Extron electronics DMP 128 Plus User manual

12x8 ProDSP Digital Matrix Processor
DMP 128 Plus
User Guide
Mixers and Processors
68-2826-01, Rev. L
01 24

Safety Instructions
.
.
.
.
.
.
.
.

Copyright
© 2017-2024 Extron. All rights reserved. www.extron.com
Trademarks
All trademarks mentioned in this guide are the properties of their respective owners.
The following registered trademarks(®), registered service marks(SM), and trademarks(TM) are the property of RGBSystems, Inc. or Extron
(see the current list of trademarks on the Terms of Use page at www.extron.com):
Registered Trademarks (®)
Extron, Cable Cubby, ControlScript, CrossPoint, DTP, eBUS, EDID Manager, EDID Minder, eLink, Everlast, Flat Field, FlexOS, Glitch Free,
GlobalConfigurator, GlobalScripter, GlobalViewer, Hideaway, HyperLane, IPIntercom, IPLink, KeyMinder, LinkLicense, LockIt, MediaLink,
MediaPort, NAV, NetPA, PlenumVault, PoleVault, PowerCage, PURE3, Quantum, ShareLink, Show Me, SoundField, SpeedMount, SpeedSwitch,
StudioStation, SystemINTEGRATOR, TeamWork, TouchLink, V-Lock, VN-Matrix, VoiceLift, WallVault, WindoWall, XPA, XTP, XTPSystems, and
ZipClip
Registered Service Mark(SM) : S3 Service Support Solutions
Trademarks (™)
AAP, AFL (Accu-RATEFrameLock), ADSP(Advanced Digital Sync Processing), AVEdge, CableCover, CDRS(ClassD Ripple Suppression),
Codec Connect, DDSP(Digital Display Sync Processing), DMI (DynamicMotionInterpolation), DriverConfigurator, DSPConfigurator,
DSVP(Digital Sync Validation Processing), EQIP, FastBite, Flex55, FOX, FOXBOX, IP Intercom HelpDesk, MAAP, MicroDigital, Opti-Torque,
PendantConnect, ProDSP, QS-FPC(QuickSwitch Front Panel Controller), RoomAgent, Scope-Trigger, SIS, SimpleInstructionSet, Skew-Free,
SpeedNav, Triple-Action Switching, True4K, True8K, Vector™ 4K, WebShare, XTRA, and ZipCaddy


FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC rules. The Class A limits provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause interference. This interference must be corrected at the expense of the user.
ATTENTION:
• The Twisted Pair Extension technology works with unshielded twisted pair (UTP) or shielded
twisted pair (STP) cables; but to ensure FCC Class A and CE compliance, STP cables and STP
Connectors are required.
• La technologie extension paires torsadées fonctionne avec les câbles paires torsadées
blindées (UTP) ou non blindées (STP). Afin de s’assurer de la compatibilité entre FCC Classe A et
CE, les câbles STP et les connecteurs STP sont nécessaires.
NOTES:
• This unit was tested with shielded I/O cables on the peripheral devices. Shielded cables must be
used to ensure compliance with FCC emissions limits.
• For more information on safety guidelines, regulatory compliances, EMI/EMF compatibility,
accessibility, and related topics, see the Extron Safety and Regulatory Compliance Guide on the
Extron website.
Battery Notice
This product contains a battery. Do not open the unit to replace the battery. If the battery needs
replacing, return the entire unit to Extron (for the correct address, see the Extron Warranty section on the
last page of this guide).
CAUTION: Risk of explosion. Do not replace the battery with an incorrect type. Dispose of used batteries
according to the instructions.
ATTENTION : Risque d’explosion. Ne pas remplacer la pile par le mauvais type de pile. Débarrassez-
vous des piles usagées selon le mode d’emploi.

Conventions Used in this Guide
Notifications
The following notifications are used in this guide:
CAUTION: Risk of minor personal injury.
ATTENTION : Risque de blessure mineure.
ATTENTION:
• Risk of property damage.
• Risque de dommages matériels.
NOTE: A note draws attention to important information.
TIP: A tip provides a suggestion to make working with the application easier.
Software Commands
Commands are written in the fonts shown here:


E X!
*X1&*
X2)* X2#* X2!
}
NOTE: For commands and examples of computer or device responses used in this guide, the
character “” is used for the number zero and “O” is the capital letter “o.”
Computer responses and directory paths that do not have variables are written in the font shown here:


Variables are written in italics as shown here:
xxx.xxx.xxx.xxx 
DataCommand
Selectable items, such as menu names, menu options, buttons, tabs, and field names are written in the font
shown here:
From the  menu, select New.
Click the OK button.
Specifications Availability
Product specifications are available on the Extron website, www.extron.com.
Extron Glossary of Terms
A glossary of terms is available at http://www.extron.com/technology/glossary.aspx.

