Clarke CAT185 Installation and operation manual

OPERATING & MAINTENANCE
INSTRUCTIONS
ORIGINAL INSTRUCTIONS GC0619 - ISS 1
AIRLINE FILTER
MODEL NO: CAT185
PART NO: 3120502

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE Air Filter.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
Your filter has been designed to give long and trouble free service. If, however,
having followed the instructions in this booklet carefully, you encounter
problems, take the unit to your local CLARKE dealer.
SPECIFICATIONS
GENERAL SAFETY RULES
WORK ENVIRONMENT
1. Keep the work area clean and tidy.
2. Dress appropriately - do not wear loose clothing or jewellery. Tie long hair
out of the way.
3. Keep children and visitors away - do not let children handle the tools.
CAT185
Dimensions (D x W x H) 46 x 50 x 166 mm
Air Inlet /Outlet Size 1/4“BSP (female)
Max Flow 55 CFM
Max Inlet Pressure 150 psi
Element Micron Rating 5μ
Max working Temperature 125 deg F
CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN
PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY.

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
4. Do not operate air tools where there are flammable liquids or gases.
USE OF AIRLINE EQUIPMENT
1. Stay alert and use common sense - do not operate an air tool when you
are tired or under the influence of alcohol, drugs or medication.
2. Do not overreach - Keep proper footing and balance at all times.
3. Never use oxygen, CO2, combustible gases or any type of bottled gas as a
source of power for air tools.
4. Do not exceed the maximum pressure for the airline component stated in
the specification.
5. Check airline hoses for leaks or worn condition before use and ensure that
all connections are secure.
6. Keep the air supply hose away from heat, oil and sharp edges.
7. Avoid damaging the component for example by applying excessive force
of any kind.
8. Always maintain the air tool with care. Keep it clean for the best and safest
performance.
COMPRESSED AIRLINE REQUIREMENTS
1. Use only clean, dry, regulated compressed air as a power source.
2. Air compressors must comply with the appropriate European Community
Safety Directives.
3. A build-up of moisture in the air compressor will accelerate wear and
corrosion in the air tool. Ensure any moisture is drained from the compressor
daily and the airline filter is kept clean.
4. If an unusually long air hose is required, (over 8 metres), the line pressure or
the hose inside diameter may need to be increased.
• The air hose must be rated at least 150% of the maximum operating
pressure of the air tool.
WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU
ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF
COMPRESSORS AND COMPRESSED AIR SUPPLY.

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
5. A typical air line layout is shown above. If an automatic in-line filter/
regulator is used it will keep the tool in good condition. The lubricator
should be adjusted to approx 2 drops per minute and SAE 10 oil should be
used.
6. Never exceed the maximum operating pressure for the air tool. Ensure that
air pressure does not exceed that stated in the specification for the tool
when running. Higher pressures and contaminated air will shorten the life of
the air tool due to faster wear and is a possible safety hazard.
INSTALLATION
1. Ensure the compressor is turned off. Before using the airline, drain water
from the air reservoir at the compressor.
• The filter should be installed with reasonable accessibility for service
whenever possible.
2. The filter should be installed upstream of regulator(s), lubricator(s), and
cycling valve(s) in the air line, and should be as close as possible to the air
tool(s) when used as a main line filter and/or as a final filter.
3. Keep pipe or tubing lengths to a minimum with the inside clean and free of
dirt. Pipe joint compound should be used sparingly and applied only to the
male pipe — never into the female port.
4. Do not use PTFE tape to seal pipe joints — pieces have a tendency to
break off and lodge inside the unit, possibly causing malfunction.
5. Install the filter so that air flows as marked by the arrow on the filter body.
6. Installation should be downstream of the regulator but upstream of any
lubricator.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
7. Install the filter vertically with the bowl drain mechanism at the bottom.
ensuring there is sufficient free space below the filter for future access.
8. Remove the blanking plugs from the connection ports and connect to the
supply and delivery hoses.
9. A drain hose can be screwed to the drain port or the filter bowl drained
manually.
10. Your filter is now ready for use.
USE AND CARE IN SERVICE
1. Let the filter run with air supply on. Ensure that the pressure to the air inlet of
the filter from air line does not exceed the maximum pressure specified in
the instructions.
2. The filter is equipped with a manual drain. Turn manual drain valve to drain
accumulated liquids inside the bowl. Take care to drain the liquids from the
bowl whenever necessary and always keep the liquids below the baffle.
3. The filter element should be replaced when the pressure drop across the
element exceeds 10 psi. When an excessive pressure drop across a
saturated but uncontaminated element occurs, it may indicate that the
tool being operated exceeds the maximum flow rate (CFM) of the filter
(See Specifications). Refer to the maximum flow rate of your filter and
make sure that the required CFM of the air tool is within the maximum flow
rate of your filter for best air tool operation.
MAINTENANCE
DISASSEMBLY
1. The filter can be disassembled without removal from the air line.
2. Shut OFF inlet pressure. Reduce
pressure in inlet and outlet lines to
zero.
3. Remove the bowl. Push into the
body and turn anti-clockwise.
4. Disassemble in general
accordance with the parts
illustrated. Do not remove the
drain unless replacement is
necessary. Remove and replace

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
only if drain malfunctions or is being replaced with optional automatic
drain.
CLEANING
1. Clean the polycarbonate bowl with warm water only. Clean other parts
with warm water and soap.
2. Rinse and dry parts. Blow out internal passages in the body with clean, dry,
compressed air. Blow air through the filter element from inside to outside to
remove surface contaminants.
3. Inspect and replace any parts found to be damaged. Replace the plastic
bowl with a metal bowl if plastic bowl shows signs of cracking or cloudiness.
ASSEMBLY
1. Lubricate the o-rings, the portion of the manual drain body that contacts
the bowl, and the hole in the manual drain body that accommodates the
stem of drain valve with o-ring grease.
2. Assemble the filter as shown on page 7.
3. Tighten the items listed in the Table below..
4. Refit the bowl assembly ensuring the O-ring is in position. Push the bowl, or
bowl with guard, into the body and turn fully clockwise
ACCESSORIES
A wide range of accessories is available including filter/regulators, lubricators,
high-pressure hoses (5 to 50 metres) etc.
Contact your CLARKE dealer for further information or CLARKE International
Service Department.
Torque Settings
Part Inch Pounds (N-m)
Screw 17 to 22 (1.9 to 2.5)
Baffle 4 to 6 (0.5 to 0.7)
Centre post 6 to 8 (0.7 to 0.9)
Nut 20 to 25 (2.3 to 2.8)

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
COMPONENT PARTS
No Description
1Body
2 Poly bowl assembly
3 Drain valve
4 O-ring
5Drainbody
6 Bowl guard
7Polycarbonatebowl
8 O-ring
9 Metal bowl assembly
10 O-ring
11 Drain valve
12 O-ring
13 Drain body
14 Screw
15 Clamp
16 Lens
17 Seal
18 Metal bowl
19 Baffle
20 5 micron element
40 micron element
21 Centre post
22 Louvre
23 Auto drain conversion
24 Nut
25 Gasket
26 Automatic drain
27 Universal wall bracket
