EUROPRO Compact-Pro 120 User manual

EUROPE PROJECTION - 228, avenue Olivier Perroy 13790 ROUSSET - Tél : [phone] – Fax : [phone]
SAS au capital de 400 000 € - RCS Aix-en-Provence B 394 961 510 - NAF 2892 Z - Intracom : FR 54 394 961 510
Compact-Pro 120
Réf. 30966
User manual
Edition of 16/12/2021
More information on www.euromair.com

User manual - Compact-Pro 120 202010-495A-ENGP2
You just acquired one of our
machines and all the team
of Europe Projection thanks
you for the condence
you have granted us.
Manufacturer of professional
equipments for paint and
llers, we have put our
know-how for 25 years
at the service of the
users of our machines.
Our technical & commercial
team is at your disposal
for any further information
you may need about the
machine you just acquired.
EUROPE PROJECTION
228, avenue Olivier Perroy
13790 ROUSSET
Tél : [phone]
[e-mail]
SUMMARY
1. USER MANUAL............................................................. p. 3
1.1. Importance of the manual .........................................p. 3
1.2. Receivers of the manual............................................p. 3
2. WARNING .................................................................... p. 4
2.1. Safety .....................................................................p. 4
2.2. Transport ................................................................p. 6
2.3. End-of-life of the product ..........................................p. 7
3. YOUR MACHINE ........................................................... p. 8
3.1. Description..............................................................p. 8
3.2. Technical characteristics ...........................................p. 8
3.3. Identication of the components ................................p. 9
4. USE OF THE MACHINE ................................................. p.11
4.1. Machine prerequisites...............................................p.11
4.2. Machine starting up .................................................p.12
4.3. High pressure washer prerequisites ............................p.13
4.4. High pressure washer starting up ...............................p.14
4.5. Water doser.............................................................p.15
5. DEFECTS AND REMEDIES............................................. p.16
6. CLEANING PROCEDURE ............................................... p.18
7. MAINTENANCE............................................................. p.19
8. SAFETY CARD RUNNING............................................... p.21
9. VOLUME SCHEME ........................................................ p.23
10. ELECTRICAL SCHEMES............................................... p.24
11. DECLARATION OF CONFORMITY ................................. p.31
12. WARRANTY CONDITIONS............................................ p.32
13. FOLLOW-UP OF REVISIONS ........................................ p.35

202010-495A-ENG User manual - Compact-Pro 120 P3
1. USER MANUAL
1.1. IMPORTANCE OF THE MANUAL
This manual is a key part for the use of your machine. It summarizes the procedures of starting-up, cleaning
and maintenance of the device and also the safety instructions you need to observe.
Read carefully all the working and safety instructions and the warnings included in this manual before
starting your machine.
Most of the accidents are caused by the non-compliance of the safety standards and rules.
This manual must be kept near the machine, within reach of the user and held in good condition until the
nal destruction of the machine.
In case of loss or deterioration of the manual, you can ask the machine manufacturer mentioned on page
4 for a copy at any moment.
1.2. RECEIVERS OF THE MANUAL
This manual is intended to any staff which will manipulate the machine :
- people in charge of the transport of the machine
- people in charge of the use of the machine
- people in charge of the cleaning and maintenance of the machine
- people in charge of the nal destruction of the machine

User manual - Compact-Pro 120 202010-495A-ENGP4
2. WARNING
2.1. SAFETY
Using the machine in an incorrect way or in non-compliance of the safety instructions indicated in
this manual can cause death or serious injuries.
Read carefully all the working and safety instructions and the warnings contained in this manual
before starting your machine.
• Respect all the safety standards before running the equipment.
• Use the equipment only for the applications specied in the manual.
• Always remain alert when using the equipment.
• Transport the machine using the handles or the appropriate grips.
• During the breaks, disconnect electrically the machine.
• Run the equipment to its nominal voltage.
• Let at least 50 cm of free space between the equipment and any obstacle so that the air ow
is not blocked.
• Know how to quickly stop the equipment in case of necessity.
• Never use the equipment while it is running abnormally or it is defective.
• Do not direct a water jet or ammable liquid on the machine.
• Never direct an air jet or product jet on a person or an animal.
• Do not touch warm surfaces of the equipment.
• Always wear adequate body protections (glasses, gloves, overall and mask) and pay attention
to long hair.
• Never touch moving parts.
• Do not insert any object or the hands inside the protection grids to avoid any accident or
damage to the machine.
• For any outside job, only use appropriate extension cords.
• Maintain the equipment carefully and clean it properly after every use.
• Disconnect the equipment before any intervention.
• Avoid absolutely to unscrew any connection while the machine is under pressure.
• Check the damaged parts.
• Do not clean the plastic parts with solvant.
• In case of needed After-Sale Service, always specify the machine model and its serial number.
• For any replacement of parts, only use genuine parts.
• Do not modify the machine.
• Do not cut or dismantle the protection grids.
• Do not open the electric box.