ivDMP 128 Plus • Contents
Contents
Introduction................................................................... 1
About this Guide..................................................... 1
DMP 128 Plus Models............................................ 1
About the DMP 128 Plus ........................................ 1
Features ................................................................. 2
Application Diagram ............................................... 3
Installation..................................................................... 4
Installation Overview ............................................. 4
Rear Panel Features .............................................. 4
Front Panel Features.............................................. 8
Connection Details ................................................ 9
TP Cable Termination for Ethernet
Communication ................................................. 9
Reset Modes .......................................................... 9
DSP Configurator Software ....................................... 11
Software Installation .............................................11
Connecting to DSP Congurator .......................... 13
Accessing the DSP Congurator Help File........... 13
DSP Congurator Main Workspace...................... 13
Menu Bar.............................................................. 14
File .................................................................... 14
Edit .................................................................... 14
View .................................................................. 14
Tools ..................................................................... 15
Window ............................................................. 16
Help................................................................... 16
Run Macros Drop-Down.................................... 16
Presets Drop-Down List .................................... 16
DSP Congurator Status Panel......................... 16
Live and Emulate Panel .................................... 16
Dante Controller ......................................................... 19
Overview............................................................... 19
Downloading and Installing Dante Controller ....... 19
Conguring the DMP 128 Plus AT in Dante
Controller............................................................. 19
Device Name..................................................... 20
Receiver and Transmitter Names...................... 20
Dante Controller Naming Conventions.............. 20
Renaming the DMP 128 Plus AT in Dante
Controller ......................................................... 21
Renaming a Receiver or Transmitter ................ 22
Finding a Dante Device IP Address .................. 24
Physical Dante Network Setup............................. 24
Redundant Conguration .................................. 25
Dante Controller Operation .................................. 26
Dante Transmitters and Receivers.................... 26
Dante Routing Operation .................................. 26
Routing Devices ................................................ 26
Disconnecting Inputs from Outputs ................... 27
Sending SIS Commands to Dante Audio
Interface Devices through the DMP................. 28
AES67 Mode ........................................................ 29
Dante Troubleshooting ......................................... 29
Simplifying the Network for Troubleshooting..... 29
Troubleshooting the Network Interface ............. 30
Restarting Dante Controller............................... 30

DMP 128 Plus • Contents v
SIS Configuration and Control.................................. 31
Host Control Ports ............................................... 31
Rear Panel RS-232 Port .................................. 31
Front Panel Conguration USB Port ................. 31
Ethernet (LAN) Port .......................................... 31
Establishing a Connection................................. 32
Verbose Modes ................................................. 32
Simple Instruction Set Control ............................. 33
Host-to-Unit Instructions ................................... 33
Device-Initiated Power-Up Message................. 33
Password Prompt ............................................. 33
Using the Command and Response Table ....... 34
Error Responses ............................................... 34
Simple Control Port Commands........................ 34
Special Characters............................................ 34
Symbol Denitions ........................................... 35
Command and Response Table for SIS
Commands .......................................................... 41
Command and Response Table for DSP SIS
Commands .......................................................... 51
Command and Response Table for VoIP SIS
Commands .......................................................... 56
Object ID (OID) Number Tables............................ 58
Input Path OIDs................................................. 58
Output Path OIDs.............................................. 60
Automixer OIDs................................................. 61
Mix-point OIDs .................................................. 62
Internal Web Pages ................................................... 70
Accessing the Embedded Web Pages ................. 70
DMP 128 Plus Default Web Page ....................... 71
Communication Settings .................................. 71
RS-232 Settings ............................................... 72
Device Info ........................................................ 72
Passwords......................................................... 73
Date/Time Settings............................................ 73
DMP 128 Plus VoIP Web Page ............................ 74
Home Tab.......................................................... 74
Network Tab ...................................................... 75
Line Tabs........................................................... 81
Logs Tab............................................................ 83
System Tab ....................................................... 83
Equipment Mounting.................................................. 86
Mounting the DMP 128 Plus................................. 86
Tabletop Use ..................................................... 86
Mounting Kits ................................................... 86

