Operator'sManual
50InchBagger
Quest®
ModelNo.126-7510—SerialNo.400000000andUp
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCalifornia
tocausecancer,birthdefects,orreproductiveharm.
Important:Thiskitrequiresthesimultaneousinstallationofotherkitstofunctionproperly.Leversteer
unitsrequireafrontweightkitandamountingkit.Steeringwheelunitsrequireamountingkit.Contact
yourAuthorizedServiceDealertoobtainthecorrespondingnecessaryparts.
Introduction
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
Wheneveryouneedservice,genuineparts,or
additionalinformation,contactanAuthorizedService
DealerorCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
g207309
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
Safetyalertsymbol
Thismanualusestwowordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
©2017—ExmarkMfg.Co.,Inc.
IndustrialParkBox808
Beatrice,NE68310
www.Exmark.comOriginalInstructions(EN)
PrintedintheUSA.
AllRightsReserved*4503-386*A

Contents
Introduction...............................................................1
Safety.......................................................................3
TowingSafety.....................................................3
SafetyandInstructionalDecals..........................5
Setup........................................................................6
1PreparingtheMachine.....................................7
2InstallingtheWeight.........................................7
3InstallingtheAttachmentMount.......................9
4AssemblingtheBaggerT op...........................12
5InstallingtheBaggerTop................................13
6InstallingtheChute........................................15
7AttachingtheDischargeTube........................16
Operation................................................................17
EmptyingtheGrassBags.................................17
ClearingObstructionsfromtheBagger.............18
RemovingtheBagger.......................................19
UsingtheDrawBar...........................................19
Transporting.....................................................19
OperatingTips.................................................20
Maintenance...........................................................22
RecommendedMaintenanceSchedule(s)...........22
InspectingtheBaggerAttachment....................22
InspectingtheMowerBlades............................23
CaringfortheGrassBags.................................23
CleaningtheBaggerAttachment......................23
Storage...................................................................23
StoringtheBaggerAttachment.........................23
2

Safety
WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemical
orchemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orreproductiveharm.
DANGER
Theenginecanbecomehotwhenitis
operating.Severeburnscanoccurfrom
contactinghotsurfaces.
Allowtheengine,especiallythemufer,to
coolbeforetouching.
DANGER
Debris,suchasleaves,grass,orbrushcan
catchre.Areintheengineareacancause
personalinjuryandpropertydamage.
•Keeptheengineandmuferareafreeof
debrisaccumulation.
•Takecarewhenopeningthebaggercover
tokeepdebrisfromfallingontotheengine
andmuferarea.
•Allowthemachinetocoolbeforestoringit.
CAUTION
Operatingthemachinewithouttheweight
attachment(whererequired)maycausean
unstableconditionwhichcouldresultina
lossofcontrol.
ContactyourAuthorizedServiceDealer
todetermineifaweightattachmentis
appropriateforyourmachine.
Thefollowinglistcontainssafetyinformationspecic
tothemanufacturer’sproductsandothersafety
informationyoumustknow.
•Becomefamiliarwiththesafeoperationofthe
equipment,withtheoperatorcontrols,andsafety
signs.
•Useextracarewithgrasscatchersorother
attachments.Thesecanchangetheoperating
characteristicsandthestabilityofthemachine.
•Followthemanufacturer'srecommendations
foraddingorremovingwheelweightsor
counterweightstoimprovestability.
•Donotuseagrasscatcheronsteepslopes.A
heavygrasscatchercouldcauselossofcontrol
oroverturnthemachine.
•Slowdownanduseextracareonhillsides.Be
suretotravelintherecommendeddirectionon
hillsides.Turfconditionscanaffectthemachine's
stability.Useextremecautionwhileoperatingnear
drop-offs.
•Keepallmovementonslopesslowandgradual.
Donotmakesuddenchangesinspeed,directions
orturning.
•Thegrasscatchercanobstructtheviewtothe
rear.Useextracarewhenoperatinginreverse.
•Usecarewhenloadingorunloadingthemachine
intoatrailerortruck.
•Neveroperatewiththedischargedeectorraised,
removedoraltered,unlessusingagrasscatcher.
•Keephandsandfeetawayfrommovingparts.Do
notmakeadjustmentswiththeenginerunning.
•Stoponlevelground,disengagedrives,chock
orblockwheels,shutoffenginebeforeleaving
theoperator'spositionforanyreasonincluding
emptyingthegrasscatcheroruncloggingthe
chute.
•Ifyouremovethegrasscatcher,besuretoinstall
anydischargedeectororguardthatmighthave
beenremovedtoinstallthegrasscatcher.Donot
operatethemowerwithouteithertheentiregrass
catcherorthegrassdeectorinplace.
•Stoptheenginebeforeremovingthegrasscatcher
oruncloggingthechute.
•Donotleavegrassingrasscatcherforextended
periodsoftime.
•Grasscatchercomponentsaresubjecttowear,
damageanddeterioration,whichcouldexpose
movingpartsorallowobjectstobethrown.
Frequentlycheckcomponentsandreplace
withmanufacturer'srecommendedparts,when
necessary.
TowingSafety
•Donotattachtowedequipmentexceptatthehitch
point.
•Followtheattachmentmanufacturer's
recommendationforweightlimitsfortowed
equipmentandtowingonslopes.
•Neverallowchildrenorothersinorontowed
equipment.
3