202010-495A-ENG User manual - Compact-Pro 120 P5
IN CASE OF NECESSITY, WE SAVE OURSELVES THE RIGHT TO MAKE ANY USEFUL
MODIFICATION WITHOUT ADVANCED NOTICE.
2. WARNING (continued)
2.1. SAFETY (continued)
WORKSPACE
• Maintain the workspace clean and clear.
• Ambient operating temperature must be from 5°C and 35°C.
• Do not use the equipment in a potentially explosive area.
• Do not place any potentially inammable objects in close proximity to the machine.
• Take away every not qualied person from the working area of the machine, as well as children and
animals.
• Do not install the equipment on an inclined surface to avoid the risks of unexpected moves or falls.
HOSES
• Always use hoses and connections adapted to the used product (genuine parts), do not try to x it.
• Do not walk on the hoses, do not bend them.
• Do not use the hoses to pull the machine.
STORAGE
• Keep the equipment in a clean and clear area in which the temperature does not exceed +35°C.
• After every use, necessarily grease the pump with a mixture of water + storage liquid to avoid it blocking
up. The storage of a not greased pump can damage it seriously.

User manual - Compact-Pro 120 202010-495A-ENGP6
IN CASE OF NECESSITY, WE SAVE OURSELVES THE RIGHT TO MAKE ANY USEFUL
MODIFICATION WITHOUT ADVANCED NOTICE.
2. WARNING (continued)
2.1. SAFETY (continued)
SAFETY SYSTEMS
This machine has been designed to allow working with the maximum safety.
So safety sensors and emergency stop has been setted on your machine without complicating your work.
We are insisting on your caring to maintain them in good condition and above all not to remove them.
In case of malfunction, please contact immediately your dealer.
HYDRAULIC
This machine is equipped with high pressure hydraulic circuits (200 bar).
The following insctructions are essential for your safety:
• Never tighten a hydraulic connection while the machine is working.
• Never try to wipe an oil drop on a hose or hydraulic component with your nger while the machine
is working.
• Take care of the good condition of the plumbing (a damaged or blistered rubber must be changed
immediately).
• Check regularly if the circuit does not have any leak.
• In any case, do not touch hydraulic parts (even when the machine is not working) because the
components shall be hot and there is a burn risk.
SAFETIES AND PROHIBITIONS
• The hopper grid rising up causes the screw movement stop.
• Emergency stop is located on the machine hood. Do not hesitate to use it if needed, this will immediately
stop the motor. To restart the machine after emergency stop button pushed, follow this procedure:
- Put the command handles in central position.
- Rearm emergency stop.
- Command panel lamps must be lighted-up (green = correct / red = default).
- Engage the starter with the contact key.
- Resume spraying procedure.

