eZi MINI User manual

ez1 MINI

Please read the user manual carefully before riding. This manual should also be attached to the scooter if you
make the second-hand sale.

Foreword
We sincerely thank you for your love of E-ZI electric bikes, and warmly welcome you to become an E-ZI user. The company
adheres to the concept of "customer-centric, product quality as life", After years of operation, our quality has been
recognizsd by the mojority of users. Keep in mind that each model is designed and manufactured for a specific intended
use. Make sure to use it according to the intended use, otherwise accidents may occur due to insufficient strength or failure
to strength, leads to unpredictable consequences.
This scooter is suitable for hard surface roads, such as asphalt roads, bikes lanes or gravel roads. Please follow the
traffic rules when riding on public roads. City bikes are not suitable for off-road driving, otherwise it may lead to unpredictable
consequences or accidents.
Note: When riding this scooter, please bring this instruction manual and maintenance manual with you.
Products and specifications are subject to change without notice

Catalogue
1Warning......................................1
2 Namesof main parts...................2
3Functionsof the each button......4
4Battery use and charging............7
5 Remote Control...........................9
6 Check before riding...................10
7 Maintenance and repair............11
8 Storage method.........................15
9 Vehicle Specification Table........15

1 WARNING
Safe riding
You have to know the following points
before riding：
·Fully understand how the scooter
operates.
·Be well noted of the warnings, notes,
and instructions in this manual.
·Persons under the age of 16 are strictly
forbidden to ride the ebike on the road;
·Don't lend e-bikes to people who is not
able to handle it, to avoid accidents；
·Wear a safety helmet that suits you
properly on your head when riding, and
tie the straps tightly.
·Please follow the local laws if you need
to carry people or goods when riding；
·Riding on rainy or snowy days, the
braking distance will be extended.
Please do not ride at high speeds and
be especially careful when turning. In
severe weathersuch as heavy rain, try
to avoid riding outside；
·E-bikes shouldbe driven in non-
motorized lanes, and the speed should
be kept at about 15km / h;
·Please do not use third-party acce-
ssories, and do not disassemble, crack or
modify the scooter without authorization.
The losses causedby this will be borne
by yourself and our warranty will no
longer be valid.
·Don’t park e-bikes in the building's
foyer, evacuation stairs, walkways, and
safe entrances.
·Don’t charge e-bicycles in residential
buildings. Keep away from combustibles
when charging. Don’t charge for too
long.
Note: All materials, pictures, and technical
parameters in this manual use the latest
products at the time of publication. As
product changes will lead to changes in
technical parameters and performance
enhancements, if this happens, without
notice, please be wall noted.
1

4
3 Functionsof each button
Steering lock
Unlock
Lock
Lock
In this position, the steering rudder
can be locked, the scooter cannot be
moved, the key can be removed.
To lock the steering
1.Turn the scooter steering to the left；
2.Insert the key into the steering lock；
3.Turn the key to [Lock] position form
the position of [Unlock]
4.Remove the key.
To open the steering lock
1.Insert the key into the steering lock；
2.Turnthe key to[UnLock] position
3.Remove the key
Warning Do not turn the key to the
[Lock] position while the scooter is
running, otherwise the scooter will be
lose control or accidents. Whether the
steering rudder is locked or not, the
key must be removed duringuse.
Indicator lights and warning lights
1 2 3 4 5 6 1
1.Turn signal indicator
2.High beam indicator
3.Low beam indicator
4.Ready indicator
5.fault light
6.Battery warning light
Direction indicator
When pushing the turn signal switch to
the left or right，this indicator starts to
flash.

5
High beam indicator
When the headlight uses ahigh beam,
this indicator lights up.
Low beam indicator
When the headlight uses alow beam
light, this indicator lights.
Ready
Lights up when starting up, indicating
that the scooter is working properly and
can be ready to ride.
fault light
The electronic circuit detects that the
scooter is not working properly, and this
warning light will stay on. When this
phenomenon occurs, please contact the
after-sales service network for system
diagnosis.
Battery warning light
This indicatorlight indicates that the
battery is low, you need to use
the charger to charge the battery.
Multifunctional LCD instrument
1 2 3 4 5
1.TRIP（Interval meter）
2.ODO（odometer）
3. Riding mode
4.Speedometer（error code）
5. Battery percentage
This multifunctional LCD instrument
has the following function modes:
·Interval meter（TRIP）
Shows the distance the scooter has
traveled so far this time.
·Odometer（ODO）
Display the total distance traveled by
the scooter.
Tip: When the scooter is stopped, pinch
the rear brake grip, and then quickly
turn the throttle handle twice to make
the TRIP and ODOon the instrument
switch.
·Riding mode
Display the driving mode of the soccter
in front of you, there are ECO and Power
modes.
·Speedometer (fault code)
The real-time speed of the soccter is
displayed while riding. When a failure
occurs, the vehicle fault code will flash.
·Battery percentage
Displays the percentage of power
remaining in the current battery.