•Onslopes,theweightofthetowedequipmentmay
causelossoftractionandlossofcontrol.Reduce
towedweightandslowdown.
•Stoppingdistanceincreaseswiththeweightofthe
towedload.Travelslowlyandallowextradistance
tostop.
•Makewideturnstokeeptheattachmentclearof
themachine.
•Donottowaloadthatweighsmorethanthe
towingmachine.
4

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decal110-6691
110-6691
1.Thrownobjecthazard—keepbystandersasafedistance
awayfromthemachine.
2.Thrownobjecthazard,mower—donotoperatewithoutthe
deector,dischargecover,orgrasscollectionsystemin
place.
3.Cutting/dismembermentofhandorfoot—stayawayfrom
movingparts.
decal131-4036
131-4036
1.Themaximumdrawbar
pullis36kg(80lb).
2.ReadtheOperator's
Manual.
decal109-6809
109-6809
1.Crushinghazardofhand—donotremovethewholebaggerfromthemachine;openthebaggertopandthenremovethebag(s)
fromthebagger.Donotremovethebaggertopwhenitisclosed;openthebaggertopandthenremoveit.
5

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Preparethemachine.
Bolt(3/8x1-1/4inches)4
Locknut(3/8inch)4
Weightmountingbracket,left1
Weightmountingbracket,right1
Washers4
Weightbracket1
Bolt(3/8x1inch)2
Flatweight1
Suitcaseweight1
2
Keyedcrossbar1
Installtheweight.
Stabilizerbracket(For2015andnewer
models)1
Carriagebolt(5/16x3/4inch)2
Locknut(5/16inch)4
Self-tappingscrew(5/16x3/4inch)2
Bolt(5/16x1inch)2
Pivotframe1
Hairpincotter2
Rod2
Washer2
3
Draw-bardecal1
Installtheattachmentmount.
Baggertop1
4Baggerscreen1Assemblethebaggertop.
Hoodrod1
Hairpincotterpin1
GrassBag2
5Upperbaggertube1
Installthebaggertop.
Chute1
Knob1
Carriagebolt(5/16x1-3/8inches)1
6Flangenut(5/16inch)1
Installthechute.
7Nopartsrequired–Connectwiththedischargetube.
6

Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
1
PreparingtheMachine
NoPartsRequired
Procedure
1.Parkthemachineonalevelsurfaceand
disengagethedrives.
2.Engagetheparkingbrake.
3.Shutofftheengineandremovethekey.
4.Waitforallmovingpartstostopbeforeleaving
theoperatingposition.
5.Ensurethatthemachineissecurefrom
movementandallowsurfacestocoolbeforeyou
begintoworkonit.
6.Cleanthemachineofanydebrisonthemachine
deckorrearpartofthemachinetoease
installation.
2
InstallingtheWeight
Partsneededforthisprocedure:
4Bolt(3/8x1-1/4inches)
4Locknut(3/8inch)
1Weightmountingbracket,left
1Weightmountingbracket,right
4Washers
1Weightbracket
2Bolt(3/8x1inch)
1Flatweight
1Suitcaseweight
1Keyedcrossbar
Procedure
Note:Thisprocedureisonlyformodelswithcontrol
levers.Steeringwheelmodelsdonotneedweights
installed.
CAUTION
Thebaggerchangestheweightdistributionof
themachine.Operatingthemachinewithout
thefrontweightsmaycauseanunstable
conditionwhichcouldresultinalossof
control.
Ensurethefrontweightsareproperlyinstalled
beforeoperatingthemachinewiththebagger
attachment.
1.Locatethefrontboltsontheundersideofthe
frame(Figure3andFigure4).
2.Removethe2bolts(3/8x1inch)and2locknuts
(3/8inch).Retainthelocknuts.
G014875
1
2
3
4
g014875
Figure3
1.Front-rightcaster(castor
forkandwheelnotshown
forclarity)
3.Bolt(3/8x1inch)
2.Fronthole,rightside4.Locknut(3/8inch)
g206983
Figure4
1.Locknut(3/8inch)3.Frontleftcaster(castor
forkandwheelnotshown
forclarity)
2.Fronthole,leftside4.Bolt(3/8x1inch)
7

3.Locatetheleftandrightweight-mounting
bracketsinlooseparts.
4.Installtheleftbrackettotheundersideofthe
frameusing2bolts(3/8x1-1/4inches),2
washersand2locknuts(3/8inch)(Figure5).
Note:Onelocknutisfromloosepartsandthe
otherisusedfromearlierremoval.
g206982
Figure5
1.Locknut(3/8inch),existing5.Hole,existinginframe
2.Forwardhole,leftside6.Washer
3.Frontleftcaster(caster
forkandwheelnotshown
forclarity)
7.Bolt(3/8x1-1/4inches)
4.Locknut(3/8inch),loose
parts
8.Leftmountingbracket
5.Ontherightsideofthemachine,installtheright
weight-mountingbracketasfollows:
•Formachineswithoutafootassistliftpedal,
securethebracketusing2bolts(3/8x1-1/4
inches),2washersand2locknuts(3/8inch)
(Figure6).
Note:Alocknutisfromtheloosepartsand
theotherisusedfromearlierremoval.
g206981
Figure6
1.Frontrightcaster(caster
forkandwheelnotshown
forclarity)
5.Bolt(3/8x1-1/4inches)
2.Forwardhole,rightside6.Washer
3.Locknut(3/8inch),existing7.Hole,existinginframe
4.Rightmountingbracket8.Locknut(3/8inch),loose
parts
Note:Formachineswithafootassistlift
pedal,thewashersarenotused.
•Formachineswithafootassistliftpedal,
removetheforwardfastenersinthefoot
assistliftpedalbracketandsecurethe
bracketusing2boltsand2locknuts(Figure
7).
Note:Onelocknutisfromthelooseparts
andtheotherisusedfromearlierremoval.
g206980
Figure7
6.Installtheweightbrackettothemounting
bracketsbyaligningtheoutboardholesinthe
bracketwiththemountingbracketsinstalled
previously(Figure8).
8

Note:Makesurethebracketiscenteredon
theframe.
7.Securetheweightbracketwith2bolts(3/8x1
inch)and2locknuts(3/8inch)(Figure8).
G014879 12
3
4
5
g014879
Figure8
1.Locknut(3/8inch)4.Bolt(3/8x1inch)
2.Weightbracket5.Rightmountingbracket
3.Leftmountingbracket
8.Installaatweighttotheweightbracketand
moveitrearward,ushwiththebracket(Figure
9).
G014880
1
2
3
g014880
Figure9
1.Keyedcrossbar3.Suitcaseweight
2.Flatweight
9.Installasuitcaseweightinfrontoftheatweight
(Figure9).
10.Securetheweightstotheweightbracketwitha
keyed-crossbar(Figure9).Installthebarand
rotateit90degreesdownwardtolockitinplace.
11.Oncealltheweightsandbracketshavebeen
installed,checkthatallthefastenersaretight.
Tightenasnecessary.
Important:Wheneveryouremovethebagger
attachment,remembertoremovethefrontweights
toreturntheproperstabilitytothemachine.
9

