EVERSPRING AN370 User manual

AN370
SMART PLUG
This AN370 plug-in ON/OFF Module is a transceiver which
is a Z-WaveTM enabled device and is fully compatible with
any Z-WaveTM enabled network. This product can be
operated in any Z-Wave network with other Z-Wave
certified devices from other manufacturers. All mains
operated nodes within the network will act as repeaters
regardless of vendor to increase reliability of the network.
Each module is designed to act as a repeater. Repeaters
will re-transmit the RF signal to ensure that the signal is
received by its intended destination by routing the signal
around obstacles and radio dead spots.
Adding to Z-WaveTM Network
The unit supports SmartStart function, where inclusion is
initiated automatically on power-on, and repeated at
dynamic intervals for as long as the device is not included
into a Z-WaveTM network. Z-WaveTM SmartStart is based on
the embedded SDK 6.8x and requires related gateway
software components.
If the gateway does not support SmartStart function, this
device can be added to the Z-WaveTM network using
manual inclusion, or by scanning the DSK QR code or
entering a 5-digit Device Specific
Key (DSK) located at bottom of
the plug when requested by the
gateway.
Safety Precautions & Installation
To ensure your safety, please read this manual carefully
before installing the device; follow the instructions exactly.
The manufacturer, Everspring Industry Co., Ltd, shall not
be legally responsible for any equipment damage or
personal injury caused by incorrect installation or operation
other than that covered in the manual.
Do not use in damp, moist or wet locations. The product
is intended for indoor use only in dry locations.
To avoid risk of electrical shock, do not operate the
device with wet or moist hands.
 This product is not a toy, keep away from children and
animals.
1. Plug this On/Off Module into a wall outlet near the load
to be controlled.
2. Plug the load into the Module. Make sure the load to be
controlled cannot exceed 2990 watts.
3. Press the button or switch on the load to the ON
position.

4. To manually turn ON the Module, press and release the
On/Off button. The LED will turn ON, and the load
plugged into the Module will also turn ON.
5. To manually turn OFF the Module, simply press and
release the On/Off button. The LED will turn OFF and
the load plugged into the Module will also turn OFF.
Programming
Z-WaveTM Group Support
The unit supports two association groups with 5 nodes
support for Grouping 1 and 5 nodes support for Grouping 2.
This has the effect that when the unit is operating, all
devices associated with the unit will receive the relevant
reports.
When the unit is powered for the first time, the unit will
send a Notification Report to the node of Group 1.
When setting the unit or changing the unit’s status, the
unit will send a Binary Switch Report to the node of
Group 1.
When performing Reset the unit will send Device Reset
Locally Notification to the node of Group1.
When the button on the unit or the wall switch is pressed,
the unit will send a Basic Set command to the nodes of
Group 2. When the unit is OFF, Basic Set Value = 0x00.
When the unit is ON, Basic Set Value = 0xFF.
Z-Wave PlusTM Info
Role Type
Node Type
Installer Icon
User Icon
Slave
Always On
Z-Wave
PlusTM node
On/Off Power
Switch
On/Off Power
Switch
Version
Protocol Library
3 (Slave_Enhance_232_Library)
Protocol Version
7.17.2
Manufacturer
Manufacturer ID
Product Type
Product ID
0x0060
0x0034
0x0001
AGI (Association Group Information) Table
Group
Profile
Command Class &
Command (List) N bytes
Group
Name(UTF-8)
1
General
Binary Switch Report,
Notification Report,
Device Reset Locally
Notification
Indicator Report
Lifeline
2
Control
Basic Set
On/Off control
Basic commands
Command
Description
Basic Get
Inquire about the status of the device
Basic Report
Report the status of the device.
Basic Set
Set the status of the device.(Value=0XFF
(ON), 0x00 (OFF))
Notification
Event
Type
Event
Event Parameters
Length
Power applied for
first time
0x08
0x01
0x00
Configuration
The configurable values are as following:
Remember the last status:
Parameter
Number
Size
Range
Default

