EVOAQ AQ-EVOFLT-AP Operating and safety instructions

Filter Replacement Manual
Please take the time to read these instructions in full before
commencing your installation.
Careful planning prior to starting work will guarantee the
fastest and best results regarding the installation.
Working in the ceiling space can be a hazard, and all
safety precautions should be used to ensure the
safety of yourself and any others.
EVOAQ
Air Quality Innovation
Home Ventilation
Filter Box Model
AQ-EVOFLT-AP
Manual Version
V3.1.0 10-2023
Filter
Replacement
Filter Media Model
AQ-FLT-MEDIA-AP

Installation Manual
Filter Media Replacement for EVOAQ Air Purification Box
Thank you for your purchase of our company’s product. It has been manufactured following
current technical safety regulations and meets international filter standards.
Please read this instruction booklet carefully before commencing installation.
TRANSPORT AND MANIPULATION
The packaging used for this product has been designed to support normal transporting
conditions. The filter must always be transported in its original packaging as not doing so
could deform or damage the product. Do not place heavy weights on the packed product and
avoid knocking or dropping it.
The product should be stored in a dry place in its original packaging, protected from dust
and dirt until it is installed in its final location. Do not accept delivery if the product is not in
its original packaging or shows clear signs of having been manipulated in any way.
Check that the product is in perfect condition and includes all 3 filters while unpacking. Any
fault or damage caused in origin is covered by our company guarantee. Please make sure
that the filter coincides with the product you have ordered.
FILTER REPLACEMENT FREQUENCY
Regularly checking and replacing your filters is essential for maintaining your ventilation
system. Filters should be checked at least every 12 months and replaced no less than once
every 2 years. Filters need to be replaced if you can visibly see dirt and dust build-up on the
filter media. If you notice reduced effectiveness or airflow of the ventilation system, musty
smells or the smell of ceiling insulation, or if the ventilation system is blowing dust and
insects into the house, make sure to check the filters and replace them if necessary.
PRODUCT DISPOSAL
Please dispose of old product responsibly. Any metal parts of the filter boxes can be recycled
and should be returned to the manufacturer or taken to a metal recycling facility when it is
no longer required.
Old filter media should be placed in general waste. Our filters cannot be cleaned or
vacuumed without causing damage to the filter. Do not re-use or recycle used filter media.
Old Filter
Visually inspect the filters to be replaced (depicted here: air purification box carbon filter)
New Filter
REPLACEMENT OF FILTER MEDIA
EVOAQ
Air Quality Innovation
EVOAQ Home Ventilation
Page 2 www.evoaq.co.nz
FILTER SCHEDULE
Use this space to record when you last replaced your filters and when the next filter
replacement is due, and save this manual for future reference. We may also add you to our
mailing list and send out an email reminder when your filters are due for replacing (you can
opt out of this at any time, just get in touch or unsubscribe through the email).
Tip: Make a note in your calendar when you last replaced the filters (especially if you use a
digital calendar) and set a yearly reminder to check your filters!
For further information, please contact EvolutionFX NZ Limited
email: [e-mail]
phone: [phone]

