laguna C FLUX 1 User manual

Owner’s Manual
1.5HP CYCLONE
1 Micron Canister
lagunatools.com | lagunacleanair.com | supermaxtools.com

Specifications
Flux 1
Flux 2
Flux 3
Models
MDCCF15110
MDCPF15110
MDCCF22201
MDCPF22201
MDCCF32201
MDCPF32201
Electrical
Power Requirements
110V-1PH-60HZ*
220V-1PH-60HZ
Amperage (FLA)
18.8 AMP / 9.4 AMP (220V Option)
14 AMP
22 AMP
Motor Power
1.5HP
2HP
3HP
Motor Speed
3450 RPM
Starter Switch
Magnetic 110V*
Magnetic 220V
Plug Included
Not Included
Not Included
Not Included
Circuit Breaker Requirement
110V 30 AMP / 220V 15 AMP
220V 20 AMP
220V 30 AMP
Receptacle Requirement
110V 5-30 / 220V 6-15
220V 6-20
220V 6-30
Notes
*220v-1ph-60hz option available with purchase of additionalcontrolpanel: part no. pdccf15110 220v
General
Certification
CSA-US: 201825
Net Weight
CFLUX 1: 232 LBS (105 KGS)
PFLUX 1: 269 LBS (122 KGS)
CFLUX 2: 296 LBS (134 KGS)
PFLUX 2: 340 LBS (154 KGS)
CFLUX 3: 309 LBS (140 KGS)
PFLUX 3: 351 LBS (159 KGS)
Shipping Weight
CFLUX 1: 287 LBS (130 KGS)
PFLUX 1: 331 LBS (150 KGS)
CFLUX 2: 364 LBS (165 KGS)
PFLUX 2: 408 LBS (185 KGS)
CFLUX 3: 375 LBS (170 KGS)
PFLUX 3: 419 LBS (190 KGS)
Shipping Dimensions (LxWxH)
45"L x 28.5"W x 47.5"H
50.25"L x 31.75"W x 50.75"H
Foot Print (LxW)
42.5"L x 24.2"W
45.1"L x 27.3"W
Machine Type: Dust Collector
Inlet Diameter
6"
8"
Inlet Air Flow (CFM)
1314 CFM
1740 CFM
2817 CFM
Max Static Pressure
10.1" H2O
9.3" H20
11.2" H20
Filter Efficiency
CFLUX: 95% 0.3 - 1 micron
PFLUX: 99.95% 0.3 micron
CFLUX: 95% 0.3 - 1 micron
PFLUX: 99.95% 0.3 micron
Filter Rating (EN Standard)
CFLUX: F9
PFLUX: H13 (HEPA)
CFLUX: F9
PFLUX: H13 (HEPA)
Filter Surface Area (actual)
48.9ft² (4.5m²)
109ft² (9.5m²)
Filter Size (Dia. x H)
15.75"Ø X 19.69"H (400MMØ X 500MM)
15.75"Ø X 37"H (400MMØ X 940MM)
Drum Capacity
32 Gal(121L)
46 Gal(174.1L)
Dimensions
Foot Print (LxW)
42.5"L x 24.2"W
45.1"L x 27.3"W
Base (LxW)
42.5"L x 24.2"W
45.1"L x 27.3"W
Inlet Diameter
6"
8"
Floor to Inlet Center
48.3"
55.3"
Drum Bag Size
24"Ø X 37.4"H (610MMØ X 950MMH)
24"Ø X 37.4"H (610MMØ X 950MMH)
Filter Bag Size
15.75"Ø X 23.6"H (400MMØ X 600MMH)
OR 15.75"Ø METAL CAP (PDCPF32201-EC-KIT)
Dust Collection
Dust Port Outer Diameter
N/A
CFM Requirement
N/A
Materials
Cyclone, Drum, Chassis
12 GA. SHEET STEAL
Filter Media
POLYESTER
Fan (Impeller)
1/8" PLATE STEEL
Sound Deadening Panels
EXPANDED POLYURETHANE MEMORY FOAM
Features
110V Operation
YES
NO
Mobility (Machine & Drum)
YES
Two Stage Dust Collector
YES
Quick Release Drum Change
YES
Quick Release Filter Change
YES
Magnetic Switch
YES
HF Remote Start
YES
Industrial Use Bearings
YES
HEPA Filtration
P FLUX MODELS ONLY
Sound Deadening Panels
P FLUX MODELS ONLY
Tool-less Bag Hold Down
P FLUX MODELS ONLY
Mechanical Filter Cleaning
C FLUX MODELS ONLY
Iteration Filter Cleaning
P FLUX MODELS ONLY
Accessories & Options
Automatic Filter Cleaner
110V CFLUX1: ADCACKIT110
220V CFLUX1: ADCACKIT220
NOT AVAILABLE FOR PFLUX 1
CFLUX: ADCACKIT220
PFLUX: ADCPF23ACKIT220
Drum Replacement Bag
PDCCF15110-25
PDCCFPF-DRUM BAG
Filter Replacement Bag
PDCCF32201-25
End Cap (standard on Pflux, allows for
iteration cleaning method)
PDCPF32201-EC-KIT
220V Switch Option
CFLUX: PDCCF15110 220V
PFLUX: PDCCF15110-220-CB
STANDARD
Dust Collector Kit
SMALL: ADC3700-0145
LARGE: ADC3750-0145

