SS1-CV
14
Balance Bar
Main Shaft
Top Main Blade
Bottom Main Blade
Searchlight
Camera
Rear Motor
Front Motor
Landing Gear
Tail Motor
Tail
Rear Tail Blade
SS1-CV Helicopter
Charge Wire
ON / OFF
INFRARED
REMOTE
SS1-CV
CAMERA / VIDEO
Fine-Tuning
Turn Left / Right
Left / Right
Forward / Backward Throttle
Video Shoot
Infrared Signal
Photo Shoot
Band Selector
ON / OFF
Power
Indicator Light
Up / Down
Hover
Throttle
Infrared Remote Control
Power Switch
Micro Memory Card
(other side)
Charging Socket
Main Blades
Tail Blade
Micro Memory Card
(inside camera)
Screwdriver
Photo / Video Download
USB cable
Parts Included
MEMORY
CARD
(1) Extreme indoor helicopter
(1) Infrared remote controller
(1) Set of extra blades
(1) Screwdriver
(1) 512 Micro memory card
(1) Photo / video download cable
also used for USB charging
(1) Warranty registration card
(1) Instruction manual
Safety instructions
Charging instructions
Flying instructions
Calibration control
Taking photos and videos
Battery installation
Part list
Manual contents
Packing list

For Parts, Service
and Exciting New Products ...
Check Out Our Website!
www.extremercbyrsi.com
Distributed and Serviced by: Extreme RC by RSI ... Ferndale, MI Tel: [phone] x 1 E: [email protected]
BATTERY INSTALLATION AND CHARGING INSTRUCTIONS
CAMERA INSTRUCTIONS
Battery
Installation
Use screwdriver to open the
controller battery cover
Insert six 1.5V “AA” Batteries
(not included)
Secure controller battery cover
with screw
1
2
AB
3
Charging
Instructions
Charge wire USB Charge wire
Camera Adjustment … Camera / Video Undercarriage Lights
Down Loading Pictures or Videos
Taking Photos
(1) Turn the helicopter switch “OFF” and the remote control switch “ON”
(2) Plug charge wire into the helicopter. Remote light starts out red, it turns green while charging,
but will turn back to red when the helicopter is fully charged. Full charge takes up to 60 minutes.
(3) Put R/C charge wire back into its storage compartment or
Unplug USB charge wire - put away for safe keeping
(4) Turn helicopter and remote control power switches to the “ON” positions.
Gently aim the camera lens as desired
Press the left
“shoulder” button.
undercarriage
indicator light will
show. Please refer
to Camera / Video
undercarriage
lights section (B).
Recording Video
Press the right “shoulder”
button. To stop recording,
push the button again.
undercarriage indicator
light will show. Please
refer to Camera / Video
undercarriage lights
section (B).
Connect the USB data transfer cable into the back of the helicopter camera. Plug the other end
into your computer’s USB port and follow the instructions on your computer screen.
AB
Camera Camera Video ON/OFF lights
2
Distributed and serviced by: Extreme RC by RSI, Ferndale, MI 48220 P:[phone] E: [email protected]
INFRARED
INFRARED
NOW YOU’RE READY TO STAR FLYING
Charge time: up to 60 minutes - Flight time: up to 7 minutes
Fresh alkaline batteries strongly recommended
SS1-CV
CAMERA / VIDEO
SS1-CV
CAMERA / VIDEO
One red light blink - photo taken
Solid red light - video is on
For Parts, Service
and Exciting New Products ...
Check Out Our Website!
www.extremercbyrsi.com
PHOTO VIDEO
For Parts, Service
and Exciting New Products ...
Check Out Our Website!
www.extremercbyrsi.com
Undercarriage photo / video indicator light

