EUROPRO Eurospray S User manual

EUROPE PROJECTION - 228, avenue Olivier Perroy 13790 ROUSSET - Tél : [phone]
SAS au capital de 400 000 € - RCS Aix-en-Provence B 394 961 510 - NAF 2892 Z - Intracom : FR 54 394 961 510
Eurospray S & S mini
Réf. 51100 / 51150
User manual
Edition of 30/09/2023
More information on www.euromair.com

User manual - Eurospray S / Eurospray S mini 202309-668-ENGP2
You just acquired one of our
machines and all the team
of Europe Projection thanks
you for the condence
you have granted us.
Manufacturer of
professional equipments
for paint and llers, we
have put our know-how for
25 years at the service of
the users of our machines.
Our technical & commercial
team is at your disposal
for any further information
you may need about the
machine you just acquired.
EUROPE
PROJECTION
228, avenue Olivier Perroy
13790 ROUSSET
Tél : [phone]
[e-mail]
SUMMARY
1. USER MANUAL................................................................ p. 3
1.1. Importance of the manual ............................................p. 3
1.2. Receivers of the manual ..............................................p. 3
2. WARNING ......................................................................... p. 4
2.1. Safety ...........................................................................p. 4
2.2. Electric connection .......................................................p. 6
2.3. End-of-life of the product..............................................p. 6
3. YOUR MACHINE .............................................................. p. 7
3.1. Description ...................................................................p. 7
3.2. Technical characteristics ..............................................p. 7
3.3. Identication of the components ..................................p. 8
4. USE OF THE MACHINE ...................................................p.11
4.1. Prerequisites ................................................................p.11
4.2. Preparing the work area...............................................p.11
4.3. Preparing the machine .................................................p.12
4.4. Preparing the product to be sprayed............................p.13
4.5. Starting up....................................................................p.14
4.6. Spraying technique ......................................................p.15
4.7. Unclogging the tip ........................................................p.17
4.8. Stopping work ..............................................................p.17
5. MAINTENANCE................................................................ p.18
5.1. Cleaning procedure......................................................p.18
5.2. Defects and remedies ..................................................p.19
5.3. Error codes...................................................................p.20
6. DECLARATION OF CONFORMITY................................ p.21
7. WARRANTY CONDITIONS............................................. p.22

202309-668-ENG User manual - Eurospray S / Eurospray S mini P3
1. USER MANUAL
1.1. IMPORTANCE OF THE MANUAL
This manual is a key part for the use of your machine. It summarizes the procedures of starting-up,
cleaning and maintenance of the device and also the safety instructions you need to observe.
Read carefully all the working and safety instructions and the warnings included in this manual before
starting your machine.
Most of the accidents are caused by the non-compliance of the safety standards and rules.
This manual must be kept near the machine, within reach of the user and held in good condition until
the nal destruction of the machine.
In case of loss or deterioration of the manual, you can ask the machine manufacturer mentioned on
page 4 for a copy at any moment.
1.2. RECEIVERS OF THE MANUAL
This manual is intended to any sta󰀨 which will manipulate the machine :
- people in charge of the transport of the machine
- people in charge of the use of the machine
- people in charge of the cleaning and maintenance of the machine
- people in charge of the nal destruction of the machine

