eXtremeAir CPC9 User manual

Instructions for Safe Operation
After washing hands, place hands approximately 4 to 6 inches (100 to 150 mm) under hand dryer nozzle until dry.
The dryer is activated by an infrared sensor. The dryer operates as long as hands are below the nozzle. There is a
maximum 35 second running time with a safety override feature if hands are not removed.
The dryer incorporates a non‑self‑resetting thermal cut‑out that is reset by disconnection of the supply mains.
CPC models are equipped with Cold Plasma Clean®technology.
eXtremeAir High Speed Hand Dryer
Owner’s Manual
Instructions apply to the following models:
CPC9 GXT9 EXT7
CPC9‑M GXT9‑M EXT7‑M
CPC9‑BG GXT9‑BG EXT7‑BG
CPC9‑C GXT9‑C EXT7‑C
CPC9‑SS GXT9‑SS EXT7‑SS
User Maintenance Instructions
DO NOT spray water or cleaning solvents through dryer vents. DO NOT use abrasive, chlorinated, or highly
alkaline cleaners. DO NOT use oil based cleaners.
Cleaning should be preformed on a regular basis at least twice per year.
Clean cover with a mild soap or detergent and warm water, using a soft cloth or sponge.
It is not necessary to disconnect power for cleaning.
eXtremeAir®
MFD by AMERICAN DRYER, INC.
33067 INDUSTRIAL ROAD, LIVONIA, MI 48150, U.S.A.
Telephone (734) 421‑2400 • Fax (734) 421‑5580
americandryer.com • Email: [e-mail]
Revised October 2014

Installation Instructions
1. Remove cover by removing (2) tamper‑proof screws using security wrench supplied. Pull cover directly toward you.
IMPORTANT: Save Security Wrench.
2. Dryers should be placed at least 2 feet (61cm) apart and at least 12” (30cm) from washbasin. Do not install dryer
over washbasin. Dryers should be at least 18” (46cm) above any projection which may interfere with the operation
of the automatic sensor.
Hold the backplate to the wall at the suggested MAXIMUM mounting height. Measure from bottom edge of the
backplate to the floor (Figure 1).
3. Mark the locations of the four mounting holes and the conduit entrance location on the wall. (The conduit entrance
is the proper hole diameter for 1/2 inch (13mm) conduit.)
4. Fasten the backplate to the wall where previously marked. RECOMMENDATION:
Wood wall – No. 14 (M6) wood screws, 2‑3/4” (70mm) long
Cement or brick – 1/4” (M6) stud expansion bolts, 3” (76mm) long
Hollow wall – 1/4” (M6) toggle bolts, length depends on wall thickness
5. Run a single phase 120V or 230V 50/60Hz electrical service to the dryer location using either the in‑wall or bottom
surface 1/2”conduit entrance and connect to the lead wires as shown on the dryer schematic. The ground wire
must be connected to the dryer ground screw. IMPORTANT: All units must be supplied with 3 wire service.
Use No. 12 or 14 wire as required by local electrical rules. Unit must be installed with separate disconnect means
by a qualified licensed electrician.
CPC/GXT ‑ Connect each dryer to a dedicated 15 or 20 amp line.
EXT - Connect up to three dryers to one dedicated 20 amp line
Dryers located in shower rooms or other wet locations should be equipped with ground fault interrupter(s).
6. Adjusting Sound & Speed ‑ The dryer is shipped set at maximum speed. Using a small flat blade screwdriver,
CAREFULLY turn the SPEED pot COUNTERCLOCKWISE 3/4 TURN MAX. to REDUCE SOUND & SPEED.
CAREFULLY turn CLOCKWISE to INCREASE SOUND & SPEED. See Figure 2.
WARNING: Disconnect Power Before Servicing
WARNING: Installation Shall be Performed by a Qualified Licensed Electrician
Maximum Mtg Height
MEN 44" (1118mm)
WOMEN 42" (1067mm)
CHILDREN 32‑42" (813‑1067mm)
DISABLED 36" (914mm)
WARNING: Do NOT modify the product in ANY way
Modifications including cutting holes may cause damage to the unit and will VOID the warranty.
5-5/8
(143mm)
eXtremeAir Series Surface Mount
WARNING: For Indoor Use Only
Figure 1
Mounting Diagram
10 1
8
" 258mm Max.
93
8
" 238mm Max.
7
8
" 22mm
Conduit Entrance
83
16
" 208mm
9
16
" 15mm Max.
9
16
" 15mm Max.
815
16
" 228mm
11
2
" 38mm
15
16
" 24mm
Mounting Holes for
1/4" [M6] screws
Template is for all
American Dryer
EXTREMEAIR, ADVANTAGE
AND GLOBAL Series dryers
Outer perimeter
of ABS Cover
Revised 10/06/2014