6
Left combination switch
Left handle switch
123
1.Dimmer button
2.Turn signal button
3.Horn button
Right handle switch
1
2
1.lighting switch
2. Mode switch
Far and near light switch /
press to turn on the high beam;
press to turn on the low beam;
Turn signal switch /
Push the switch to Can make the
right directionlight flash；Push the switch
to Canmake the left direction light
flash.If you want to cancel the blinking
of the directionlight, you canmove
the switchback to the middle position.
Horn button
Press this button to make the speaker
sound.
Mode switch
Press this button to switch the vehicle's
driving mode between ECO and Power.
Rear brake grip
The rear brake grip is located on the
left handle, and graspthe grip inthe
direction of the handle to make the
rear wheel brake.
Front brake grip
The front brake gripis located onthe
right handle. Graspthe grip in the direction
of the handle to make the front wheel
brake.

7
4 Battery use and charging
Battery installation and use
open the seat barrel with key andmake
sure the circuit breaker lever is in the
ON position.
Tip: if you do not use the scooter for a
long time, you should turn the circuit
breaker to the OFF position.
Then put the battery into the battery
compartment and Insert the discharge
plug into the discharge port, replace
the seat cushion, and confirm that the
seat barrel lock has been locked.
Warning It is strictly forbidden to short
circuit the battery fuse Nonmaintenance
personnel are strictly prohibited from
wiring the discharge cables；
Descriptionof batterypower indicator
1：In the charging state, the indicator
will show the current power.
2：In the non-charging state, pressing
the battery indicator button will display
the battery electricity. (A flashing red
light indicates low power and the battery
should be charged)
Battery usage environment
·The ambient temperature of the battery
is -20 ~ 60 ℃. Avoid water, beverages
or corrosive liquids into the battery.
·Don’t put the battery near fire and
flammable and explosive gas liquids,
otherwise it may cause deflagration or
explosion.
·Please avoid foreign matter such as
metal powder entering the battery,
otherwise it will cause a short circuit and
make the battery over heat or explode.
·If the battery has a strange smell,heat,
deformation during use, please stop
using it immediately and contact our
after-sales personnel for inspection and
repair.

8
After replacing the battery, do
notdisassemble the used battery
without authorization, it should be
recycled by the relevantprofessional
departments；
Note
Battery maintenance
·If you don’t use your battery foralong
time, please charge your battery
regularly to keep the power above
50%. If the battery power is lower
than 20% for a long time, it may
cause the battery to lose power and
cause irreversible attenuation to the
battery capacity.
·The battery is a consumable, and the
capacity will naturally decay during
use. When you feel that the cruising
range can’t meet the demand for
using, you should replace it.
·If you encounterbattery failure, please
contact our after-sales personnel for
repair and replacement. Don’t disassemble
the battery without permission, otherwise
it may cause the battery togenerate
heat and smoke, which may seriously
cause fire or explosion.
·Please try to avoid storing the battery
in a place where it is easy to drop, so
as to prevent the battery from heating,
smoking or even exploding due to the
fall.
Charging mode selection
External charging mode
After pulling the battery out of the seat
barrel, you can insert the charging head
into the charging interface for external
charging. At this time, the battery power
indicator will light up anddisplay the
battery power.

9
5 Remote Control
The scooter has a one-key start function,
only need to use the remote control to
start the scooter.
Start
Lock
Unlock
Power
Lock the scooter
When you finish riding, press the power
button on the scooter to switch from the
steady light to the flashing state, and
then press the lock button on the remote
control, the scooter will be locked.
Unlock the scooter
When you press the unlock button on
your remote control, the power button
on the vehicle will light blue and flash,
the scooter is unlocked successfully.
Start the scooter(Method 1)
Press the start button twice on your
remote control when the scooter is
locked. The scooter is now powered,
then press the mode button on your
handle bar. You can ride by turning
the throttle handle.
Start the scooter(Method 2)
Press the power button on the scooter
after unlocked the scooter. The scooter
is now powered, then press the mode
button on your handle bar. You can ride
by turning the throttle handle.

