Extron electronics VLP 102 User manual

This guide provides instructions for an experienced installer to set up, install, and
connect the Extron®VLP 102 Pendant Microphone or VLH 102 Handheld Microphone,
the VLC 202 Charging Station, the VLR 102 Receiver, and the VLR 102SR Secondary Receiver.
Setting Up the VLP 102 and VLH 102 Microphones
1. Set the channel using the rotary switch. Aand C= 2.3 MHz; Band D= 2.8 MHz. For the VLH 102, remove the battery
cover to access this switch.
NOTE: Each microphone must be on a different frequency. On the pendant microphone, set the channel to Cor D
to disable the volume buttons (the handheld microphone has only channels A and B).
2. (Pendant microphone only) Apply the appropriate sticker to identify the microphone.
3. Remove the battery cover and insert the AA battery. If necessary, replace the battery cover and charge the battery.
4. (Pendant microphone only) Attach the lanyard to the rotating clip. Adjust the lanyard to position the microphone
approximately 4 inches (10.2 cm) below the chin of the user.
5. Turn the microphone on by sliding the power switch up.
6. Speak in a normal tone of voice. Do not block the microphone port or grille opening.
7. Adjust the volume if necessary. On the VLH 102, replace the battery cover.
Installing the VLC 202 Charging Station
To install the VLC 202 Charging Station:
1. Plug the wall charger (5 V, 1 A) into a wall outlet.
2. Connect the wall charger cable to the charging station
power jack.
3. Place the microphone in one of the slots in the charger,
with the charging contacts facing down.
The charge is complete when the LED turns green. (This
can take up to 5 hours.)
NOTE: The microphone can be left to charge for
extended periods. In maintenance mode,
the charge is retained when complete.
CAUTION: Do not charge alkaline batteries.
Top
1
4
6
2
Power
Indicator
LED
Power
Indicator
LED
AB
VOLUME
VLH 102 Handheld Microphone
AB
3
5
7
6
1
23
1Pwr LED
Pendant or
Handheld
Microphone
5
73
VLP 102 Pendant Microphone
1
Get other manuals https://www.bkmanuals.com

Extron USA - West
Headquarters
+800.633.9876
Inside USA/Canada Only
+1.714.491.1500
+1.714.491.1517 FAX
Extron USA - East
+800.633.9876
Inside USA/Canada Only
+1.919.863.1794
+1.919.863.1797 FAX
Extron Europe
+800.3987.6673
Inside Europe Only
+31.33.453.4040
+31.33.453.4050 FAX
Extron Asia
+800.7339.8766
Inside Asia Only
+65.6383.4400
+65.6383.4664 FAX
Extron Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Extron China
+400.883.1568
Inside China Only
+86.21.3760.1568
+86.21.3760.1566 FAX
Extron Middle East
+971.4.2991800
+971.4.2991880 FAX
©2011 Extron Electronics All rights reserved. www.extron.com
Installing the VLR 102 Receiver and the VLR 102SR Secondary Receiver
To install the VLR 102 IR Receiver or the VLR 102SR Secondary Receiver in a drop ceiling:
1. In the ceiling tile, cut a hole 2 to 3 inches (50 to 76 m) in
diameter.
2. Align the center of the receiver housing with the hole in
the ceiling tile.
3. Insert the mounting screw through the receiver housing
and the hole in the ceiling tile.
4. Attach the provided Z-bracket to the end of the screw on
the back side of the ceiling tile. Replace the ceiling tile.
5. Pull an Ethernet cable to the receiver location, and connect
one end of the cable to the RJ-45 jack (labeled OUT) on the
receiver base.
6. Align the arrow on the dome tab with the raised arrow on
the edge of the housing. Rotate the dome clockwise until
the arrow on the tab aligns with the raised dot on the
housing.
7. Connect the other end of the Ethernet cable to the
PoleVault switcher.
8. If you are connecting a VLR 102SR secondary
receiver:
Connect an Ethernet cable to the RJ-45 jack labeled OUT
on the secondary receiver and to the RJ-45 jack labeled IN
on the VLR 102 Receiver.
4
2
3
1
5
7
6
PoleVault Switcher
VLR 102SR
Out OutIn
VLR 102
LR
LR
LR
AUX AUDIO
INPUT 5
LINE OUT
VOICELIFT
RECEIVER
PAGING
SENSOR
DO NOT
GROUND
OR SHORT
SPEAKER
OUTPUTS
1B RGB
1A RGB
2B RGB
2A RGB
3B RGB
/VIDEO
4B RGB
/VIDEO
3A RGB4A RGB
I
N
P
U
T
S
RS-232 MLC/IR
2/4/8
Ohms
CLASS 2 WIRING
AMPLIFIED AUDIO OUT
VOL/MUTE
Tx Rx IR 12V
10V50mA
POWER
US
LISTED
17TT
AUDIO/VIDEO
APPARATUS
®
RGB VIDEO
OUTPUTS
CONTROL
N15779
12V
5A MAX
2A RGB
1A RGB
1B RGB 2B RGB
4A RGB
3A RGB
3B RGB
3 VIDEO
4B RGB
4 VIDEO
5
8
7
2
68-1631-01 Rev. B
