Expain Change Neck & Shoulders User manual

USER MANUAL
English
Norsk
Dansk
Svensk
Suomi
CHANGE NECK
& SHOULDERS

English
2
Contents
1 Components
2 Introduction
3 Before use
4 How to mount the device
5 How to unmount the device
6 Usage
7 Usage with app
8 Biofeedback and habits
9 Battery and charging
10 Maintenance and storage
11 Technical specications
12 Safety information

English
3
Components
1 Button
2 Light
3 USB connector
4 Fast snap connector
5 Adhesive patches snap
6 USB cable
1
4
56
2 3

English
4
Introduction
Congratulations on your new
EXPAIN Change Neck & Shoulders!
This is a unique device that allows
you to monitor the muscle activity in
the neck and shoulder muscles in a
new way. EXPAIN Change Neck &
Shoulders provides Biofeedback to
help you change habits that may
cause pain. Biofeedback is a
learning process where observation
of the signals from your own body,
leads to a changed habits. The
device vibrates when you have
strained muscle activity patterns.
This allows you to change your bad
habits, which again may eliminate
the cause of your pain.
EXPAIN Change Neck &
Shoulders can be connected
with a smartphone via Bluetooth
Smart, or it can be used without
connection to a phone. If you wish
to keep track of your historical
muscle activity pattern, download

English
5
EXPAIN app
(iOS or Android).
See separate section or
www.expain.com for more
information. The unit is wireless,
powered with a rechargeable
battery and is attached to the
skin over the muscles in the neck /
shoulder region with the
included patch.
Before Use
EXPAIN Change Neck & Shoulders
is made for personal use. Read
instructions carefully. The unit must
be charged before the rst use. See
section for battery and charging for
more information on how the device
is charged.
(NB: The device should not be used
at night, and the unit should not be
on the body continuously for over
16 hours. If there are signs of allergic
reactions or rash, immediately stop
using the device. Use the device
with caution).

English
6
How to mount the device
1. Attach two patches to
the bottom of the
product with the metal
snap buttons. Make
sure both patches are
securely connected to
the product.
2. Remove the protective
plastic lm from
both patches.
3. Mount the device on the
body as indicated in the
gure. Attach the device
to the skin over the
muscle on the side you
have most pain. For
most people
this is the dominant side
(Right for right-handers
and left for left-handers).
Place the product with
the USB connector
pointing downwards
towards the arm. If you

English
7
wish to measure
on both sides
simultaneously,
we recommend that you
use one extra device.
Let the device be on
your body for the
time period you
want biofeedback.
1
2
3

English
8
How to unmount your device
1. Loosen the unit from the
body by gently pulling
the patches up from the
skin. If the patches
have lost much of their
adhesive effect, they
can be washed in water
without soap. NB!
Remember to take
patches off the EXPAIN
Change Neck &
Shoulders device before
you wash. The unit
is not waterproof.
2. Recharge the unit
to ensure that
it is fully charged for the
next use.
Place the device
back in the travel case
after use for
safe storage.

English
9
Usage
EXPAIN Change Neck & Shoulders
is turned on by pressing the button
on top of the unit.
When using the device, it will vibrate
when it recognizes strained
muscle activity patterns. Read more
in the section of Biofeedback
and habits.
On/Off button

English
10
Usage with app
You can get more from the EXPAIN
Change Neck & Shoulders device if
you connect it to a smartphone.
The unit will then automatically
transfer data to your smartphone
when it is within reach and you can
follow the historical development in
your app. You can, for example do
ergonomic changes by looking at
your muscle activity.
1. EXPAIN Change Neck &
Shoulders are
connectable whenever
the device is turned on.
It is not possible
to connect the
device to multiple
phones simultaneously.
If you want to pair the device with
another phone, you must remove
the device in the settings in your

English
11
app / phone, and restore factory
settings if necessary, see the Battery
and charging section.
The EXPAIN app can be
downloaded from Apple
App Store or Google Play Store.
Follow the instructions in the app.
The app has a built in pain diary
that allows you to compare your
muscle activity patterns with
your pain. In this way
you can see when you’ve had the
most strained muscle activity and if
this has a relationship with
your pain. It is recommended to
register your pain regularly, and
to use the device at least for a few
days to get the most out of EXPAIN
Change Neck & Shoulders.