1
1
1/0
1: remember(0: do not
remember)
LED on/off:
Parameter
Number
Size
Range
Default
2
1
0~2
2: on for 5 seconds
(0: disable, 1: Always
on)
Command Classes
The module supports Command Classes including…
Command Class
Version
Required Security
Class
ZWAVEPLUS_INFO
2
None
ASSOCIATION
2
Highest granted
Security Class
MULTI_CHANNEL_ASSOCIATI
ON
3
Highest granted
Security Class
ASSOCIATION_GRP_INFO
3
Highest granted
Security Class
TRANSPORT_SERVICE
2
None
VERSION
3
Highest granted
Security Class
MANUFACTURER_SPECIFIC
2
Highest granted
Security Class
DEVICE_RESET_LOCALLY
1
Highest granted
Security Class
INDICATOR
3
Highest granted
Security Class
POWERLEVEL
1
Highest granted
Security Class
SECURITY
1
None
SECURITY 2
1
None
SUPERVISION
1
None
FIRMWARE_UPDATE_MD_
5
Highest granted
Security Class
NOTIFICATION
8
Highest granted
Security Class
SWITCH_ BINARY
2
Highest granted
Security Class
CONFIGURATION
4
Highest granted
Security Class
Indicator Command Class
Indicator
ID
Property
ID
Value
Description
0x50
0x03
0~255
On/Off Period
0x50
0x04
0~255
On/Off Cycle
0x50
0x05
0~255
On time within an
On/Off period
Additional Command Classes Supported
Power Level: For test purpose during product
installation.
Binary Switch: Refer to Basic.
Firmware Update: For OTA function.
Troubleshooting
The table below lists the several steps involved when
adding or removing the detector from the Z-WaveTM
network.
Action/
Status
Description
LED
indication
No node ID
The Z-WaveTM Controller does not
allocate a node ID to the unit.
2-second
on,
2-second off
Inclusion
1. Put the Z-WaveTM Controller into
inclusion mode.
2. Press the button three times within
1.5 seconds to put the unit into
inclusion mode.
Exclusion
1. Put the Z-WaveTM Controller into

exclusion mode.
2. Press the button three times within
1.5 seconds to put the unit into
exclusion mode.
Reset
(This
procedure
should only
be used
when the
network
primary
controller
is
inoperable.
)
1. Press the button three times within
1.5 seconds to put the unit into
exclusion mode.
2. Within 1 second of step 1, press
link key again and hold until LED
is off (about 5 seconds).
3. Node ID is excluded. The
device reverts to factory default
state and will be in auto-inclusion
mode for 4 minutes.
Failed or successful results in including/excluding the ID can
be viewed on the Z-WaveTM Controller.
Note: If you are connecting this unit to a Z-WaveTM Controller that utilizes
the S2 security protocol, you may be asked to enter a 5 digit Device
Specific Key (DSK) that is unique to each unit by your controller. This can
be found in one of two places:
- on the QR code label on the unit
- on the insert card inside the packaging
Symptom
Cause of Failure
Recommendation
Device not
responding and
LED not
displaying
The device is not
connected to the
mains power
correctly
Check if
connection is
correct, or voltage
is too high or too
low
Device
malfunction
Send the device to
be repaired
LED displaying,
but cannot
control On/Off
status of
connected load
The connected
load has its own
on/off switch
Turn the switch of
the connected
load to On.
Can press
RF interference is
Wait for a while
button to control,
but cannot
control by RF
occurring.
Someone nearby
might be emitting
RF signal of the
same frequency
and retry the
operation
Specification
Operating Voltage
230VAC/50Hz
Maximum Load
UK Plug
Resistive load: 2990W
Incandescent load: 1500W
Fluorescent load: 15 x 40W
LED: 200W
Range
100 m line of sight
Frequency Range
AN370-3:868.42 MHz(UK)
** Specifications are subject to change and improvement without
notice.
Warning:
Do not dispose of electrical appliances as unsorted municipal waste, use separate
collection facilities.
Contact your local government for information regarding the collection systems
available.
If electrical appliances are disposed of in landfills or dumps, hazardous substances
can leak into the groundwater and get into the food chain, damaging your health
and well-being.
When replacing old appliances with new once, the retailer is legally obligated to
take back your old appliance for disposal at least for free of charge.
www.everspring.com
50 Sect. 1 Zhonghua Rd Tucheng New
Taipei City 236 Taiwan.
