SFC BA Contents
3
Contents
1. Introduction 5
1.1 Documentation 5
1.2 Conventions 6
2. Safety 7
2.1 Intended use 7
2.2 General safety instructions 7
2.3 Warranty conditions 8
2.4 Specific Operating Phases 9
2.5 Notes on Special Dangers 10
3. Description 11
3.1 Versions 11
3.2 Technical Data 11
3.3 Scope of supply 14
3.4 Description 15
3.5 System configuration 15
4. Functions 19
4.1 General 19
4.2 Outputs 28
4.3 Alarms 29
4.4 CAN interface 31
4.5 Firmware Update 32
4.6 Digital inputs 34
4.7 SD memory card 34
4.8 System configuration 36
5. Installation 37
5.1 Transport and storage 37
5.2 Installation 38
5.3 Start-up 43
5.4 Shut-down 55

4 WT.050.590.030.IM.DE.0719
Contents SFC BA
6. Operation 57
6.1 Display and operator controls 57
6.2 Notes on operation 61
6.3 Menu structure 63
6.4 Calibration 80
6.5 Errors and remedies 83
7. Maintenance 87
7.1 Maintenance Schedules 87
7.2 CAN membrane sensor maintenance 88
7.3 Changing the fuse on the A&C board 88
7.4 Replacing the battery 89
8. Complete Systems, Retrofit Kits and Spare Parts 91
9. Wiring Diagram 95
10. Index 97

SFC BA Introduction
1.
5
1. Introduction
1.1 Documentation
1.1.1 Target groups
This operating manual provides the information for installation,
operating and maintenance personnel. It is required for operation
and maintenance of the system.
This operating manual is intended for the operating personnel. It
contains important information for safe, reliable, trouble-free and
economical operation of the system. Observance of this
information helps to prevent danger, lowers repair costs, reduces
down-times, and also increases the reliability and service life of the
system.
The chapters on installation and maintenance are solely provided
for trained service personnel. These sections contain important
information on the installation, configuration and start-up of the
system as well as information on its repair.
All persons working with the system must have read and
understood the operating manual, in particular, the safety
instructions it contains.
Please consult the table of contents and the index to find the
information you require quickly.

6 WT.050.590.030.IM.DE.0719
Introduction SFC BA
1.
1.2 Conventions
Please note
This operating manual contains a number of notes with different
priorities, which are marked with symbols.
Symbol Caption Meaning
Danger! Immediate danger to life and limb! If
the situation is not handled properly,
death or serious injury may be the
result.
Warning! Danger to life and limb! If the
situation is not handled properly,
death or serious injury may be the
result.
Attention! If this warning is not observed,
medium or slight injury or damage to
the equipment may the result.
Warning! Electrical hazard.
Please
note These notes facilitate work with the unit/system.

SFC BA Safety
2.
7
2. Safety
2.1 Intended use
The SFC BA is intended exclusively for measuring residuals in
clear water, potable water and industrial water.
The operational safety of the system is only guaranteed if it is used
in accordance with its intended application. The system may only
be used for the purpose defined in the order and under the
operating conditions indicated in the technical specifications.
Compliance with the intended use also includes reading this
operating manual and observing all the instructions it contains.
Furthermore, all inspection and maintenance work must be
performed at the prescribed intervals.
The operator bears full and sole responsibility if this system is put
to any use which does not comply strictly and exclusively with this
intended use.
2.2 General safety instructions
Evoqua attaches great importance to ensuring that work on its
system is always perfectly safe. This has been taken into account
in the design of the system, by the integration of safety features.
Safety instructions The safety instructions in this documentation must always be
followed. These do not affect the validity of any additional national
or company safety instructions.
Safety instructions printed on
the system All safety instructions attached to the system itself must be followed. They must always be complete and easily legible.