User manual - Eurospray S / Eurospray S mini 202309-668-ENGP4
2. WARNING
2.1. SAFETY
Using the machine in an incorrect way or in non-compliance of the safety instructions
indicated in this manual can cause death or serious injuries.
Read carefully all the working and safety instructions and the warnings contained in this
manual before starting your machine.
• Respect all the safety standards before running the equipment.
• Use the equipment only for the applications specied in the manual.
• Always remain alert when using the equipment.
• Transport the machine using the handles or the appropriate grips.
• During the breaks, disconnect electrically the machine.
• Run the equipment to its nominal voltage.
• Let at least 50 cm of free space between the equipment and any obstacle so that the air
ow is not blocked.
• Know how to quickly stop the equipment in case of necessity.
• Never use the equipment while it is running abnormally or it is defective.
• Do not direct a water jet or ammable liquid on the machine.
• Never direct an air jet or product jet on a person or an animal.
• Do not touch warm surfaces of the equipment.
• Never touch moving parts.
• Do not insert any object or the hands inside the protection grids to avoid any accident or
damage to the machine.
• For any outside job, only use appropriate extension cords.
• Always wear adequate body protections (glasses, gloves, overall and mask) and pay
attention to long hair.
• Maintain the equipment carefully and clean it properly after every use.
• Disconnect the equipment before any intervention.
• Avoid absolutely to unscrew any connection while the machine is under pressure.
• Check the damaged parts.
• Do not clean the plastic parts with solvant.
• In case of damage of the electric cable or the plug, do not run the machine and contact a
licensed After-Sale Service to put genuine parts instead of the defective ones.
• In case of needed After-Sale Service, always specify the machine model and its serial
number.
• For any replacement of parts, only use genuine parts.
• Do not modify the machine.
• Do not cut or dismantle the protection grids.
• Do not open the electric box.

202309-668-ENG User manual - Eurospray S / Eurospray S mini P5
IN CASE OF NECESSITY, WE SAVE OURSELVES THE RIGHT TO MAKE ANY USEFUL
MODIFICATION WITHOUT ADVANCED NOTICE.
2. WARNING
2.1. SAFETY
WORKSPACE
• Maintain the workspace clean and clear.
• Ambient operating temperature must be from 5°C and 35°C.
• Do not use the equipment in a potentially explosive area.
• Do not place any potentially inammable objects in close proximity to the machine.
• Take away every not qualied person from the working area of the machine, as well as children
and animals.
• In case of installation of the machine on sca󰀨olding or a plan above ground level, attach the machine
to avoid any fall while operating.
• Do not install the equipment on an inclined surface to avoid the risks of unexpected moves or falls.
HOSES
• Always use hoses and connections adapted to the used product (genuine parts), do not try to x it.
• Do not walk on the hoses, do not bend them.
• Do not use the hoses to pull the machine.
STORAGE
• Keep the equipment in a clean and clear area in which the temperature does not exceed +35°C.
• After every use, necessarily grease the pump with a mixture of water + storage liquid to avoid it
blocking up. The storage of a not greased pump can damage it seriously.

User manual - Eurospray S / Eurospray S mini 202309-668-ENGP6
2. WARNING (continued)
2.2. ELECTRIC CONNECTION
The electric connection of the machine must be on a 16A - 230V plug with a di󰀨erential circuit
breaker.
Before any intervention on the machine, make sure that every energy supply is cut (air and
electricity).
GROUND CONNECTOR
All the machines must be connected to the ground when they work to protect the operator from electric
shocks. Our machines are all equipped with standardized connection plugs.
Electric connection must be made by a qualied technician. It is fobidden to modify or dismantle the
machine, especially the electric box.
Repairs must be made by an authorized center or our After-sale Service.
During any intervention on the machine, make sure that the ground is well reconnected.
EXTENSION CORDS
During the use of an extension cord, make sure that it is not crushed or damaged and that it contains a
ground. Check that the section of the used extension cord is su󰀩cient to support the machine when it
is working. A too thin extension cord can cause voltage drops or overheating of the machine.
In case of use of a cable reel, it is imperative to unwind it entirely, otherwise, the equipment can be
damaged. The section must be proportional to the length of the cord.
2.3. END OF LIFE OF THE PRODUCT
At its end-of-life, the machine must not be eliminated with the other household waste. The
uncontrolled elimination of waste can harm the environment or human health. Individuals are
invited to contact the distributor which sold them the product or to inquire with their city hall
to know where and how to get rid of the product so it can be recycled while respecting the
environment.
Under the regulation of Waste of Electrical and Electronic Equipments (WEEE), we undertake
to process the used EEEs according to the following provisions: applicable only to products on
the market since 08/13/05, under the brands EUROPE PROJECTION or VOLUMAIR, products
of other brands sold by our company (upon presentation of the corresponding invoices),
products that operate using electrical energy (for example, thermal washers or compressors
do not fall into this category).
Treatment modality
WEEE returns collected by our clients/distributors at their own expense to our collection points
in Antony (92) or Rousset sur Arc (13). Upon receipt, the products are sorted by our employees
and directed to the most appropriate processing channels.
For any further information, please contact our hotline [phone] or [e-mail].

