Evco EVJ LCD User manual

EVCO | 19.09.2022 | AZ | 1114VJLCDE204
EVJ LCD
Remote User Interfaces
|Static LCD display
|6 capacitive touch keys
|INTRABUS or RS-485 communication port
|Built-in alarm buzzer
|Built-in temperature and humidity sensor
|Built-in Bluetooth Low Energy sensor
Applications
Heat
pump Air handling unit

EVCO | 19.09.2022 | AZ | 2114VJLCDE204
EVJ LCD - Remote user interfaces
IMPORTANT
Read this document thoroughly before installation and before use of the device and follow all recommendations;
keep this document with the device for future consultation.
Only use the device in the way described in this document; do not use the same as a safety device
USE
Device for indoor applications
CONSIDER THE ENVIRONMENT
Please read careffully and save this document
DISPOSAL
The device must be disposed of in compliance with local standards regarding the collection of electric and electronic
equipment

EVCO | 19.09.2022 | AZ | 3114VJLCDE204
EVJ LCD - Remote user interfaces
Index
| Introduction 5
| Purchasing codes 6
|12 VAC/DC models for panel or wall mounting 6
| Purchasing codes description 6
|12 VAC/DC models for panel or wall mounting 6
| Purchasing codes 7
|115... 230 VAC models for wall mounting 7
| Purchasing codes description 7
|115... 230 VAC models for wall mounting 7
| Dimensions 8
|12 VAC/DC models for panel mounting 8
|12 VAC/DC models for wall mounting 8
|115... 230 VAC models for wall mounting 8
| Installation 9
|12 VAC/DC models for panel mounting 9
|To be tted to a panel with elastic holding aps 9
|12 VAC/DC models for wall mounting 9
|A) Wall mounting 9
|B) Flush mounting box 9
|115... 230 VAC models for wall mounting 10
|Mounted onto in-wall electrical box with rear housing of back power module 10
| Electrical connections 11
|12 VAC/DC models for panel mounting 11
|Connectors and parts 11
|Electrical connection with independent power supply 12
|Electrical connection with device powered by a controller 12
|12 VAC/DC models for wall mounting 13
|Connectors and parts 13
|Electrical connection with independent power supply 14
|Electrical connection with device powered by a controller 14
|Termination of the RS-485 network 14
|Electrical connection for models with RS-485 port 15
|Connectors description 15
|Micro-switch EVIF22ISX 15
|115... 230 VAC models for wall mounting 16
|Connectors and parts 16
|Electrical connection with independent power supply 17

EVCO | 19.09.2022 | AZ | 4114VJLCDE204
EVJ LCD - Remote user interfaces
| User interface 18
|Key description 18
|Switching ON/OFF the device 18
|Accessing the procedure 18
|Accessing the menù 18
| Settings menu 19
|Sensitive areas description and parameters settings 19
|Keys 19
|Parameters settings 19
| Technical data 22

EVCO | 19.09.2022 | AZ | 5114VJLCDE204
EVJ LCD - Remote user interfaces
Introduction
The remote user interfaces EVJ LCD can be used as remote
displays for a wide range of EVCO controllers for HVAC
applications and many programmable controllers in the c-pro 3
range.
Depending on the model, a number of different features are
installed:
–1 or 2 analogue/digital input
–2 digital outputs
–1 built-in temperature and humidity sensor
–1 built-in Bluetooth BLE communication module
Equipped with INTRABUS proprietary port, they provide an effective
and economical alternative for point-to-point applications.
With their clean modern lines, LCD display, function icons and 6
capacitive keys, these interfaces blend perfectly with any type of
environment also given their panel and wall mounting and the option
of their own or controller power feed. The version housed in a
built-in box enables it to be powered directly from the mains
(115...230 VAC) with no need for transformers.

