Euromatic EUR-TF30BC User manual

Model Number EUR-TF30BC
INSTRUCTION MANUAL
30cm Metal Table Fan
AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761

2
Contents
Important Safety Instructions 3
Product Overview 5
Getting Started 6
Instructions 7
Other Useful Information 8
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]

3
Important Safety Instructions
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read this manual thoroughly before first use, even if you are familiar with this
type of product. The safety precautions enclosed herein reduce the risk of fire,
electric shock and injury when correctly adhered to. Make sure you understand all
instructions and warnings. Keep the manual in a safe place for future reference,
along with any warranty information, your purchase receipt and the original
packaging. Always follow basic safety precautions and accident prevention
measures when using an electrical appliance, including the following:
• Voltage: Ensure your outlet voltage and circuit frequency correspond to the
voltage stated on the appliance rating label. If this is not the case, do not use.
• Water: To protect against fire and electric shock, do not immerse the cord, plug
or fan in water or other liquid, or expose the electrical connections to water.
Ensure your hands are dry before handling the plug or switching on the fan. Do
not use the fan outdoors or on wet surfaces. Protect it from liquid spills.
• Damage: Check the power cord regularly for visible damage. If the cord is
damaged, it must be replaced by the manufacturer, its authorised service
centres or appropriately qualified personnel in order to avoid any hazards.
WARNING! Do not pick up or operate the fan if the supply cord, plug or hous-
ing is damaged, or after it malfunctions or has been dropped or damaged in
any manner. If damaged, contact our after sales support centre for advice.
Do not open or try to repair the fan yourself: risk of electric shock!
• Protect the power cord:
• Do not operate the fan with the cord coiled up; always fully unwind.
• Do not twist or kink the cord or let it touch heated surfaces.
• Do not put any stress on the cord where it connects to the product.
• Never carry the fan by the cord.
• Arrange the cord away from any traffic area so no one will trip over it.
• Do not run the cord under carpeting or cover it with rugs or runners.
• WARNING! No extension cord, no timer: Do not use this fan with an
extension cord, plug adaptor, external timer or separate speed control device.
• Connection: To insert the plug, grip it firmly and guide it into the outlet. Do not
use more than one electrical appliance at the same time on the same outlet.
• Disconnection: Do not use the power button as the sole means for discon-
necting power. Always unplug the fan from the power outlet when it is not in
use and before cleaning, servicing, moving or storing the appliance. Grasp the
plug and remove it from the outlet, do not pull the cord when disconnecting.
• Guard removal: Ensure the fan is disconnected from the power supply before
removing a front or rear guard (grille).
• Attachments: The use of accessory attachments not recommended in this
manual may cause injury or hazards.
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]

4
Important Safety Instructions (Cont.)
• RCD: Unless your home is already fitted with a residual current device (safety
switch), we recommend installing an RCD with a rated residual operating
current not exceeding 30mA to provide additional safety protection when using
electrical appliances. See your electrician for professional advice.
• Domestic use only: This appliance is intended for indoor household use only.
It is not suitable for commercial, industrial or outdoor use. Do not use it for any-
thing other than its intended purpose, such as for drying clothes. Only use it as
described in this manual. Any other use may cause fire, electric shock or injury.
• Misuse: We accept no liability for any damages or personal injury caused by
misuse of the product and/or failure to follow these instructions.
• Usage restriction: This fan is not intended for use by persons (including chil-
dren) with reduced physical, sensory or mental capabilities, or lack of experi-
ence and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Children: Supervise children to ensure they do not play with the fan. Close
supervision is necessary when any appliance is used by or near children.
• WARNING! Do not leave unattended during use! Always switch it off and
unplug when not in use, if left unattended and before cleaning and storing.
• Location: Place the fan on a dry, flat, stable surface to avoid overturning.
• Keep the top clear: Do not place anything on top of fan.
• Proper assembly: Do not operate the fan until fully assembled on the base;
the fan must stand upright for operation. Do not use the appliance without the
protective grilles (rear and front guards).
• WARNING! DO NOT use the fan in the following areas:
* near an open flame, a hot burner, oven or other source of high heat
* on a soft surface (such as carpet) or where it may tip over during use
* outdoors or in areas of high humidity without suitable ventilation (such as in a
bathroom or laundry area), or near a sink, washer, pool or any source of water
* near curtains, plants, window furnishings or where objects can become caught
in the blades
* near a window, where rain may create an electrical hazard
* in areas where paint, petrol, etc. is stored and there is a risk of explosion or fire
from flammable gases, or in areas where substances are being sprayed.
• CAUTION! Personal safety: Avoid contact with moving parts. Never insert
fingers, pencils or any other objects through the grilles/housing when the fan is
running. Keep hair and loose clothing well away from the fan when it is in use.
• Free airflow: Ensure nothing is blocking the air outlet and intake. Do not insert
objects into any opening as this may cause electric shock and/or a fire hazard.
• Misuse: We accept no responsibility for any injuries or damages caused by
misuse of the product or noncompliance with these instructions.
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]

5
Product Overview
NOTE: Due to continued product improvement, images and illustrations in this manual
may vary slightly from the product purchased. All images in this manual are for reference
purposes only. Parts are not necessarily pictured to scale.
Parts list
1 Safety guards (front and rear grilles)
2 Carry handle
3 Fan blade
4 Motor housing (at the back) with oscillation and speed controls
5 Pivot knob
6 Support post
7 Stand base
5
1
2
6
3
7
4
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]

