eZLO EZ001-1 User manual

How about…
Smart life made easy anytime... anywhere.
US
ER
M
A
N
Version: 1.0
HOME AUTOMATION
S Y S T E M

Introducing eZLO!
The home automation system that lets
you manage, monitor, and connect
with all your smart home devices using
your smartphone.
What are you waiting for?
It’s time to create your own smart home!

Table of Contents
Introduction .................................................................................................................................... 1
In The Box........................................................................................................................................ 2
Setup and Basics ............................................................................................................................. 3
Your eZLO at a Glance
Setting Up Your eZLO
Connecting Your eZLO Controller to Your Account
Adding Devices to Your eZLO Controller
Connecting with Wi-Fi & WPS
Connecting with Ethernet Cable
Functions......................................................................................................................................... 6
LED Indicators
Backlight LED Notifications
Front LED
Product Specifications
Safety & Handling ........................................................................................................................... 8
Important Safety Instructions
Troubleshooting
One Year Limited Warranty
Legal Notice................................................................................................................................... 13
Governing Law
Trademarks
Copyright Statement

User Manual Introduction
1 | P a g e
Introduction
eZLO is an established provider of home automation and control solutions marketing
mainly in North America and expanding to Europe and Asia. eZLO focuses on giving you
the best there is in virtually controlling any device in your home and business.
You can now manage your home with just a simple tap in your smart phones and tablets.
The EZLO app is perfect for you to improve, modernize, and upgrade your home the way
you wanted. EZLO will help you simplify your daily life.
eZLO functions are, but not limited to the following:
Lighting
HVAC
Sensors
Security
Home Entertainment
Domestic Appliances
Our goal is to deliver an easy-to-use and a more affordable smart home system to let
everyone experience easy living while guaranteeing a secured, comfortable, and
convenient home. It’s time to create your own smart home. Now, let’s get started!

User Manual In The Box
2 | P a g e
In The Box
Ready to experience your newly purchased eZLO Controller?
Let us begin with unboxing the hardware. The box should include the following
hardware and accessories:
oeZLO Controller (Image 2.1)
oPower Cord (Image 2.2)
oEthernet Cord (Image 2.3)
Image 2.1
Image 2.2
Image 2.3

User Manual Setup and Basics
3| P a g e
Setup and Basics
Your eZLO at a Glance
1 - Power Indicator
2 - Ethernet Indicator
3 - Wireless Indicator
4 - Ready Indicator
5 - Error Indicator
6 - Message Indicator
7 - Z-Wave Indicator
8 - Antennae
9 - Soft Reset Button
10 - Factory Reset Button
11 - LAN Port
12 - USB Port
13 - AC/DC Input
8
9
10
11
12
13
1
2
3
4
5
6
7
Image 3.1
Image 3.2

User Manual Setup and Basics
4| P a g e
Setting up Your eZLO
To setup your eZLO home automation controller, you’ll need a power outlet nearby, a
Wi-Fi connection, and the mobile/tablet application.
Follow this quick guide to set up your eZLO Home Automation:
Plug in eZLO home controller to the
power outlet and wait until backlight LED
blinks blue; it should take about 2
minutes.
Connect the UTP/Ethernet cable from the
eZLO controller to your router.
oWait until the backlight LED stays
steady with light-blue and the
Ready front LED (#4) is on.
Download the eZLO App to your
smartphone or tablet from App
Store/Google Play.
Connect your device(s) using the
smartphone app.
Step 1
Step 2
Step 3
Step 4

User Manual Setup and Basics
5| P a g e
Connect Your eZLO Controller to Your Account
i. Register & log into your account.
ii. Click “Add eZLO”.
iii. Click “Where is my eZLO?”
iv. Follow the on-screen instructions.
Adding Devices to Your eZLO Controller
i. Log into your account on your mobile app.
ii. Select your eZLO device.
iii. On the upper right corner, click on the icon.
iv. Select “Devices” on the dropdown menu.
v. Click on “ADD NEW DEVICE”.
vi. Follow the on-screen instructions.
Connect with Wi-Fi & WPS
i. Turn your eZLO controller on.
ii. Wait until the backlight LED blinks blue (takes about 2 minutes).
iii. Press the WPS button of your Wi-Fi router.
iv. Wait until the backlight LED stays steady with light-blue and the Ready front LED
(#4) is on.
You need to have a WPS function on your Wi-Fi router.
Connect with Ethernet Cable
i. Connect the Ethernet cable to your controller.
ii. Turn your eZLO controller on.
iii. Wait until the backlight LED stays steady with light-blue and the Ready front LED
(Refer to Image 3.1) is on.
You need to have your eZLO controller connected to the router with Ethernet cable before power-on.