EVCO | 19.09.2022 | AZ | 6114VJLCDE204
EVJ LCD - Remote user interfaces
Features Codes
12 VAC/DC - Static LCD display - Panel mounting - INTRABUS - Alarm and signalling buzzer EVJD900N2
12 VAC/DC - Static LCD display - Wall mounting - NTC/DI - INTRABUS -
Alarm and signalling buzzer EVJD900N2VW
12 VAC/DC - Static LCD display - Wall mounting - NTC/DI - RS-485 INTRABUS -
Alarm and signalling buzzer EVJD900N2VWTX
12 VAC/DC - Static LCD display - Wall mounting - NTC/DI - INTRABUS -
Alarm and signalling buzzer -
Built-in Bluetooth Low Energy sensor EVJD900N2VWIV
12 VAC/DC - Static LCD display - Wall mounting - NTC/DI - INTRABUS -
Alarm and signalling buzzer -
Built-in temperature and humidity sensor EVJD920N2VW
12 VAC/DC - Static LCD display - Wall mounting - NTC - NTC - INTRABUS -
Alarm and signalling buzzer -
Built-in Bluetooth Low Energy sensor - Built-in temperature and humidity sensor EVJD920N2VWIV
Features 12 VAC/DC models for panel or wall mounting
EVJD900N2 EVJD900N2VW EVJD900N2VWTX EVJD900N2VWIV EVJD920N2VW EVJD920N2VWIV
Power supply
12 VAC/DC ••••••
Analog/digital input
NTC/DI 11111
User interface
Static LCD display ••••••
Installation mode
Panel mounting
(black front) •
Wall mounting
(white front) •••••
Connections
Removable screw
terminal •
Fixed screw terminal
blocks •••••
Communication
ports
INTRABUS 11 111
RS-485 INTRABUS 1
Other Features
Alarm and signalling
buzzer ••••••
Built-in temperature
and humidity sensor • •
Built-in Bluetooth
Low Energy sensor • •
For further informations look at chapter “Technical data”
Purchasing codes
12 VAC/DC models for panel or wall mounting
The following table shows the available EVJ LCD models and the relative purchasing codes
Purchasing codes description
12 VAC/DC models for panel or wall mounting

EVCO | 19.09.2022 | AZ | 7114VJLCDE204
EVJ LCD - Remote user interfaces
Purchasing codes
115... 230 VAC models for wall mounting
The following table shows the available EVJ LCD models and the relative purchasing codes
Purchasing codes description
115... 230 VAC models for wall mounting
Features Codes
115... 230 VAC - Static LCD display - Wall mounted - 2 NTC/DI - 2 relais - Alarm and signalling buzzer - INTRABUS EVJD902N9VP
115... 230 VAC - Static LCD display - Wall mounted - 2 NTC/DI - 2 relais - Alarm and signalling buzzer - INTRABUS -
Built-in Bluetooth Low Energy sensor
EVJD902N9VPIV
115... 230 VAC - Static LCD display - Wall mounted - 2 NTC/DI - 2 relais - Alarm and signalling buzzer - INTRABUS -
Built-in temperature and humidity sensor EVJD922N9VP
115... 230 VAC - Static LCD display - Wall mounted - 2 NTC/DI - 2 relais - Alarm and signalling buzzer - INTRABUS -
Built-in Bluetooth Low Energy sensor - Built-in temperature and humidity sensor EVJD922N9VPIV
Features 115... 230 VAC models for wall mounting
EVJD902N9VP EVJD902N9VPIV EVJD922N9VP EVJD922N9VPIV
Power supply
115... 230 VAC ••••
Analog/digital inputs
NTC/DI 2222
Digital outputs (electromechanical relays)
Relay 1 1 A 1 A 1 A 1 A
Relay 2 1 A 1 A 1 A 1 A
User interface
Static LCD display ••••
Installation mode
Wall mounted (white front) ••••
Connections
Fixed screw terminal blocks ••••
Communication ports
INTRABUS ••••
Other Features
Alarm and signalling buzzer ••••
Built-in temperature and humidity sensor • •
Built-in Bluetooth Low Energy sensor • •
For further informations look at chapter “Technical data”