202010-495A-ENG User manual - Compact-Pro 120 P7
2. WARNING (continued)
2.2. TRANSPORT
• This machine was the object of a road homolagation (n°e2*2007/46/0673). As such, it must be
registered and can be thus dragged normally on the road network.
• The adjustable jockey wheel easily allows you to x the helm to the harness of your vehicle.
• The adjustable helm gives you the possibility of adjusting the machine horizontally.
• An electric cable provided with a grip allows you to link the device of lighting of the trailer with the
tractor truck.
• A cable of break allows to bind the device of harness of your vehicle with the machine in case of hanging
problem of the helm during a travel.
It is imperative to collide this cable on the harness of the vehicle.
Before any road travel:
• Check the pressure of the pneumatics which has to be 2.8 bar max.
• Check the tightening of the nuts of wheels.
• Check the tightening of the nuts of the articulated helm and the presence of pins.
• Clean reectors.
• Clean and check the functioning of the device of lighting.
• Collide the cable of break.
2.3. END OF LIFE OF THE PRODUCT
At its end-of-life, the machine must not be eliminated with the other household waste. The
uncontrolled elimination of waste can harm the environment or human health. Individuals are
invited to contact the distributor which sold them the product or to inquire with their city hall
to know where and how to get rid of the product so it can be recycled while respecting the
environment.
For any further information, please contact our hotline [phone] or [e-mail].
Only are exempted from the obligation of brakes the only trailers under the double condition
that their total weight authorized in load does not exceed 750 kg nor half of the pure weight
of the truck tractor.
Compact-Pro 120 is not a transport trailer, it is strictly forbidden to transport people or
products related to the application of the machine.

User manual - Compact-Pro 120 202010-495A-ENGP8
3. YOUR MACHINE
3.1. DESCRIPTION
Very high-volume diesel spraying machine for liquid screed applications.
Made in France, it is equipped with a button control panel for simplied use, an automatic accelerator,
reinforced motor and hydraulic pump.
The safety devices comply with the standards in place and the hydraulic circuits are protected against
possible blockages of the rotating elements. An air cooler ensures that the oil temperature is maintained
within the correct range.
3.2. TECHNICAL CHARACTERISTICS
Motor Kohler KDW 1404
Motor power 19 kW
Fuel Gasoil
Diesel tank 25 L
Cooling liquid
Speed of rotation 2500 RPM
Number of cylinders 4
Consumption 4,1 L/h
Hydraulic system 28 L
Engine monitoring panel complete
Hydraulic controls manual
Pump speed setting yes
Automatic accelerator control yes
Hopper capacity 230 L
Variable ow from 0 to 200 L/min - 12 m3/h
Pressure from 0 to 30 bar
Maximum grain size up to 8 mm
Pump MAP 9
Pump reverse operation yes
HP washer max pressure 140 bar
HP washer ow-rate 11 L/min
Overall length with tow bar 3,58 m
Overall length without tow bar 3,20 m
Overall width 1,24 m
Height at the highest point 1,28 m
Weight when full with oil and diesel 720 kg
Delivery height 80 m
Max. hose length 120 m
Delivered with
- a 20 m hose
- two cleaning balls Ø50
- a grease pump with a grease cartridge
- a complete high pressure washer lance
- a 10 m high pressure washer hose
- a storage carry-case

10
11
12
4
1
5
2
6
98
7
3
202010-495A-ENG User manual - Compact-Pro 120 P9
3. YOUR MACHINE (continued)
3.3. IDENTIFICATION OF THE COMPONENTS
1Hydraulic oil level 7Adjustable pump
2Engine oil level 8Product pressure control manometer
3Electric circuit breaker 9Pump outlet
4Hopper bearing lubricator 10 Jockey wheel
5Diesel tank cap 11 Hood clips
6Hopper vibrator 12 Emergency stop

21
20
19
23
22
18
17
151413
16c 16e16a 16b 16d
User manual - Compact-Pro 120 202010-495A-ENGP10
3. YOUR MACHINE (continued)
3.3. IDENTIFICATION OF THE COMPONENTS (continued)
13
Automatic accelerator control
By default, when the switch is in the 0 position, the
engine is idling.
It is the wired remote control (to be connected to the
control panel under the switch (13)) which activates or
deactivates the acceleration of the diesel engine.
14 Hopper vibrator control
15 Remote control plug
16 Diesel engine display
16a Low fuel level (diesel).
16b Battery (lights up when the alternator does not charge
the battery).
16c Oil (lights up when oil pressure is insufcient).
16d Cooling liquid (lights up when the maximum operating
temperature is reached and causes the engine to stop).
16e Pre-heating (switches off when the pre-heating
temperature is reached).
17 Screw hopper circuit pressure manometer
Maximum pressure 200 bar.
18 Washer circuit pressure manometer
Maximum pressure 150 bar.
19
Hopper screw speed controller
Clockwise rotation: increase speed.
Counter-clockwise rotation: decrease speed.
20 Hour meter
21 Switching on the machine and starting the engine
22
Product pump rotation control handle
Reverse: left position with spring return to the centre.
Stop: centre position.
Forward: right position maintained.
23 Handle On (right position) / Off (left position) HP
washer

