IMPORTANT INFORMATION
CARE AND MAINTENANCE
For long lasting durability and the best possible protection for your
E-Z UP®Instant Shelter®product, follow these E-Z care and
maintenance instructions:
• Use a mild soap (not detergent) and plenty of water for top cleaning.
• Let the E-Z UP®top and frame dry completely before closing or storing to
avoid mildew.
• Frame will operate and look better if occasionally wiped with silicone spray,
especially before and after use in damp conditions. Remove excess silicone
residue before attaching top.
• Use a seam sealer if top leaks or drips water. Available at most sporting
goods and hardware stores.
• Slightly tighten bolts if frame becomes loose.
IMPORTANT! Read this information before proceeding. It is the
user’s responsibility to take the following precautions at all times.
•Always stake or weigh down your E-Z UP® shelter. Do not use in any
potentially windy or rainy weather. Wind and rain can damage your E-Z
UP®shelter and may also result in injury to you or others. Therefore, do
not rely on shelter for protection in heavy or prolonged rain storms.
•The E-Z UP®shelter is designed as a temporary sun shelter. Do not leave up
for extended periods.
• Use caution when handling the E-Z UP®frame. Avoid pinching
hands or fingers as frame opens or closes.
• Do not use shelter in a lightning storm.
• Do not leave your E-Z UP®Instant Shelter®product unattended.
• Do not build fires under shelter.
WARNING: KEEP ALL FLAME AND HEAT SOURCES AWAY
FROM THE TOP, AWNING AND SIDEWALL FABRICS. These
fabrics meet the flammability requirements of CPAI-84. The
fabric may burn if left in continuous contact with any flame
source. The application of any foreign substance to the fabric
may render the flame-resistant properties ineffective.
EX2S10BJWHRB7A 022A-10-R01
INTERNATIONAL E-Z UP, INC., manufacturer of the E-Z UP®
Instant Shelter®product, warrants to the original purchaser
who provides a dated sales receipt from an Authorized
Dealer, each part of the E-Z UP®shelter to be free from
defects in material or workmanship for a period of two
years after the date of original purchase. The E-Z UP®
Instant Shelter®frame is covered under a limited two year
warranty and guarantees the frame to be free from defects
in material or workmanship. This warranty applies only for
normal and expected uses, as determined by the
manufacturer.
INTERNATIONAL E-Z UP, INC.’s obligation and liability
under this warranty is limited to the repair or replacement
(at its option) of the product or its parts, after its own review
and examination.
RETURN ADVISORY - Before returning any part or product
to INTERNATIONAL E-Z UP, INC. or its designated
representative, please phone or write to obtain specific
return shipping instructions. All shipping costs must be
prepaid, and INTERNATIONAL E-Z UP, INC. is not
responsible for products damaged in transit.
CONDITIONS - This warranty shall be void as to any
product which has been altered or modified in any manner.
This warranty does not apply to damages caused by wind,
rain, or other forces of nature, not to accidental or
deliberate damage of the product, nor to use of the product
that does not conform with the product instructions.
This warranty is provided in lieu of all other warranties,
expressed or implied.
2 YEAR LIMITED WARRANTY
We Make Life E-Z!™
INTERNATIONAL E-Z UP, INC.
1601 Iowa Avenue, Riverside, California 92507
(909) 426-0060 • Fax (909) 426-0063
ezupdirect.com
Customer Service Hot Line
1 (800) SHADE ME
74233 63
Customer Service Hot Line
1 (800) SHADE ME
ezupdirect.com
74233 6 3
Take time to learn how to provide
years of durable and safe use from
your E-Z UP®Instant Shelter®product.
After reading these instructions
carefully, if you have any need of
assistance, call our Customer Service
Department.
OM Express II BJs 2010.qxd 7/27/10 9:32 AM Page 1
FIRST TIME TOP
ATTACHMENT
WHAT’SINTHE BOX
1.With partner, slightly lift up
two adjacent outer legs 1",
depress snap button and slide
inner legs into outer legs.
Repeat on the opposite legs -
making sure to do two legs at a
time on same side.
3. Lift two adjacent outer legs
up and slide out the inner legs
until the snap button locks.
Repeat on the opposite legs -
make sure to do two legs at a
time on same side.
3. Grasp the top diamond on
opposite sides by “close“ sticker.
Lift the shelter up slightly and
shake it while stepping towards
your partner until the unit is 3/4
closed. With partner grasp two
outer legs and push frame
together to fully close it.
BBeeccaarreeffuullnnoottttooppiinncchh
ffiinnggeerrss..Store shelter in roller
bag. (See Roller Bag Instruction
Enclosed within your Warranty
Kit).
2. Pull the fabric top corners
away from the frame as shown.
Engage Pull Pin slider at each
corner by pushing up on trusses
with one hand while holding down
on top of leg with other hand until
Pull Pin slider engages. Pull down
fabric top corner and repeat on
other legs.
1. Place your E-Z UP®frame in
the center of area to be sheltered.
With partner on opposite side,
grasp two outer legs, slightly lift
off ground and step backwards,
stopping at full arms' length -
approximately 3/4 its total size.
2. Gently unfold the fabric top
and place it over the open frame.
3. Attach the fabric top to the
E-Z UP®frame by matching hook &
loop strips on the top with the hook
& loop strips on the frame. Pull the
corners down fully.
HOW TO
TAKE DOWN
1. Grasp the bottom of the
diamond shaped area of trusses on
opposite sides by the “open”
sticker. Lift up and step backwards
until shelter is fully opened, being
careful not to pinch fingers.
2. Release the Pull Pin slider
at each corner by first lifting
fabric top corner and pull the pin
out to release.
• E-Z UP®Instant Shelter®frame • 4 Zippered
Dura-Lon®
Sidewalls
• Commercial Grade Top • Awning Fabric
• 4 Piece Stake Kit • 2 Awning Poles
• Roller Bag
• Name Banner Fabric
Pull Pin
HOW TOSET UP
Diamond Area of
Frame
First: Repeat Step 1, in ‘First Time Top Attachment’
See other instructions in Warranty Kit
Diamond Area of
Frame
Please read each step before you attempt to set up.
Save these instructions for future reference.