DMP 128 Plus • Introduction 1
Introduction
This section gives an overview of the DMP 128 Plus and its features. Topics include:
• About this Guide
• DMP 128 Plus Models
• About the DMP 128 Plus
• Features
• Application Diagram
About this Guide
This user guide contains installation, configuration, and operating information for the Extron DMP 128 Plus
ProDSP Digital Audio Matrix Processor.
NOTE: Throughout this guide, the general terms “DMP 128 Plus," “mixer,” or "device" are used interchangably
to refer to the DMP 128 Plus.
DMP 128 Plus Models
Model Description
DMP 128 Plus 12x8 ProDSP Processor
DMP 128 Plus C 12x8 ProDSP Processor with Acoustic Echo Cancellation (AEC)
DMP 128 Plus C V 12x8 ProDSP Processor with AEC and VoIP
DMP 128 Plus AT 12x8 ProDSP Processor with Dante
DMP 128 Plus C AT 12x8 ProDSP Processor with AEC and Dante
DMP 128 Plus C V AT 12x8 ProDSP Processor with AEC, VoIP and Dante
About the DMP 128 Plus
The Extron DMP 128 Plus Digital Audio Matrix Processor is a 12x8 audio mixer with broad I/O expansion
capabilities including:
• 8 auxiliary inputs via VoIP (V models only), USB, and internal audio files.
• 16 x16 expansion bus
• Dante 48x24 AT channels (AT models only)
• VoIP (V models only)
• Digital I/O
The DMP 128 Plus features Extron ProDSP, automixing, AEC (Acoustic Echo Cancellation), and USB audio for
use as an audio-to-PC interface. The DMP 128 Plus offers a configuration approach to DSP to simplify mixing,
routing, conferencing, and room optimization. Quick and intuitive configuration using the Extron DSP Configurator
software allows the DMP 128 Plus to be installed in very little time with easy-to-learn adjustments that can be
applied in real-time.
A digital audio expansion port (EXP) allows two EXP-capable devices to be linked together to expand input and
output signal management and routing capabilities. The DMP 128 Plus is ideal for presentation and conferencing
applications in boardrooms, courtrooms, and conference centers requiring advanced matrix mixing and DSP.

DMP 128 Plus • Introduction 2
In addition to EXP expansion capabilities, DMP 128 Plus AT models allow connection to a Dante audio network for
transporting audio across a TCP/IP network. This further increases the DMP 128 Plus input and output expansion
capabilities.
DMP 128 Plus V models can register up to 8 VoIP lines per device. The DMP 128 Plus V can function as a VoIP
interface, removing the need for dedicated VoIP hardware.
The DMP 128 Plus has no front panel controls. All configuration is performed using the Extron DSP Configurator
software from a host computer via Ethernet (recommended) or USB. The rear panel RS-232 port allows for serial
control via SIS commands. Signal presence and clip LEDs for the twelve input channels and eight output
channels are on the front panel. Status indicators for EXP, LAN, and USB audio are also on the front panel.
Features
• 12 mic/line inputs — on 3.5 mm 3-pole and 6-pole captive screw connectors.
• 8 line level outputs — on 3.5 mm 6-pole connectors.
• Extensive 52x48 internal mix matrix —A single DMP 128 Plus can be used as the central audio processor
for a sizeable system.
• USB audio interface — The DMP 128 Plus provides up to 4 channels of digital audio sends and returns for
simplifying implementation of systems with soft-codec conferencing or computer based audio.
• Twelve channels of AEC - acoustic echo cancellation C models only — The four DMP 128 Plus C models
include twelve independent channels of high performance AEC, as well as selectable noise cancellation.
Extron AEC features advanced algorithms that deliver fast echo canceler convergence for optimal intelligibility
in situations that challenge AEC performance, including double-talk, and the use of wireless microphones at
the near end.
• VoIP capability supporting Session Initiation Protocol (V models only) — A single DMP 128 Plus V
model can be used for a single VoIP line or as a VoIP farm for up to 8 rooms.
• AT models include 48x24 Dante™ digital audio network expansion — 48 Dante inputs (Rx) and 24 Dante
outputs (Tx) via a 4-port gigabit switch allow flexibility in building large audio DSP systems with multiple DMP,
AXP, and AXI units.
• Remote port for ACP control panels — For audio systems that do not need a full control system, Extron
Audio Control Panels (ACP) offer flexible audio control, interfaced directly with the DMP 128 Plus.
• Macros — Command sequences can be sent to the local device and external devices via the LAN port. This
allows a single DMP 128 Plus to act as the central interface from a control system, sending commands to
other DMP 128 Plus and DTP CrossPoint units.
• 8 Aux I/O ports — Configurable digital audio connectivity allows these ports to be configured as VoIP audio
(V models only), USB communications audio, USB playback audio, or audio file players.
• Advanced audio processing on all 8 analog outputs and all 16 direct EXP outputs — Up to 24 speaker
zones can be implemented on one DMP 128 Plus with full processing for each zone.
• 8 audio file players — Up to 8 audio file players can be used to play back audio files for system setup or as
part of the system design. Pink noise, white noise, and sine waves are included with the device. Any WAV,
AIFF, or MP3 files up to 24-bit 48 kHz can be uploaded.
• 16 virtual processing loops – Virtual loops allows great flexibility in sub-mixing and processing.
• Lower latency — Newer, faster, and more powerful DSP chips mean maximum performance resulting in a
lower latency of 16 ms when fully loaded.
• Adaptive gain — A new adaptive gain processor that allows a given microphone input to affect levels on any
one or all other inputs and virtual returns, ensuring background music and paging are the right volume,
whether the room is quiet or noisy.

