Exsound Orca User manual

正面 95mm x 145mm
Safety Notice
Product Features
Continued exposure to high volumes of noise in headsets can cause long-term hearing
damage. Your ears will adapt to loud volume levels over time and damage your hearing
even if you don't feel any discomfort. Maintain the volume at an adequate level is
important while using the headset. The louder the sound is, the less time it takes
to affect your hearing. It is recommended that before putting the headset on, turn the
volume down completely, then slowly increase it to a moderate and comfortable level.
Warning
EXSOUND ORCA - USB Gaming Headset with Dolby technology
virtual 7.1 Channels Surrounding Sound
Over-the-ear design provides solid sound effect & clear positioning
with industrial fashionable design gives it a total gaming style
High-fidelity sound quality with crystal clear high&mid range and booming bass
Using Dolby DigitalPro Logic IIX, Dolby Headphone technolgies
to output virtual 7.1 channel surround sound
Built-in ENC (Environment Noise Cancellation) function for ultimate voice
communication experience
Adjust Different Combinations of EQs, Surround Sound, and Mic Volumes
with User Interface
Industrial fashionable design with mysteries green LED lights on each side
Detachable gaming microphone for easy storage
Comfortable design headset for long period of wearing
2
A. EXSOUND ORCA HeadsetA. EXSOUND ORCA Headset
B. EXSOUND ORCA Inline Controller
1
2
3
4
Note
Connect&Remove Microphone with
Headset by Aligning Two Line.
Secure the Microphone by
Rotating it 90 Degrees Counterclockwise
Hardware Diagram
4
1. High Quality and Soft Material Headband
2. Easy to Adjust to Fit in Head Shape
3. Detachable Mic with Indicator
4. Omni-direction Mic
B. EXSOUND ORCA Inline Controller
5. Volume Up
6. Mic On/Off
7. Mute
8. Volume Down
ORCA Manual Table Of Contents
Package Contents
1. One EXSOUND ORCA Headset
2. One EXSOUND ORCA Microphone
3. One Operation Manual
4. One Driver Disk
1
Package Contents
Safety Notice
Product Features
Hardware Diagram
ORCA Connects to PC / Laptop
ORCA User Interface
Important Information
1
2
2
3
5
5
7
Hardware Diagram
3
5
6
8
7

背面 95mm x 145mm
ORCA USER GUIDE
ORCA Connects to PC / Laptop
EXSOUND ORCA User Interface
5
TO ENJOY THE FULLEXSOUNDORCA EXPERIENCE,
PLEASEENSURE THEDRIVERTOBEINSTALLEDCOMPLETELY.
TO MAKESUREYOURORCA HEADSETWORKINGPROPERLY,
PLEASE CHECKYOURPCAUDIOSETTING AS BELOW:
1. Youcanusedriverdiskordownloadthedriver fromwww.goexsound.com
2. Pleaseconnect the USBconnector to an availableUSBportonyour PC or
Laptop.
3. Installthedriver.
4. Rebootyourcomputerafter the driverinstallationhascompleted
5. Poweron, thenyoucanenjoytheORCA
1. Go to Controlpanel>SoundsandAudioDevices>Audio > SoundPlayback >
Select“EXSOUNDORCA”.
2. Go to Controlpanel>SoundandAudioDevices > Audio > SoundRecording >
Select“EXSOUNDORCA”.
1. Bypass means original sound without any processing. Click it to have
original sound play. You can select different inputs and outputs: 2CH or 7.1CH
2. DH+PLIIX means the sound will be simulate to 7.1channel Surround Sound through
Dolby Headphone and Dolby Pro Logic II X technologies.
Click it to have 7.1 channel Surround Sound effect.
3. Click “ENC(Environment Noise Cancellation)” to activate the function to enhance
the voice quality when communicating. When the ENC is ON, the button will lights up
in blue. It will turn back to black when the function is turned off.
4. Customize your own Surround Sound by moving each speaker’s location
under virtual 7.1 mode.
5. EQ: There are many pre-set EQ to choose, such as Rock, Classic, Bass, Treble.. etc.
Choose one of your preference or create your own EQ!
EXSOUND ORCA User Interface
6
EXSOUND ORCA User Interface
All other trademarks are property of their respective owners.
Important Information