EVCO | 19.09.2022 | AZ | 8
004_EVJLCD_Parete_001_0.1_AZ
004_EVJLCD_PareteAllogPosteriore_001_0.1_AZ
004_EVJLCD_Pannello_001_0.1_AZ
114VJLCDE204
EVJ LCD - Remote user interfaces
3,35 in
3,35 in
12 VAC/DC models for wall mounting
3,35 in
Dimensions
12 VAC/DC models for panel mounting
WARNINGS
–The thickness of a metal panel must be between 0.8 and 1.5 mm (
1⁄32
and
1⁄16
in), while that for a plastic panel must be
between 0.8 and 3.4 mm (
1⁄32
and
1⁄8
in)
–The measurements of drilling template must be 107.6 x 72.6 mm (3
15⁄16
x 2
7⁄8
in), with rounded corners R 3.0 mm (
1⁄8
in).
115... 230 VAC models for wall mounting
Flap for
plastic panel
Flap for
metal panel
111.4 mm (4 3⁄8in)12 mm (1⁄2in)
25 mm (1 in)
76, 4 mm (3 in)
111.4 mm (4 3⁄8in)
18.5 mm (3⁄4in)
76, 4 mm (3 in)
51.5 mm (2 in) 111.4 mm (4 3⁄8in)
76.4 mm (3 in)

EVCO | 19.09.2022 | AZ | 9
008_EVJLCD_Pannello_001_0.1_AZ
008_EVJLCD_Parete_001_0.2_AZ
008_EVJLCD_PareteScatola_001_0.1_AZ
A)
B)
114VJLCDE204
EVJ LCD - Remote user interfaces
Installation
12 VAC/DC models for panel mounting
To be tted to a panel with elastic holding aps
12 VAC/DC models for wall mounting
Seat
Seat
Front
Front
Wall
Wall
Back shell
Back shell
Opening to get the
connecting cables to pass
Opening to get the
connecting cables to pass
Connection
cable
Connection
cable
Slot
Slot
107.6 mm (3 15⁄16 in)
72.6 mm (2 7⁄8in)
Plastic
panel
DRILLING template
Rounded corners R 3 mm (1⁄8in)
Rounded corners R 3 mm (1⁄8in)
Example for plastic panel
1. Make a hole of 107.6 mm (3 15⁄16 in) x 72.6 mm (2 7⁄8in)
with rounded corners R 3 mm (1⁄8in)
2. Make the electrical connection without powering up the
device
3. Fasten the device to the panel
A) Wall mounting
1. Unhook the back shell from the front through a
screwdriver in the proper seat
2. Lean the back shell against the wall in a position suitable
to get the connecting cable to pass through the proper
opening
3. Use the slots of the back shell as template to drill 4 holes
having a diameter suitable to the bolt 5.0 mm (3⁄16 in)
diameter bolts are suggested
4. Insert the bolts in the holes drilled in the wall
5. Fasten the back shell at the wall with 4 screws
Countersunk head screws are suggested
6. Make the electrical connection without powering up the
device
7. Fasten the front of the device at the back shell
B) Flush mounting box
1. Unhook the back shell from the front through a
screwdriver and the proper seat
2. Fasten the back shell at the box with 4 screws
Countersunk head screws are suggested
3. Make the electrical connection without powering up the
device
4. Fasten the front of the device at the back shell

EVCO | 19.09.2022 | AZ | 10
21
ON
008_EVJLCD_PareteAllogPosteriore_001_0.2_AZ
114VJLCDE204
EVJ LCD - Remote user interfaces
115... 230 VAC models for wall mounting
Mounted onto in-wall electrical box with rear housing of back power module
1. Unhook the back shell from the front through a
screwdriver and the proper seat.
2. Fasten the back shell at the box with 4 screws.
Countersunk head screws are suggested.
3. Make the electrical connection without powering up the
device
4. Fasten the front of the device at the back shell Seat
Front
Wall
Back shell
Connection
cable
Slot
Flush
mounting box
WARNINGS FOR INSTALLATION
–Ensure that the working conditions are within the limits indicated in the “Technical data” chapter
–Do not install the device close to heat sources, equipment with a strong magnetic eld, in places subject to direct
sunlight, rain, damp, excessive dust, mechanical vibrations or shocks
–In compliance with safety regulations, the device must be installed properly to ensure adequate protection from contact
with electrical parts. All protective parts must be xed in such a way as to need the aid of a tool to remove them