English
12
Light and vibration
The table below shows the meaning
of various lights and vibrations.
Function Light/Vibration
Connected
Bluetooth Smart
Blue ash
Low battery Red ash
On, without
Bluetooth
connection
Purple ash
Low battery Red ash
Fully charged Purple
Notice sustained
muscle activity
Short vibrations
Low battery Long vibrations

English
13
Function Light/Vibration
Connected
Bluetooth Smart
Blue ash
Low battery Red ash
On, without
Bluetooth
connection
Purple ash
Low battery Red ash
Fully charged Purple
Notice sustained
muscle activity
Short vibrations
Low battery Long vibrations
Biofeedback and habits
Habit change happens when
the device is used often and you
take breaks or do some exercises
every time the device vibrates.
Research shows that biofeedback,
which is a learning process, helps
to improve health and overall
performance by observing the
signals generated by one’s own
body.
The device will vibrate when
it recognizes strained
muscle activity patterns
(Sustained muscle activity). When
the device vibrates, try to take a
short break from the work, do some
shoulder exercises or
lower your shoulders so that the
muscles in neck / shoulder regions
relax. A good relaxation exercise is
to breathe calmly in with the nose
and then releasing the breath out of

English
14
your mouth while you
let your arms and shoulders hang
down by the side of the body.
Repeat this exercise 2-5 times.
Battery and charging
The device has a battery life of
approximately 8 hours of normal
use. The sensor ashes red to
indicate low battery. In addition, the
device vibrates Long
vibrations when the
battery is critically
low. EXPAIN Change
Neck & Shoulders is
charged with
supplied or
corresponding micro
USB cable. Unmount
the device from your
body and charge it completely
before next use.
The light is red during charging, and
purple when it is fully charged.

English
15
Restoring factory settings
If you can’t connect your phone the
device can be reset to its original
state. This is done as follows: Turn
the device on and set it to charge.
Press the button until the device
starts ashing red. When the device
lights red and vibrates, the factory
settings are restored.
Maintenance and Storage
Clean the device with a dry or
slightly damp cloth. The device
is best kept in the accompanying
travel case. Also carryyour extra
patches and USB charging cable in
this case so that you always have
them available.
Make sure the device does not get
wet. It is not recommended to use
the device in humid environments
or if you plan to do activities that will

English
16
cause sweating.
The patches can be worn out, but
are made to last at least 10 times
/ 10 hours of use. If the adhesive
effect is low, the patches can
be gently washed in water. NB!
Remember to remove the patches
from the device before washing,
otherwise the unit can be destroyed
by moisture penetration. NB! If
the desired adhesive effect is not
obtained by washing, the patches
are ready for replacement.
EXPAIN Change Neck & Shoulders
comes with three pairs of patches.
New patches can be purchased at
www.expain.com
The unit should be transported,
stored and operated in
temperatures between 10°C
and 40°C, at a relative humidity

English
17
between 30% and 85% and with an
atmospheric pressure between 500
and 1060 hPa.
Keep the device and patches
in their original packaging or
supplied travel case when not
in use.
Cover patches with the
protective lm when they are not
in use. If the device does not work
correctly, contact support at
www.expain.com

English
18
Technology Surface Electromyog-
raphy (sEMG)
Power LiPo rechargeable
battery
Bluetooth Bluetooth 4.2 Smart
Size (DxBxH) 32 mm x 60 mm x
13 mm
Weight 20 g
Safety IEC 62133
EN 60950
EMC EN 301 489-17
EN 300 328
EN 301 489-1
Safety RoHS, REACH
Primary Skin Irritation
Test
Made in Norway
Tehnical specications

Safety information
Applications
For Biofeedback against
strained (sustained) muscle activity
in the Upper
Trapezius muscle.
Safety precautions
Do not use this product if you
have very sensitive skin.
Warning!
Do not use the device on other
locations on the body other than
those specied in this manual.
Technology Surface Electromyog-
raphy (sEMG)
Power LiPo rechargeable
battery
Bluetooth Bluetooth 4.2 Smart
Size (DxBxH) 32 mm x 60 mm x
13 mm
Weight 20 g
Safety IEC 62133
EN 60950
EMC EN 301 489-17
EN 300 328
EN 301 489-1
Safety RoHS, REACH
Primary Skin Irritation
Test
Made in Norway

Expain AS
Karl Johans gate 13
0154 Oslo, Norway
www.expain.com
Support:
www.expain.com
[phone]
