PiXORD PL721 User manual

July 2014
PL721 3MP IR Bullet
Network Camera
User’s Manual
Version 2.01

Trademark Acknowledgments:
All trademarks used in this handbook are registered trademarks of their respective companies.
Copyright © 2014
All Rights Reserved
We reserves the right to make corrections, modifications, enhancements, improvements, and other changes to its
products and services at any time and to discontinue any product or service without notice. Customers should
obtain the latest relevant information before placing orders and should verify that such information is current and
complete. All products are sold subject to our terms and conditions of sale supplied at the time of order
acknowledgment.
We are not responsible or liable for the resale of its products with statements different from or beyond the
specification/parameters stated by our company. Customers are responsible for their applications using our
products. To minimize the risks associated with customer applications, customers should provide adequate
operating safeguards. We are under no obligation to provide any further technical support service or
product/software alteration beyond our representation.
Our products are not authorized for use in safety-critical applications where a failure of our product would cause
severe personal injury or death, unless officers of the parties have executed an agreement specifically governing
such use.
Reproduction of our information or datasheets with alteration is prohibited. We are not responsible or liable for
any of such altered statements.
Every care has been taken in editing this manual. If there are any inaccuracies or omissions, please inform our
local office. We cannot be held responsible for any typographical or technical errors. We are not liable or
responsible for incidental or damages caused by any misinterpretation of this publication.

Contents
Contents
ContentsContents
Contents
Contents
ContentsContents
Contents iii
iiiiii
iii
Important Notes ............................................................................................................. v
1
11
1 Introduction
IntroductionIntroduction
Introduction 1
11
1
Hardware Overview........................................................................................................ 2
2
22
2 Install
InstallInstall
Installation and Setup
ation and Setupation and Setup
ation and Setup 5
55
5
2.1 Connecting Camera to Network through LAN Router Cable.................................... 5
2.2 Configuring and Finding Camera via Software ......................................................... 6
2.2.1 Open the Web-based UI ........................................................................... 11
3 Camera Live View UI Settings
3 Camera Live View UI Settings3 Camera Live View UI Settings
3 Camera Live View UI Settings 13
1313
13
3.1 Quick Access Buttons ........................................................................................... 15
3.2 Camera Live View UI Setting Tools ...................................................................... 16
4
44
4 Setup Execution
Setup ExecutionSetup Execution
Setup Execution 1
11
1
4.1 System Setup Execution........................................................................................ 18
4.1.1 Information Tab ....................................................................................... 19
4.1.2 Time Tab.................................................................................................. 20
4.1.3 Security Tab............................................................................................. 21
4.1.4 Maintenance Tab...................................................................................... 24
4.1.5 System Log Tab ....................................................................................... 26
4.2 Network Setup Execution..................................................................................... 27
4.2.1 General Tab.............................................................................................. 27
4.2.2 DDNS Tab............................................................................................... 29
4.2.3 Multicast Tab ........................................................................................... 30
4.2.4 IP Filter Tab............................................................................................. 31
4.3 Video & Audio Setup Execution ........................................................................... 32
4.3.1 Stream Tab............................................................................................... 33
4.3.2 Video Tab ................................................................................................ 35
4.3.3 Audio Tab................................................................................................ 41
4.3.4 Privacy Mask Tab..................................................................................... 41
4.3.5 ROI Tab................................................................................................... 43
4.4 Event Setup Execution.......................................................................................... 44
4.4.1 Motion Tab .............................................................................................. 44
4.4.2 Video Tab ................................................................................................ 47
4.4.3 Snapshot Tab ........................................................................................... 51
4.5 Local Storage Setup Execution ............................................................................. 56
4.5.1 Local Storage Tab.................................................................................... 56

Revision History
iv PL721 User’s Manual
4.5.2 Playback Tab............................................................................................ 57
5
55
5 Appendix
AppendixAppendix
Appendix 5
55
5
5.1 Firmware upgradem Setup Execution.................................................................... 67
Revision History
Doc.
Version Revision Description Date
1.0 Initial Official Release 2014/04/28
2.0 Add chapter 5 Appendix 2014/07/07

Read Me First!
PL721 User’s Manual v
Read Me First!
Important Notes
This User Manual is intended for administrators and users of the PL721 IR Bullet
Network Camera, including instructions for using and managing the camera on
your network. The use of surveillance devices may be prohibited by law in your
country or area. It is therefore the user’s responsibility to ensure that the
operation of such devices is legal before installing this unit for its intended use.
Before the Network Dome Camera is installed, carefully read and follow all the
safety and operating instructions to avoid damage due to faulty assembly and
installation. This also ensures that the device is used properly as intended.
Heed All Warnings


Do not drop or hit the device.
Sensitive electronics inside the camera are vulnerable to excessive impact.