EVCO | 19.09.2022 | AZ | 11
4
3
2
1
EVJ LCD
002_EVJLCD_Pannello_DescrizConnettori_001_0.1_AZ
114VJLCDE204
EVJ LCD - Remote user interfaces
Electrical connections
12 VAC/DC models for panel mounting
Connectors and parts
Connector 2
Connector 1
Connector 2
Number Description
EVCO reserved
Connector 1
Number Description
1INTRABUS port reference (GND)
2INTRABUS port data (IB)
3Device power supply (12 VAC/DC); if the device is
fed by DC power, connect terminal minus
4Device power supply (12 VAC/DC); if the device is
fed by DC power, connect terminal plus
WARNINGS FOR ELECTRICAL CONNECTIONS
–Use cables of an adequate section for the current running through them
–To reduce any electromagnetic interference connect the power cables as far away as possible from the signal cables
and connect to a INTRABUS network by using a twisted pair
WARNINGS FOR ELECTRICAL CONNECTIONS
–If using an electrical or pneumatic screwdriver, adjust the tightening torque
–If the device has been moved from a cold to a warm place, the humidity may have caused condensation to form inside.
Wait about an hour before switching on the power
–Make sure that the supply voltage, electrical frequency and power are within the set limits
–Disconnect the power supply before doing any type of maintenance
–Do not use the device as safety device
–For repairs and for further informations, contact the EVCO sales network; possible returns without label data will not be
accepted

EVCO | 19.09.2022 | AZ | 12
c-pro 3 OEM
001_EVJLCD_Pannello_AlimentazioneDaControllo_001_0.1_AZ
GND 12VS 5VS IB GND A/+ B/- CAN+ CAN- 21
ON
IB
GND
+
4
3
2
1
EVJ LCD
+
001_EVJLCD_Pannello_AlimentazioneIndipendente_001_0.1_AZ
IB
GND
4
3
2
1
EVJ LCD
114VJLCDE204
EVJ LCD - Remote user interfaces
Electrical connection with device powered by a controller
Example: c-pro 3 OEM
Make sure that the current supplied
by the controller is suitable
to power the device
Electrical connection with independent power supply
Device with
INTRABUS port
INTRABUS
230 VAC / 12 VAC 10 VA
safety transformer
Do not supply another
device with the same
transformer
Electricity grid
230 VAC
WARNINGS
–Make sure that the current supplied by the controller is within the limits stated in the TECHNICAL SPECIFICATIONS section
–The maximum permitted length for connection cables of the INTRABUS port is 10 m (32.8 ft)
WARNINGS
–Do not supply another device with the same transformer
–The maximum permitted length for connection cables of the INTRABUS port is 30 m (98.4 ft)

EVCO | 19.09.2022 | AZ | 13
6
5
4
3
2
1
EVJ LCD
12
ON
002_EVJLCD_Parete_DescrizConnettori_001_0.1_AZ
114VJLCDE204
EVJ LCD - Remote user interfaces
12 VAC/DC models for wall mounting
Connectors and parts
Connector 2
Temperature
and humidity
sensor
Micro-switch
Connector 1
Connector 2
Number Description
EVCO reserved
Temperature (AI3) and humidity (AI5) sensor
Number Description
According to the model
Bluetooth Low Energy sensor
Number Description
According to the model
Bluetooth
Low Energy
sensor
Connector 1
Number Description
1INTRABUS port reference (GND) or
RS-485 signal B (-) (according to the model)
2INTRABUS port data (IB) or
RS-485 signal A (+) (according to the model)
3Device power supply (12 VAC/DC). If the device is
fed by DC power, connect terminal minus
4Device power supply (12 VAC/DC). If the device is
fed by DC power, connect terminal plus
5Analog/digital input AI4 (NTC/DI)
6Reference analog/digital input AI4 (GND)
Micro-switch
Number Description
2To terminate the RS-485 MODBUS network
1EVCO reserved

