Evoqua WALLACE & TIERNAN DEPOLOX 5 E User manual

WALLACE & TIERNAN
®
DEPOLOX
®
5 E
FLOW CELL
INSTRUCTION MANUAL

2WT.050.810.040.DE.IM.0817
DEPOLOX®5 E flow cell
Please note
Original instruction manual!
Simone

DEPOLOX®5 E flow cell Contents
3
Contents
1. Introduction 5
1.1 Documentation 5
1.2 Conventions 6
1.3 Disclaimer 7
2. Safety 9
2.1 Intended use 9
2.2 General safety instructions 10
2.3 Specific operating phases 11
2.4 Warranty conditions 12
3. Description 13
3.1 General 13
3.2 Versions 14
3.3 Design and functions 19
3.4 Optional accessories 23
3.5 Technical Data 24
4. Installation 31
4.1 Scope of supply 31
4.2 Transport and storage 33
4.3 Ambient conditions 33
4.4 Mechanical installation 35
4.5 Commissioning 55
4.6 Shutting down 55
4.7 Recommissioning 56

4WT.050.810.040.DE.IM.0817
Contents DEPOLOX®5 E flow cell
5. Maintenance 57
5.1 Maintenance intervals 57
5.2 Maintenance parts kit 58
5.3 Checking for leakage 58
5.4 Checking electrode cleaning sand 59
5.5 Checking electrolyte solution level 59
5.6 Checking diaphragms 59
5.7 Replacing or cleaning electrode cleaning sand,
electrolyte solution, reference electrode and
diaphragms 60
5.8 Cleaning or replacing the fine filter 63
5.9 Cleaning flow rate monitor and check valve 64
5.10 Cleaning 64
6. Retrofit kits, spares and accessories 65
6.1 Retrofit kits 65
6.2 Installing retrofit kits 66
6.3 Spare parts 71
6.4 Accessories 79
7. Declarations and certificates 81
7.1 Declaration of Conformity 81
7.2 Certificate of CSA 83
8. Index 87

DEPOLOX®5 E flow cell Introduction 1.
5
1. Introduction
1.1 Documentation
1.1.1 Target groups
This instruction manual provides the information for installation,
operating and maintenance personnel. It is required for operation
and maintenance of the DEPOLOX®5 E flow cell (module type
D01).
All persons working with the DEPOLOX®5 E flow cell must have
read and understood the instruction manual, in particular, the
safety instructions it contains.
1.1.2 Documentation Structure
This instruction manual is intended for operators of the
DEPOLOX®5 E flow cell. It contains important information for
safe, trouble-free, and efficient operation of the DEPOLOX®5E
flow cell. Observing these instructions will help prevent risks,
reduce repair costs and downtimes, and increases the reliability
and service life of the DEPOLOX®5 E flow cell
Chapters Installation, Commissioning, and Maintenance are
intended only for trained and authorized service personnel. These
chapters contain important information on the assembly, configu-
ration, commissioning and start-up, maintenance and repair of the
DEPOLOX®5 E flow cell that should only be performed by this tar-
get group.
Please consult the table of contents and the index to quickly find
the information you require.
