Extron electronics PVT RGB D Plus User manual

Installation
1. Using the mud ring or a junction box as a guide, mark the edges and cut out
the material within the marked area.
NOTE: If installing a junction box, allow enough depth for the wallplate and
cables. The box should be at least 2.0 inches (5.1 cm) deep for the
connectors and cables.
2. Either:
Insert the mud ring into the opening, rotate the locking arms, and secure
with the supplied screws,
Or, Insert the wall box and secure with nails or screws.
3. Run the CAT 5 cables from the PoleVault switcher location, going behind the
wall and to the PVT location, then thread the cables through the mud ring or
wall box.
NOTE: Two cables (A and B) are needed for RGB signals.
NOTE: The CAT 5 cables supplied are terminated to the TIA 568A standard.
Other CAT 5 cables can be used if they are TIA 568A or TIA 568B
standards and terminated to the same standard at both ends.
4. Connect the cables to connectors on the rear of the wallplate (cable labeled
A to port A, cable B to port B).
5. If available, connect the switcher line out port to the rear panel 3-pole captive
screw connector, using a line out audio cable: L = left (tip), R = right (ring),
G = ground (sleeve). See inset, step 5.
6. Connect an IR cable from the MediaLink® Controller to the rear panel IR connector
by inserting the signal wire into the hole marked “S” and the ground wire into
the hole marked “G” (see inset, step 6).
7. If the display refresh rate and resolution is known, set the EDID Minder
5-pole DIP switches according to the EDID table (see reverse side for details).
Alternatively, if the EDID Minder is used in the learn mode, set all the DIP switches to off.
8. Mount the device into the mud ring or wall box and attach the supplied Decora faceplate.
9. Connect a source device to “Computer In” and a local display device to “Monitor Out.”
10. Connect the IR emitter to the front panel 2-pole captive screw connector with the signal
wire in the hole marked “S” and the ground wire in the hole marked “G.”
Place the IR emitter near or in front of the IR pickup sensor on the device.
11. To complete system installation refer to the PoleVault System Installation Guide,
available at www.extron.com.
The Extron® PVT RGB D Plus with EDID is a 1-gang A/V wallplate for
PoleVault™ Systems that transmits high-resolution computer video and
audio signals to the PoleVault switcher. This model incorporates
EDID Minder®, which allows the transmitter to communicate the appropriate
EDID information to the source, ensuring correct video output resolution.
See reverse side for EDID Minder operation.
NOTE: The 5-pole EDID Minder settings switch is located on the rear of the wallplate. After
installation, these switch settings are only accessible by removing the device from its installed
location. The factory EDID setting (default) is 1024x768@60 Hz (preset 2).
Continued on side 2.
COMPUTER IN
AUDIO
IN OUT
MONITOR OUT
IR OUT
S G
COMPUTER IN
AUDIO
MONITOR OUT
IR OUT
S G
IN OUT
Decora®
Faceplate
Extron
PVT RGB D Plus (EDID)
Wall
Wall Mounting
Bracket (mud ring)
RGB output cables
5
Pin
1
2
3
6
7
8
4
Wire Color
White-green
Green
White-orange
White-blue
Orange
White-brown
Brown
568A
Blue
Wire Color
568B
White-green
Green
White-orange
White-blue
Orange
White-brown
Brown
Blue
12345678
RJ-45
Connector
Insert Twisted
Pair Wires
Pins:
IR OUT
S G
GL
R
Step 5
Step 6
Step 10
PVT RGB D Plus (EDID) • Setup Guide
11

EDID Minder
The EDID Minder has two modes; a preset mode and a learn mode.
Preset mode allows selection of pre-programed EDID rates, as shown in the table below.
Learn mode enables the displays specific EDID information to be recorded and emulated
by the input wallplate.
To use the EDID Minder mode in preset or learn Mode, follow the instructions below.
Using Preset mode
1. If already installed, disconnect any sources and displays from the front panel and
remove the wallplate from the wall.
2. On the rear panel, set DIP switch 1 to the 50 or 60 kHz setting as desired.
Set DIP switches 2 to 5 accordingly, to match the desired EDID rate (see table below).
3. Connect the video source to the “Computer In” VGA connector and a local display
device to the “Monitor Out” port.
4. Restart the video source and display devices. Verify the image, making any
changes to the EDID settings as needed.
5. When the image is correct, re-install the wallplate. Re-connect and restart the source and display devices.
Preset
Number
Switch setting Resolution
2345
0 Off Off Off Off Learn mode
1 Off Off Off On 800 x 600
2 Off Off On Off 1024 x 768 (default)
3 Off Off On On 1280 x720
4 Off On Off Off 1280 x 768
5 Off On Off On 1280 x 800
6 Off On On Off 1280 x 1024
7 Off On On On 1360 x 768
8 On Off Off Off 1366 x 768
9 On Off Off On 1400 x 1050
A On Off On Off 1440 x 900
B On Off On On 1600 x 1200
C On On Off Off 1680 x 1050
D On On Off On 1920 x 1080
E On On On Off 1920 x 1200
F On On On On N/A
Using Learn mode
1. Disconnect any sources from the front panel and remove the wallplate from the wall.
2. On the rear panel, set all the DIP switches to off (down).
3. Temporarily connect the main display device (the projector) to the “Monitor Out” port.
4. On the front panel, the learn LED is lit solid green. Press and release the Learn button.
5. The LED flashes red when in learn mode, then returns to solid green when complete.
6. Re-install the wallplate and reconnect the source device.
Connect a local display device to the “Monitor Out” port as needed.
7. Reconnect the projector to the PoleVault switcher. Restart the source and display devices.
Extron USA - West
Headquarters
+800.633.9876
Inside USA / Canada Only
+1.714.491.1500
+1.714.491.1517 FAX
Extron USA - East
+800.633.9876
Inside USA / Canada Only
+1.919.863.1794
+1.919.863.1797 FAX
Extron Europe
+800.3987.6673
Inside Europe Only
+31.33.453.4040
+31.33.453.4050 FAX
Extron Asia
+800.7339.8766
Inside Asia Only
+65.6383.4400
+65.6383.4664 FAX
Extron Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Extron China
+400.883.1568
Inside China Only
+86.21.3760.1568
+86.21.3760.1566 FAX
Extron Middle East
+971.4.2991800
+971.4.2991880 FAX
68-1823-50
Rev B
10 10
©2010 Extron Electronics. All rights reserved - www.extron.com
COMPUTER IN
AUDIO
IN OUT
MONITOR OUT
IR OUT
S G
EDID Learn
Status LED
EDID Learn
Button
EDID
Selection
60
Hz
50
1 2 3 4
ON
5
NOTE This setting is for 1024x768@60 Hz,
preset 2 (factory default)
2
PVT RGB D Plus (EDID) • Setup Guide, cont’d