6
Unpacking
• This product has been packaged to protect it against transportation
damage. Unpack the appliance and keep the original packaging carton
and materials in a safe place. It will help prevent any damage if the product
needs to be transported in the future, and you can use it to store the
appliance when it is not in use. In the event that the packaging is to be
disposed of, please recycle it where possible.
• Plastic wrapping can be a suffocation hazard for babies and young children,
so ensure all packaging materials are out of their reach and disposed of safely.
• Unwind the cord and inspect it for damage. Do not use the appliance if the
appliance or cord has been damaged or is not working properly.
• Make sure you have read and understood all instructions and warnings in
this manual. Refer to the illustrations to familiarise yourself with the product
and identify all parts. Pay particular attention to the safety instructions on
the previous pages.
• Your new fan has been shipped fully assembled ready for use.
Getting Started
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]

7
Instructions
The table fan features three speeds and a swivel action head for a smooth
oscillation action. To use the fan, follow the simple instructions below.
Place the fan on a dry, level surface where it will not overturn during use.
Make sure the speed control on top of the motor housing is in the OFF [ 0 ]
position, then insert the power plug into an appropriate electrical outlet.
Speed selection
• Move the speed control to
the desired speed setting:
0................OFF
1................LOW
2................MEDIUM
3................HIGH
Oscillation
The fan can operate in
oscillation or static mode.
• Push down the
oscillation knob
to activate the oscillation
function for widespread
breeze distribution.
The fan head will pivot from
one side to the other.
• For stationary operation,
pull up the knob to stop
oscillation when the fan
head is in the correct
position.
Tilt adjustment
The fan head can be slightly tilted up or down.
• Loosen the pivot knob, adjust the fan to the desired angle, then tighten the
knob firmly to secure.
Speed control
Oscillation knob
Pivot knob
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]

8
Other Useful Information
Cleaning and maintenance
• Dusting: Clean your fan periodically by lightly running a vacuum cleaner
nozzle (soft brush) over the front and rear guards to remove any dust or dirt
that may have accumulated inside or on the unit. Alternatively, use a soft,
dry cloth for dusting.
• Stubborn stains: Use a slightly damp, soapy cloth for stubborn stains but
be sure the cloth is not too wet. Use caution around the motor housing
area. Do not allow the motor or other electrical components to be exposed
to water.
• End of season cleaning: When you have finished using the fan at the end
of the season, wipe off any dust to maintain it in good working order for
the next season. Disassemble the front grille to get access to the fan blade
(remove the screw and nut and open the clips). Carefully clean the blade
and guards using a mild detergent and a damp cloth. Dry thoroughly.
• Storage: When storing your fan in the off season, make sure to
disassemble and clean the fan before storing. Follow the assembly
instructions in reverse order. It is important to keep the fan in a safe, dry
location, protected from dust. We recommend using the original carton
for storage. If you are storing the appliance fully assembled, place a large
plastic bag or piece of material over the top of the cleaned appliance for
dust protection.
• Service/repair: The appliance requires no maintenance and contains no
user-serviceable parts. Do not attempt to take the motor housing apart.
Do not try to repair or modify the appliance. Do not operate the fan if its
power cord or plug is damaged, or when it is working abnormally. In case
of damage or malfunction, or if the cord is damaged, have the unit repaired
by trained personnel only, or contact the after sales support line for advice
on repair or replacement. Before phoning for a service, please ensure that
your fan is properly assembled and connected to your power supply.
WARNING!
• Before cleaning, maintenance or moving the fan, and before removing a
front or rear guard, switch off the fan and unplug it from the wall outlet.
• Do not immerse the fan in water or other liquids. Do not spray it with
liquids. Do not allow water to drip on or into the fan motor housing.
• Never use petrol, solvents, harsh detergents, or abrasive or alkaline
cleaners on the fan.
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]

9
Other Useful Information (Cont.)
Technical specifications
Power 40W, 220-240V ~, 50Hz
Fan speeds 3 (Low - Medium - High)
Dimensions (mm) 420 x 340 x 250 mm
Weight (approx.) 3kg
Responsible disposal
• At the end of its working life, make the appliance unserviceable by
unplugging it from the power outlet and cutting the power cord.
• Do not throw this appliance out with your household rubbish. Electrical
and electronic products contain substances which can have a detrimental
effect on the environment and human health if disposed of inappropriately.
Observe any local regulations regarding the disposal of electrical consumer
goods and dispose of it appropriately for recycling. Contact your local
authorities for advice on recycling facilities in your area.
Compliance
This appliance has been fully tested and meets all requirements as set out by
standards AS/NZS 60335.1 and AS/NZS 60335.2.80.
The RCM Mark (Regulatory Compliance Mark) indicates that the product
complies with the relevant guidelines of the ACMA as well as corresponding
government requirements for the safety of electrical devices.
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]

10
This page has been left blank intentionally.
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]

11
This page has been left blank intentionally.
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]

Warranty returns
Should you for any reason need to return this product for a warranty
claim, make sure to include all accessories with the product.
Product does not work?
If you encounter problems with this product, or if it fails to perform
to your expectations, make sure to contact our After Sales Support
Centre on (AU) 1300 886 649 or (NZ) 0800 836 761 for advice.
Distributed by Tempo (Aust) Pty Ltd ABN 70 106 100 252
PO BOX 6056 Frenchs Forest, Australia NSW 2086
Customer Helpline:
(AU) 1300 886 649 (NZ) 0800 836 761
Email: [email protected]
For an electronic version of this manual, please contact our after sales support centre.
IM Version No: V1.0 Issue: May 2020
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
