SDI-AVR 100 – SDI TO A NALOG V IDEO C ONVERTER
Accepts 4:2:2 SDI in
NTSC and PAL standards
10 bit processing
Auto-detects input format
and de-serializes 270 Mbps
Auto input equalization
Re-clocked SDI input
loop-through
Simultaneous composite
and S-video outputs,
third output available as
component video or RGB
RGB or Betacam output
NTSC or PAL color
bar test pattern
Rack mountable enclosure
Internal power supply

The Extron SDI-AVR 100 is a 10 bit Serial Digital Interface (SDI) to analog video
signal converter. The SDI-AVR 100 is ideal for A/V systems that use a mix of
analog and SDI sources and helps integrate SDI sources into an analog video
environment. Example applications include presentations utilizing disk recorders,
broadcast production, non-linear editing stations, and rental and staging events.
The SDI-AVR 100 accepts a 4:2:2 (270 mbs), ITU-R BT 601 input and provides
equalization for the input and a re-clocked loop-through. It outputs analog
composite and S-video (available simultaneously) and also allows the user to select
between component, RGsB, RGBS, or RGBHV for the third output. The SDI-
AVR 100 outputs NTSC, PAL, or Betacam component levels and includes an
internal color bar generator.
■Accepts 4:2:2 SDI in NTSC and PAL (525/60 and 625/50) standards
■10 bit processing
■Auto-detects input format and de-serializes 270 Mbps digital stream
■Auto equalization provided for input
■One re-clocked SDI loop-through
■Outputs composite video and S-video (Y/C) simultaneously, third output
available as component video (Y, R-Y, B-Y) or RGB (RGsB, RGBS, or RGBHV)
■RGB or Betacam output, switch-selectable
■NTSC or PAL color bar test pattern
■1/2rack width, 1U high metal enclosure
■100-240VAC, 50/60 Hz, auto-switchable, internal power supply
Video
Differential phase error............................ <1º
Differential gain error.............................. <1%
Video input and loop through
Number/signal type ................................ 1 SDI (4:2:2, SMPTE 259M-C)
Connectors .............................................. 1 female BNC (SDI input)
1 female BNC (SDI reclocked loop
through)
NOTE: The equalization applied to the SDI-AVR 100’s looped through signal is
sufficient for a coaxial cable length of at least 1,000 feet (305 meters) of Extron
SHR cable or Belden 8281 cable.
Minimum/maximum level(s) .................. 0.5V to 1.0V p-p with no offset
Impedance .............................................. 75 ohms
Return loss ............................................ >-15dB @ 0 MHz to 270 MHz
Maximum DC offset .............................. ±0.5V
Video processing
Encoder .................................................. 10 bit digital
Frequency response.................................. Luminance 0 to 5.75 MHz, ±0.5dB
Chroma .................................................. 0 to 2.75 MHz, ±0.5dB
S/N.......................................................... >70dB
RGB matrix error .................................... <1%
Video signal characteristics
Dot clock ................................................ 27 MHz
Pixel clock accuracy ................................ 30 ppm
Video output
Number/signal type ................................ 1 composite video and 1 S-video, and
1 analog RGBHV/RGBS/RGsB or
component video (R-Y, B-Y, Y)
(switch selectable)
DESCRIPTION SPECIFICATIONS (Cont.)
FEATURES
SPECIFICATIONS
Extron Electronics, USA
1230 South Lewis Street, Anaheim, CA 92805
800.633.9876 714.491.1500 FAX [phone]
USA
Extron Electronics, Europe
Beeldschermweg 6C, 3821 AH Amersfoort
+31.33.453.4040 FAX [phone]
The Netherlands
Extron Electronics, Asia
135 Joo Seng Rd. #04-01, PM Industrial Bldg.
+65.383.4400 FAX [phone]
Singapore 368363
Extron Electronics Information
ExtronWEB™: www.extron.com
ExtronFAX™: 714.491.0192
24-hour access—worldwide!
01-05
68-592-01
REV. A
SOG
RGB/YUV
SETUP
BETA
COLORBARS
NTSC/PAL
100-240V50/60Hz0.2A
SDIINPUTOUTPUTS
IN
OUT
COMPOSITE
OUTPUT
S-VIDEO
OUTPUT
R/R-Y G/Y B/B-Y
HVS
ON
OFF
SDI-AVR 100
Betacam Recorder
SDI Camera
Monitor
Monitor
Large Screen
Rear Projector
Connectors .............................................. 1 female BNC (composite video)
1 female 4-pin mini DIN (S-video)
6 female BNC (RGB, component
video, or S-video)
Level(s).................................................... Composite video 1V p-p (nominal)
S-video 1V p-p/luma, 0.9V
p-p/chroma (max.)
RGB: 0.7V (nominal)
Component video
Y = 1V p-p; R-Y, B-Y = 1V p-p
(max.)
Levels depend on the format selected
(NTSC, PAL, Betacam).
Impedance .............................................. 75 ohms
Return loss ............................................ -30dB @ 5 MHz
Sync
Output type ............................................ RGBHV, RGBS, RGsB
Standards ................................................ NTSC 3.58, PAL 4.43, Betacam
Output impedance .................................. 75 ohms
Max. rise/fall time.................................... 200 nS
Polarity .................................................... Negative
General
Power ...................................................... 100VAC to 240VAC, 50/60 Hz,
6 watts, internal, auto-switchable
Temperature/humidity ............................ Storage -40°to +158°F (-40°to
+70°C) / 10% to 90%,
non-condensing
Operating +32°to +122°F (0°to
+50°C) / 10% to 90%,
non-condensing
Rack mount ............................................ Yes, with optional rack shelf,
part #60-190-01
Enclosure type ........................................ Metal
Enclosure dimensions .............................. 1.75" H x 8.75" W x 8.0" D
(1 rack unit high, 1/2 rack unit wide)
4.5 cm H x 22.2 cm W x 20.3 cm D
(Depth excludes connectors.)
Shipping weight ...................................... 5 lbs (2.3 kg)
Vibration ................................................ ISTA/NSTA 1A in carton
(International Safe Transit Association)
Approvals ................................................ UL, CUL, CE
MTBF .................................................... 30,000 hours
Warranty ................................................ 2 years parts and labor
Part Number
SDI-AVR 100.......................................... 60-400-01
Copyright © 2001 Extron Electronics. All rights reserved. All trademarks mentioned are the property of their respective owners.
APPLICATION DIAGRAM