10
6 Check before riding
Please check the following details before
riding.
Warning If the vehicle is not properly
inspected and maintained, it will increase
the chance of accidents or damage to
components. Once any problem is found,
you must not ride the scooter. If the
problem cannotbe solved in this manual,
please find the nearest service outlet
for repair and inspection.
Inspection steering handlebar
1. Turn on the power, operate the lighting
switch, check all the lights-High Beam,
Low Beam, Brake Light, Turn Signal
Indicator, etc.
Inspection of front and rear brakes
1.Use the front and rear brake handles
for braking, and check whether the braking
effect is normal.
2. Recommended brake fluid DOT4.
3. Check the front brake pads, if a brake
pad has worn to the point that the wear
indicator grooves were mostly disappeared,
have a dealer replace the brake pads
as a set.
tread height on the tire is less than 2mm).
If so, you should go to the after-sales
service department to replace the new
tires in time.
Inspection the Horn
Check whether the horn can work.
Inspection of reflectors and license
plates
1. Check the side reflector, and rear reflector
for dirt and damage. If there is, it should
be cleaned or replaced in time.
2. Check whether the license plate is installed
securely, the number is clear, and there
is no dirt and damage.
Inspection the battery
Check adequate for planned distance to
travel.
Inspection of tires
1. Check the tire pressure, the proper
pressure of front and rear tire is 280kpa.
2.Check the tire for cracks or openings and
excessive wear (the

11
7 Regular inspection, maintenance
and repair
Users are advised to have the scooter
checked and maintained on a regular
basis, even for the scooters that are not
used for a long time.
Regular Maintenance
Users are advised to have their scooters
checked 2 months after purchased or
with 1000km travelled distance. Overall
check and maintenance is advised to be
conducted every 6 months or 3000km
thereafter.
Daily Maintenance
If any problem occurs during checks,
please look through the user's manual
or send the scooter to the dealer's for
checks and maintenance.
Scooter Washing
Please use neutral detergent and water
to wash the scooter. Use soft cloth to
wipe the scooter after washing to prevent
scratching.
Note If the scooter is frequently used in
overload, high-speed, bumpy or up/down
hill riding conditions, the maintenance
cycle should be shortened. For more
guaranteed quality and longer service
life, please use original parts, which
will be the only way to keep the scooter
warranty.
Warning
If you find yourself incapable to perform
the checking or maintenances, please
contact authorized dealers for assistance.
Warning
Do not use pressurized water jets to wash
the scooter, especially around the battery
compartment. Do not spray the water around
the area of the foot rest, where the control
circuits, controller and other parts installed
inside. If the charging port on the scooter is
wet, please do not charge before the charger
dries off.

12
Maintenance schedule

Failures and solutions
13
Failure Causes Solutions
The scooter has no power
Power switch not in right position
Battery is not connected correctly
Battery has low power
Put the Power switch is in the ON position
Re-connect the battery plug
Charge the battery
Brake handle is blocked
The scooter does not accelerate
Throttle handle failure
Place the brake handle at the right
position Change handlebar if damaged
Insufficient mileage
The battery is not fully charged
Under inflated tire
Heavily overloaded
Brake pads interference Battery
is aging or normal scrap
Charge the battery
Check the tire pressure and inflate if needed
Keep the appropriated load
Check the brake system before driving
Replace battery
Battery cannot be charged The charger is not plugged in Ambient
temperature too high or too low
Check if the plug is loose
Charging the battery in normal conditions
The instrument cannot display Scooter without power
Displayer is broken
Charging the battery in normal conditions
Contact after-sales, replace parts
USB without power The plug is not plugged in properly
The USB is damaged
Check if USB plug is loose
Contact after sales, replace parts

14
Fault code Causes Solutions
01 Motor Hall element failure Contact after-sales for repair
02 Scooter throttle handle malfunction Replace the throttle handle
03 Controller failure Contact after-sales for repair or replacement
04 Failure of brake sensor Replace the brake sensor
05 Motor phase loss Contact after-sales for repair
06 Undervoltage protection Contact after-sales for repair
07 Battery communication failure Contact after-sales for repair
CH charging The battery is charging, you can only ride after you
stop charging
30 Instrument communication failure Contact after-sales for repair

8 Storage method 9 Scooter Specification Table
15
Short-term Storage
● Keep the scooter in flat, steady, well-
ventilated and dry area.
● Charge the battery to 50% before storage
to maximize battery life.
● Avoid exposure under sunlight and rain
to reduce damage or aging.
Long-term Storage
● Remember to have a cycle of charge
and a discharge at least every 2 months
and charge the battery to 50% before
storage to maximize battery life.
● Charge the battery to 100% after long-
term storage before riding.
● Check all the parts carefully to make
sure that there is no problem before riding it.
If there's any problem, contact authorized
dealer for maintenance or repair.
Warning
Please take out the battery from the scooter
when long-term storage.
Scooter Performance
Size: L x W x H 1720mm×680mm×1030mm
Wheel base 1195mm
Weight 54.5Kg
Max speed 45/30/25km/h
Range 45/59/65km
Max Load 150kg
Battery type Lithium-ion battery
Battery capacity 20Ah
Voltage 48V
Undervoltage
protection value
41±1V
Overcurrent
protection value 35±1A
Motor model Rear Hub Motor
Rated outpower 1000w
Rated voltage 48V