202010-495A-ENG User manual - Compact-Pro 120 P11
4. USE OF THE MACHINE
4.1. MACHINE PREREQUISITES
• Check the hydraulic oil level (1) and complete if necessary.
• Check engine oil level (2) and complete if necessary.
• Check the lubrication of the motor bearing of the hopper (4).
• After a prolonged standstill, it is possible that the pump might be blocked. If this is the case, alternately
turn the pump forwards and backwards for 5 second sequences using the handle (22). As soon as the
engine starts to turn normally, the pump is unblocked.
There must be no foreign objects in the hopper (trowel, tools, etc.).
The machine is delivered with a 20 m hose length, this length is optimized to obtain the best
output in normal conditions of use.
If a longer length is used, it is essential to check the correct operation of the whole unit.
Increasing the length of the hose may result in a reduction of the ow rate to zero (too much
pressure drop in the hose).
The pressure drop in the hoses is proportional to their length and to the viscosity of the
product. In some cases, it will be necessary to use a pump that generates a higher pressure
to compensate for this loss. Whenever possible, a dilution of the product and a higher pump
pressure will allow a better ow in the hoses.
Never use petroleum-based products in the pump, as they may damage it.
Never run the pump without water or product.

User manual - Compact-Pro 120 202010-495A-ENGP12
4. USE OF THE MACHINE (continued)
4.2. MACHINE STARTING UP
1. Place the machine horizontally by lowering or raising the jockey wheel (10) so that the machine is
stable and level.
2. Unlock the emergency stop (12) on top of the xed polyester hood.
3. Place the contact key in the ON position. The lights should light up, otherwise check that the circuit
breaker (3) located under the hood, above the battery, is in the ON position.
4. Wait until the preheating indicator light (16e) turns off and then activate the engine starter by turning
the contact key (21).
5. Let the engine run for 5 to 10 minutes to warm up before continuing work.
6. Fill the hopper with approx. 30 litres of water.
7. Check the pump pressure and adjust if necessary (see procedure below).
8. Connect the remote control cable to the socket (15).
9. Connect the product hose to the pump outlet (9).
10. Press the button on the remote control to turn the screw of the hopper. Turn the pump to the FORWARD
position by turning the lever (22) to the right.
11. Run water through the hose and then empty the hose.
12. Prepare a mixture of water and liquid cement and pour it into the hose.
13. Empty the remaining water in the hopper by opening the plug for this purpose.
14. Pour the product to be used into the hopper. The machine is now ready to work.
15. During use, use the control (19) to adjust the product ow rate.
PUMP PRESSURE CONTROL :
• Pour water into the tank.
• Connect the control hose to the pump outlet (9).
• Set the ow rate to maximum.
• Turn the screw (handle (22)). When water comes out, close the valve of the pressure controller and read
the value on the manometer (8).
• To adjust the pump pressure, tighten or loosen the screws on the pump.
Never run the screw without product or water.
The screw rotation control handle has a preferential direction characterized by a held
position. Reverse rotation is possible by holding the handle manually in the LEFT position.

202010-495A-ENG User manual - Compact-Pro 120 P13
4. USE OF THE MACHINE
4.3. HIGH PRESSURE WASHER PREREQUISITES
• Control is carried out by the HP WASHER handle (23).
• The high pressure cleaner kit includes:
- the quick coupler for connecting the water supply
- the 10 m pressure hose, the gun and the lance
• Before switching on the washer, check that the water supply hose as well as the pressure hose and the
complete lance are connected.
HOSES CONNECTION :
Remember to clean the suction lter very regularly (at least once a week) to avoid cavitation
of the pump. The lter is located just behind the water inlet connection.
It is essential for the proper functioning and longevity of the washer that it never operates
without water. Therefore, before starting the washer, it is imperative to open the water
supply valve of the supply source and check that there are no knots in the supply hose.
Under pressure outlet
Water inlet with Gardena type
connection