DMP 128 Plus • Introduction 3
Application Diagram
100-240V 0.7A MAX
50 - 60 Hz
DMP 128 Plus C V
INPUTS
RxTx G
RS-232
21
+S+V -S G
GIN
1
O1O2 GIN
2
O1O2 GIN
3
O1O2 GIN
4
O1O2 GIN
5
O1O2 GIN
6
O1O2 GIN
7
O1O2 GIN
8
O1O2
56 78 11 12
12 34
910
1 2 3 4 5 6 7 8
I/O
OUTPUTS
DMP EXP
ACP
REMOTE
USB AUDIORESET
LAN/VoIP
•
P
H
U
S
•
•
P
H
U
S
•
•
P
H
U
S
•
•
P
H
U
S
•
•
P
H
U
S
•
•
P
H
U
S
•
•
P
H
U
S
•
•
P
H
U
S
•
Help System
Off
Display
Room
Control
Off
Mute
Screen
Lighting
December15, 2013 - 7:58 AM
Audio
Control
Volume
Mute
Tuner
12 3
VCRLaptopPC DVD Doc
Cam
Tuner
On
Channel
Last
Presets
More
Presets
321
654
987
Enter
0
CONFIG
DTP CROSSPOINT 4K SERIES
DIGITAL PRESENTATION SWITCHER
CONTROL I/O
AUDIO
VIDEO
LOGO
SELECT ENTERPRESET VIEW ESC
1234
123 4
5678MIC VOLUMEVOLUME
INPUTS
OUTPUTS
eBUS
COM
112
12 2334
12
34
IR/S I/ORELAYS
SLIMIT
OVER
RTS
CTS
Tx
Rx
HDCP
SIGNAL
AUTO
SWITCH
DTP T USW 233
CONFIG
1
STATUS
23 123
MODE NORMAL AUTO
WiFi 1234
Extron
DMP 128 Plus C V
Digital Matrix Processor
Extron
SF 26CT
Full-Range Ceiling Speakers
Conference Table Credenza
Audio
Audio
VoIP
LAN
Extron
DTP CrossPoint 82 4K IPCP MA
Scaling Presentation Matrix Switcher
Table
Microphones
Camera
PC
Flat Panel Display
Ethernet
Ethernet
Ethernet
USB Audio
USB Video
HDMI
DMP EXP
Audio
Extron
TLP Pro 1020T
10" Tabletop
TouchLink Pro
Touchpanel
Extron
DTP T USW 233
Transmitter
Laptop
Ethernet
Cat 5/5e/6/7
HDMI
HDMI
LAN
Ethernet
LAN
Figure 1. Typical Application of the DMP 128 Plus
1

DMP 128 Plus • Installation 4
Installation
This section describes the installation of the DMP 128 Plus, including:
• Installation Overview
• Rear Panel Features
• Front Panel Features
• Connection Details
• Reset Modes
Installation Overview
Follow these steps to install and set up the DMP 128 Plus for operation:
1. Disconnect power from the DMP, and turn off all devices connected to the DMP.
2. If desired, mount the DMP (see Equipment Mounting on page 86).
3. Connect the cables, and configure the DMP (see “Rear Panel Features” starting below).
4. Plug in the power supply and all connected devices.
Rear Panel Features
100-240V 0.7A MAX
50 - 60 Hz
DMP 128 Plus C V AT
INPUTS
RxTx G
RS-232
+S+V -S G
GIN
1
O1 O2 GIN
2
O1 O2 GIN
3
O1 O2 GIN
4
O1 O2 GIN
5
O1 O2 GIN
6
O1 O2 GIN
7
O1 O2 GIN
8
O1 O2
56 78
11 12
1234
910
12 3 4 5 6 7 8
I/O
OUTPUTS
DMP EXP
ACP
REMOTE
USB AUDIORESET
AT
1(SEC) 234
(PRI)
LAN/VoIP
1
2
A B C D E F G HJ K
I
APower input DLine output GRS-232 port JUSB Audio port
BDigital I/O ports EEXP port HLAN ports KReset button and LED
CMic/Line inputs FACP port IAT ports (AT models only)
Figure 2. Rear Panel Features
APower input — Plug a standard IEC power cord into this connector to connect the unit to a 100 VAC to
240 VAC, 50-60 Hz power source.
BDigital port — Connect up to eight 4-pole 3.5 mm captive screw connectors (see figure 3 for wiring details).
These configurable digital input and output ports are designed to connect to microphones with logic circuitry
for mic mute and tally back functionality. Each port provides a common ground (see Configure Digital I/O on
page 15 or the DSP Configurator Help File for configuration details).
The Digital Input and Output ports function by reacting to either HIGH
or LOW logic based on applied voltages.
6-pole Captive Screw
Connector
12
GIN OGIN O
4-pole Captive Screw
Connector
G
IN
O1
O2
Figure 3. Digital I/O Connector
2
3