3
InstallingtheAttachment
Mount
Partsneededforthisprocedure:
1Stabilizerbracket(For2015andnewermodels)
2Carriagebolt(5/16x3/4inch)
4Locknut(5/16inch)
2Self-tappingscrew(5/16x3/4inch)
2Bolt(5/16x1inch)
1Pivotframe
2Hairpincotter
2Rod
2Washer
1Draw-bardecal
For2015andNewerModelsOnly
Note:Thestabilizerbracketisusedonlyon2015
andnewermodels(seeFigure10).
1.Installthestabilizerbrackettotheengineguard
usingtwocarriagebolts(5/16x3/4inch)and
twolocknuts(5/16inch).
g030494
g030494
Figure10
2015modelshown
1.Stabilizerbracket
2.Carriagebolt(5/16x3/4inch)
3.Locknut(5/16inch)
2.Installthepivotframetothemachineframe.
Securethepivotframetothemachineframe
usingtwobolts(5/16x1inch)andtwolocknuts
(5/16inch).
g028227
Figure11
1.Machineframe4.Bolt(5/16x2-1/2inch)
2.Locknut(5/16inch)5.Pivotframe
3.Hole
3.Securethepivotframetothebottomofthe
machineframeusingtwoself-tappingscrews
(5/16x3/4inch).
g028174
Figure12
1.Self-tappingscrew(5/16x3/4inch)
2.Pivotframe
4.Attachthedrawbardecal1/2inch(1.3cm)to
theleftoftheattachmentmount.
10

g028305
Figure13
1.Drawbardecal
5.Installthebent,aredendofarodintothekeyed
slotintheleftsideofthemachineframe,and
movetherodrearwardtoseatitintheframe.
Note:Repeatthisstepfortherightsideofthe
machine.
g028306
Figure14
Leftsideshown
1.Pivotframehole4.Supportrod
2.Washer5.Keyedslot,existing
3.Hairpincotter6.Bent,aredendofrod
6.Insertthebentendsoftherodsintothe
attachmentmountasshowninFigure14and
securetheendofeachrodwithawasherand
hairpincotter.
For2011through2014Models
Only
Note:Thestabilizerbracketisnotusedon2011
through2014models.
Note:For2011through2014models,therear-engine
guardisoptionalforthisbagger.
1.Installthepivotframetothemachineframe.
Securethepivotframetothemachineframe
usingtwobolts(5/16x1inch)andtwolocknuts
(5/16inch).
12
34
5
g030496
g030496
Figure15
1.Machineframe4.Bolt(5/16x2-1/2inch)
2.Locknut(5/16inch)5.Pivotframe
3.Hole6.Rear-engineguard
(optional)
2.Securethepivotframetothebottomofthe
machineframeusingtwoself-tappingscrews
(5/16x3/4inch).
11

1
2g030497
g030497
Figure16
1.Self-tappingscrew(5/16x3/4inch)
2.Pivotframe
3.Attachthedraw-bardecal1/2inch(1.3cm)to
theleftoftheattachmentmount.
g030498
1
g030498
Figure17
1.Drawbardecal
4.Installabent,aredendofarodintothekeyed
slotintheleftsideofthemachineframe,and
movetherodrearwardtoseatitintheframe.
Note:Repeatthisstepfortherightsideofthe
machine.
g030499
1
23
4
6 5
g030499
Figure18
Leftsideshown
1.Pivot-framehole4.Supportrod
2.Washer5.Keyedslot(existing)
3.Hairpincotter6.Bent,aredendofsupport
rod
5.Insertthebentendsoftherodintothe
attachmentmountandsecuretheendofeach
rodwithawasherandhairpincotterasshown
inFigure18.
4
AssemblingtheBaggerTop
Partsneededforthisprocedure:
1Baggertop
1Baggerscreen
Procedure
Turnthebaggertopover.Installthescreenasshown
inFigure19soitslopesdowntowardthecollection
bags.Makesurethescreenssnapintoplaceandthe
tabsengagethebaggertop.
12