Warranty
Registration
To prevent voiding this warranty, all products sold must be registered within thirty (30) days of receiving
the product. All registered purchases will receive notifications about important product changes, receive
customer service, and be able to file a warranty claim against defective workmanship, parts, or materials.
You must register your purchase! Please follow this link:
https://lagunatools.com/policies/warranty/
Length of Warranty
All new machines and optional accessories sold through an authorized dealer carry a two-year warranty
effective the date of receiving the product. Machines sold for either commercial or industrial use have a
one-year warranty. Wearable parts like throat plates, band-saw guides, etc., have a ninety-day warranty.
Aside from being free of defects upon receiving, consumable parts, like cutters and abrasives, are not
covered by this warranty unless otherwise stated by Laguna Tools. These parts are designed to be used at
the expense of the operator and are available for replacement or inventory purchase. The determination
of a consumable part will be made on a case-by-case basis by Laguna Tools.
2 Year – New Machines Sold Through an Authorized Dealer
2 Year – Accessories Sold as Machine Options (excluding blades)
1 Year – Machines Sold for Commercial or Industrial Use
1 Year – Blades and Accessories outside of Machine Options
90 Days – Wearable Parts
Who is Covered
The applicable warranty covers only the initial purchaser of the product from the date of receiving the
product. To file such claims, the original purchaser must present the original receipt as proof of purchase.
What is Covered
The warranty covers any defects in the workmanship of all parts and materials that make up the machine
unless otherwise specified. Any part, determined by Laguna Tools®, to have a defect will be repaired or
replaced (and shipped), without charge. The defective item must be returned to Laguna Tools with the
complaint and proof of purchase and in the original packaging. In the event the item is determined to be
not covered by this warranty, the customer will be responsible for the cost to replace the item/part and all
related shipping charges.
Warranty Limitations
This limited warranty does not apply to natural disasters, acts of terrorism, normal wear and tear, product
failure due to lack of maintenance or cleaning, damage caused by accident, neglect, or inadequate dust
collection. The warranty may be voided against proof of misuse/abuse, damage caused where repair or
alterations have been made or attempted by others, using the product for purposes other than those
described as intended use (unless with consent by Laguna Tools®), modification to the product, or use
with an accessory that was not designed for the product. It is the responsibility of the user to understand
basic woodworking machinery settings and procedures and to properly maintain the equipment in
accordance with the standards provided in this manual.
Shipping Damage
Laguna Tools® is not responsible for damage or loss caused by a freight company or other circumstances
not in the direct control of Laguna Tools. All shipping-related claims for loss or damage goods must be
made to Laguna Tools within twenty-four hours of delivery.
How to Receive Support
To file a warranty claim, please contact the warranty department at 1-949-474-1200. To receive customer
service or technical support please contact the customer service department at 1-800-332-4094. Warranty
parts are shipped at the expense of Laguna Tools either by common carrier, FedEx ground services or
similar method. Technical support to install replacement parts is primarily provided by phone, fax, email,
or the Laguna Tools Customer Support Website.