DMP 128 Plus • Installation 5
Digital Input —
• If the input voltage is lower than 0.8 V, it is considered logic "LOW."
• If the input voltage is lower than 0.8 V, it is considered logic "LOW."
• If the input voltage is greater than 3.0 V, it is logic "HIGH."
• The maximum input voltage is 12.0 VDC.
Digital Output —
• The output port has an internal pull up to 5 V.
• The output "LOW" is less than 0.7 V.
• The output "HIGH" is greater than 3.5 V.
The maximum output voltage is 5.0 VDC.
CMic/Line inputs (see figure 2 on page 4) — On inputs 1 through 8, use the included 3-pole 3.5 mm captive
screw connectors to connect eight mono balanced or unbalanced microphone or line level sources (see
figure 4 for wiring details). For all models, Inputs 1 through 8 provide phantom power. For C models, Inputs 1
through 12 provide AEC.
On inputs 9 through 12, use 3-pole or 6-pole 3.5 mm captive screw connectors to connect up to four mono
balanced or unbalanced microphone or line level sources, or two stereo sources (see figure 4 and figure 5 for
wiring details).
"
(5 mm) MAX.
3
16
3-pole Audio INPUT Wiring
Balanced Input
Sleeve
Ring
Tip Tip
Sleeve
Jumper
Unbalanced Input
Figure 4. Audio Input Wiring
Tip
Sleeve
Ring
Tip
Sleeve
Ring
Tip
Sleeve
Tip
Sleeve
6-pole Audio INPUT Wiring
Balanced Input Unbalanced Input
Jumper
Jumper
Figure 5. Audio Output Wiring
ATTENTION:
• Condenser microphones require phantom power.
• Les microphones électrostatiques nécessitent une alimentation fantôme.
• Dynamic microphones do not need power.
• Les microphones dynamiques n’ont pas besoin d’alimentation.
• When a line level source is connected, be certain the +48 V phantom power is off (cleared).
• Lorsqu’une source de niveau ligne est connectée, soyez certain que l’alimentation fantôme +48 V
est débranchée (enlevée).
Mic/Line inputs
4
5

DMP 128 Plus • Installation 6
DLine output (see figure 2 on page 4) — Use 3-pole or 6-pole 3.5 mm captive screw connectors to connect
up to four mono balanced or unbalanced line level devices or two stereo devices (see figure 6 for wiring
details).
Tip
Sleeve
Tip
Sleeve
Tip
Sleeve
Ring
Tip
Sleeve
Ring
6-pole Audio OUTPUT Wiring
Balanced Output Unbalanced Output
NO Ground Here
NO Ground Here
3-pole Audio OUTPUT Wiring
Unbalanced Output
Tip
Sleeve
NO Ground Here
Balanced Output
Tip
Sleeve
Ring
Figure 6. 6-pole Audio Output Wiring
ATTENTION:
• For unbalanced audio, connect the sleeves to the ground contact. DO NOT connect the sleeves to
the negative (–) contacts.
• Pour l’audio asymétrique, connectez les manchons au contact au sol. Ne PAS connecter les
manchons aux contacts négatifs (–).
EEXP port — Connect an EXP-enabled device to this RJ-45 port for a digital audio connection using Extron
proprietary protocol.
NOTE: A one foot shielded CAT 6 cable is provided for the EXP connection. The maximum EXP cable
length supported is 33 feet (10 meters).
FACP port — Use a 4-pole 3.5 mm captive screw connector to connect an ACP control device for configuration
(see figure 7 for wiring details and Configure ACP Panels on page 15 or the DSP Configurator Help File for
details on configuring the ACP).
NOTES:
• The DMP 128 Plus rear-panel ACP port provides 6 W of power.
• Use an Extron PS 1220EB power supply or Extron 12 V desktop power supply when additional
power is required.
• Refer to the applicable Audio Control Panel (ACP) setup guide, available at www.extron.com, for
wiring details.
G
- S
+S
+V
Ground
+Signal
- Signal
+12 VDC
Black
and
Drains
Green
White
Red
G
-
S+S
+V
Drain Wires
Basic ACP Connector Wiring
Figure 7. ACP Port Connector Wiring
GRS-232 port — For bidirectional RS-232 (±5 V) serial control of the DMP, connect a host device, such as a
computer or control system, via the 3-pole 3.5mm captive screw port. The default baud rate is 38400.
RS-232
Tx Rx G
REMOTE
Transmit
Receive
Ground
Tx
Rx
G
Figure 8. RS-232 Wiring
Line output
6
EXP port
ACP port
7
RS-232 port
8