Do not install the device under high temperature (higher than 50°
°°
°C)
environment.
Excessive heat could damage the equipment.


Do not cover device with any object or install it in a poorly ventilated
vicinity.
Overheating could damage the camera.


Do not expose the device to rain or moisture. Do not touch the power
connection with wet hand.
Risk of short circuit, electric shock, or fire


Do not damage the power cord or leave it under pressure.
Risk of fire or circuit electric shock


To reduce the risk of electric shock or damage, do not open the cover
except qualified person.
There is no user-serviceable parts inside. Misusage, improper, or negligent
handling could damage the device. Refer to qualified service personnel from
our distibutor/dealer for any device related trouble shooting need.

Read Me First!
vi PL721 User’s Manual


Do not continue to operate the device if it appears to malfuntion.
Contact qualified service personnel from our distibutor/dealer for help.


Installation of the product should be made by qualified service personnel
or system installers from our distibutor/dealer.

Chapter 1
PL721 User’s Manual Introduction
•
••
•1
1
11
1 Introduction
IntroductionIntroduction
Introduction
PL721 is a IR Bullet Network Camera featured with 3Mega Pixel resolution and
superior H.264-AVC performance and rich functions.
It is very suitable to view a wide/Tele area such as station, commercial, banking
communication and government building, schools and airport.
PL721 value-added features include; on-board video motion detection, and
two-way audio. PL721E, the PoE available, full PoE (IEEE-802.3af) feature
supplies power to the camera via the network, eliminating the need for power
cables, reducing installation costs and complexity. Consequently, PL721 is “Best
in Class” for maximum performance IP video surveillance systems, demanding
superior image quality, ease of installation, and intelligent video capabilities
Further functions include DI/DO alarm application and micro SD card support
for local storage application.

Chapter 1
2 •
••
•Introduction PL721 User’s Manual
Hardware Overview

Chapter 1
PL721 User’s Manual 3 •
••
•Introduction
PL721 provides extra connections with outside devices via water proven RJ45 connector. User
can make the connectors to support 1) Video Out, 2) Audio In, 3) Audio Out, 4) Terminal Block
for GPIO. Please refer to following table of the pins definition of RJ45:

Chapter 1
4 •
••
•Introduction PL721 User’s Manual
Pin Function Description
1 DO_COM
Digital Output: each digital output pin to COM (Pin1)
is a photo-coupled relay on Normal Open status.
External device can directly connect to the terminals.
However the current that will go through the 2 nodes
must not exceed 130mA. An external “Relay” can also be
connected to the terminals as an implementation. In this
case, current (or/and voltage) limitation is specified by
the external Relay.
Digital Input: Only one set is designed in this Camera
Model. The internal device is also photo-coupled
electrical relay; and the external device can be simply an
On/Off switch. Each set of On/Off switch can be
connected as one trigger source.
Default Setting: Short Pin4 and Pin5 with a wire PIN
with a short wire to revert to factory default settings.
Break the short when the LED starts quick flashing, and
then camera will reboot automatically a few minutes
later.
Don’t forget to connect Audio In / Audio Out / CVBS
Out GPIO Pin to GND for active; or leave floating (or
unconnected) to deactivate.
2 DO_NO
3 DI
4 GND
5 Default Setting
6 Audio In
7 Audio Out
8 CVBS Out

Chapter 2
PL721 User’s Manual Installation and Setup
•
••
•5
2
22
2 In
InIn
Installatio
stallatiostallatio
stallation
nn
n
and Setup
and Setupand Setup
and Setup
2.1 Connecting Camera to Network through LAN
Router Cable
Figure 2-1 Connecting IP Camera to Network
1. Prepare a PC/notebook/ultrabook with Ethernet link to the network.
2. When PC/notebook is used, connect the LAN port of the device to the network router
with an RJ45 network cable (1
11
12
22
2).
3. Plug the DC power jack of the power adaptor (3
33
34
44
4) to power jack on the extension
cable of Camera and connect the power adaptor to power outlet (110V or 220V).
4. Connect the network router to the LAN port on the extension cable of Camera with an
RJ45 network cable (5
55
5).
5. With power switched on a few minutes later, you should find out this camera via
CAM FINDER utility in CD.
Power Adapter

Chapter 2
6 •
••
•Installation and Setup PL721 User’s Manual
2.2 Configuring and Finding Camera via Software
You could find CAM FINDER utility from the attached Software Package CD.
The CAM FINDER is used to find and configure network cameras on the LAN.
This utility is useful for conveniently configuring the network settings of the
device, or for finding a device once the network settings have been modified.
To install the CAM FINDER, from the Software Package CD, select CAM
FINDER, then follow the instructions to complete the installation.
NOTE
1. In order to ensure CAM FINDER utility has the best compatibility with Camera,
kindly please goes to the PIXORD website for the latest version downloading.
2. In order to ensure Camera will be assigned IP Address properly, please confirm
the following things.
Always consult your network administrator in order to avoid using a
previously assigned IP address.
Check if the Camera is powered on and correctly connected to the network.
In order to connect to the Web-based user interface of the camera, the host
PC must be in the same subnet. For more information about subnets, please
consult your network administrator.