RED
BLACK
Wiring

Wiring
For 220V Conversion. Aditional parts required: CLFUX 1 220v Switch Assembly: PDCCF15110 220V

For machines that are already assembled in your shop, follow the steps below to assemble the
crossbar to your unit for better and improved dust separation.
1. Remove the drum and set aside to later connect back with unit.
2. Loosen two of the bolts which are opposite each other that are connecting the drum lid to the
cyclone cone.
3. The crossbar below is common for all models (CFLUX and PFLUX series and the TFLUX5).
4. Take the crossbar and attach to the drum lid and tighten using the two bolts removed in the
previous step. It does not matter which position you attach the crossbar. As long as it does not
obstruct the sensor on the drum lid.
5. Compelte the assembly by sliding your drum back in place.
CROSSBAR ASSEMBLY
TO IMPROVE PSYCLONIC SEPARATION
READ AND UNDERSTAND ALL WARNINGS AND OPERATING
INSTRUCTIONS BEFORE USING THIS EQUIPMENT. Failure to follow all instructions listed below,
may result in electric shock, fire, and/or serious personal injury or property damage.
Before removing any parts, turn OFF the machine and remove the power source.
PFLUX1 drum lid and crossbar PFLUX2 drum lid and crossbar

1.5HP Mobile Dust Cyclone Manual
1
TABLE OF CONTENTS
Important Safety Instructions
Safety Guidelines - Definitions
General Safety Rules
Additional Safety For Dust Collectors
Power Connections
Motor Specifications
Grounding Instructions
Key Features and Components
Functional Description
Product Specifications
npacking
Assembly
General Tool Assembly
Maintenance Procedures
Cleaning the Filter
Changing the Filter Bag
Emptying the Drum
Routine Inspection
Trouble Shooting
Parts breakdown and Parts list

1.5HP Mobile Dust Cyclone Manual
2
IMPORTANT SAFETY INSTRUCTIONS
READ AND UNDERSTAND ALL WARNINGS AND OPERATING
INSTRUCTIONS BEFORE USING THIS EQUIPMENT. Failure to follo all instructions listed
belo , may result in electric shock, fire, and/or serious personal injury or property
damage.
Wood orking can be dangerous if safe and proper operating procedures are not follo ed.
As ith all machinery, there are certain hazards involved ith the operation of the product.
Using the machine ith respect and caution ill considerably lessen the possibility of
personal injury. Ho ever, if normal safety precautions are overlooked or ignored, personal
injury to the operator may result. Safety equipment such as guards, push sticks, hold-
do ns, featherboards, goggles, dust masks and hearing protection can reduce your
potential for injury. But even the best guard on’t make up for poor judgment,
carelessness or inattention. Always use common sense and exercise caution in the
orkshop. If a procedure feels dangerous, don’t try it. Figure out an alternative procedure
that feels safer. REMEMBER: Your personal safety is your responsibility.
This machine as designed for certain applications only. We
strongly recommend that this machine not be modified and/or used for any application
other than that for hich it as designed. If you have any questions relative to a
particular application, DO NOT use the machine until you have first contacted the
manufacturer to determine if it can or should be performed on the product.
If you have any questions relative to its application DO NOT use the product until you
have contacted the manufacturer and e have advised you.
When using an electrical appliance, basic precautions should al ays be follo ed, including
the follo ing:
READ ALL INSTRUCTIONS BEFORE USING (THIS APPLIANCE)
To reduce the risk of fire, electric shock, or injury:
1. Do not leave appliance hen plugged in. Unplug from outlet hen not in use and before
servicing.
2. Do not use outdoors or on et surfaces
3. Do not allo to be used as a toy. Close attention is necessary hen used by or near
children.
4. Use only as described in this manual. Use only manufacturer’s recommended
attachments.
5. Do not use ith damaged cord or plug. If appliance is not orking as it should, has
been dropped, damaged, left outdoors, or dropped into ater, return it to a service center.