EVCO | 19.09.2022 | AZ | 14
c-pro 3 OEM
001_EVJLCD_Parete_AlimentazioneDaControllo_001_0.1_AZ
6
5
4
3
2
1
EVJ LCD
12
ON
GND 12VS 5VS IB GND A/+ B/- CAN+ CAN- 21
ON
IB
GND
+
+
001_EVJLCD_Parete_AlimentazioneIndipendente_001_0.1_AZ
6
5
4
3
2
1
EVJ LCD
12
ON
IB
GND
12
ON
114VJLCDE204
EVJ LCD - Remote user interfaces
AI4 analog/
digital input
Electrical connection with device powered by a controller
Example: c-pro 3 OEM
Electrical connection with independent power supply
Termination of the RS-485 network
To terminate the RS-485 network:
–Place micro-switch 2 in position ON
–Let the micro-switch 1 in position OFF (EVCO reserved)
WARNINGS
–Do not supply another device with the same transformer
–The maximum permitted length for connection cables of the INTRABUS port is 30 m (98.4 ft),
–1.000 m (3.280 ft) in models with RS-485 with INTRABUS communication protocol
WARNINGS
–Make sure that the current supplied by the controller is within the limits stated in the TECHNICAL SPECIFICATIONS section
–The maximum permitted length for connection cables of the INTRABUS port is 10 m (32.8 ft)
The micro-switch is on the back of the device
(remove the back shell from the front before)
Device with
INTRABUS port
AI4 analog/
digital input
Mobile device
INTRABUS
230 VAC / 12 VAC 10 VA
safety transformer
Do not supply another
device with the same
transformer
Electricity grid
230 VAC
Temperature (AI3)
and humidity (AI5)
sensor
Bluetooth
sensor
Make sure that the current supplied
by the controller is suitable
to power the device
Mobile device
Temperature (AI3)
and humidity (AI5)
sensor
Bluetooth
sensor

EVCO | 19.09.2022 | AZ | 15
1 2 3
+
001_EVJLCD_Parete_PortaRS-485_001_0.1_AZ
6
5
4
3
2
1
EVJ LCD
12
ON
A+
B-
GND 12VS 5VS IB GND A/+ B/- CAN+ CAN- 21
ON
6 5 4
EVIF22ISX
c-pro 3 OEM
12
ON
213
ON
12
ON
EVJ LCD
–RS-485
EVIF22ISX
–INTRABUS
–RS-485
INTRABUS
c-pro 3 OEM
–INTRABUS
114VJLCDE204
EVJ LCD - Remote user interfaces
Electrical connection for models with RS-485 port
Mobile device
RS-485 port
Maximum permitted length for connection cables is 1.000 m (3280.84 ft)
Maximum permitted length for connection cables is 30 m (98.4 ft)
INTRABUS port
RS-485 INTRABUS port
Place the dip 1 of the
two-way micro-switch in OFF
INTRABUS
LED
RS-485
INTRABUS LED
230 VAC / 12 VAC 10 VA
safety transformer
Do not supply another
device with the same
transformer
Electricity grid
230 VAC
Temperature (AI3)
and humidity (AI5)
sensor
Bluetooth
sensor
Micro-switch EVIF22ISX
–Place the dip 1 of the two-way micro-switch in OFF
The micro-switch is on the EVIF22ISX device side
Port Terminal Meaning
INTRABUS
1 12 V
2 INTRABUS port data
3 INTRABUS port reference (GND)
RS-485
4 RS-485 port reference (GND)
5 RS-485 port negative signal
6 RS-485 port positive signal
Connectors description
AI4 analog/
digital input

