Extron electronics VoiceLift VLP 202 User instructions

This guide provides instructions for an experienced installer to set up, install, and
connect the Extron VLP 202 VoiceLift Compact Pendant Microphone or VLH 102 VoiceLift
Handheld Microphone, the VLC 202 Charging Station and the VLR 102 Receiver in a system
with a PVS 405D PoleVault Digital Switcher.
Setting Up the VLP 202 and VLH 102 Microphones
1. Set the channel using the rotary switch. Aand C= 2.3 MHz; Band D= 2.8 MHz. For the VLH 102, remove the battery cover
to access this switch.
NOTE: Each microphone must be on a different frequency. On the pendant microphone, set the channel to Cor Dto
disable the volume buttons (the handheld microphone has only channels A and B).
2. For pendant microphones only, apply the appropriate sticker (provided) to identify the
microphone.
3. Remove the battery cover and insert a AA battery. If necessary, replace the battery cover and
charge the rechargeable battery (see “Installing the VLC 202 Charging Station,” below).
4. For pendant microphones only, attach the lanyard lock to the lanyard, then press the top of the
microphone clip to raise it. Slide the lanyard lock under the clip and release the clip (see the
illustration at right). Place the lanyard around your neck and slide the lanyard through the lock
until the microphone is positioned approximately 4 inches (10.2 cm) below your chin.
5. Turn the microphone on by sliding the power switch up.
6. Speak in a normal tone of voice. Do not block the microphone port or grille opening.
7. Adjust the volume if necessary.
8. Ensure that a direct line of sight exists from the microphone to the receiver (required for proper
operation). Do not block the microphone IR transmitter window.
Installing the VLC 202 Charging
Station
To install the VLC 202 Charging Station:
1. Plug the wall charger (5 V, 1 A) into a wall outlet.
2. Connect the wall charger cable to the charging station
power jack.
3. Place the microphone in one of the slots in the
charger. The charge is complete when the microphone
LED turns green (this can take up to 5 hours).
NOTE: The microphone can be left to charge
for extended periods. It should be turned
off while charging.
4
Clip
Lock
23
1
Pwr LED
OFF/MUTE
ON
Top
Power
Indicator
LED 6
1
2
4
ABC
D
Rear
3
5
7
VLP 202 Pendant Microphone
8
8
Power
Indicator
LED
ABVOLUME
VLH 102 Handheld Microphone
AB
3
5
7
6
1
8
1

Extron Headquarters
+800.633.9876 Inside USA/Canada Only
Extron USA - West Extron USA - East
+1.714.491.1500 +1.919.850.1000
+1.714.491.1517 FAX [phone] FAX
Extron Europe
+800.3987.6673
Inside Europe Only
+31.33.453.4040
+31.33.453.4050 FAX
Extron Asia
+65.6383.4400
+65.6383.4664 FAX
Extron Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Extron China
+86.21.3760.1568
+86.21.3760.1566 FAX
Extron Middle East
+971.4.299.1800
+971.4.299.1880 FAX
Extron Korea
+82.2.3444.1571
+82.2.3444.1575 FAX
Extron India
1800.3070.3777
(Inside India Only)
+91.80.3055.3777
+91.80.3055.3737 FAX
© 2014 Extron Electronics All rights reserved. All trademarks mentioned are the property of their respective owners. www.extron.com
CAUTION: Risk of explosion. Do not replace the battery with an incorrect type.
ATTENTION:
• Do not charge alkaline batteries.
• Dispose of used batteries according to the instructions provided on the battery packaging.
Installing the VLR 102 Receiver
To install the VLR 102 IR Receiver in a drop ceiling:
1. In the ceiling tile, cut a hole 2 to 3 inches (50 to 76 mm) in
diameter.
2. If necessary, separate the receiver housing from the base (see
the VoiceLift Microphone System User Guide, available at
www.extron.com).
3. Align the center of the receiver housing with the hole in the
ceiling tile.
4. Insert the mounting screw through the receiver housing and
the hole in the ceiling tile.
5. Attach the provided Z-bracket to the end of the screw on the
back side of the ceiling tile. Replace the ceiling tile.
6. Pull a shielded CAT5 cable to the receiver location, and
connect one end of the cable to the RJ-45 jack (labeled OUT)
on the receiver base.
7. Align the arrow on the dome tab with the raised arrow on the
edge of the housing. Rotate the dome clockwise until the
arrow on the tab aligns with the raised dot on the housing.
8. Connect the other end of the shielded CAT5 cable to the
PoleVault switcher.
5
4
1
6
7
Base
Housin
g
3
2
2
LR
DO NOT
GROUND
OR SHORT
SPEAKER
OUTPUTS
4/8
Ω
3A MAX
POWER
12V
HDMI
1/2
SIGLINKSIG LINK
3/4
INPUTS OUTPUT AUDIO OUT PVS 405D AMPLIFIED AUDIO OUT
PAGING
SENSOR
PVT IN PVT IN
LR
AUX OVER PVT REMOTE
VOICELIFT
LAN 1LAN 2LAN 3
INPUT 5
+V
LR
RS-232
Tx Rx
IR
SG G
PoleVault Switcher
Out
VLR 102
6
8
2
68-2548-50 Rev. A
02 14
