eyecloud.ai eyecloudCam User manual

eyecloudCam
User Manual
Hello! Thank you for purchasing eyecloudCam.
III. Place and Mount eyecloudCam
1. Ways to Place your eyecloudCam
2. Recommended Surfaces
3. How Not to Use your eyecloudCam
4. Adjust the Monitoring Range
II. Set-Up eyecloudCam
1. Charge your eyecloudCam
2. Get the App
3. Sync the Device with the App
4. Detection Modes
5. Share with Family
I. eyecloudCam General Information
1. What’s Inside
2. Camera Information
3. Battery Level
4. LED Status
Contents
1
V19.02.19

2
I. eyecloudCam General Information
1. What's Inside
A B C
D E
A. 1 x eyecloudCam
B. 1 x magnetic mount
C. 2 x stickers
D. 1 x type-C USB cable
E. 3 x mounting screws
2. Camera Information
Rectangle magnetic area
Function button/Indicator blue light
Lens
Speaker
Charging Port
Microphone

3. Battery Level
3.1 eyecloudCam App
3.2 Device
Check the battery level via: App -> Camera -> Settings -> Camera Info -> Battery Level
Check the Camera Battery Level by pressing the function button ( ) once.
Low Battery (30%-16%)
LED is off when you press the
button.
The following functions are
blocked:
Pairing
OTA
Wifi Reconfiguration
Unbind
100%-81%
all functions supported
80%-61%
all functions supported
60%-31%
all functions supported
30%-16%
ota update not allowed
15%
Not allowed:
- live streaming;
- ota update;
- playback.
30%-16%
PAIRED
Low Battery (30%-16%)
LED blinks for 3 seconds when
you press the button.
The following functions are
blocked:
Pairing
OTA
Wifi Reconfiguration
Unbind
30%-16%
NOT PAIRED
<
3

Low battery ( 15%)
LED is off when you press the
button.
The following functions are
blocked:
Saving a Notification
Live streaming
Capture Region
Pairing
OTA
Wifi Reconfiguration
Unbind
15%
Normal
LED is off
PAIRED NOT PAIRED
<Low battery ( 15%)
LED blinks for 3 seconds when
you press the button.
The following functions are
blocked:
Saving a Notification
Live streaming
Capture Region
Pairing
OTA
Wifi Reconfiguration
Unbind
Normal
LED is off
<
4
<15%
<

4. LED Status
When being
charged
Off
When in Stand-by
Mode or Hibernate
Mode
Off
When pairing the
camera to the App
Hold the button for
5-8 seconds. When the
blue light blinks once,
the camera is ready to
pair.
When triggered
by an event
One blink
When upgrading
Continuous
blinking
When low on battery
and PAIRED
LED is off even when
you press the button.
5
3s
When low on battery
and NOT PAIRED
Press the button, the
blue light blinks for
3 seconds.

II. Set-Up eyecloudCam
1. Charge your eyecloudCam
1. Get the camera out of the box.
2. Get the USB Cable from the package
3. Open the rubber cover of the Data Interface on the Camera Body.
4. Use the USB cable to charge the battery.
2A
21 34
>
4.75V5.25V
V
< <
Around 6 hours Fully charged
Charging Time
Voltage:
Current:
INSTALL
eyecloudCam
1
2
E-mail Address
E-mail Code
Type Password
Register
Hi
Welcome to your
smart home
3
E-mail Address
Password
E-mail Code
Sign In
Hi
Welcome to your
smart home
2. Get the App
1. Download the app via App Store or
Google Play
2. Register with your email address
3. Log in
6
1 2 3
Or direct download
on your smartphone