User manual - Compact-Pro 120 202010-495A-ENGP14
4. USE OF THE MACHINE (continued)
4.4. HIGH PRESSURE WASHER STARTING UP
• Move the washer starting handle to the right position.
• Press the trigger of the cleaning lance and clean the machine.
ONCE THE CLEANING IS COMPLETE:
• Move the washer starting handle to the left position.
• Turn off the water supply at the source and disconnect the supply hose.
• Press the gun on the cleaning lance to release the residual pressure in the high pressure hose.
• Disconnect the high pressure hose.
• Clean the lter behind the water inlet quick coupling.
Always wear the appropriate personal protective equipment (goggles, gloves, etc.) so as not to
injure yourself during cleaning.
This cleaner is dedicated exclusively to the cleaning of the machine.

B3L1 L2
B1
B2
B5
B4
A2A1
202010-495A-ENG User manual - Compact-Pro 120 P15
4. USE OF THE MACHINE (continued)
4.5. WATER DOSER
B1 Power On / Power Off / Reset A1 Display of the actual ow rate
B2 Start / Stop / Resume dosing A2 Setpoint display (desired water volume)
B3 Impulse water addition L1 Power-on indicator light
B4 Increase of the dosing setpoint L2 Dosage run indicator light
B5 Decrease of the dosage setpoint
START / STOP
• When the power is turned on or the engine is running, the water meter indicates OFF.
• Pressing the ON / OFF button switches the water doser on.
• The display (A1) shows 0 and the display (A2) shows the value of the last setpoint.
WATER DOSAGE
• Set the desired amount of water with buttons (B4) and (B5). The display (A2) shows the setting in litres.
• Pressing the DOSAGE button (B2) starts water dosing, the light (L2) lights up during the entire dosing
time and the display (A1) increments the volume of water injected. When the set value is reached, the
water ow stops automatically and the indicator (L2) lights off.
• During the automatic cycle, pressing the DOSAGE button (B2) will pause the cycle. Pressing it again
resumes the cycle.
• Pressing the +WATER button (B3) will cause water to ow for as long as the button is held down. The
display (A1) adds the volume of water added to the displayed volume. This function is only possible
outside of the automatic water dosing cycle seen above.
If the water doser is ON and the engine is stopped, it will automatically return to OFF when
the engine is started. It is therefore necessary to avoid starting a dosing cycle during this time.

User manual - Compact-Pro 120 202010-495A-ENGP16
5. DEFECTS AND REMEDIES
n° Defects To check Remedies
1
Dashboard lights do not
illuminate.
The circuit breaker is not engaged. Check the position of the circuit breaker,
turn the key clockwise.
The dashboard fuse is out of order. Change the fuse.
The battery connections are bad. Check both battery terminals. Check the
presence of grey-green, brush the pods.
The battery is out of order or not
charged.
Contact the nearest technical service, the
battery must be changed, pay attention
to the polarities.
The power supply circuit must be swit-
ched off somewhere. Contact Technical Service.
2Engine does not start when cold
Check for diesel fuel. Fill up the tank.
Check the quality of the fuel.
Drain the tank, clean and rell with qua-
lity diesel fuel.
Change the lter.
Check fuel lter. It must be changed regularly, check the
maintenance booklet, change the lter.
The engine has been switched off.
Re-start the engine with the hand pump
(see engine manual) and check the hoses
(air inlet).
Problem with the electrical supply. See problem 1.
Diesel solenoid valve. Check wire on diesel solenoid valve.
Check emergency stop.
Preheating does not work. Check the 50A reed switch fuse in the
dashboard housing.
I've already checked all these points, but
it doesn't change anything. Contact technical service.
3Engine does not start when hot
First See problem 2.
The engine safety system prevents
starting due to lack of oil pressure.
Check the oil level of the combustion
engine (engine cold).
The safety relay is out of order Contact technical service.
The engine oil pressure sensor is out of
order. Contact technical service.
4The diesel engine smokes white
There is water in the diesel fuel.
Drain the tank, clean and rell with
quality diesel fuel.
Change the lter.
Check the injection / Clean the injection Contact technical service.
Cylinder head gasket.
Check the cooling liquid level.
Check engine oil level and texture
("mayonnaise").
5The diesel engine smokes black Check engine oil level. If low level contact technical service.
Check the injection / Clean the injection Contact technical service.