202309-668-ENG User manual - Eurospray S / Eurospray S mini P7
3. YOUR MACHINE
3.1. DESCRIPTION
Airless sprayer for all types of paint on small and medium-sized sites.
It is very practical on site, with its simplied control panel, quick-release pump, suction rod to draw paint
directly from the bucket, cable reel and robust chassis on rubber pads.
The S version is equipped with a retractable arm, which enables the hose to be rolled up, and large-
diameter wheels to make it easy to transport and handle.
APPLICATIONS
Water-based or solvent-based paints: lacquers, woodstains, varnishes, primers, ceiling mattes,
disinfectants, enamels, wood treatment, etc.
3.2. TECHNICAL CHARACTERISTICS
Eurospray S Eurospray S mini
Max. working pressure 200 bar
Max. product ow rate 1,6 L/min
Power 0,75 kW
Supply 230 V / 50-60 Hz
Max tip (new) 0,021"
Dimensions (L x w x h) 56 x 48 x 94 cm 56 x 45 x 38 cm
Weight 21,5 kg 18 kg
Delivered with
- a Ø1/4" x 15 m hose, 270 bar
- a PaintSpray gun with tip holder
- a 417 standard tip
- a 100 mL bottle of oil for piston pump
- a case containing :
• a Ø3 Allen key
• a 17/19 open-end spanner
• a 19/22 open-end spanner
Do not use abrasive products, acids, alkalis, combustible products, facade paints,
etc.

F
G
C
D
E
I
H
A
B
J
User manual - Eurospray S / Eurospray S mini 202309-668-ENGP8
3. YOUR MACHINE (continued)
3.3. IDENTIFICATION OF THE COMPONENTS
AOn/o󰀨 switch
BControl panel
CProduct suction rod
DReturn hose
EPower cable
FProduct outlet connector
GBy-pass valve
HPump lter
IPump lubrication slot
JPump removal nuts

G
F
E
K
C D
H
I
A
B
J
202309-668-ENG User manual - Eurospray S / Eurospray S mini P9
3. YOUR MACHINE (continued)
3.3. IDENTIFICATION OF THE COMPONENTS (continued)
AOn/o󰀨 switch
BControl panel
CProduct suction rod
DReturn hose
EPower cable
FProduct outlet connector
GBy-pass valve
HPump lter
IPump lubrication slot
JPump removal nuts
KBucket support

N
L
M
R
Q
P
O
ST
User manual - Eurospray S / Eurospray S mini 202309-668-ENGP10
3. YOUR MACHINE (continued)
3.3. IDENTIFICATION OF THE COMPONENTS (continued)
LTrigger
MTrigger locking pin
NGrip lter
OProduct intlet connector
PTrigger protection
QTip support
RTip
STip gasket
TTip seat

202309-668-ENG User manual - Eurospray S / Eurospray S mini P11
4. USE OF THE MACHINE
4.1. PREREQUISITES
• The electric connection has to be 230 V - 16 A - 50 or 60 Hz with a 3 x 2,5 mm² cable reel of 40m
maximum, completely unreeled.
THERMAL PROTECTION
• The machine is equipped with a thermal protection which stops the motor in the event of overheating.
If this happens, stop the machine (button (A) on the housing), turn the valve (G) to the vertical
position (priming) and disconnect the mains plug. Let the machine cool down for at least 30 minutes.
Eliminate the cause of the overheating (poor room ventilation, blocked air intake slots, etc.).
TOOLS REQUIRED FOR USE
• A mallet.
• An empty receptacle.
• A large piece of cardboard.
• Masking kit (protective lm + adhesive).
4.2. PREPARING THE WORK AREA
• When spraying paint, a mist may form. Use the masking material to cover all the areas and objects
to be protected from the paint or remove them from the spraying area if possible (door and window
frames, furniture and objects, electrical sockets and switches, etc.).
Any penetration of the sprayed product into an electrical socket or switch could
lead to an electric shock which could cause serious injury and/or damage.
If a product containing silica is used, ensure that glass or ceramic surfaces that
could be damaged by such a product are properly masked.
Avoid using masking tape that is too strong on sensitive areas (wallpaper, painted
surfaces) to avoid damaging them when the tape is removed.