Distributed and Serviced by: Extreme RC by RSI ... Ferndale, MI Tel: [phone] x 1 E: [e-mail]
3
Distributed and serviced by: Extreme RC by RSI, Ferndale, MI 48220 P: [phone] E: [email protected]
INFRARED
REMOTE
SS1-CV
CAMERA / VIDEO
INFRARED
REMOTE
SS1-CV
CAMERA / VIDEO
INFRARED
REMOTE
SS1-CV
CAMERA / VIDEO
INFRARED
REMOTE
SS1-CV
CAMERA / VIDEO
INFRARED
REMOTE
SS1-CV
CAMERA / VIDEO
INFRARED
REMOTE
SS1-CV
CAMERA / VIDEO
SS1-CV
CAMERA / VIDEO
Calibration control knob
SS1-CV
CAMERA / VIDEO
Calibration control knob
Hover up and down
RELEASE SAFTY
Turn counter clockwise and clockwise
Forward Reverse
Note: Calibration trim control ... if the helicopter is turning excessively to the right or left,
or turning out of control, adjust the trim control knob using the instructions below.
If helicopter rotates counter-clockwise ... turn calibration control knob right until excessive turning stops.
If helicopter rotates clockwise ... turn calibration control knob left until excessive turning stops.
Learn how to hover (fly in place) first - once you’ve mastered
this operation, flying is easy. Once you can hover, try moving
up and down with the throttle stick (left). Move the throttle
stick gradually.
Push the right control throttle up - the nose of the helicopter
will point downward, the tail motor will activate, and the
helicopter will fly froward.
Pull right control throttle down - the nose of the helicopter
will point upward, the tail motor will activate, and the
helicopter will fly backward.
While hovering helicopter, push throttle stick left for
counter-clockwise turns or right for clockwise turns.
INFRARED
REMOTE
SS1-CV
CAMERA / VIDEO
A safty is built into the remote control. To release the safty
move the left throttle up down. Safety has been released.
YOU ARE NOW READY TO START FLYING!!
UP
DOWN
MIDDLE POSITION
SAFTY IS OFF

PARTS LIST: ALSO AVAILABLE AT WWW.EXTREMERCBYRSI.COM
SAFETY INSTRUCTIONS
4
Distributed and serviced by: Extreme RC by RSI, Ferndale, MI 48220 P: [phone] E: [email protected]
USE GOOD COMON SENSE WHEN FLYING!
#
1Head cover
#
2Main blades
#
3Tail blade
#
4
Fuselage housing with
bottom outer shaft
#
5Landing gear
#
6Balance bar
#
7
Tailpipe with motor,
fin and tail
#
8
Main inner shaft
with motor gears
#
9Li-poly battery
#
10
Side support metal
plates
#
11 Tail support bar
#
12 Blade connectors
#
13
Center outer shaft
support cover
#
14
Top shaft center
head cover
#
15 Top blade connector
#
20 Camera / video
#
16 Front motor
#
18
Bottom outer shaft
with blade connector
#
19
Circuit board with
ON / OFF switch
#
21 Photo / Video
download USB wire
#
22 Remote control
#
17 Rear motors
PARTS - SERVICE - REPAIRS
Toll Free: 888-221-8851 Tel: [phone] x 1
E-mail: [e-mail]
Website: www.extremercbyrsi.com
OPEN: Mon - Fri 9 AM to 6 PM ... Sat 10 AM to 3 PM (EST)
ENVIRONMENT FOR FLIGHT
Recommended flying area for indoor: 12’L x 12’W x 12’H (3.65 m L x 3.65 m W x 3.65 m H)
Avoid drafts, forced air, water, fans, heat and air conditioning vents.
Keep flying helicopters away from pets, young children, the elderly and the disabled.
WARNING
Do not place stickers, weight, or anything else on the helicopter. This may cause the helicopter to crash or malfunction.
Avoid flying the unit under low ceilings. Crashing into ceilings may cause damage to the helicopter.
To avoid injury, do not touch the blades or any other moving parts.
When not in use (especially for 30 days or more) remove ‘AA’ batteries from remote control unit -
batteries may leak and cause damage.