1
Devices
Wi-
Password
Next
2
45
3
Camera Configuration
6
Connect
1.
A. When adding your first device:
Click “Start”.
B. When adding new devices:
Click the ‘’+Add new camera” field.
2. Enter your wi-fi network name and
password.
3. Click “Next”.
4. Hold the function button on the front of
the camera ( ) for 5-8 seconds and then
release it to wake on the device from
stand-by mode.
5. After hearing “Please scan the QR code on
your App using your eyecloudCam”, press
“Next” on the App.
6. Here's your QR code
7. Scan QR code in a recommended 1-1.3 feet
distance.
* Suggested distance
between camera and QR code:
1 ~ 1.3 feet
*5-8 seconds
7
Connect
Next
3. Sync the Device with
the App
Hi John,
Let’s get started!
Wi-
Password
Next
Start
Type in Wi-fi and Password
Connect
Next
7
Please scan the QR
Code on your App using
your eyecloudCam.
Next
Devices
A B
+ Add new camera

8. After hearing “QR code successfully
scanned”, press ‘Next’ on the App to config-
ure your device
9. Wait for a few seconds to connect.
9
Camera Configuration
1. On your app, click the “Settings” button
underneath the camera placeholder.
2. Click the “Alerts Settings” button. Here
you’ll find:
“Motion Detection” detects and records
any type of motion.
“Person Detection” detects and records
people only.
“Stranger Detection” is an expansion of
Person Detection. Once you’ve uploaded a
close up face image of a family
member/friend on the app and enabled this
feature, the camera will notify you each time
a stranger or a familiar person walks by.
3. Click the two slider buttons to enable or
disable “Person Detection” and “Stranger
Detection”.
4. Now “Person Detection” and “Stranger
Detection” are active.
4. Detection Modes
8
Camera Configuration x
Next
QR Code successfully
scanned.
8
Motion Detection
Alerts Settings
Person Detection
Stranger Detection
Motion Sensitivity Indoor
Devices
1
Camera Settings
Watch Together Capture Region
Device Reset
Sys Upgrade
Info
Photo-AudioAlerts Settings
Unbind Camera
2
Motion Detection
Alerts Settings
Person Detection
Stranger Detection
Motion Sensitivity Indoor
4

1. On your app, click the “Settings” button
underneath the camera placeholder.
2. Click the “Watch Together” button.
3. Click the QR Code icon in the “Scan Guest
Sharing QR Code” field.
4. Scan the Family Member’s QR Code.
* Family Member can access his or her QR
Code by pressing the QR button on the upper
right of the Home Screen.
5. Family Member was added in your Share
Camera screen.
5. Share with Family
Devices
1
Camera Settings
Watch Together Capture Region
Device Reset
Sys Upgrade
Info
Photo-AudioAlerts Settings
Unbind Camera
2
4
My QR Code
Scan Sharing QR Code
3
Share Camera
Scan Guest Sharing QR Code
0 guest(s) successfully added.
5
Share Camera
Scan Guest Sharing QR Code
1 guest(s) successfully added.
Family Member Unbind
4*
Devices
Hi John,
Let’s get started!
Wi-
Password
Next
Start
Type in Wi-fi and Password
9

III. Place and Mount eyecloudCam
1. Ways to Place your eyecloudCam
1.1 Horizontal surfaces
Place the camera on any horizontal surface.
That's about that.
1.2 Vertical Walls
A. Use Sticker B. Use Screws
C. Use Magnet Mount
10

1.3 Roofs and Ceilings
A.Sticker
Usually those surfaces
that you don’t want to
drill through.
Furniture
Tile
Glass
Interior walls
Exterior walls etc.
B. Screws
Drillable Surfaces
Wood
Interior walls
Exterior walls (cement, bricks)
etc.
C. Magnet Mount
Magnetic Surfaces
A. Use Sticker C. Use Magnet
Mount
B. Use Screws
2. Recommended Surfaces
11

4.1 Rotate the camera
body to adjust the
horizontal range.
4.2 Rotate the
camera head to adjust
the vertical
monitoring range.
4. Adjust the Monitoring Range
35
60
3.1 In front of windows
The camera cannot properly detect events
through glass.
3.2 Too far from a router
Place your eyecloudCam in the proximity of a
wireless router.
12
3. How Not to Use your eyecloudCam