DMP 128 Plus • Installation 7
HLAN ports (see figure 2 on page 4) — One RJ-45 port (non-V models) or two RJ-45 ports (V models) are
available for control network traffic (all models) and VolP network traffic (V models only) (see TP Cable
Termination for Ethernet Communication on page 9 for wiring details). The host PC or control system and
the DMP 128 Plus must be connected to the same network. The ports have two LEDs:
• Link LED — Lights green steadily to indicate a LAN connection.
• Signal LED — Blinks amber to indicate LAN signal activity.
NOTE: Only the DMP 128 Plus V-models have two LAN/VoIP ports. Non-V-models only have one LAN
port.
LAN 1 defaults:
IP Address Subnet Mask Gateway DHCP
   
LAN 2 (V models only) defaults:
IP Address Subnet Mask Gateway DHCP
   
There are three ways the dual LAN ports can be configured on DMP 128 Plus V-models:
1. Control and VoIP traffic on one LAN port — Both control and VoIP traffic can be transported via a
single LAN port.
NOTE: By default, control and VoIP traffic are both transported on LAN 1.
2. Control and VoIP traffic on one LAN port using a VLAN — Both control and VoIP traffic can be
transported via a single physical LAN port while utilizing a VLAN for VoIP traffic.
3. Control and VoIP traffic on separate LAN ports — Control and VoIP traffic can be transported on
separate LAN ports with unique IP configurations.
The IP addresses can be configured via the internal web page (see Communication Settings on page 71) or
Toolbelt (see Software Installation on page 11 for details on downloading Toolbelt and the Toolbelt Help File
for device configuration).
IAT ports (AT models only) — Four RJ-45 ports form a Gigabit switch that interfaces with the AT bus. The AT
expansion bus uses Dante®protocol for digital audio networking and allows DMP 128 Plus AT models to
connect with other Dante-enabled devices to form a larger matrix (see Dante Controller on page 19 for
details on the software required to configure the AT extension bus).
The 4-port switch can be configured as two 2-port switches for redundant Dante configuration. In redundant
configuration, audio traffic is duplicated. Port 3 and 4 are primary switch (PRI), and Port 1 and 2 are the
secondary switch (SEC) (see Redundant Configuration on page 25 for details on redundant mode).
NOTE: Connecting an external power supply is not necessary when using PoE+ for power.
JUSB Audio port — Connect a Windows or Mac computer to this USB mini-B port to interface with the DMP
128 Plus as a USB audio device (see Configure USB Audio on page 15 or the DSP Configurator Help File
details on configuring the USB audio). Audio sample rate is 48 kHz/16-bit.
KReset button and LED — Initiates three levels of resets. Use a pointed stylus, ballpoint pen, or small
screwdriver to access the recessed button (see Reset Modes on page 10 for details on the different reset
modes). When not displaying reset functions, the LED operates as a power indicator and matches the front
panel power LED.
LAN ports
AT ports (AT models only)
USB Audio port
Reset button and LED

DMP 128 Plus • Installation 8
Front Panel Features
DIGITAL MATRIX PROCESSOR
CONFIG
CLIP
EXP LAN USB SIGNAL
CLIP
SIGNAL
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 89 10 11 12
ACTIVITY
INPUTS OUTPUTS
DMP 128 Plus
B C D E F GA
100-240V 0.7A MAX
50 - 60 Hz LAN
DMP 128 Plus C
INPUTS
RxTx G
RS-232
+S+V -S G
GIN
1
O1 O2 GIN
2
O1 O2 GIN
3
O1 O2 GIN
4
O1 O2 GIN
5
O1 O2 GIN
6
O1 O2 GIN
7
O1 O2 GIN
8
O1 O2
56 78 11 12
12 34
910
1 2 3 4 5 6 7 8
I/O
OUTPUTS
DMP EXP
ACP
REMOTE
USB AUDIORESET
A B C D E F G H I J
Figure 9. DMP 128 Plus Front Panel
APower LED — Blinks during boot up and lights steadily when the DMP 128 Plus is operational.
BUSB Config port — One USB type mini-B port is used for configuration. This port can also be used for
firmware updates.
CEXP Activity indicator LEDs — These green activity LEDs behave differently depending on the model of
DMP 128 Plus:
• Non-AT Models
• Off — The unit is not connected to a second EXP device.
• On — The unit is connected to a second EXP device and is configured as the primary unit.
• Blinking — The unit is connected to a second EXP device and is configured as the secondary unit.
• AT Models
• On — The unit is connected to a second EXP non-AT device and is configured as the primary unit.
• Blinking — The unit is not connected to a second device.
DLAN Activity Indicator LED — Blinks to indicate rear panel LAN port activity.
EUSB Activity Indicator LED — Blinks to indicate audio streaming over USB.
FInput indicator LEDs — Stacked green and red LEDs display input signal presence and input signal clipping.
The green signal presence LED varies in brightness, corresponding to the real-time input signal level. It lights
at -60 dBFS and increases in brightness until signal level reaches -3 dBFS. When the signal reaches or
exceeds -3 dBFS, the red clip LED lights. The clip LED remains lit for 200 ms after removing the clip
condition.
GOutput indicator LEDs — Stacked red and green LEDs display output signal presence and output signal
clipping.
Output indicator LEDs function identically to the input indicator LEDs (F).
9

