remove rain y. Open doors and shake debris out through
the doors. Pull pole posts out of all grommets. Slide poles out of sleeves. Fold
tent to the length of the poles. Fold dierently each time to prevent creases
that may damage the tent. Roll tent toward a door to push air out.
Ventilation
One adult produces about a pint of water overnight. If this water vapor
cannot escape, it reappears as condensation. If the inside of the tent is wet in
the morning but there is no obvious leak, you probably have condensation.
Usually, condensation is heaviest on the tent oor, where objects touch the
cool earth. You can help prevent condensation by leaving your windows
open at night. To vent this tent in wet weather, open the top of the front door
under the hood in the rain y.
Pitching the Rain fly Only:
1. Assemble all three poles. Unfold the rain y with the desired color down.
2. There are three black Rain y Pitching Webs [ RPW ], two with buckle ends
and one with snap ends. Attach a buckle RPW to its mate at Dof the rain y .
Repeat with a second buckle RPW at B. Snap the remaining RPW to ring at F.
3. Following the seam, thread a pole from Ato B, passing through two web
loops. Place the pole's post into the grommet where the RPW is attached to
the rain y. Repeat, threading a second pole from Cto D.
4. Wrap the Velcro®at the peak of the rain y to capture both poles.
5. Thread the last pole from
Eto F, passing through the
web loop above the vestibule
zipper, and through the web
loops where it crosses the
other two poles.
Web loop above vestibule zipper

F
D
A
E
C
B
Insert post into
grommet
6. Attach the other buckle of the RPW connected at B to the
buckle at corner C. Push the pole from Atoward B(post already
inserted). Place the free post into the grommet at A.
7. Attach the second RPW, connected at Dto the buckle at A.
Push the pole from corner Ctoward Dand place the pole's post
into the grommet at C.
8. Snap the loose end of the middle RPW to the ring on the rain
y at E. Push the third pole toward Fand place the pole's post into
the grommet at E.
9. Turn the rain y over and stake down the corners and the
vestibules. Use the center snaps in the RPWs to adjust the rain
y’s height. Restake the corners and/or the vestibule stake loops if
needed.

WARNING:
Do NOT operate any device which burns fuel inside this tent.
Combustion consumes oxygen, and can produce dangerous levels of
carbon monoxide which could lead to serious injury or death.
Tent Use, Care and Maintenance:
 ob-
jects such as stones or branches. If possible, use a ground cloth under
the tent to protect the oor. Make sure the ground cloth doesn't stick
out or it will funnel water under the tent.

food will chew or claw through fabric.

daily to protect the oor.
 leaky
batteries can damage the fabric. Do not put them in the tent.

taped and require no sealing. If there is water intrusion due to dam-
age, apply Seam Grip found in the repair kit. Set the tent up. Make
sure the fabric is clean and dry. Follow instructions on Seam Grip. Al-
low to dry. If quick dry is necessary, follow instructions on the talcum
packet from the repair kit.

repair sleeve over the break. Pitch tent, holding the pole repair sleeve
in place. When the pole bends enough, the repair sleeve will not
move. Replace broken rod as soon as possible.

Small holes. Seal extremely small holes with Seam Grip. For holes up
to 1/2" across, put a piece of tape over the hole on the outside of the
tent. From inside, apply Seam Grip at least 1/8" thick and 1/4" beyond

Striking The Rain fly
Pull up all stakes. Unfasten Velcro® from poles. Pull all pole posts out
of all grommets. Disconnect rain y pitching webs.


The patch should be 1'' larger than the hole. Sew with needle and
thread. Seal sewing repairs on water proof fabric with Seam Grip.

piece of web to the same length. Burn the ends of new web to pre-
vent fraying. Restitch and seal stitching with Seam Grip.

sewing. Thread onto web (use another male part as an example). If
the male part fails to hold, it is on the web backward. Remove, turn
over, and rethread. To repair female buckle, resew to web.

material. If a zipper separates, work the slider until the zipper is all the
way open. Close the zipper again; the zipper may repair itself. Sand
or grit can cause zipper failure. If the tent has been used in sandy soil,
ush zippers with clean, fresh water.
-
lowed by a fresh water rinse.  use washing machines, dryers, or
detergent. Do not rub or scrub.

packed damp, remove and dry completely before storing for longer
than two days. This prevents mildew damage to the waterproof

(they nest in tents). Store the tent away from heat.
Shok locks: Use when replacing broken pole rods.
1. Assemble the broken pole.
2. Pull one end rod away from the pole. Cut the shockcord so that it
is even with the insert on the end rod.
3. Disassemble pole and replace any broken rods.Thread the
shockcord back through the rods. Because you need to stretch the
shockcord as you do this, use a vice grip pliers to hold the shock-
cord before you thread it through the last rods.
Cut here

4. Gently squeeze a shok lock between thumb and forenger and
push its angled end into the insert up to the rst barbs. The shok lock
must be straight.
5. 
pole tip should point up. Tap the pole tip lightly with a plastic mallet
until the bottom of the shok lock is inside the insert.
6. Push the shok lock into the insert another 1/2".
7. Thread 2" of shockcord into the insert on the end rod. The shok
lock will hold the shockcord.
8. Release the vice grips and check the tension of the shockcord. If
loose, add tension by pushing more shockcord into the end rod. Be
careful. Once inserted, shockcord cannot be released.
Insert
Pull shockcord taut and attach
vice grips here
End rod
Shok Lock
Angled End

LIMITED WARRANTY
WhatIs Covered. Eureka!warrantsthatits productsarefree
from defects in material and workmanship for two years
from the in service date except as qualied below, and
as described in contract GSA# : GS-03F-0024U.
What Is Not Covered. Eureka! shall be not responsible for
normal wear and tear (e.g. exhausted zippers), or de-
fects caused by accident, abuse, alteration, misuse or
improper care.




What Eureka! Will Do. If after inspection we nd that a
product failed due to a manufacturing or material de-
fect, we will repair or replace the product, at our option,
without charge.
HowToObtainWarrantyService. Contact Eureka!'sCustomer
Satisfaction Department for return authorization.
Eureka! Customer Satisfaction
P.O. Box 966
 
800. 847.1460
Collect shipments or shipments without return
authorization cannot be accepted.
How State Law Relates To This Warranty. This warranty gives
you specic legal rights, and you may have other rights
which vary from state to state.
We accept government credit cards (IMPAC), Master
Card, or Visa.

 

Example
Erect Strike
1. Aug. 1, 2010 1. Aug. 7, 2010
2. 2.
3. 3.
    

MISSION LOG
Combat Tent




TO PURCHASE EUREKA! TENTS::
GSA Advantage!
Eureka! brand tent products are available for sale through
GSA Advantage! if you are a qualified buyer. To view our
products and pricing, simply go to www.gsaadvantage.
gov and search our contract number GS-03F-0024U.
Defense Supply Center Philadelphia
Eureka! brand tent products are available for sale through
the DLA/DSCP. To view our products and pricing, simply
go to our website and review available products. Our
Soft Shelter contract number is SPM100-05-D-6059.

215-737-0388
Johnson Outdoors Inc. / Eureka!
You can also purchase Eureka! brand tent products directly
from the manufacturer. For pricing and availability,
contact our internal customer service department at
800-847-1460.
