EZTRUNK 1900 0072 User manual

BEFORE BEGINNING,SEE THE ASSEMBLY INSTRUCTION VIDEO ON EZTRUNK.NET
Alumiumum Door Lift
Ver A_13/8/22
CUSTOMER SERVICE: [email protected]
Text & Call : 203-901-0055 / Call 203-591-9060
Page 1
PO#
:
Print the latest manual &
Watch the EZTRUNK Video
Scan QR CODE for Video &
PDF MANUALS
MAKE IT
MAN
U
A
L
A
SS
EMBL
Y
WE CAN HELP YOU!
Customer Service
Any question? WE ARE HERE TO HELP!
EMAIL US: [email protected]
Text or Call 203-901-0055 / Call 203-591-9060
7 days a week 8:30 am EST
EZ Aluminum Door Lift
#1900 0072

BEFORE BEGINNING,SEE THE ASSEMBLY INSTRUCTION VIDEO ON EZTRUNK.NET
Alumiumum Door Lift
Ver A_13/8/22
CUSTOMER SERVICE: [email protected]
Text & Call : 203-901-0055 / Call 203-591-9060
Page 2
Please read instructions fully before beginning assembly
NO Illustration Description Part# QTY.
1Sliding Frame
Sliding Plates (#7201-7) pre installed (4)
7201 2
2Side upright Frame 7202 2
3Top Rail 7203 1
4 Middle Rail 7204 2
5 Middle Side Rail 7205 2
6 Bottom Rail 7206 2
7Wheels Rail
Wheels (#7207-3) Pre Installed (4) 7207 2
8Door Support Panel 7208 2
9Bolt M6x45 06452 6 + 1 extra
10 Bolt M6x70 06702 8 + 1 extra
11 Bolt M8x75 08752 8 + 1 extra
12 Lock Nut M8 10082 8+ 1 extra
13 Lock Nut M6 10062 18 + 2 extra
14 Locking Pin 08352 4
15 Thumb Turn Bolt M6 06750 4
16 Offset Nut M6 10162 4
17 Handle for Sliding Frame 10262 2
18 Metal Washer ( Small ) 6012 14 + 2 extra
19 Metal Washer ( Large ）8012 12 + 2 extra
20 Thumb Turn Bolt 6200 4
21 #4 Allen Wrench #4 1
22 #5 Allen Wrench #5 1
23 #10 & #13 Wrench #10 1
Use same bolt as tire table for next bath
of production

BEFORE BEGINNING,SEE THE ASSEMBLY INSTRUCTION VIDEO ON EZTRUNK.NET
Alumiumum Door Lift
Ver A_13/8/22
CUSTOMER SERVICE: [email protected]
Text & Call : 203-901-0055 / Call 203-591-9060
Page 3
2
Top Rail #7203
X1
Middle Rail #7204
X2
Middle Side Rail #7205
Offset Hole
X2
Bottom Rail #7206
X2
Components of tubes.
1
Install bottom side rails to frame: use bolt M8x75 (#08752), large washer (8012),
and lock) nut M8 (10082)-see diagram (4)
Check diagonal dimensions to ensure they are egual. Tighten all bolts.
4
Install the Sliding Frame with Thumb Turn Bolts and Offset Nuts(left and right side).
The nut on upper side for the Offset Nut ( Figure 6.1). You can slide the frame
when the Nut Clips are off the square tube. ( Figure 6.2)
6
Hole facing
down
Install middle side rails to rail frame, NOTE: rails should have the hole facing down
when bolting: use bolt M6x70 (06702), small washer (6012), and lock nut M6
(10062)-see diagram (3) Bolts should be snug, not tight.
3
Diagram (5) Install Wheel Rail (7207) attach with bolt M8x75 (08752), (1) large
washer (8012) on top of bar and (1) large washer below bar, secure with lock nut
M8 ( 10082).Repeat on both sides
5
=
=
10162
hole offset side
facing out
Top Rail #7203
06452
Middle Side
Rail #7205
10062
10062
6012
6012
6012
1808012
Middle Rail #7204
06702
06702
08702
08702
8012
8012
06750
10082
Bottom Rail #7206
10062
10082
6.2
6.1
Top Rail #7203
X1
Middle Rail #7204
X2
Middle Side Rail #7205
Offset Hole
X2
Bottom Rail #7206
X2
Install the Top Rail and Middle Rails to sides frame. Keep the bolts snug.

BEFORE BEGINNING,SEE THE ASSEMBLY INSTRUCTION VIDEO ON EZTRUNK.NET
Alumiumum Door Lift
Ver A_13/8/22
CUSTOMER SERVICE: [email protected]
Text & Call : 203-901-0055 / Call 203-591-9060
Page 4
9
Aseembly completed.
10
7
Install door support panel to sliding frame with lock nut M6, Make sure the folded
edges face up. Loge edge on outside to stop vehicle door slide.
8
06200
7201
Long edge
7208
06452
12
How to Take off the Door
11
#7201-7
sliding plates
pre installed
Install the Plates on sliding frame with Thumb turn bolts.
Intall the handle on sliding frame.
Roll down the glass window. Release the door limit strap. Unplug wiring harness. Roll EZ door lift touch to door even

BEFORE BEGINNING,SEE THE ASSEMBLY INSTRUCTION VIDEO ON EZTRUNK.NET
Alumiumum Door Lift
Ver A_13/8/22
CUSTOMER SERVICE: [email protected]
Text & Call : 203-901-0055 / Call 203-591-9060
Page 5
Hook the webbing to back of sliding frame. Pull other side webbing tight. Crank the
handle on top of sliding frame and carefully move out the door from the vehicle.
14
Roll the door panel support to door bottom edge, Adjust the thumb turn bolt make
the door panel touch the door bottom edge even.
13
WE CAN HELP YOU!
Customer Service
Any question? WE ARE HERE TO HELP!
EMAIL US: [email protected]
Text or Call 203-901-0055 / Call 203-591-9060
7 days a week 8:30 am EST
Storage PositionStorage Position
Clip the Locking Pin in Hole in the tube when folded position.
15
Crank the sliding frame up to top ( Figure 1), Loosen the Offset Nut ( Figure 2) and