DMP 128 Plus • Installation 9
Connection Details
TP Cable Termination for Ethernet Communication
It is vital that your Ethernet cable be the correct cable type and that it be properly terminated with the correct
pinout. Ethernet links use Category (CAT) 3, 5e, or CAT 6, unshielded twisted pair (UTP) or shielded twisted pair
(STP) cables, terminated with RJ-45 connectors. Ethernet cables are limited to a length of 328 feet (100 meters).
The cable can be terminated as either a patch cable or a crossover cable (see figure 10) and must be properly
terminated for the application:
• Patch (straight-through) cable — Connection of the device to an Ethernet hub, router, or switch that also
hosts a controlling computer.
• Crossover cable — Direct connection between the processor and a controlling computer
12345678
RJ-45
Connector
Insert T
wisted
Pair Wires
Pins:
A cable that is wired as TIA/EIA T568A at one
end and T568B at the other (Tx and Rx pairs
reversed) is a "crossover" cable.
A cable wired the same at both ends is called
a "straight-through" cable because no pin/pair
assignments are swapped.
T568B T568A T568B T568B
Straight-through Cable
(for connection to a switch, hub, or router)
End 1 End 2
Pin Wire Color Pin Wire Color
1 white-orange 1 white-orange
2 orange 2 orange
3 white-green 3 white-green
4 blue 4 blue
5 white-blue 5 white-blue
6 green 6 green
7 white-brown 7 white-brown
8 brown 8 brown
Crossover Cable
(for direct connection to a PC)
End 1 End 2
Pin Wire Color Pin Wire Color
1 white-orange 1 white-green
2 orange 2 green
3 white-green 3 white-orange
4 blue 4 blue
5 white-blue 5 white-blue
6 green 6 orange
7 white-brown 7 white-brown
8 brown 8 brown
Figure 10. RJ-45 Pin Assignment for Ethernet Connection
Reset Modes
The rear panel Reset button initiates three levels of resets. Use a pointed stylus, ballpoint pen, or small
screwdriver to access the recessed button.
See the Reset Modes on page 10 for a summary of the reset.
ATTENTION:
• Review the reset modes carefully. Some reset modes delete all user loaded content and revert the
device to default configuration.
• Analysez minutieusement les différents modes de réinitialisation. Certains modes de réinitialisation
suppriment l’intégralité du contenu chargé de l’utilisateur et remettent l’appareil au mode de
configuration par défaut.
NOTE: The reset modes listed in the Reset Modes table close all IP connections, Telnet connections, and
sockets.
10