G005666
1
2
3
4
g005666
Figure19
1.Baggertop3.Screentab
2.Screen4.Slotinbaggertop
5
InstallingtheBaggerTop
Partsneededforthisprocedure:
1Hoodrod
1Hairpincotterpin
2GrassBag
1Upperbaggertube
Procedure
1.Installthehoodrodtothebaggerframewitha
hairpincotterpin.Installthehairpincotterpin
fromthebottom.
g032708
Figure20
1.Baggerframe3.Hairpincotterpin(install
fromthebottom)
2.Hoodrod
2.Installthebaggertoptothebaggerframe.
Rotatethebaggertoptoalignthekeyholesin
thebaggertopbracketswiththekeysinthe
postsonthebaggerframe.Slidethebrackets
overthepostsandrotatethebaggertopdown
totheoperatingposition.
Note:Thebaggertopiseasiertoinstalliftwo
peopleworktogether.
13

g032709
Figure21
1.Baggertop4.Bracket,baggertop
2.Baggerframe5.Key
3.Keyhole6.Post
3.Liftthebaggertopandinstallthebagsbysliding
thebagframehooksontotheretainingbrackets.
1
2
3
4
g028327
g028327
Figure22
1.Bag3.Retainingbracket
2.Baggerframe4.Bagframehook
4.Lowerthebaggertopontothebag.
g207349
Figure23
5.Installtheupperbaggertube.Insertthecurved
endintotheopeninginthebaggertop.Make
surethearedendwiththeretentionpostis
pointingdownandforwardinpreparationtobe
matedwiththeFinishingKit.
6.Aligntheholeintherubberhoodlatchwiththe
hoodrod.
14

g018363
1
2
3
g018363
Figure24
1.Rubberhoodlatch3.Latchedposition
2.Hoodrodend
7.Pushthehoodlatchovertheendofthehood
rodasshowninFigure24.
6
InstallingtheChute
Partsneededforthisprocedure:
1Chute
1Knob
1Carriagebolt(5/16x1-3/8inches)
1Flangenut(5/16inch)
Procedure
1.Removetheplateassemblythatincludesthe
sidedischargechute(Figure25).Thebafewill
comeoffatthesametime.Savethishardware
andplateassembly.
g017834
1
2
3
g017834
Figure25
1.Flangenuts3.Carriagebolts
2.Plateassemblywith
dischargechute
2.Installtheexistingbafewiththeexistingbolts
andnutsafterremovingtheplateassembly
(Figure26).
3.Installacarriageboltandangenutintothe
frontholeshowinFigure26.
g018309
1
2
4
3
5
g018309
Figure26
1.Newangenut(5/16inch)4.Existingbafe
2.Newcarriagebolt(5/16x
1-3/8inches)
5.Existingnuts
3.Existingbolts
4.Aligntheholeinthechuteandinstallitontothe
bolt.Securethechutetothemowerdeckwith
theknobandatwasher(5/16inch)(Figure27).
15

g018310
1
2
3
g018310
Figure27
1.Knob3.Chute
2.Flatwasher(5/16inch)
5.Hooktheexiblelatchonthechutetothe
retainingclaspweldedonthemowerdecktothe
rearoftheopening(Figure28).
g017841
1
2
3
X
Y
Z
g017841
Figure28
1.Chute3.Retainingclasp(weldedto
mowerdeck)
2.Flexiblelatch
6.Rotatethelatchuntilithooksintotheholeinthe
mowerdeckstiffener(Figure29).
g017842
1 2
g017842
Figure29
1.Latch2.Holeinthemowerdeck
stiffener
7
AttachingtheDischarge
Tube
NoPartsRequired
Procedure
1.Slidethecurvedendofthedischargetubeinto
theopeninginthebaggertop(Figure30).
16