User manual - Eurospray S / Eurospray S mini 202309-668-ENGP12
4. USE OF THE MACHINE (continued)
4.3. PREPARING THE MACHINE
ASSEMBLY
1. Screw the hose onto the high-pressure lter support (F) using the spanners supplied.
2. Screw the other end of the hose onto the spray gun connector.
3. Fit the tip gasket (S) and tip seat (T) into the tip support, then screw the tip support onto the spray
gun and screw it in as far as it will go to secure it.
CONTROLS
• The on/o󰀨 switch (A) is located on the machine housing.
• The 2-position valve (G) is located near the high-pressure lter:
Vertical position (priming) ► Preliminary lling of the paint circuit.
► Pressure release.
Horizontal position (spraying) ► Spraying onto the surface to be painted.
• The control panel (B), located on the housing, is used to adjust the spraying pressure according to
the product and the work to be carried out (buttons - and +) and to start the motor for pumping (OK
button).
SPRAY GUN
• To lock or unlock the spray gun trigger, press the locking pin (M) (trigger released).
• The tip must be inserted with the point facing forward.
• Replace the lter in the gun grip:
- Release the trigger protection.
- Unscrew the product inlet connector and pull the grip downwards to release the lter and
remove it.
- Install the new lter in its place, pierced side up.
- Ret the handle in reverse order.
The trigger must always be locked when the gun is not in use or for any manipulation
on the gun (tip change, repair, etc.).
The lter must be replaced without any pressure in the gun.
Carry out a pressure relief (see next page) before this operation.
Depending on the product to be sprayed, it may be necessary to change the size of
the tip and/or the grip lter.

202309-668-ENG User manual - Eurospray S / Eurospray S mini P13
4. USE OF THE MACHINE (continued)
4.3. PREPARING THE MACHINE (continued)
PRESSURE RELIEF
1. Lock the gun trigger.
2. Switch o󰀨 the machine (button (A) in position 0).
3. Turn valve (G) to vertical position.
4. Unlock the trigger, place the gun over an empty container, then press the trigger to release the
pressure.
5. When all the pressure has been released, lock the trigger again.
4.4. PREPARING THE PRODUCT TO BE SPRAYED
• To ensure optimum atomisation of the product, it is important to dilute it if necessary in accordance
with the manufacturer’s dilution recommendations (refer to the technical data sheet for the product
to be sprayed).
• Mix the product (by hand or using a portable mixer) and dilute it directly into the bucket.
DILUTION RECOMMENDATIONS
Products Dilution
Water-based or solvent-based paints from 5 to 10%
Wall paints
(water-based or solvent-based) from 0 to 10%
Varnishes none
Wood protection products, oils, stripping products, disinfectants,
phytosanitary products none
The values given in the table above are for guidance only. Dilution must comply with
the recommendations on the product packaging and can be adjusted by carrying
out spray tests (see Spraying technique section).
It is essential to release the pressure from the hose and gun when the machine is
switched o󰀨 (for any reason). This procedure avoids the risk of injury when resuming
work.

User manual - Eurospray S / Eurospray S mini 202309-668-ENGP14
4. USE OF THE MACHINE (continued)
4.5. STARTING UP
1. Lubricate the pump using the burette supplied (through the slot (I)).
2. Disconnect the return hose (D) from the suction rod (C) (S version only).
3. Place the return hose (D) in an empty bucket and the suction rod in the bucket of product to be
sprayed (or water for the rst use).
4. Plug the machine into the mains.
5. Turn the valve (G) to the vertical position (priming).
6. Set switch (A) to position I to switch on the machine.
7. Adjust the pressure using the - and + buttons, suction will start.
8. As soon as the product ows into the empty container through the return hose, stop the machine
(button (A)).
9. Attach the return hose to the suction rod (S version only).
10. Turn the valve (G) to the horizontal position (spraying).
11. Point the spray gun at a piece of cardboard and start the machine (button (A)).
12. Unlock the spray gun and press the trigger to spray the cardboard until the product comes out
evenly.
13. Release the trigger and lock the gun.
14. When the red light on the control panel is on, the machine is ready to work.
Before connecting the machine to the mains, check that the voltage is suitable for
the machine’s needs.
When using the machine for the rst time, start it up with water to check that it is
working properly and to remove any impurities.

