LEGO® R2-D2™
#75308 LIGHT KIT & SOUND KIT
INSTALLATION GUIDE

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
2
Light My Bricks
LEGO® R2-D2 ™ #75308 LIGHT & SOUND KIT
INSTALLATION GUIDE
Hi There!
We’re here to help you get started on the LEGO®
R2-D2 ™ (75308) Light & Sound Kit.
This PDF details the instructions for the LED light & sound
kit only.
If you run into any issues, please refer to the
troubleshoot-ing section towards the end of this guide.
Have fun and enjoy!
INSTALLATION GUIDE

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
PACKAGE CONTENTS 3
PACKAGE CONTENTS:
EXTRA COMPONENTS
INCLUDED WITH THE
LIGHT & SOUND KIT:
LEGO PIECES:
1 x Red to Blue 15cm Bit Light
1 x Green to Orange 15cm Bit Light
10 x Cool White 30cm Bit Lights*
1 x 12-Port Expansion Board
1 x 2-Port Expansion Board (Not required for the Remote Control &
Sound version)
•2 x Trans Clear 1x1 Round Plate
•2 x Trans Clear 2x2 Plate w/ Rounded Bottom
•2 x Trans Light Blue 1x1 Plate
•1 × Remote Control & Sound Board
•1 × Remote Control
•1 × IR Receiver w/ 30cm Cable
•1 × Audio Speaker w/ 15cm Cable
•1 × Micro SD Memory Card (128MB)
•1 × Micro USB Cable (to transfer audio files from PC)
2 x Sparkle Eects Board
4 x Adhesive Squares
3 x 5cm Connecting Cables*
1 x 50cm Connecting Cable
1 x USB Power Cable
(Power Source not Included)
Asterisks * indiciates 1 extra component has been included just in case!

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
CONTENTS 4
Contents
Before You Begin 5
Instructions 8
Final Product 34
Troubleshooting 35
Contact 40

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
BEFORE YOU BEGIN 5
Before You Begin
Laying cables in between
and underneath bricks
Cables can fit in between and underneath
LEGO® bricks, plates, and tiles providing
they are laid correctly between the
LEGO® studs. Do NOT forcefully join
LEGO® together around cables; instead
ensure they are laying comfortably in
between each stud.
CAUTION: Forcing LEGO® to connect over
a cable can result in damaging the cable
and light.
Connecting Cable
Connectors To Expansion
Boards
Take extra care when inserting connectors
to ports of Expansion Boards. Connectors
can be inserted only one way. With the
expansion board facing up, look for the
soldered “=” symbol on the left side of the
port. The connector side with the wires
exposed should be facing toward the
soldered “=” symbol as you insert into the
port. If a plug won’t fit easily into a port
connector, do not force it.
Incorrectly inserting the connector can
can result in bent pins inside the port or
possible overheating of the expansion
board when connected.

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
BEFORE YOU BEGIN 6
Before You Begin
Connecting Cable
Connectors To Strip Lights
Take extra care when inserting connectors
to ports on the Strip Lights. Connectors
can be inserted only one way. With the
Strip Light facing up, ensure the side of
the connector with the wires exposed is
facing down. If a plug won’t fit easily into
a port connector, don’t force it. Doing so
will damage the plug and the connector.
Connecting Micro Cable
Connectors To Micro
Expansion Board Ports
Take extra care when inserting the
micro connectors to micro ports of Micro
Expansion Boards. Connecting Micro Bit
Lights to Micro Expansion Boards is similar
to connecting lights and cables to Strip
Lights. With the expansion board facing
up, ensure the side of the connector with
the wires exposed is facing down. If a plug
won’t fit easily into a port connector, do
not force it. Use your fingernail to push the
plastic part of the connector to the micro
port.

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
BEFORE YOU BEGIN 7
Before You Begin
Installing Bit Lights Under
Lego® Bricks And Plates
When installing Bit Lights under LEGO®
pieces, ensure they are placed the correct
way up (Yellow LED component exposed).
You can either place them directly on top of
LEGO® studs or in between.

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
INSTRUCTIONS 8
INSTRUCTIONS
To ensure a smooth installation of
your light kit, please read and follow
each step carefully. If you run into
any issues, please refer to the online
troubleshooting guide.
888INSINSINSINSTRUCTIONSTRUCTIONSTRUCTIONSTRUCTIONS
LEGEND:DISCONNECT DIRECTIONAL
LEGENDE:TRENNEN DIRECTIONAL
LÉGENDE:DÉCONNECTER DIRECTIONNEL
LEGGENDA: SCOLLEGARE
CONNECT / RECONNECT
VERNINDEN / WIEDERVERBINDEN
CONNECTER / RECONNECTER
CONNETTI / RICONNETTI
TURN / FLIP
WENDEN / KIPPEN
TOUR / INCLINAISON
ROTARE / INCLINARE DIREZIONALE
TWIST / BRAID
DREHEN / VERDREHEN
TORSION / TRESSER
TWIST / TRECCIA
POWER ON / TEST
EINSCHALTEN / TESTEN
POWER ON / TEST
POWER ON / TEST

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
INSTRUCTIONS 9
1
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
INSTRUCTIONS 10
2
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Cool White 30cm Bit Light
Trans Clear 1x1 Round Plate

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
INSTRUCTIONS 11
3
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Red to Blue 15cm Bit Light Trans Clear 2x2 Plate w/
Rounded Bottom
Ensure the LED is
facing down

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
INSTRUCTIONS 12
4
5
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Connect 2x Cool
White 30cm Bit
Lights to the exact
OUT ports as shown
Sparkle Eects Board2x Cool White 30cm Bit Light
5cm Connecting Cable
Connect the 5cm
Connecting Cable to
the IN port

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
INSTRUCTIONS 13
7
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Ensure the LED
is facing the back of
the brick as shown
12-Port Expansion Board
If you experience any issues with the lights not working and suspect an issue with a component, please try a dierent port on the expansion board to verify where the fault lies (with the light or
expansion board). To correct any issues with expansion board ports, please view the section addressing expansion board issues in our troubleshooting section.
USB power Cable
6
Connect to a
USB Power Bank,
USB to AA Battery
Pack or USB Wall
Adaptor (each sold
separately)
Connect the two
Bit Lights from step
2 and 3 as well as
the 5cm Connecting
Cable to the 12-Port
Expansion Board
Secure the
second Bit Light with
the 1x6 Plate from
Step 4
2x Trans Light Blue 1x1 Plate

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
INSTRUCTIONS 14
8
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
INSTRUCTIONS 15
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
INSTRUCTIONS 16
9
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Sparkle Eects Board3x Cool White 30cm Bit Light

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
INSTRUCTIONS 17
10
11
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Connect the
three Bit Lights to
the OUT ports of
the Sparkle Eects
Board
Cool White 30cm Bit Light
Trans Clear 1x1 Round Plate

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
INSTRUCTIONS 18
12
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Green to Orange 15cm Bit Light Trans Clear2x2 Plate w/
Rounded Bottom
Ensure the LED is
facing up

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
INSTRUCTIONS 19
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
13

LEGO R2-D2™ 75308 LIGHT & SOUND KIT INSTALL GUIDE
INSTRUCTIONS 20
14
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Reconnect the ‘Z’
shape LEGO pieces
from step 1
5cm Connecting Cable
Connect the
two Bit Lights from
step 11 and 12 to the
12-Port Expansion
Board