DMP 128 Plus • Installation 10
Reset Modes
Activation Result Purpose and Notes
Use Factory Firmware
Hold in the recessed rear
panel Reset button while
applying power to the unit.
The device reverts to the factory default firmware for a
single power cycle.
Use this mode to revert to the
factory default firmware for a
single power cycle if
incompatibility issues arise
with user-loaded firmware. All
user files and settings are
maintained.
NOTE: Do not operate with the default firmware loaded by this reset. Use it only to load the most current
firmware to the device.
*Reset Network Settings
Hold in the Reset button
until reset LEDs blink
twice (once at 3 seconds,
again at 6 seconds). Then,
release and press the
Reset button again within
1 second*.
Sets the following back to factory default:
• Digital I/O port mapping.
• IP address for LAN 1 ().
• IP address for LAN 2 ()
• Subnet mask address for LAN 1 and LAN 2
(V-models only) = ().
• Gateway IP address for LAN 1 and LAN 2
(V-models only) = ().
Enable ARP capability.
Turns off DHCP for LAN 1 and LAN 2 (V-models only)
Use this mode to reset all IP
settings back to factory
defaults.
*Full Factory Reset
Hold in the Reset button
until reset LEDs blink
three times (once at
3 seconds, again at
6 seconds, again at
9 seconds). Then, release
and press the Reset
button again within
1 second*.
Performs a complete reset to factory defaults (except
the firmware).
• Includes the factory defaults from the Reset All IP
Settings reset.
• Mix-points are set to unity gain (0 dB) and the
following connections are made:
• Input 1 is routed to output 1.
• Input 2 is routed to output 2.
• Input 3 is routed to output 3.
• Input 4 is routed to output 4.
• Input 5 is routed to output 5.
• Input 6 is routed to output 6.
• Input 7 is routed to output 7.
• Input 8 is routed to output 8.
• All audio inputs are set to unity gain.
• All outputs are unmuted and set to unity again.
• Any inserted or active DSP removed.
• All preset and group master memory is cleared.
Use this mode to start over
with default configuration and
uploading, and also to
replace events.
NOTE: *For these modes, nothing happens for if the momentary press does not occur within 1 second.
Reset Modes

DMP 128 Plus • DSP Congurator Software 11
DSP Configurator Software
Extron DSP Configurator Software is the main user interface for control and management of the Extron
DMP 128 Plus and all of its audio functions, including mixing, gain, dynamics, filtering, delay, microphone ducking,
and monitoring. This section describes the Extron DSP Configurator software and covers the following topics:
• Software Installation
• Accessing the DSP Configurator Help File
• DSP Configurator Main Workspace
• Menu Bar
Software Installation
Visit www.extron.com to download and install the DSP software.
NOTES:
• Download the latest versions of software and firmware for your product.
• An Extron Insider account is required to download and use the firmware or software.
1. Mouse over the Download tab (see figure 11, 1) at the top of the page.
Figure 11. Software Links on Download Screen
2. Click the appropriate link on the drop-down list. The  page opens.
For software, either click the Software link (2) or, if the software is listed, click directly on that link (see the
DSP Configurator Software link 3) and skip to step 5.
NOTE: If there is no direct link to your software, click the Software link (2).
For firmware, click the Firmware link (4).
3. Scroll down to the alphabetic navigation bar (see figure 12).
Figure 12. Alphabetic Navigation Bar
4. Click the appropriate letter to locate the software or firmware.
11
12

DMP 128 Plus • DSP Congurator Software 12
5. Click Download (see figure 13 and figure 14, 1). The  page of the selected software/
firmware opens and an executable () file is downloaded to the PC. Make a note of the folder where the
software/firmware file was saved.
NOTE: (Optional) Click Release Notes (2) for more information about the software/firmware update.
Figure 13. DSP Configurator Software
For firmware:
NOTE: Firmware will only be listed if your device has a firmware update.
Figure 14. DMP Plus Firmware
6. Install the software.
a. Navigate to the folder where the software file was downloaded.
b. Double-click the executable file and follow the on-screen directions to install the software.
For firmware:
a. To install via internal web page, see To update firmware on page 72.
b. To install via Toolbelt, see the Toolbelt Help File.
c. To install via Firmware Loader, see the Firmware Loader Help File.
NOTE: Firmware Loader can also be open from DSP Configurator in the  menu, if installed (see
Firmware Loader on page 15.
step 5
13
14

DMP 128 Plus • DSP Congurator Software 13
Connecting to DSP Configurator
1. Open the DSP Configurator Software program from the desktop shortcut.
Alternatively, to run DSP Configurator from the default install
location, click
Start> Programs> Extron> DSP Configurator.exe
The Extron  splash screen opens (see
figure 15).
2. From the   splash screen drop-down list
(1), select the DMP 128 Plus being connected to the host
PC and click OK (2).
Figure 15. DSP Configurator
Accessing the DSP Configurator Help File
DSP Configurator comes loaded with a context-sensitive help file that can be accessed by clicking the help icon
( ) in the top right corner of any dialog box in DSP Configurator.
Alternatively, click Help > Contents in the menu bar at the top of the main workspace, or press <F1> on your
keyboard. This help file contains detailed procedures and further instruction on all DSP Configurator features.
DSP Configurator Main Workspace
NOTE: For details about specific software features and device configurations, refer to the DSP Configurator
Help File.
The DSP Configurator main workspace contains various functions to configure the DMP 128 Plus (see figure 16).
Use the expand and collapse buttons ( ) next to the input and output group names to show or hide input and
output groups and their corresponding mix matrices. If necessary, scroll through the window by using the mouse
wheel or the scroll bar at the right side of the DSP Configurator main workspace.
Figure 16. DMP 128 Plus DSP Configurator Main Workspace
15
16