1.5HP Mobile Dust Cyclone Manual
3
6. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord
around sharp edges or corners. Do not run appliance over cord. Keep cord a ay from
heated surfaces.
7. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
8. Do not handle plug or appliance ith et hands.
9. Do not put any object into openings. Do not use ith any opening blocked; keep free of
dust, lint, hair, and anything that may reduce air flo .
10. Keep hair, loose clothing, fingers, and all parts of body a ay from openings and
moving parts.
11. Turn off all controls before unplugging.
12. Use extra care hen cleaning on stairs.
13. Do not use to pick up flammable or combustible liquids, such as gasoline, or use in
areas here they may be present.
14. Connect to a properly grounded outlet only. See Grounding Instructions.
SAVE THESE INSTRUCTIONS
1. Read and understand the arnings posted on the machine and in this manual.
Failure to comply ith all of these arnings may cause serious injury.
2. Replace the arning labels if they become obscured or removed.
3. This 1.5HP Portable Cyclone Dust Collector is designed and intended for use by
properly trained and experienced personnel only. If you are not familiar ith the
proper and safe operation of this type of dust collector, do not use until proper
training and kno ledge have been obtained.
4. Do not use this machine for other than its intended use. If used for other purposes,
LAGUNA TOOLS INC., disclaims any real or implied arranty and holds itself
harmless from any injury that may result from that use.
5. Al ays ear approved safety glasses/face shields hile using this machine.
6. Before operating this dust collector, remove tie, rings, atches and other je elry,
and roll sleeves up past the elbo s. Remove all loose clothing and confine long hair.
Non-slip foot ear or anti-skid floor strips are recommended. Do not ear gloves.
7. Wear ear protectors (plugs or muffs) during extended periods of operation.
8. Some dust created by po er sanding, sa ing, grinding, drilling and other
construction activities contain chemicals kno n to cause cancer, birth defects or
other reproductive harm. Some examples of these chemicals are:
•Lead from lead based paint.
•Crystalline silica from bricks, cement and other masonry products.
•Arsenic and chromium from chemically treated lumber.

1.5HP Mobile Dust Cyclone Manual
4
Your risk of exposure varies, depending on ho often you do this type of ork. To
reduce your exposure to these chemicals, ork in a ell-ventilated area and ork
ith approved safety equipment, such as face or dust masks that are specifically
designed to filter out microscopic particles.
9. Do not operate this machine hile tired or under the influence of drugs, alcohol or
any medication.
10.Make certain the s itch is in the OFF position before connecting the machine to the
po er source.
11.Make certain the machine is properly grounded.
12.Make all machine adjustments or maintenance ith the machine unplugged from
the po er source.
13.Form a habit of checking to see that all extra equipment such as adjusting keys,
renches, scrap, stock, and cleaning rags are removed a ay from the machine
before turning on.
14.Keep safety guards in place at all times hen the machine is in use. If removed for
maintenance purposes, use extreme caution and replace the guards immediately
hen maintenance is complete.
15.Make sure the dust collector is on a flat even surface and the heels locked in place
before use.
16.Check damaged parts. Before further use of the machine, a guard or other part that
is damaged should be carefully checked to determine that it ill operate properly
and perform its intended function. Check for alignment of moving parts, binding of
moving parts, breakage of parts, mounting and any other conditions that may
affect its operation. A guard or other part that is damaged should be properly
repaired or replaced.
17.Provide for adequate space surrounding ork area and non-glare, overhead lighting.
18.Keep the floor around the machine clean and free of scrap material, oil and grease.
19.Keep visitors a safe distance from the ork area. Keep chil ren away.
20.Make your orkshop child proof ith padlocks, master s itches or by removing
starter keys.
21.Give your ork undivided attention. Looking around, carrying on a conversation and
“horse-play” are careless acts that can result in serious injury.
.

1.5HP Mobile Dust Cyclone Manual
5
22.Maintain a balanced stance at all times so that you do not fall or lean against the
dust collector. Do not overreach or use excessive force to perform any machine
operation.
23.Use the right tool at the correct speed and feed rate. Do not force a tool or
attachment to do a job for which it was not designed. The right tool will do the job
better and safer.
2 .Use recommended accessories; improper accessories may be hazardous.
25.Maintain machinery with care. Follow instructions for lubricating and changing
accessories.
26.Turn off the machine before cleaning. Use a brush or compressed air to remove
dust or debris — do not use your hands.
27.Do not stand on the machine. Serious injury could occur if the machine tips over.
28.Never leave the machine running unattended. Turn the power off and do not leave
the machine until it comes to a complete stop.
29.Never operate or run the machine without closing the drum up against the lid.
Failure to do so will result in the machine amperage increasing and may trip your
circuit.
Familiarize yourself with the following safety notices used in this manual:
SAFETY GUIDELINES - DEFINITIONS
This manual contains information that is important for you to know and understand. This
information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS.
To help you recognize this information, we use the symbols below. Please read the manual
and pay attention to these sections.
Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.