202309-668-ENG User manual - Eurospray S / Eurospray S mini P15
4. USE OF THE MACHINE (continued)
4.6. SPRAYING TECHNIQUE
Make sure that the hose is not pinched or bent and that it is not in contact with
objects with sharp edges that could damage it.
It is advisable to carry out test sprays on a piece of cardboard to obtain the optimum
spray pattern and to familiarise yourself with the use of the gun.
During use, it is normal for the pump to stop and restart. This is a matter of pressure
regulation and not a malfunction of the machine.
If the product dilution and pressure setting are
correct, the paint jet will be regular.
If the paint jet shows irregularities or spray
cords :
• Increase the pressure gradually.
• Dilute the product further (in 5% increments,
without ever exceeding the dilution limit
recommended by the product manufacturer).
• Reduce the tip size.

25 - 30 cm 25 - 30 cm
User manual - Eurospray S / Eurospray S mini 202309-668-ENGP16
4. USE OF THE MACHINE (continued)
4.6. SPRAYING TECHNIQUE (continued)
To achieve optimal results, the surface must be covered as evenly as possible, using the right gestures:
• The arm must move at a regular speed, without interruption, and the distance between the gun and
the surface to be painted must be constant (25 to 30 cm).
• Press the trigger only after starting the gun movement and release it before ending the movement.
• To obtain an even coverage, overlap the strokes by approximately 30%.
• Move your whole arm, not just your wrist, to limit irregularities.
• The spray gun should be perpendicular to the surface to be painted to avoid di󰀨erences in the
thickness of the paint layer.

202309-668-ENG User manual - Eurospray S / Eurospray S mini P17
4. USE OF THE MACHINE (continued)
4.7. UNCLOGGING THE TIP
If, during spraying, the paint jet becomes distorted or stops completely, the tip may be blocked. In this
case, proceed as described below.
1. Lock the gun trigger.
2. Turn the tip 180° in the tip support (with the tip pointing towards the back of the gun).
3. Place valve (G) in horizontal position.
4. Unlock the gun and press the trigger (gun pointing towards a cardboard box). The pressure in the
hose will remove the obstruction.
5. When the tip is unclogged, the paint jet becomes straight and regular again. Release the trigger
and lock the gun.
6. Turn the tip back to its original position (pointing forward) and resume spraying as normal.
4.8. STOPPING WORK
• Stop the machine (switch (A)), then disconnect the power cord (E).
• Place the gun in a plastic bag and seal the bag.
• Use a little water to lightly dampen the surface of the paint in the bucket. This prevents a layer of
dried paint forming.
Never try to unclog the tip with your ngers.
The pressurised product can cause serious injection injuries.
Carry out a pressure relief (see 4.3.) after stopping the machine and before carrying
out any work on it.

User manual - Eurospray S / Eurospray S mini 202309-668-ENGP18
5. MAINTENANCE
5.1. CLEANING PROCEDURE
1. Carry out the pressure relief procedure (see 4.3.).
2. Lock the gun trigger.
3. Remove the tip holder.
4. Place the suction tube and return hose in a bucket of water (or a solution suitable for cleaning the
product).
5. Turn the valve (G) to the horizontal position, then set the pressure to maximum on the control
panel.
6. Point the gun at an empty container.
7. Unlock the gun and press the trigger until the water (or solvent) comes out clean from the gun.
8. Stop the machine and disconnect the power cable.
9. Turn the valve (G) to the vertical position.
10. Pull the trigger to release the pressure, then lock the gun.
11. Remove the gun from the hose using the spanners supplied.
12. Dismantle the connector (O) and remove the grip lter.
13. Clean the grip lter using a soft brush and a suitable product.
14. Ret the clean lter (pierced side up) and ret the gun grip.
15. Clean the tip holder, seal, seat and tip.
16. Replace the gasket and seat in the tip holder and ret it to the gun.
17. Pinch the hook to remove the suction pipe (C) and clean it with a cloth.
18. Also clean the return hose (D) with a cloth.
19. Remove the hose from the connector (F) using the spanners supplied.
20. Pour approximately 60 ml of oil into the slot (I), then plug in the power cord.
21. Switch on the machine and run it for a few seconds so that the oil ows into the circuit and
preserves it until the next time it is used (place a cloth over the connector (F) to prevent the oil
dripping onto the oor).
The machine must be cleaned immediately after each use to ensure optimum
performance. Dried paint residues can cause malfunctions.
Never use a combustible product for cleaning.
If rinsing with a solvent, use a metal container placed on the oor and maintain
contact between the gun and the container.