EVCO | 19.09.2022 | AZ | 16
6 7 8 9 10
1 2 3 4 5
EVJ LCD
002_EPJLCD_PareteAllogPosteriore_DescrizConnettori_001_0.1_AZ
114VJLCDE204
EVJ LCD - Remote user interfaces
115... 230 VAC models for wall mounting
Connectors and parts
Connector 2
Connector 1
Connector 1
Number Description
1Device power supply (115... 230 VAC)
2Device power supply (115... 230 VAC)
3DO2 digital output normally open contact
(1 A res. at 250 VAC)
4DO1 digital output normally open contact
(1 A res. at 250 VAC)
5DO1 and DO2 digital outputs common contact
(max. 2 A)
Connector 2
Number Description
6Analog/digital input AI2 (NTC/DI)
7Analog/digital input AI1 (NTC/DI)
8Reference analog/digital inputs AI1 and AI2 (GND)
9INTRABUS port data (IB)
10 INTRABUS port reference (GND)
Temperature
and humidity
sensor
Temperature (AI3) and humidity (AI5) sensor
Number Description
According to the model
Bluetooth
Low Energy
sensor
Bluetooth Low Energy sensor
Number Description
According to the model

EVCO | 19.09.2022 | AZ | 17
K2 K1
001_EVJLCD_PareteAllogPosteriore_001_0.2_AZ
6 7 8 9 10
1 2 3 4 5
EVJ LCD
IB GND
114VJLCDE204
EVJ LCD - Remote user interfaces
Electrical connection with independent power supply
INTRABUS
Device with
INTRABUS port
Analog/digital input AI2
Digital output DO2 Digital output DO1
Analog/digital input AI1
Max. 2 A
Power supply
(115... 230 VAC)
Mains
Temperature
and humidity
sensor
Mobile device
Bluetooth
sensor

EVCO | 19.09.2022 | AZ | 18
005_EVJLCD_InterfacciaUtente_001_0.1_AZ
005_EVJLCD_ON-OFF_001_0.1_AZ
114VJLCDE204
EVJ LCD - Remote user interfaces
User interface
Switching ON/OFF the device
Progression Description
1
Connect the power supply:
it will be started an internal test that takes
typically a few seconds
2Touch SET key for 7 seconds:
the display will show “Mnu” and “Inf”
3To switch OFF the device switch OFF the power
supply
Key description
Key Instructions
ON/STAND-BY
LEFT AND RIGHT
UP AND DOWN
SET
Accessing the procedure
Key Instructions
Touch SET key for 7 seconds:
the display will show “Mnu” and “Inf”
Touch ON/STAND-BY key few times to return to the
previous displays
Accessing the menù
Key Instructions
Touch SET key for 7 seconds:
the display will show “Mnu” and “Inf”
Touch DOWN key:
the display will show “Mnu” and “PAr”
Touch SET key:
the display will show “PSU”- Password
Touch SET key:
the display will show “0000”
Touch UP or DOWN keys to set-up the password
“-019”
Touch SET key
Touch UP or DOWN keys to see the menu
Touch SET key to select the menu
Touch UP or DOWN keys to see the parameters
Touch SET key to access the value
Touch UP or DOWN keys to set-up the value
Touch SET key to conrm the value
Touch ON/STAND-BY key few times to return to the
previous displays