1.5HP Mobile Dust Cyclone Manual
6
Used ithout the safety alert symbol indicates potentially hazardous
situation hich, if not avoided, may result in property damage.
GENERAL SAFETY RULES
WARNING FAILURE TO FOLLOW THESE RULES MAY RESULT
IN SERIOUS PERSONAL INJURY.
FOR YOUR OWN SAFETY, READ AND UNDERSTAND THE INSTRUCTION MANUAL
BEFORE OPERATING THE MACHINE. Learn the unit’s application and limitations as ell
as the specific hazards peculiar to it.
KEEP WORK AREA CLEAN. Cluttered areas and benches invite accidents.
DON’T USE IN DANGEROUS ENVIRONMENT. Don’t use this unit in damp or et
locations, or expose it to rain. Keep ork area ell-lighted.
KEEP CHILDREN AND VISITORS AWAY. All children and visitors should be kept a safe
distance from ork area.
DISCONNECT UNIT before servicing.
CHECK DAMAGED PARTS. Before further use of the unit, properly repair or replace any
part that is damaged.
FAILURE TO FOLLOW THESE RULES MAY RESULT IN
SERIOUS INJURY.
ADDITIONAL SAFETY FOR DUST COLLECTORS
Inten e use. This dust collector is only intended for collecting ood dust and chips from
ood orking machines. Do not use this dust collector to collect metal, dirt, pebbles,
dry all, asbestos, lead paint, silica, liquids, aerosols, or any flammable, combustible, or
hazardous materials.
Hazar ous ust. Dust created hile using machinery may cause cancer, birth defects, or
long-term respiratory damage. Be a are of dust hazards associated ith each ork piece
material, and al ays ear a NIOSH-approved respirator to reduce your risk.

1.5HP Mobile Dust Cyclone Manual
7
Dust allergies. Dust from certain oods may cause an allergic reaction in people and
animals.
Make sure you kno hat type of ood dust you ill be exposed to in case there is a
possibility of an allergic reaction.
Wear respirator. Fine dust that is too small to be caught in the filter ill be blo n into
the ambient air during operation. Al ays ear a NIOSH-approved respirator during
operation and for a short time after to reduce your risk of permanent respiratory damage.
Emptying ust. When emptying dust from the collection container, ear a respirator and
safety glasses. Empty dust a ay from ignition sources and into an approved container.
Disconnecting power supply. Turn the s itch off, disconnect the dust collector from the
po er supply, and allo the impeller to come to a complete stop before leaving the
machine unattended or doing any service, cleaning, maintenance, or adjustments.
Suspen e ust particles an ignition sources. Do not operate the dust collector in
areas ere explosion risks are high. Areas of high risk include, but are not limited to,
areas near pilot lights, open flames, or other ignition sources.
Fire suppression. Only operate the dust collector in locations that contain a fire
suppression system or have a fire extinguisher nearby.
Impeller hazar s. Do not place your hands or tools near the open inlet during operation
for any reason. The po erful suction could easily cause accidental contact ith the
impeller, hich ill
cause serious personal injury or damage to the machine. Al ays keep small animals and
children a ay from open dust collection inlets.
Avoi ing sparks. Do not allo steel or rocks to strike the impeller—this may produce
sparks.
Sparks can smolder in ood dust for a long time before a fire is detected. If you
accidentally cut
Into ood containing tramp metal (nails, staples, spikes, etc.), immediately turn off the
dust collector, disconnect it from po er, and ait for the impeller to stop—then empty the
collection container into an approved airtight metal container.
Operating location. To reduce respiratory exposure to fine dust, locate permanently
installed dust collectors a ay from the orking area, or in another room that is equipped
ith a smoke detector. Do not operate the dust collector in rainy or et locations—
exposure to ater may create a shock hazard or decrease the life of the machine.
Static electricity. Plastic dust lines generate high amounts of static electricity as dust
chips pass through them. Although rare, sparks caused by static electricity can cause
explosions or fire. To reduce this risk, make sure all dust lines are thoroughly grounded by
using a grounding ire.