User Manual Functions
6| P a g e
Functions
LED Indicators
Backlight LED Notifications
Notification
Meaning
BLUE - blinking
Waiting for the Wi-Fi router in WPS mode.
WHITE - blinking
Connecting to the configured Wi-Fi network.
GREEN - blinking
Connected to the local network.
MAGENTA - blinking
Unable to find Wi-Fi (may need to reconfigure).
YELLOW - blinking
Wrong Wi-Fi key (need to reconfigure).
RED - blinking
General Connection Error
Light Blue-Cyan-Light Violet
Connected to the local network - default standby
effect.
Front LED
Order (left-to-right)
Color
Meaning
#1 Power
Green
On - if power is connected.
#2 Ethernet
Yellow/Green
Blinking - if there’s network activity.
#3 Wi-Fi
Blue
On - if Wi-Fi is connected.
#4 Ready
Yellow
On - if controller is ready.
#5 Error
Red
Not Used
#6 Message
Blue
Not Used
#7 Z-Wave
Red/Green
Red: Z-Wave Excluded
Green: Z-Wave Included

User Manual Functions
7| P a g e
Product Specifications
General
Model
DS-201
Physical
Dimensions
101 * 148 * 1.6mm
Weight
0.08KG
Environmental
Operating Temperature
-20 -+ 70 °C
Power
Power Requirements
5V@2A (AC voltage, DC input)
Power Consumption
7.5W/2W (Max/Idle in watts)
I/O Interface
Ethernet
10Base-T, 100Base-TX, 1000Base-T IEEE802.3
Standards
Wi-Fi
Compatible with IEEE 802.11b/g/n Standard
Bluetooth
BT4.0
Z-wave
2405-2480MHz
USB Port
2x USB 2.0 Host
Display
7x Status LEDs

User Manual Safety & Handling
8| P a g e
Safety & Handling
Important Safety Instructions
Troubleshooting
The backlight LED blinks blue after connecting with Wi-Fi.
'Blinking Blue' means that it’s waiting for a WPS and your previous connection to Wi-Fi failed.
Quick Fix:
Your Wi-Fi router may not have power. Ensure that it functions properly.
If you have changed the place of your eZLO, its new place may be out of wireless range.
Try to take it back to its previous location.
If you have changed the Wi-Fi key, you need to reconfigure the eZLO by WPS.
Press WPS button of your router.
If the problem still exists, try to reboot your router and eZLO controller.
The backlight LED blinks blue after connecting with cable.
'Blinking Blue' means that it’s waiting for WPS and your previous Ethernet connection failed.
Quick Fix:
Your router may not have power. Ensure that it functions properly.
The cable may have defect. Try to replace it.
If the problem still exists, try to reboot your router and eZLO controller.

User Manual Safety & Handling
9 | P a g e
The backlight LED blinks red with some interval, and Ready front LED (#4) is OFF after
connecting with cable.
'Blinking Red' means there’s a connection error with your router.
Quick Fix:
Ensure that your router provides DHCP service.
Try to reboot your router and eZLO controller after checking your router's settings.
The backlight LED is light-blue (not blinking), but the Ready front LED is not ON.
This means that your router is not connected to the Internet.
Quick Fix:
Try to reboot your router.
Contact your ISP.
The backlight LED blinks red while updating firmware of my eZLO.
This means that the firmware update process has failed.
Quick Fix:
Check the current firmware of your eZLO controller and compare it with an available
version.
If the problem still exists, try to reboot your router and eZLO controller.

User Manual Safety & Handling
10 | P a g e
The backlight LED blinks red while including a Z-wave device.
This means that the Z-Wave inclusion process has failed.
Quick Fix:
You need to include your device again.
The backlight LED blinks red while excluding a Z-wave device.
This means that the Z-Wave exclusion process has failed.
Quick Fix:
You need to exclude your device again.