Installation Manual
Filter Media Replacement for EVOAQ Air Purification Box
Thank you for your purchase of our company’s product. It has been manufactured following
current technical safety regulations and meets international filter standards.
Please read this instruction booklet carefully before commencing installation.
TRANSPORT AND MANIPULATION
The packaging used for this product has been designed to support normal transporting
conditions. The filter must always be transported in its original packaging as not doing so
could deform or damage the product. Do not place heavy weights on the packed product and
avoid knocking or dropping it.
The product should be stored in a dry place in its original packaging, protected from dust
and dirt until it is installed in its final location. Do not accept delivery if the product is not in
its original packaging or shows clear signs of having been manipulated in any way.
Check that the product is in perfect condition and includes all 3 filters while unpacking. Any
fault or damage caused in origin is covered by our company guarantee. Please make sure
that the filter coincides with the product you have ordered.
FILTER REPLACEMENT FREQUENCY
Regularly checking and replacing your filters is essential for maintaining your ventilation
system. Filters should be checked at least every 12 months and replaced no less than once
every 2 years. Filters need to be replaced if you can visibly see dirt and dust build-up on the
filter media. If you notice reduced effectiveness or airflow of the ventilation system, musty
smells or the smell of ceiling insulation, or if the ventilation system is blowing dust and
insects into the house, make sure to check the filters and replace them if necessary.
PRODUCT DISPOSAL
Please dispose of old product responsibly. Any metal parts of the filter boxes can be recycled
and should be returned to the manufacturer or taken to a metal recycling facility when it is
no longer required.
Old filter media should be placed in general waste. Our filters cannot be cleaned or
vacuumed without causing damage to the filter. Do not re-use or recycle used filter media.
Thick, blue and black filter media:
Carbon filter - middle filter
Thin honeycomb-pattern filter:
Catalyst network screen - final
filter (fan side)
White and green filter media:
PM2.5 filter - first filter (inlet side)
REPLACEMENT OF FILTER MEDIA
EVOAQ
Air Quality Innovation
EVOAQ Home Ventilation
Page 3www.evoaq.co.nz
Locate your fan and filter inside the ceiling space.
Be careful not to damage or remove the tape connecting the fan to the filter as this
could cause the fan to bypass the filter and draw in air directly from the ceiling space.
Unclip the lid of the filter box and slide out the old filters, taking note of the position
and orientation of these filters.
Unwrap the new filter media and slide them into place in the same order and
orientation that the old filters were in.
The filters are all different thicknesses and fit only in their own slot, but make sure to
note which way around they go.
The primary PM2.5 filter should be with the white side on the inlet side. The white
side is the PM2.5 side, which removes larger particles, dust, insects, etc. The green
side is the HEPA filter side which takes out the finer particles that got through.
The middle filter is the carbon filter. The blue side is the antibacterial network which
faces the primary filter. The black side is the active carbon side, with the H11 HEPA
filter in between the two.
The final filter on the fan side is the cold catalyst network. Its job is to kill any viruses
and bacteria that got through the filters. This filter is the same on both sides so can
be placed any way around.
Close the filter box lid and clip it closed again. You should make sure to push the
filters in fully and may need to tilt/move the lid around to get it to close and seal fully.
FILTER SCHEDULE
Use this space to record when you last replaced your filters and when the next filter
replacement is due, and save this manual for future reference. We may also add you to our
mailing list and send out an email reminder when your filters are due for replacing (you can
opt out of this at any time, just get in touch or unsubscribe through the email).
Tip: Make a note in your calendar when you last replaced the filters (especially if you use a
digital calendar) and set a yearly reminder to check your filters!
For further information, please contact EvolutionFX NZ Limited
email: [e-mail]
phone: [phone]

Installation Manual
Filter Media Replacement for EVOAQ Air Purification Box
Thank you for your purchase of our company’s product. It has been manufactured following
current technical safety regulations and meets international filter standards.
Please read this instruction booklet carefully before commencing installation.
TRANSPORT AND MANIPULATION
The packaging used for this product has been designed to support normal transporting
conditions. The filter must always be transported in its original packaging as not doing so
could deform or damage the product. Do not place heavy weights on the packed product and
avoid knocking or dropping it.
The product should be stored in a dry place in its original packaging, protected from dust
and dirt until it is installed in its final location. Do not accept delivery if the product is not in
its original packaging or shows clear signs of having been manipulated in any way.
Check that the product is in perfect condition and includes all 3 filters while unpacking. Any
fault or damage caused in origin is covered by our company guarantee. Please make sure
that the filter coincides with the product you have ordered.
FILTER REPLACEMENT FREQUENCY
Regularly checking and replacing your filters is essential for maintaining your ventilation
system. Filters should be checked at least every 12 months and replaced no less than once
every 2 years. Filters need to be replaced if you can visibly see dirt and dust build-up on the
filter media. If you notice reduced effectiveness or airflow of the ventilation system, musty
smells or the smell of ceiling insulation, or if the ventilation system is blowing dust and
insects into the house, make sure to check the filters and replace them if necessary.
PRODUCT DISPOSAL
Please dispose of old product responsibly. Any metal parts of the filter boxes can be recycled
and should be returned to the manufacturer or taken to a metal recycling facility when it is
no longer required.
Old filter media should be placed in general waste. Our filters cannot be cleaned or
vacuumed without causing damage to the filter. Do not re-use or recycle used filter media.
REPLACEMENT OF FILTER MEDIA
Page 4 www.evoaq.co.nz
EVOAQ
Air Quality Innovation
EVOAQ Home Ventilation
FILTER SCHEDULE
Use this space to record when you last replaced your filters and when the next filter
replacement is due, and save this manual for future reference. We may also add you to our
mailing list and send out an email reminder when your filters are due for replacing (you can
opt out of this at any time, just get in touch or unsubscribe through the email).
Tip: Make a note in your calendar when you last replaced the filters (especially if you use a
digital calendar) and set a yearly reminder to check your filters!
For further information, please contact EvolutionFX NZ Limited
email: [email protected]
phone: [phone]
For all our manuals, fan
specifications, system details
and more information visit
www.evoaq.co.nz/downloads
Filter Replacement Record
Filters Replaced Next Replacement Due