1.5HP Mobile Dust Cyclone Manual
8
Regular cleaning. Regularly check/empty the collection bags or drum to avoid the
buildup of fine dust that can increase the risk of fire. Make sure to regularly clean the
surrounding area here the machine is operated—excessive dust buildup on overhead
lights, heaters, electrical panels, or other heat sources ill increase the risk of fire.
This means that if precautions are not heeded, it may result in minor injury and/or
possible machine damage.
This means that if precautions are not heeded, it may result in serious injury or possibly
even death.
SAVE THESE INSTRUCTIONS.
Refer to them often nd use them to instruct others.
POWER CONNECTIONS
DO NOT EXPOSE THE MACHINE TO RAIN OR OPERATE THE
MACHINE IN DAMP LOCATIONS.

1.5HP Mobile Dust Cyclone Manual
9
MOTOR SPECIFICATIONS
Your machine is ired for 110 volts, 60 HZ alternating current. Before connecting the
machine to the po er source, make sure the s itch is in the "OFF" position.
GROUNDING INSTRUCTIONS
THIS MACHINE MUST BE GROUNDED WHILE IN USE TO PROTECT
THE OPERATOR FROM ELECTRIC SHOCK.
1. This appliance must be connected to a grounded metal, permanent iring system; or
an equipment-grounding conductor must be run ith the circuit conductors and connected
to the equipment-grounding terminal or lead on the appliance.
The installer, such as a qualified electrician, cut (or bend over) and insulate the grounding
conductor from a field iring supply cable.
In the event of certain types of malfunctions or breakdo ns, grounding provides a path of
least resistance for electric current—in order to reduce the risk of electric shock.
Improper connection of the equipment-grounding ire can result in a risk of electric shock.
The ire ith green insulation ( ith or ithout yello stripes) is the equipment-grounding
ire. If repair or replacement of the po er cord or plug is necessary, do not connect the
equipment-grounding ire to a live (current carrying) terminal.
Check ith a qualified electrician or service personnel if you do not understand these
grounding requirements, or if you are in doubt about hether the tool is properly
grounded. If you ever notice that a cord or plug is damaged or orn, disconnect it from
po er, and immediately replace it ith a ne one.
Full Load
a mperage Draw
Amp draw at 110V ( p r e wi r e d ) .................. 18.8 Am ps
Amp draw at 220V ................................ 9.4 Am ps
Power Supply Circuit Requirements
The po er source c i r cu i t for your m a ch i ne must be ground e d and r a t e d f o r the
a m p er a g e g iv en belo . Never replace a circuit breaker on an exist ing circuit ith
one of higher amperage without consulting a qualified electrician to ensure
compl i ance ith iring codes. If you are unsure about the wiring co es in your
area or you plan to connect your machine to a share circuit, consult a qualifie
electrician.
C i r c u i t Size ( 220 V ) .................................. 15 A m p s
M i n i m u m C i r c u i t Size (110V) ................. 30 A m p s m i n i m u m

1.5HP Mobile Dust Cyclone Manual
10
IN ALL CASES, MAKE CERTAIN THE RECEPTACLE IN QUESTION IS
PROPERLY GROUNDED. IF YOU ARE NOT SURE, HAVE A QUALIFIED ELECTRICIAN CHECK
THE RECEPTACLE.
110 VOLT Single Phase Operation
The motor supplied ith your machine is a dual voltage, 110/220 volt motor. It is
shipped ready-to-run for 110 volt operation. Ho ever, it can be converted for 220 volt
operation.
A qualified electrician should do the conversion, or the machine can be taken to an
Authorized Dealer Service Center. When completed, the machine must conform to the
National Electric Code and all local codes and ordinances.
The machine is converted by re- iring the motor for 220 volts, and replacing the s itch
ith one that is rated for 220 volt operation.
FUNCTION
High frequency remote control switch
NOTICE
This Machine i s p r e w i r e d f o r 1 1 0 V . If
you plan to operate the machine at
220V, you must replace the entire control
panel switch with the optional 220V
c ont r ol pa ne l switch, and rewire the
motor at the junction box.
ON/OFF Switch
Motor Cord
On board circuit brea er
Power Cord