G010641
12
3
4
5
g010641
Figure30
1.Dischargetube,curved
end
4.Peg
2.Openinginbaggertop5.Rubberstrap
3.Dischargetube,aredend
2.Slidethearedendofthedischargetubeover
theendofthechute.Movetherubberretaining
straponthechutesnapsoverthepegonthe
dischargetubetosecureit(Figure30).
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
Note:Overallwidthofunitwithbagger:58.7inches
(149cm).
WARNING
Toavoidpersonalinjury,followthese
procedures:
•Becomefamiliarwithalloperatingand
safetyinstructionsintheOperator's
Manualforthemowerbeforeusingthis
attachment.
•Neverremovethedischargetube,bags,
baggertop,orthechutewhiletheengine
isrunning.
•Alwaysshuttheengineoffandwaitforall
movingpartstostopbeforeclearingan
obstructionfromthebaggingsystem.
•Neverdomaintenanceorrepairswhilethe
engineisrunning.
WARNING
Withoutthegrassdeector,baggertubesor
completebaggerassemblymountedinplace,
youandothersareexposedtobladecontact
andthrowndebris.Contactwiththerotating
mowerblade(s)andthrowndebriswillcause
injuryordeath.
•Alwaysinstallthegrassdeectorwhen
removingthebaggerandchangingtoside
dischargemode.
•Ifthegrassdeectoriseverdamaged,
replaceitimmediately.Thegrassdeector
routesmaterialdowntowardtheturf.
•Neverputyourhandsorfeetunderthe
mower.
•Nevertrytoclearthedischargeareaor
mowerbladesunlessyoumovethepower
takeoff(PTO)tooffandrotatetheignition
keytooff.Alsoremovethekeyandpull
thewireoffofthesparkplug(s).
•Turnofftheenginebeforeuncloggingthe
dischargechute.
EmptyingtheGrassBags
Becarefulwhenliftingorhandlingagrassbagthatis
full.Toemptythegrassbags:
17

1.Parkthemachineonalevelsurfaceand
disengagethebladecontrolswitch.
2.Stoptheengine,removethekey,settheparking
brakeandwaitforallmovingpartstostopbefore
leavingtheoperatingposition.
3.Open(raise)thebaggertop(Figure31).
g207340
Figure31
4.Compressdebrisintothebags.Withboth
hands,liftuponthebagandunhookitfromthe
retainingbracket.Emptythebag.Repeatthe
procedurefortheotherbag.
5.Installthebagsbyslidingthebagframehooks
ontotheretainingbrackets(Figure32).
1
2
3
4
g028327
g028327
Figure32
1.Bag3.Retainingbracket
2.Baggerframe4.Bagframehook
6.Lowerthebaggertopontothebags.
ClearingObstructionsfrom
theBagger
1.Parkthemachineonalevelsurfaceand
disengagethebladecontrolswitch.
2.Movethemotioncontrolleversoutwardtothe
neutrallockposition,stoptheengine,remove
thekey,settheparkingbrakeandwaitfor
allmovingpartstostopbeforeleavingthe
operatingposition.
3.Checkthegrassbagsandemptythemifthey
arefull.
4.Removeandseparatethedischargetubeand
chutefromthebaggertopandmower.Using
astickorsimilarobject,carefullyremoveand
cleartheobstructionfromthemower,discharge
tube,chute,andthebaggertop.
5.Afteryouremovetheobstruction,installthe
completebaggersystemandresumeoperation.
18