8 WT.050.590.030.IM.DE.0719
Safety SFC BA
2.
Technical standard The system has been constructed in accordance with state-of-the-
art technology and the accepted safety regulations. However, in
the event of the system being used by persons who have not been
adequately instructed, risks to life and limb of such persons or third
parties and damage to the system itself or to other property cannot
be ruled out. Work not described in this operating manual may only
be performed by authorized personnel.
Personnel The operator of the system must ensure that only authorized and
qualified specialized personnel are permitted to work with and on
the system within their defined scope of authority. "Authorized
specialized personnel" refers to trained technicians employed by
the operator, Evoqua or, if applicable, the service partner. Only
qualified electricians may perform work on electrical components.
Spare parts / components Trouble-free operation of the system is only guaranteed if original
spare parts and components are used in precisely the combination
described in this operating manual. Failure to observe this
instruction may incur the risk of malfunction or damage to the
system.
Modifications and extensions Never attempt to perform any modifications, extensions or
conversions to the system without the written approval of the
manufacturer! These could have an adverse affect on safety!
Electrical power During normal operation, the control unit must remain closed.
Before starting any assembly, inspection, maintenance, or repair
work, the system must be switched OFF using the emergency off
switch and the switch must be secured against reactivation.
Connect all cables in accordance with the wiring diagram.
Disposal Ensure safe and environmentally-friendly disposal of agents and
replaced parts.
2.3 Warranty conditions
The following must be observed for compliance with warranty
conditions:
• Installation, commissioning by Evoqua technicians or
trained and authorised specialised personnel, e.g. of
contracted companies
• Intended use
• Observation of the operational parameters and settings.
• The system may only be operated by trained personnel.

SFC BA Safety
2.
9
• An operating log book must be kept (only in the public
sector).
• The system must not be exposed to frost.
• Maintenance work must be carried out.
• Use of original spare parts.
If any of the above conditions are not met, the warranty is void.
2.4 Specific Operating Phases
Normal operation Never employ any working methods which could affect safety!
Only run the system when the housing is closed!
Inspect the system at least once daily for externally visible damage
and faults! Inform the responsible person/authority immediately of
any detected changes (including any changes in the operating
performance)!
In the event of malfunctions, always switch the system off
immediately! Have malfunctions remedied immediately!
Installation and
maintenance Always perform installation or maintenance work in accordance with this operating manual or the technical documentation for
installed system components!
Secure the system against activation during installation and
maintenance work!
Always retighten released screw connections!
Never use corrosive cleaning agents!
Use only a damp cloth to clean the system.
Ensure safe disposal of agents and replaced parts in accordance
with environmental regulations!

10 WT.050.590.030.IM.DE.0719
Safety SFC BA
2.
2.5 Notes on Special Dangers
Electrical power Only use original fuses with the prescribed current rating! In the
event of a fault in the electrical power supply, switch the system off
immediately!
Only qualified electricians or trained personnel supervised by a
qualified electrician are permitted to perform any work on electrical
components in accordance with valid electro-technical regulations.
If stipulated, disconnect all parts of the system from the power
supply before performing any inspection, maintenance or repair
work. Then first test the disconnected components to ensure they
do not carry any voltage.
Inspect/check the electrical system of the system regularly.
Remedy any faults immediately!
Connect disconnected cables in accordance with the wiring
diagram!
Agents und
chemicals When handling agents and chemical substances always observe the safety regulations valid for each product!
Always remove leaked agents immediately with a suitable binder
or wipe up with a cloth. Danger of slipping!
Always collect and dispose of agents or used cleaning material
separately and in accordance with valid national regulations!

SFC BA Description
3.
11
3. Description
3.1 Versions
The SFC BA is available as standard wall-mounted system.
It has the following inputs and outputs:
•2 relays
• 1x digital input
• 1x mA output
• 1x CAN interface for connecting the sensor
• 1x SD memory card slot
• 1x firmware update interface
3.2 Technical Data
3.2.1 SFC BA electronics module
Close the housing
Electronics
Attention!
* Only at 24 V DC.