Chapter 2
PL721 User’s Manual 7 •
••
•Installation and Setup
1. Once CAM FINDER has been successfully installed on the PC/notebook/ultrabook,
double click Mouse left button to run the software.
2. Click the [Device Search] to search the device in the LAN.
Figure 2-2 Find the Camera Device via “Device Search” button
3. Under your selected item, double-click the left Mouse button or Right-click the
Mouse button to open the Property Page item [Single Device Setting].
Figure 2-3 Open the Camera’s Property setting page via “Single Device Setting” item

Chapter 2
8 •
••
•Installation and Setup PL721 User’s Manual
4. Check [Static IP address] or [Use DHCP Service] item to select the network
connection method of the camera.
Figure 2-4 Enter the Camera Device’s network setting manually.
Figure 2-5 Check “Use DHCP Service” item to let camera get IP Address automatically.

Chapter 2
PL721 User’s Manual 9 •
••
•Installation and Setup
5. After modifying the camera properties, click [Set] button to save and enable the
configuration modifications.
Figure 2-6 Click “Set” button to save and enable the modification.

Chapter 2
10 •
••
•Installation and Setup PL721 User’s Manual
6. Use“Ctrl”or“Shift”key on the keyboard to choose several Camera Devices.
Then click the [Batch Device Setting] to configure them together.
Figure 2-7 Select multi-Camera Devices and then configure their properties together
via “Batch Device Setting” item
Figure 2-8 Check “Increase IP” setting to set Camera Device’s IP address increasing one by one.
Then click “Set” button to save and enable the modification.
7. [Language] support for Chinese, English and Spanish.
Figure 2-9 Selecting “Language” item could change the displayed language font of CAM FINDER utility.

Chapter 2
PL721 User’s Manual 11 •
••
•Installation and Setup
2.2.1 Open the Web-based UI
1. To access the Web-based UI of the selected unit, run the [Open Web] on the
select item.
Figure 2-10 Open the Camera’s Web-based UI Page via “Open web” item
2. For first time user, there will be a prompt to install the ActiveX control.
Comply with the ActiveX installation as they are needed to view the video
stream and some other operations.
Besides, use of Microsoft IE browser is recommended as it offers a better
compatibility.
Figure 2-11 ActiveX components are required for Camera’s Live Stream
and configuration operation.
※ Please also note to close all browser applications before
NetcamViewer web component installation.

Chapter 2
12 •
••
•Installation and Setup PL721 User’s Manual
3. If the camera and browser components have been configured correctly, the
default Web browser will open to the Live View page of the selected camera.
* Username and password is required to enter “SETUP” Webpage.
(Default is admin / admin)
Verify and Complete the Installation from Your Browser
If your IE Browser can’t get the ActiveX download properly, you may have
to temporarily lower your security settings to perform a one-time-only
installation of the ActiveX component onto your workstation, as described
below:
1. From the IE Browser menu, select
[Internet Options] -> [Security] -> [Custom Level]
2. Set the security level to Low and click [OK].
3. Don’t forget to restore the security level after the ActiveX
installation.

Chapter 3
PL721 User’s Manual Camera Live View UI Settings •
••
•13
3
33
3
Camera Live View UI
Camera Live View UI Camera Live View UI
Camera Live View UI
Settings
SettingsSettings
Settings
Using PC/notebook/ultrabook, you may change and reconfigure the Camera live
view user interface (UI) settings to suit your need by following the procedures
below.
1) Execute your Web Browser and then manually enter the Camera Device’s IP
address gotten via CAM FINDER utility.
NOTE
For first time user, there will be a prompt to install the ActiveX control.
Conply with the ActiveX installation as it is needed to view the video stream
and some other operations.
Use of Microsoft IE browser is recommended as it offers a better
compatibility.
2) Then the “Windows Security” dialog displays. Enter a username and
password. You may enter “admin” for both. Click OK button when
completed.
(Note that same Browser with different version or different vendor Browser
will behave different dialog window. Below picture is belonging to IE
Browser’s diagram.)
Figure 3-1 “Windows Security” Dialog

3) The “Live View Setting” window will then display offering all the necessary
set up tools for changing the live view reconfigurations. The functions of each
of these tools are explained in the following sections.
Figure 3-2 Camera “Live View Setting” Window
