Extralite The Post UL2 User manual

Read carefully instruction before installation
T h e P o s t UL2
Features
Material: Triple butted AL7075T6, Titanium.
Finishing: hard black, bronze anodized.
Graphics: laser etched
Clamp Adjustment: +18° / -6.5° **
Destination: X-Country or Road use only.
Upper Clamps
Lower Clamp
Titanium Bolts
Max 3.5 Nm
Pivot
Seatpost Tube
ontFr Rear
Rium r 0mWA NING:Min m inse t 9 m
WARNING: ini m i er m
M mu
nst90 m
Compatibilty
Clamps are designed to
accept standard 6.8-7mm
round rails.
Contact us to check
compatibilty in any other case.
Installation
1) Position saddle rails between
upper and lower clamps (be
careful for front and rear side).
2) Screw in front clamp bolt to
reach correct position (rear
bolt must be loose).
3) Tight rear bolt (Max torque
3.5 Nm).
Warning: overtightening bolts may damage clamps
and be very dangerous for your safety.
adjustment
To adjust saddle angle turn titanium bolts as follow:
(example: lowering saddle nose)
1) Unscrew rear bolt 1 turn
2) Screw in front bolt 1 turn
Repeat 1 & 2 until saddle has right angle.
Maximum torque: 3.5 Nm
Warnings
Seat post tube insertion have to reach and slightly pass
frame junction (horizontal tube and seatstay tubes).
We prudentially reccomend a minimum insert of 90mm
to prevent possible damages to the frame.