EVCO | 19.09.2022 | AZ | 19114VJLCDE204
EVJ LCD - Remote user interfaces
Settings menu
Sensitive areas description and parameters settings
Parameters settingsKeys
“InF” menu
N. Param. Def. “InF” menu Min/max
1Prn - Project number -
2Pru - Project version -
3Prr - Project revision -
4FUu - Firmware version -
5FUr - Firmware revision -
6FUS - Firmware subversion -
7HUu - Hardware version -
8HUr - Hardware revision -
“PAr” menu
N. Param. Def. “PAr” menu Min/max
9bKU 15 Backlight intensity 0... 100
xed value 30 in
the models with
incorporated
temperature and
humidity sensor
10 bKt 30 Backlight timeout 0... 255 s
xed value 30 in
the models with
incorporated
temperature and
humidity sensor
11 bKM tiME Backlight mode off=off
on=on (not
used in the
models with
incorpo-rated
temperature and
humidity sensor)
tiME=with bKt
12 EU3 OFF Enable compatibility
with Vled 3
On... OFF
“InF” menu
Key Instructions
Touch SET key for 7 seconds:
the display will show “Mnu” and “Inf”
Touch SET key to access the parameters
Touch UP or DOWN keys to see the parameters
Touch ON/STAND-BY key few times to return to the
previous displays
“PAr” menu
Key Instructions
Touch SET key for 7 seconds:
the display will show “Mnu” and “Inf”
Touch DOWN key:
the display will show “Mnu” and “PAr”
Touch SET key:
the display will show “PSU”- Password
Touch SET key:
the display will show “0000”
Touch UP or DOWN keys to set-up the password
“-019”
Touch SET key
Touch UP or DOWN keys to see the parameters
Touch SET key to access the value
Touch UP or DOWN keys to set-up the value
Touch SET key to conrm the value
Touch ON/STAND-BY key few times to return to the
previous displays
WARNINGS
Turn off the power after changing the conguration

EVCO | 19.09.2022 | AZ | 20114VJLCDE204
EVJ LCD - Remote user interfaces
“nEt > Itb” menu
N. Param. Def. “nEt > Itb” menu Min/max
13 nOd 4 INTRABUS node 1... 127
se EU3C=On,
nOdE=3
14 StA - INTRABUS status
communication
OK... Err
15 nrH - Number of received
INTRABUS packages
0... 999
16 ntH - Number of
transmitted INTRABUS
packages
0... 999
17 nEr - Number of INTRABUS
receipts in error
0... 999
18 bAu - INTRABUS baud rate 19200
19 Stb 1 INTRABUS bit stop
number
0... 2
20 PtY 2 INTRABUS parity 0... 2
“NET > BLE” menu
N. Param. Def. “NET > BLE” menu Min/max
21 StA - Enable Bluetooth On... OFF
22 nrH - Number of BLE
packages received
0... 999
23 ntH - Number of BLE
transmitted received
0... 999
24 nEr - Number of intercepted
BLE errors
0... 999
25 bAu - BLE baud rate 19200
26 Stb 1 BLE bit stop number 0... 2
27 PtY 2 BLE parity 0... 2
“diA” menu
N. Param. Def. “diA” menu Min/max
28 MEm - EEPROM memory
status
OK... Err
29 PSU - Power supply voltage
status
OK... Err
“nEt > Itb” menu
Key Instructions
Touch SET key for 7 seconds:
the display will show “Mnu” and “Inf”
Touch DOWN key twice:
the display will show “Mnu” and “nEt”
Touch SET key:
the display will show “nEt” and “Itb”
Touch SET key
Touch UP or DOWN keys to see the parameters
Touch ON/STAND-BY key few times to return to the
previous displays
“NET > BLE” menu
Key Instructions
Touch SET key for 7 seconds:
the display will show “Mnu” and “Inf”
Touch DOWN key twice:
the display will show “Mnu” and “nEt”
Touch SET key:
the display will show “Mnu” and “Itb”
Touch DOWN key:
the display will show “Mnu” and “bLE”
Touch SET key
Touch UP or DOWN keys to see the parameters
Touch SET key to access the value
Touch UP or DOWN keys to set-up the value
(available only for “Pty” parameter)
Touch SET key to conrm the value
Touch ON/STAND-BY key few times to return to the
previous displays
“diA” menu
Key Instructions
Touch SET key for 7 seconds:
the display will show “Mnu” and “Inf”
Touch DOWN key three times:
the display will show “Mnu” and “diA”
Touch SET key
Touch UP or DOWN keys to see the parameters
Touch ON/STAND-BY key few times to return to the
previous displays