7. Adjusting Sensitivity ‑ The sensor is adjusted at the factory to turn on when hands are 4‑6 inches away from the
bottom of the dryer. To INCREASE SENSITIVITY turn the pot CLOCKWISE up to 1/3 TURN MAX. To DECREASE
SENSITIVITY turn the pot COUNTERCLOCKWISE up to 1/3 TURN MAX. See Figure 3.
8. Carefully replace the cover using (2) tamper‑proof screws supplied. Apply a bead of caulk around edges of cover to
wall.
9. Notes ‑ The dryer incorporates a non‑self‑resetting thermal cut‑out that is reset by disconnection of the supply
mains.
Figure 2 - Adjusting sound & speed
The dryer is shipped set at maximum speed. Turn
counterclockwise to reduce sound and speed. 3/4
of a turn max.
Screwdriver
Quieter Faster
Figure 3 - Adjusting sensitivity
Place the screwdriver through the access hole as
shown to adjust sensitivity. Range is set at the
factory for 4 ‑ 6 inches (100‑150mm).
Screwdriver
+ Sensitivity
‑ Sensitivity
Figure 4 ‑ pArts List
ITEM PART NO. DESCRIPTION
1 GXT202 COVER, WHITE ABS*
2 GXT202‑M COVER, WHITE STEEL*
3 GXT202‑BG COVER, BLACK GRAPHITE STEEL*
4 GXT202‑C COVER, CHROME PLATED STEEL*
5 GXT202‑SS COVER, STAINLESS STEEL *
6 GXT212 NOZZLE ASS’Y
7 GXT216 MOTOR/BLOWER
8 GXT218 HEATING ELEMENT**
9 SM239 SMART SENSOR COMPLETE
10 GB232 SECURITY SCREWS & WRENCH
* Must specify complete model number
** CPC & GXT Only
7
8
9
6
10
1
2
3
4
5

Service Instructions
Each component used in your dryer has been designed to provide years of trouble‑free service. However, if trouble
should develop, it can normally be located by visual examination. Removal or replacement of most parts is simple and
can be done without special tools.
IF THE DRYER WON’T TURN ON:
Check electrical service, circuit breaker. Make sure proper voltage is being supplied to the dryer. Check for loose or
disconnected terminals to sensor. INCREASE sensitivity (Figure 3) by inserting a flat‑blade screwdriver through the hole
and into the pot to CAREFULLY turn the adjustment pot located on the sensor CLOCKWISE 1/3 turn MAX. If necessary,
replace sensor.
IF DRYER WILL NOT SHUT OFF:
Make certain black foam is attached to lens and lens is clean. If damaged, replace. DECREASE sensitivity (Figure 3) by
inserting a flat‑blade screwdriver through the hole and into the pot to CAREFULLY turn the adjustment pot located on
the sensor COUNTER‑CLOCKWISE, 1/3 turn MAX. If necessary, replace sensor.
CPC AND GXT ONLY - IF COLD AIR IS COMING FROM THE NOZZLE:
Turn off breaker for 30 seconds to reset thermostat. If necessary, inspect heating element by unfastening blower housing
from backplate (3 screws). Remove heating element from blower housing to inspect for damage. Replace if necessary.
IF NO AIR IS COMING FROM THE NOZZLE:
If the dryer also trips the circuit breaker, replace the motor/blower assembly by unfastening the blower housing from the
backplate (3 screws) and remove the inlet shield. Otherwise, replace the sensor.
COLD PLASMA GENERATOR:
The cold plasma generator is maintenance free. There are no chemicals to refill and no filters to change.
eXtremeAir LIMITED WARRANTY
All parts of the eXtremeAir models are warranted to the original consumer purchaser to be free from defects in
material workmanship for a period of five (5) years from the date of purchase from the manufacturer. All models
outside of the U.S.A. one (1) year. We will replace, during the warranty period, any warranted part which proves
defective in material and or workmanship under normal installation, use, and service, excluding normal wear.
Replacement parts can be obtained by returning the part, TRANSPORTATION CHARGES PREPAID. You must
notify factory prior to returning part or dryer. Any damage to this dryer as a result of misuse, abuse, neglect,
accident, improper installation, unauthorized repairs, or any other use violative of instructions furnished by us
WILL VOID THIS WARRANTY. THIS LIMITED WARRANTY IS THE SOLE WARRANTY ON OUR PRODUCTS, AND
WE DISCLAIM AND EXCLUDE ANY AND ALL OTHER WARRANTIED, EXPRESS OR IMPLIED, INCLUDING ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. OUR LIABILITY SHALL
NOT EXCEED IN ANY EVENT THE REPLACEMENT OR SALE PRICE OF THE ALLEGEDLY NONCONFORMING
PRODUCT AND SHALL EXCLUDE LABOR CHARGES. TO THE EXTENT PERMITTED BY LAW WE SHALL NOT BE
LIABLE FOR ANY LOSS, COST, EXPENSE, OR INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY KIND.
WHETHER BASED UPON WARRANTY (EXPRESS OR IMPLIED), CONTRACT, NEGLIGENCE OR STRICT LIABILITY
AND ARISING IN ANY WAY IN CONNECTION WITH THE DESIGN, MANUFACTURE, SALE, USE OR REPAIR OF
THE PRODUCT.
WARNING: Disconnect Power Before Servicing
WARNING: Installation Shall be Performed by a Qualified Licensed Electrician