For connection of membrane sensors FC2-BA CAN (Part No.
W3T365499), CAN FC1 (Part No. W3T168596) and 
CAN TC1 CAN (Part No. W3T168595) the supply voltage 
must be 24 V DC ± 3%.
Dimensions (WxHxD) 185 x 265 x 145 mm
Weight approx. 2.5 kg
Protection type IP 66
Mains connection
100 – 240 V AC ± 10%, 50-60 Hz, 10 W, Fuse 1A (T) Type: TR5
24 V DC ± 20%*, 10 W, Fuse 1 A (T) Type: 5x20 mm

12 WT.050.590.030.IM.DE.0719
Description SFC BA
3.
Attention!
Do not use the system in measuring categories II, III and IV.
Ports
Display and operating unit
Relay outputs
Insulation
Overvoltage category 2
Contamination level 2
Measuring category I
Operating conditions
Ambient temperature 0 – 50 °C
Humidity < 80 %
Environment No direct sunlight
Atmospheric pressure 75 – 106 kPa
Max. altitude 2,000 m
Storage temperature -20 – +70 °C
Noise emission <45 dB
Digital input
1x input for voltage-free contact (< 100 Ohm) power supply via
SFC BA (12 V)
DI 1: Sample water monitoring
1x RS232 for firmware updates (not galvanically isolated)
1 x operating panel with 9 keys
1 x Graphic display:
• Resolution 128 x 64 pixels
• white background illumination
2 relay outputs (2 two-way switches)
Switching values 5 A, 250 V AC, 1250 VA max.
5 A, 220 V DC, 150 W max.
UL/CSA-rating 5 A, 1/6 HP 125, 250 V AC
5 A, 30 V DC, 30 W max.
1 A, 30 V DC - 0.24 A, 125 V DC

SFC BA Description
3.
13
mA output
3.2.2 SFC BA flow cell module
Picture 1 SFC BA flow cell module with dimensions
G Flow control valve 
Dimensions
Connections
1x mA output:
• Output 0/4 – 20 mA
• Accuracy < 0.5% FS
• Load max. 500 Ohm
• Temperature drift max. 0.2% / 10°C
• Load monitoring
• Electrically isolated up to 50 V to earth
G
Dimensions (WxHxD) 136 x 195 x 61 mm
Weight Approx. 0.5 kg
Sample water PVC hose 6 x 3 mm or 
PE hose 6 x 1 mm
Thread connection G1/2"

14 WT.050.590.030.IM.DE.0719
Description SFC BA
3.
Flow rate
Sample water
Please note
*The actual flow rate required to ensure safe and economical
operation (approx. 10 – 15 l/h) needs to be determined by
gauging. The flow rate can be varied using the flow control valve
(G). To reduce the flow rate, turn the flow control valve (G)
clockwise. See Fig. Page 18.
3.3 Scope of supply
Please note
You will find the order numbers under 8. “Complete Systems,
Retrofit Kits and Spare Parts”.
3.3.1 Standard
Depending on the individual order, the scope of supply includes
the following:
Electronics module SFC BA 
incl. accessories set and mounting set, comprising:

4 screws (Ø = 5 mm)
4 dowels (Ø = 8 mm)
4 washers
3 multiple seal inserts 2 x 6 mm
3 multiple seal inserts 4 x 5 mm
3 reducing seal rings Ø = 8 mm
4 bolts for multiple seal inserts 5 mm
2 bolts for multiple seal inserts 6 mm
Flow rate* Approx. 10 – 15 l/h
(Can be set using the flow control
valve)
Pressure range 0.2 - 4.0 bar
Back pressure Non-pressurized version (gravity
drain)
Water quality Drinking water, swimming pool
water
Sample water temperature max. +45 °C

