Eureka V18C01A User manual

Service Manual
Vacuum Cleaner
V18C01A
Midea LOGO

Contents
1. Specifications…………………………………………………………
…1
2 Electrical Diagram…………..…………………………….…………..1
3 Schematic Diagram……………………………..…………………….2
4 Repair of Main Parts…………………………………….……………3
4.1 Upper、Lower Body、Motor cover、Re-winder 、
Hose…………….……………….………………………………………… 3-4
4.2 Motor…………………………….……………………………………….4
4.3 Connection hose, Hose…….…………………………………….5
5 Trouble Shooting Chart……………………………………..……….6
6 Replacement Parts List………………………………………………6
7 Packing Instruction……………………………………………….……7

Follow caution information wherever you see this symbol.
1 Spcifications
Model
V18C01A
Power Source
AC 220~240V,50/60Hz
Motor Power MAX.
800W
Air Power
≥170W
Dust Capacity
2.0L
Cord Length
5m
Weigth(Main Body)
4.5Kg
Dimension(W*L*H)
410*265*240mm
Attachments
Multi surface floor nozzle, combination tool, hose,
extension wand
2 Electrical Diagram

3 Schematic Diagram

4 Repair of Main Parts
4.1 Upper、Lower Body、Motor cover、Re-winder、
Hose
Assembly
1.
2.
4.
3.
5.
Remove the 6 screws from the body.
Then take the middle cover away.
Remove the four screws one by one from
the motor cover and PCB. Then take the
re-winder and air inlet cover away.
Press the button of hose connector to
release hose from main body.

4.2 Motor
Removing
DS
4.3 connection hose ,Hose
Removing :
Remove the two screws from the motor
cover. Then take the motor cover away.
Pull the entire plug out smoothly and
press the rewinder frame to take all the
cord in to test whether it works well.
Plug
Step 1 Detach the body partition and cord reel ass.
Step 2 Remove the motor
Step 3 Take out the motor sealing, motor, motor
sponge, motor support and motor support rubber.
Motor Sealing
Motor
Motor Sponge
Motor Support

Step 1 Disconnect the hose by depressing the projection in the hole on each side of handle.
Assembling
Step 1 Slide the projection on the hose supporter of the hose into on either side.
5 Trouble Shooting Chart
Trouble
Possible Causes
Countermeasure
The vacuum cleaner can not
start operation
1.The plug is not plugged in
2.The power switch didn't open.
3.Internal wiring of loose
4.The motor burned out
1.Re plug
2.Press the power switch
3.Re connect the internal wiring
4.Repair or replacement of the
new machine
The suction become smaller
1.The channel blocked suction head
2. Poor ventilation dust bag
3. Air inlet and outlet filter blocked
4. Motor problems
1.Clean the suction
head channel
2.Clean up the dust bag
3.Cleaning filter
4. Repair replacement of
the motor
1. The dust suction channel block
1.Clean up the dust absorption

Full dust indicator of
adverse action
2. The buoy stuck
3. Spring is broken
channel
2. Repair full dust indicator
3. Repair full dust indicator
6 Replacement Parts List
No.
Part Name
Part Code
Specs.
QTY
1
AIRINLET HEPA
12175000077043
1
2
CORD REWIND
ASSEMBLY
12175000077041
According to the power cord
1
3…
AIROUT HEPA
12175000065393
-
1
AIROUTLET PLATE
12175000077042
Color：black
1
SWITCH
17475000001065
According to the
required Specification
1
Hose
12175000016148
According to the
required Specification
1
Main Brush
12175000075865
According to the
required Specification
1
Tube
12975000000737
According to the
required Specification
1
Wires
17475000014230
17475000014231
17475000014236
17475000014233
According to the
required Specification
1
Protector
17475000014451
According to the
required Specification
1
7 Packing Instruction
