Specifications — MLC 206 Series
Control/remote — controller
Serial control port ........................ RS-232, 9-pin female D connector
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Serial control pin configurations 2 = TX, 3 = RX, 5 = GND
Slave switcher control port ........ (1) 3.5 mm direct insertion captive screw connector, 4 pole
Program control ........................... Extron’s control/configuration program for Windows®
Extron’s Simple Instruction Set (SIS™)
Control — room relays
Number/type ............................... 3 momentary or latching (configurable via control software)
Connectors .................................... (1) 3.5 mm direct insertion captive screw connector, 6 pole
Contact rating............................... 24 V, 1 A
Control — projector/source
Display/source control port (IR) (1) 3.5 mm direct insertion captive screw connector, 5 pole
Display/source control port (RS-232) (1) 3.5 mm direct insertion captive screw connector, 5 pole
IR learning frequencies ............... 30 kHz to 62 kHz
IR learning distance..................... 4" (10 cm) to 14" (36 cm) from the MLC’s faceplate
General
Power............................................. Supplied by an optional MediaLink Switcher (MLS) or the included external power
supply
External power supply ............... 100 VAC to 240 VAC, 50/60 Hz, external, autoswitchable; to 12 VDC, 1 A,
regulated
Power input requirements ......... 12 VDC, 0.38 A
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Rack mount................................... Yes, with optional MLM-RAAP rack mounting kit; also furniture or wall-
mountable
Enclosure type.............................. Metal
Enclosure dimensions
MLC 206 faceplate ........... 4.5" H x 6.4" W x 0.1" D (11.4 cm H x 16.3 cm W x 0.3 cm D) (3 gang)
MLC 206 L faceplate........ 3.2" H x 6.5" W x 0.1" D (8.1 cm H x 16.5 cm W x 0.3 cm D)
MLC 206 EC faceplate ..... 3.2" H x 6.3" W x 0.1" D (8.1 cm H x 16.0 cm W x 0.3 cm D)
MLC 206 AAP EC faceplate 3.2" H x 9.8" W x 0.1" D (8.1 cm H x 24.9 cm W x 0.3 cm D)
MLC 206 AAP faceplate . 4.5" H x 10.1” W x 0.1" D (11.4 cm H x 25.7 cm W x 0.3 cm D) (5 gang)
Controller (all models) .... 2.75" H x 5.25" W x 1.2" D (fits in a 3 gang box)
(7.0 cm H x 13.3 cm W x 3.1 cm D)
(Depth excludes connectors and knobs. Allow at least 1.75" depth within the wall
or furniture.)
Product weight
MLC 206 ............................ 1.7 lbs (0.8 kg)
MLC 206 L, MLC 206 EC 0.7 lbs (0.3 kg)
MLC 206 AAP EC ............ 0.7 lbs (0.3 kg)
MLC 206 AAP .................. 0.8 lbs (0.4 kg)
Shipping weight (all models)..... 6 lbs (3 kg)
Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
(7.51-020305-D5)