SFC BA Description
3.
15
3.4 Description
3.4.1 Versions
SFC BA There are two voltage versions of the SFC BA.
• 100 – 240 V AC
• 24 V DC
3.5 System configuration
Overall design The SFC BA electronics module can be installed on a DIN rail or
using wall fastening brackets.
The SFC BA flow cell module is screwed straight onto the wall.
Picture 2 SFC BA flow cell module with CAN membrane sensor
and SFC BA electronics module
A SFC BA flow cell module
B CAN membrane sensor
C CAN bus connecting cable M12
D SFC BA electronics module
AB C D

16 WT.050.590.030.IM.DE.0719
Description SFC BA
3.
Electronics module SFC BA The electronics module SFC BA consists of a plastic housing (C)
with a removable cover.
The housing contains:
• A&C board (A)
• the cable glands (B)
Picture 3 SFC BA Basic
A A&C Board
B Cable glands
CEnclosure
A
B
C

SFC BA Description
3.
17
The following are integrated into the cover:
• Front panel board with graphic display (B)
• Insertable strips (C)
Picture 4 SFC BA Operating front (rear)
A Housing cover
B Front panel board
C Insertable strips
A
B
C

18 WT.050.590.030.IM.DE.0719
Description SFC BA
3.
SFC BA flow cell module
Non-pressurized version The SFC BA flow cell module with integrated sensor ensures
optimum flow over the sensors due to its special design.
The SFC BA flow cell module guarantees a stable measurement
signal combined with low water consumption of just 10 – 15 l/h due
to:
• CAN bus membrane sensors (B)
• Constant flow rate of sample water using the flow control valve
(G)
• Optimum flow over the membrane sensors
Picture 5 SFC BA flow cell module, non-pressurized version
A CAN bus connecting cable M12
B CAN bus membrane sensor
C Sample water outlet, non-pressurized
D Cell body
E Flow body
F Stop valve
G Flow control valve
H Sample water inlet
D
A
B
C
E
F
H
G

SFC BA Functions
4.
19
4. Functions
4.1 General
The SFC BA is a special measuring instrument for use in drinking
water treatment as well as for industrial process and swimming
pool water treatment.
A typical application is:
• Measurement and recording of water parameters
Potential process measurements include:
• Free chlorine and total chlorine
The integrated graphical display displays the following:
• Measured values
• Bar graph with limit values
• Measuring range screen
•etc.
The menu operation via the softkeys is self-explanatory thanks to
the plain text displays.
A 30 day trend display allows past measurements of up to two
freely selectable process variables to be displayed (with an SD-
card). Without an SD-card the trend displays the past 0 – 24 h.
If an SD-card is installed, a file containing the measurements taken
and the time they were taken is saved for each month. This file is
a text file and can be opened with any text editor.
A mA output is provided to permit connection to a display system.

20 WT.050.590.030.IM.DE.0719
Functions SFC BA
4.
Total function Potential parameters include:
• Total chlorine* (CAN membrane sensor)
• Free chlorine* (CAN membrane sensor)
* These measurements are automatically temperature-compensated.
CAN interface • The SFC BA has an integrated CAN interface. This is used to
exchange data with CAN-capable sensors (for a description
and bus design, see 4.4 “CAN interface”).
4.1.1 CAN membrane sensors
CAN membrane sensors The following CAN membrane sensors are available:
• Free chlorine - FC2-BA CAN (replacement for CAN FC1)
• Free chlorine - CAN FC1
• Total chlorine - CAN TC1
The CAN membrane sensors and the integrated electronics allow
the system to be connected directly to the CAN interface on the
electronics module (see chapter 9. “Wiring Diagram”).
All of the CAN membrane sensors are fitted with an integrated
temperature sensor and provide temperature-compensated
measurements as well as allowing the sample water temperature
to be measured.
Please note
For a better overview, the start-up, maintenance, trouble-shooting,
de-bugging and storage is listed here for each sensor.