202309-668-ENG User manual - Eurospray S / Eurospray S mini P19
5. MAINTENANCE (continued)
5.2. DEFECTS AND REMEDIES
Defects Causes Remedies
The machine does not
start.
The machine is not plugged in. Plug in the power cable.
The machine is stopped. Turn switch (A) to position I.
The machine has been switched o󰀨 while
under pressure.
Release the pressure, then return the valve
(G) to the horizontal position.
The mains plug does not supply any
voltage. Check the mains plug.
The electric extension cable is unsuitable or
damaged. Change the extension cable.
The machine is overheating. See procedure 4.1.
Motor fault. Contact the After-Sales Service.
The machine runs but
does not suck in paint
when the valve (G) is in
the vertical position.
The machine does not prime. Try to prime the machine again.
The suction rod (C) is not fully immersed
in the paint bucket or the paint bucket is
empty.
Immerse the suction pipe in the paint or
replace the paint bucket.
The suction rod is blocked. Clean the suction pipe.
The suction rod is not tted correctly. Pinch the hook to dismantle the rod and
reassemble it correctly.
Ball(s) stuck. Unblock.
Valve (G) is blocked. Contact the After Sales Service.
The machine sucks in
paint but, when the gun
is activated, the pressure
drops.
The tip is worn. Replace the tip with a new one.
Pump lter (H) clogged. Unscrew the cover and remove the lter to
clean it.
Gun lter (N) clogged. Clean or replace the lter.
Paint not su󰀩ciently diluted. Dilute the paint further.
Impurities in the paint. Filter the paint.
Ball(s) stuck Unblock.
The gun is leaking. Some parts of the gun are dirty or worn. Contact the After Sales Service.
The tip support is leaking. The tip is incorrectly tted. Remove the tip and ret correctly.
The seal is worn. Clean the seal.
The gun does not work. The gun or tip are blocked. Clean the lter (N) or the tip.
The tip is mounted upside down. Replace the tip.
The paint jet is dripping.
The paint is too viscous or contains
impurities. Dilute the paint further or lter it.
Gun or tip clogged. Clean the lter (N) or the tip.
The tip is worn. Replace the tip with a new one.
Pump lter (H) clogged. Unscrew the cover and remove the lter to
clean it.
Gun lter (N) clogged. Clean or replace the lter.
In case of an unknown defect or a doubt on the good running of the machine, do not
try to repair it by yourself or to dismantle it.
Contact an authorized After-Sale Service or our hotline : [phone].

User manual - Eurospray S / Eurospray S mini 202309-668-ENGP20
5. MAINTENANCE (continued)
5.3. ERROR CODES
The various error codes are displayed on the control panel (B).
Codes Causes Remedies
E01 Electrical card overheating.
Find a suitable power supply.
Contact after-sales service.
Clean pressure sensor.
E03 Damaged pressure sensor. Replace pressure sensor.
Find a suitable power supply.
E05 Motor overcurrent.
Check that the pump is not mechanically
blocked.
Contact after-sales service.
Let the equipment cool down.
E10 Motor overheating.
Find a suitable power supply.
Check that the pump is not mechanically
blocked.
Use a suitable nozzle.
Contact After-Sales Service.
Contacter le Service Après-Vente.