1.5HP Mobile Dust Cyclone Manual
11
Hand held remote controller
PROGRAMMING THE REMOTE CONTROL
1. Ensure the machine is switch ON before programming the remote control.
2. Press the black set button on the bottom of the remote switch until you hear two beeps.
3. Press the Remote set button on your hand held controller simultaneously with the black
button until you hear three beeps to complete the set up.
OFF button ON button
*Remote set button
*Used to match up a new hand held
controller with the remote switch
Receiver set button

1.5HP Mobile Dust Cyclone Manual
12
PRODUCT SPECIFICATIONS
Motor Specs: 1.5 HP
Electrical Specs:
1
1
0V/2
2
0V
/
60Hz
/
1PH
/
3450 RPM
Running AMP ( ith 6” inlet) 18.8A at 110V; 9.4A at 220V
Air Volume: 900CFM (cubic feet per minute)
Max. static pressure
9
Inch
es of ater
Fan size 13”
Inlet:
Ø
6” by
Ø
4” x 2 ports
S itch High frequency remote control s itch
Collection capacity
32 gallon Octagon
drum
Packing Size:
(L x W x H)
43.7” x 27.2” x 46.1”
(111 x 69 x 117 cm)
Machine eight 232 lbs (105 kgs)
Shipping eight
287
lbs (
130
kgs)
Filter Media filtering area: 4.5 m2 (48.4 ft2)
Cartridge Filter
1 Micron
Ø
15.74
” x
19
.68” (
Ø40 x 50cm)
x 1pc

1.5HP Mobile Dust Cyclone Manual
13
UNPACKING
Your 1.5HP Mobile Dust Cyclone comes packed in a single box. Before attempting to
assemble this machine, follo these directions for unpacking:
1. Carefully cut the banding straps and remove them from the box.
2. Cut along the tape line at the top of the box.
3. Remove all parts from the top of the styrofoam and set aside.
4. Remove the styrofoam packing material from the top of the machine.
5. Carefully take out the machine components from the box and set aside.
6. Using the diagram belo , ensure that all parts are present and in good condition.
DESCRIPTION (QUANTITY) Figure 1
A. Motor
B. S itch and remote controller
C. Dust chute
D. Top upright supports (3)
E. Base frame
F. Canister filter
G. Octagon drum left panel
H. Octagon drum right panel
I. Octagon drum front panel
J. Octagon drum back panel
K. Octagon drum base panel
L. Octagon drum lid
Report any missing or damaged parts to your dealer or distributor. Prior to tool
assembly and use, read this manual thoroughly to familiarize yourself ith proper
assembly, maintenance and safety procedures.
G
H
I
J
K
L
M
N
P
Q
V
S
R
R1
R2
R
3
Manual
M.
Octagon drum foot peddle
N. Lo er upright supports (3)
O. Drum insert
P. Upright support reinforcement plate (3)
Q. Foot peddle bar (left and right)
R. Foot peddle assembly fittings
R1. Lo er triangular support plate (2)
R2. Foot peddle bar support (2)
R3. Lo er support plate (2)
S. Inlet adapter
T. Hard are box
U. Operating and Parts Manual
T
U
A
B
C
D
E
F
Hardware
box
A
O





GENERAL TOOL ASSEMBLY
This step requires two adults. This 1.5 HP Mobile
Dust Cyclone is heavy, be careful when lifting and handling it! Failure to
comply may cause serious injury and/or damage to the machine and/or
property!
Tools Required
10mm wrench / 12mm wrench / 14mm wrench
Phillips screwdriver
4mm hex wrench / 5mm hex wrench
To assemble your dust cyclone, follow these steps:
For your own safety, do not connect the machine to the power source until
the machine is completely assembled. Please also make sure that you read
and understand the entire instruction manual.
ASSEMBLY TIME ESTIMATE 4 hour to 5 hour
Step One: Turn the unit upside. Make sure you use a cushion under the
canister top side to even out the unit to the same height as the motor. Do
not have the unit lopsided.
 