202010-495A-ENG User manual - Compact-Pro 120 P17
5. DEFECTS AND REMEDIES (continued)
n° Defects To check Remedies
6Hopper screw does not turn
Check the speed control knob. Increase speed.
Check the position of the grid. Close the grid (see electronic board
indicator).
Check that the security card is working properly.
Power supply problem. See Problem No. 1.
Hydraulic problem. Contact the technical service.
7Hopper screw does not stop Hydraulic problem. Contact technical service.
8The product does not come out
at the end of the spray lance
Check that there are no plugs in the
product pipes.
Check the consistency of the product.
Unclog hoses.
Check that the hopper screw rotates
properly. See problem 6.
Check the pump for wear. Use the pressure controller at the pump
outlet.
9HP washer does not work
Check the water supply. The hose must not be pinched and the
water valve open.
Check the lter for clogging. Clean the supply lter before each use.
Hydraulic problem. Contact a dealer.

User manual - Compact-Pro 120 202010-495A-ENGP18
6. CLEANING PROCEDURE
1. Empty the tank to the maximum without adding water inside.
2. Clean the tank (remove the drain plug to allow water to drain, never run water through the full product
hose).
3. Once the tank is clean, replace the plug.
4. Disconnect the product hose and ll the tank with clean water.
5. Activate the rotation of the screw to clean the pump.
6. Place the cleaning ball in the product outlet (9) and replace the hose.
7. Start the machine.
8. When the ball comes out of the hose, stop the machine and repeat operations 6 and 7 until water comes
out of the hose clean.
The direct projection of water under pressure onto the control panel has to be stopped at the
risk of water inltration. Proceed by simply cleaning with a humid sponge.
Before unscrewing the hose, make sure it is not under pressure anymore.

202010-495A-ENG User manual - Compact-Pro 120 P19
7. MAINTENANCE
After the rst 50 hours of operation:
- Replace the return lter cartridge on the hydraulic tank.
Every 50 hours:
- Check cooling radiator ns for cleanliness.
- Check the hydraulic oil level on the level indicator on the tank and rell with HV46 hydraulic oil if necessary.
- Grease the hopper bearing and the jockey wheel.
- Check the safety devices hopper grid.
- Check the operation of the emergency stop located on the xed cover.
Every 125 hours:
- Check the drawbar axle mountings.
- Check the condition of the axle and tyres.
- Check the condition of the clamping screws of the swivel drawbar as well as the pins.
- Check the attachment and proper functioning of the coupling system.
Every 500 hours:
- Replace the return lter cartridge on the hydraulic tank.
Every 1000 hours and/or every year:
- Drain the hydraulic tank, clean the suction strainer and replace the lter cartridge.
Verications concerning the diesel engine and hydraulic part must always be carried out on
a cold machine.
For any work on the diesel engine, refer to the maintenance manual supplied with the
machine.
In order to guarantee a long-lasting operation of the machine, we invite you to contact your
dealer for any maintenance intervention. He will carefully carry out the operations and check
the various points we recommend.

User manual - Compact-Pro 120 202010-495A-ENGP20
7. MAINTENANCE (continued)
Interval in hours of use or months,
whichever comes rst.
Hours 50 250 500 750 1000
Months 2 12 24 36 48
Replace engine oil XXXXX
Replace oil lter XXXXX
Replace diesel lter XXXXX
Replace air lter X X X X
Replace belts X X
Replace coolant X X
Replace cooling hoses X
Replace fuel hoses X
Replace hydraulic oil lter XXXXX
Clean hydraulic tank strainer X X X
Replace hydraulic oil X X
Replace cleaner oil X X X X
Replace timing belt 4000 hours ou 4 years
Adjust valve clearance X X
Tare and clean injector X
Clean radiator (outside) X X X X
Clean radiator (inside) X
Clean fuel tank X
Clean hydraulic tank X
Check tightening of screws and hoses XXXXX
Check pump, seals and ectors At every use
