Euri ECS-150W1050 User manual

WARNINGS
• Do not use the electric generator to test the LED lamp.
• Please abide by related country, regional and local law and regulations when installing this fixture.
• Please turn off the power before installation or maintenance.
• Proper grounding is required to ensure safety.
WARNING/ AVERTISSEMENT
MIN 75°C SUPPLY CONDUCTOR
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH THE
CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
IMPORTANT WIRING DIAGRAM
• To avoid possibility of electrical shock or fire, the installation
personnel must have professional electric knowledge.
• Please wear gloves to avoid injury before installation.
• If smoke or fire is found in wires or led fixture during or after installation,
please turn off the power immediately and notify relevant personnel.
• Please check if there is any damage during shipping. If so, please
contact manufacturer immediately.
• Please read the installation instruction carefully to check whether
all the accessories are complete. After confirmation, then install the
fixture according to the installations.
INSTALLATION (1)
INSTALLATION GUIDE
MODEL #: ECS-150W1050
©2020. Euri Lighting | A Division of IRTRONIX Inc. All Rights Reserved
For customer service please call us at 1-310-787-1100
Office Hours: 8:00 a.m. – 5:00 p.m. PST Monday-Friday
E-mail: [email protected]
Questions?

THIS PRODUCT MAY NOT BE COMPATIBLE WITH ALL DIMMERS, FOR MORE INFORMATION ABOUT DIMMER COMPATIBILITY PLEASE VISIT: WWW.EURILIGHTING.COM
LED Commercial Fixture
Canopy Light|Square Class
PLEASE REVIEW THE INSTRUCTIONS AND WARNINGS LISTED BELOW PRIOR TO PROPER INSTALLATION
LED Square
Canopy Light
1
3
Fix one side of the accessory
safety rope on the back of the
fixture.
Use electric drill to set fixed
holes through the ceiling.
12Fix another side of safety rope on the ceiling, then
connect the wire of fixture to main power source
according to local electrical connection code, make
sure the wire joints are well protected, after that, fix
the fixture on the ceiling with accessory screws.

INSTALLATION (2)
INSTALLATION (3-1)
INSTALLATION (3-2)
RECOMMENDED DIMMER LIST
LUTON: NTSTV-DV / LEVITON: DS710-10Z / LEVITON: IP710 / Legrand: RH4FBL3PW
1
2
2
3
1
1 2 3
4
INSTALLATION GUIDE
MODEL #: ECS-150W1050
©2020. Euri Lighting | A Division of IRTRONIX Inc. All Rights Reserved
For customer service please call us at 1-310-787-1100
Office Hours: 8:00 a.m. – 5:00 p.m. PST Monday-Friday
E-mail: [email protected]
Questions?

THIS PRODUCT MAY NOT BE COMPATIBLE WITH ALL DIMMERS, FOR MORE INFORMATION ABOUT DIMMER COMPATIBILITY PLEASE VISIT: WWW.EURILIGHTING.COM
LED Commercial Fixture
Canopy Light|Square Class
PLEASE REVIEW THE INSTRUCTIONS AND WARNINGS LISTED BELOW PRIOR TO PROPER INSTALLATION
LED Square
Canopy Light
Connect the wiring to the
local power supply in the
3/4”NPT Stem.
Fix the mounting bracket
on the back of fixture with
supplied screws.
Drill the alignment holes on the top
ceiling, to match the holes on mounting
bracket.
Insert the supplied rubbers into the
alignment holes, then fix the mounting
plate on the ceiling with supplied
screws.
Mount the fixture on the mounting
plate with supplied screws.
Make wiring connections per “Electrical
Connections” section and make sure
the wires are well protected.
Screw the fixture to the
3/4”NPT Stem.
Unscrew the nut from customer supplied 3/4”NPT
stem, make the stem hole on mounting bracket
through 3/4”NPT stem, then screw the nut back to
3/4”NPT, and fix it.
Make wiring connections per “Electrical Connections”
section and make sure the wires are well protected.