RemovingtheBagger
CAUTION
Failingtoremovethefrontbaggerweights
fromleversteermodelsandoperatingthe
machinewithoutthebaggerattachmentmay
causeanunstableconditionwhichcould
resultinalossofcontrol.
•Alwaysremovethefrontweights(where
required)whenremovingthebagger
attachment.
•Neveroperatethemachinewithoutthe
baggerattachmentandthefrontweights
(whererequired)stillinstalled.
ThebaggercanberemovedbyrepeatingtheSetup
sectionsfromallinstalledbaggerrelatedkitsin
reverseorder.Ifweightsareinstalled,alwaysremove
thefrontbaggerweightswhenremovingthebagger
attachments.
Note:Itisonlynecessarytoremovethecutoffbafe
wheninstallingamulchingkit.
UsingtheDrawBar
Theattachmentmounthasadrawbarfeaturethat
canbeusedfortowing.
•Readandunderstandalltheoperatinginstructions
ofthemachine.
•Whenturning,slowdownandobservethe
clearance.
•Makewideturnsandkeeptowedequipmentclear
ofthetowingvehicle.
•Themaximumdrawbarpullis36kg(80lb).
•Excessivedrawbarpullmaycausehydrostatic
transmissionfailure.
g028309
Figure33
1.Attachmentmountwithdrawbar
Transporting
TransportingtheMachine
Useaheavy-dutytrailerortrucktotransportthe
machine.Ensurethatthetrailerortruckhasall
necessarybrakes,lighting,andmarkingasrequired
bylaw.Pleasecarefullyreadallthesafetyinstructions.
Knowingthisinformationcouldhelpyou,yourfamily,
pets,orbystandersavoidinjury.
WARNING
Drivingonthestreetorroadwaywithoutturn
signals,lights,reectivemarkings,oraslow
movingvehicleemblemisdangerousandcan
leadtoaccidentscausingpersonalinjury.
Donotdrivemachineonapublicstreetor
roadway.
Totransportthemachine:
1.Ifusingatrailer,connectittothetowingvehicle
andconnectthesafetychains.
2.Ifapplicable,connectthetrailerbrakes.
3.Loadthemachineontothetrailerortruck.
4.Stoptheengine,removethekey,setthebrake,
andclosethefuelvalve.
5.Tiedownthemachinenearthefrontcaster
wheelsandtherearbumper(Figure34).
g027708
Figure34
LoadingtheMachine
DoNottransportthemachinewiththehopper
full.Emptythehopperbeforeattemptingtoload
machineontrailerortruck.Thiswillreducethe
chanceofrearwardtipup.
Useextremecautionwhenloadingorunloading
machinesontoatraileroratruck.Useafull-width
rampthatiswiderthanthemachineforthisprocedure.
Backuprampsanddriveforwarddownramps(Figure
35).
19

g027995
Figure35
1.Backupramps2.Driveforwarddownramps
Important:Donotusenarrowindividualramps
foreachsideofthemachine.
Ensuretherampislongenoughsothattheanglewith
thegrounddoesnotexceed15degrees(Figure36).
Onatground,thisrequiresaramptobeatleastfour
times(4X)aslongastheheightofthetrailerortruck
bedtotheground.Asteeperanglemaycausemower
componentstogetcaughtastheunitmovesfromthe
ramptothetrailerortruck.Steeperanglesmayalso
causethemachinetotiporlosecontrol.Ifloadingon
ornearaslope,positionthetrailerortrucksothatitis
onthedownsideoftheslopeandtherampextends
uptheslope.Thiswillminimizetherampangle.
WARNING
Loadingamachineontoatrailerortruck
increasesthepossibilityoftip-overandcould
causeseriousinjuryordeath.
•Useextremecautionwhenoperatinga
machineonaramp.
•Useonlyafull-widthramp;donotuse
individualrampsforeachsideofthe
machine.
•Donotexceeda15-degreeanglebetween
therampandthegroundorbetweenthe
rampandthetrailerortruck.
•Ensurethelengthoframpisatleastfour
times(4X)aslongastheheightofthe
trailerortruckbedtotheground.Thiswill
ensurethatrampangledoesnotexceed15
degreesonatground.
•Backuprampsanddriveforwarddown
ramps.
•Avoidsuddenaccelerationordeceleration
whiledrivingthemachineonarampas
thiscouldcausealossofcontrolora
tip-oversituation.
g027996
5
1
2
6
g027996
Figure36
1.Full-widthrampinstowed
position
4.Rampisatleastfourtimes
(4X)aslongastheheight
ofthetrailerortruckbed
totheground
2.Sideviewoffull-width
rampinloadingposition
5.H=heightofthetraileror
truckbedtotheground
3.Notgreaterthan
15degrees
6.Trailer
OperatingTips
BaggingTips
Size
Rememberthatthemowerislongerandwiderwith
thisattachmentinstalled.Byturningtoosharplyin
connedplacesyoumaydamagetheattachment.
Trimming
Alwaystrimwiththeleftsideofthemower.Donottrim
withtherightsideofthemowerbecauseyoucould
damagethebagger'schuteanddischargetube.
20