User Manual Safety & Handling
11 | P a g e
One Year Limited Warranty
LIVEWELL HOME RENTAL, LLC. warrants to the original purchaser of the Product that for
Warranty Period (as defined below), the product will be free from material defects in
materials and workmanship. The foregoing warranty is subject to the proper installation,
operation and maintenance of the Product in accordance with installation instructions
and the operating manual supplied to Customer. Warranty claims must be made by the
Customer in writing within thirty (30) days of the manifestation of a problem with the
receipt of the returned product. If the product is found to be defective in material or
workmanship, or if the product does not perform as warranted above during the
warranty period, LIVEWELL HOME RENTAL, LLC. will eat its option either 1) repair the
defect using new or refurbished replacement parts, or 2) replace the product with a new
product that is functionally equivalent to the original.
The “Warranty Period” begins on the date the product is delivered and continues for 12
months. Any repairs under this warranty must be conducted by an authorized LIVEWELL
HOME RENTAL, LLC. service personnel. Any repairs conducted by unauthorized persons
shall void this warranty.
Excluded from the warranty are following: 1) damage caused by failure to follow
instructions relating to the Product’s use or installation of components; 2) damage due
to accident, abuse, misuse, transport neglect, fire, floods, earthquake, or other natural
catastrophes; 3) damage caused by any person who is not an authorized representative
of LIVEWELL HOME RENTAL, LLC.
IN NO EVENT SHALL LIVEWELL HOME RENTAL, LLC. BE LIABLE FOR ANY INDIRECT,
INCIDENTAL, PUNITIVE, SPECIAL OR CONSEQUENTIAL, CORRECTIVE, SPECIAL OR
CONSEQUENTIAL DAMAGES, OR DAMAGES FOR LOSS OF PROFITS, REVENUE, OR USE
INCURRED BY CUSTOMER OR ANY THIRD PARTY, WHETHER IN AN ACTION IN CONTRACT
OR TORT, OR OTHERWISE EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
LIVEWELL HOME RENTAL, LLC.’S LIABILITY AND CUSTOMER EXCLUSIVE REMEDY FOR
ANY CAUSE OF ACTION ARISING IN CONNECTION WITH THIS AGREEMENT OR THE SALE
OR USE OF THE PRODUCTS, WHETHER BASED ON NEGLIGENCE, STRICT LIABILITY,
BREACH OF WARRANTY, BREACH OF AGREEMENT OR EQUITABLE PRINCIPLES, IS
EXPRESSLY LIMITED TO, AT LIVEWELL HOME RENTAL, LLC.’S OPTION, REPLACEMENT OF,
OR REPAYMENT OF THE PURCHASE PRICE FOR THAT PORTION OF PRODUCT WITH
RESPECT TO WHICH DAMAGES ARE CLAIMED. ALL CLAIMS OF ANY KIND ARISING IN

User Manual Safety & Handling
12 | P a g e
CONNECTION WITH THIS AGREEMENT OR THE SALE OR USE OF PRODUCTS SHALL BE
DEEMED WAIVED UNLESS MADE IN WRITING WITHIN THIRTY (30) DAYS FROM LIVEWELL
HOME RENTAL, LLC.’S DELIVERY, OR DATE FIXED FOR DELIVERY IN THE EVENT OF NON-
DELIVERY.
THE INDEMNITY AND WARRANTY IN ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL THE
OTHER INDEMNITIES OR WARRANTIES, WHETHER EXPRESS OR IMPLIED, INCLUDING THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.
For repair or replacement during the warranty period, call 000-000-0000 and send the
product, along with other required materials to:
Livewell Home Rental, LLC
ATTN: eZLO Warranty

User Manual Safety & Handling
15 | P a g e
Legal Notice
Governing Law
This Limited Warranty shall be governed by the laws of the State of New Jersey and by
the laws of the United States, excluding their conflicts of laws principles. Some states do
not have limitations on how long an implied warranty lasts, allow exclusion or limitation
of consequential or incidental damages; thus, the foregoing limitations and exclusions
may not apply. This limited warranty provides specific legal rights and the product
owner may also have other rights which vary from state to state.
Trademarks
eZLO is a registered trademark of Livewell Home Rental, LLC.
Other brands and product names are trademarks or registered trademarks are the
property of their respective manufacturers or owners.
Copyright Statement
No part of this documentation or publication, accompanying this product, may be
reproduced or transmitted, in any form or by any means, without prior written consent
from Livewell Home Rental, LLC., as provisioned by United States copyright law
governed by the federal Copyright Act of 1976.
© 2014 Livewell Home Rental, LLC. All Rights Reserved.
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities.
Contact your local government for information regarding the collection systems available.

Have Questions?
While we strive to create the very best product possible,
you may still need a little assistance every now and then.
Please feel free to browse our online support page for
quick fixes or simply contact us, as our friendly support
team is more than willing to help you.
Toll Free: 1 [phone]
Email: [email protected]
Online Support: http://support.ezlo.com
Operating Hours: Monday –Friday: 10:00am to 5:00pm (Pacific Time)

FCC Warning:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by
manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
“To comply with FCC RF exposure compliance requirements, this grant is applicable to
only mobile configurations. The antennas used for this transmitter must be installed to
provide a separation distance of at least 20 cm from all persons and must not be co-
located or operating in conjunction with any other antenna or transmitter.”
